Modular Grid System Utility-scale solar power
stations
Modular Solar Grid System
Operational Capabilities
MSGS consists of multiple clusters of 20-foot
steel containers equipped with pre-wired solar
collection modules. Each module requires approx.
1 hr. for site-prep and positioning, and each
module is capable of harvesting 10kw of solar
power. Clusters consisting of 10-12 units are
interconnected. The base unit in each cluster is
equipped with a grid-tie inverter.
Proposed Approach
ROM Cost and Schedule
COST 550k per 100kw cluster approx. 5.50
per watt, installed Production schedule 25
units per month Install a 1 megawatt system in
4-6 months

• Rugged steel containers
• Aluminum truss racks cradle PV panels
• All connections pre-wired and pre-tested
• Grid-tie inverters
• Containers are delivered, placed on
  pre-positioned concrete piers
• Minimize on-site labor and installation
  complexity
