Decision Tree and Concept Learning

1
Decision Tree and Concept Learning
2
Outline

• Types of learning
• Inductive learning
• non-incremental
• incremental
• Decision trees (non-incremental)
• Current best hypothesis (incremental)
• Candidate elimination (incremental)

3
Why should programs learn?

• All the programs seen up to now have been static
• if we run the programs again on the same data,
  they will do exactly the same as before
• they cannot learn from their experience
• they require us to specify everything they will
  ever need to know, at the outset.
• We would like programs to learn from their
  experience.
• We would like the possibility of learning being
  continous.
• Learning is fundamental to intelligence.

4
How do you learn?

• By being told relies on
• someone to do the telling
• something to tell!
• By finding a teacher, who provides a set of
  pre-classified examples (i.e. I/O pairs), or
  taking action and obtaining correct answer from
  observations Supervised learning
• By searching for regularities in unclassified
  data (e.g. clusters) Unsupervised learning
• By trying things, and seeing which outcomes are
  desirable (i.e. earn rewards) e.g. learning the
  heuristic evaluation function in game-playing
  Reinforcement learning

5
Inductive learning

• Learning by example (supervised learning)
• teacher provides good training instances and the
  learner is expected to generalise
• in knowledge acquisition it is often easier to
  get an expert to give examples than to give rules
• this is how experimental science works (the
  'teacher' is the natural world)

6
Application of knowledge (deduction)
Output 1
Knowledge
Input 1
Output 2
Knowledge
Input 2

• We have
• inputs
• knowledge

• We get
• outputs

7
Inductive learning (induction)
Output 1
Input 1
Knowledge
Output 2
Input 2


Input n
Output n

• We have
• inputs
• outputs

• We get
• knowledge

8
Knowledge as a function

• Knowledge (performance element) can be described
  as a function
• given a description, x, for a given object or
  situation, the output is given by f(x) where f
  embodies the knowledge contained in the
  performance element.
• could be
• analytical mathematical function
• lookup table
• rule set (including STRIPS rules)
• neural network
• decision tree
• etc.

9
Definition of inductive learning

• Given a set of input/output pairs (examples)
  (x, f(x))
• where f is unknown, but the output f(x) is
  provided with its corresponding input, x.
• find a function, h(x) (hypothesis) which best
  approximates f(x).
• finding implies searching in a space of
  different possible hypotheses.

10
Inductive learning
Non-incremental
Input 1
Output 1
Output 2
Knowledge
Input 2


Incremental
Input 1
Knowledge 1
Output 1
Output 2
Knowledge 2
Input 2

Assume that Knowledge 2 is more complete than
Knowledge 1, etc.
11
Non-incremental vs. Incremental

• Non-incremental
• learning from all examples at once
• Incremental
• learning by refining from successive examples
• If you havent seen all possible examples, you
  can never know that the system is going to give
  the correct answer for a previously unknown
  example.
• You may never see all possible examples.

12
Wait for a table at a restaurant

• To avoid arguments, you and your friends want to
  have a clear decision procedure for the situation
  where you turn up at a restaurant and have to
  make a decision as to whether you will wait to
  get a table.
• In advance you
• specify a number of attributes
• draw up a decision tree of your own preferences
• When you get to the restaurant you use the
  decision tree to find the value of the goal
  predicate Will wait

13
Attributes involved in the decision

• Is there anything else nearby? Near yes / no
• How long will the wait be? Time 0-10 / 10-30 /
  30-60 / gt60
• Does the restaurant have a bar? Bar yes / no
• Is it the weekend? W/E yes / no
• Are you hungry? Hun yes / no
• How many tables are occupied? Occ. none / some
  /all
• Is it raining? Rain yes / no
• Have you booked? Book yes / no
• What type of restaurant? Type Fren / Chin /
  Ital / US
• How expensive is the restaurant? cheap /OK /
  exp

14
Agreed Decision TreeWait for a table in a
restaurant?
15
Decision treesPerformance element

• Object or situation described by a set of
  discrete attributes
• Task is to classify the object
• binary (yes/no)
• a member of a discrete set of possible outcomes
• An internal node represents a test on one
  attribute.
• An arc represents a possible value for that
  attribute.
• A leaf node indicates the classification
  resulting from following the path to that node.
• A decision tree can be converted to a set of
  rules.
• This example represents a groups subjective way
  of making a decision about whether or not to wait
  for a table at a restaurant.

16
Task

• An outsider observes the group on a number of
  occasions.
• The values of all the attributes are noted.
• Can (s)he learn a decision tree that leads to the
  same conclusion for these examples and will
  predict future behaviour?

17
Set of examples

• Near Bar W/E Hun Occ Rain Book
  Type Time Decide
• 1 yes no no yes some exp no yes
  Fren 0-10 YES
• 2 yes no no yes all cheap no no
  Chin 30-60 NO
• 3 no yes no no some cheap no no US
  0-10 YES
• 4 yes no yes yes all cheap yes no
  Chin 10-30 YES
• 5 yes no yes no all exp no yes
  Fren gt60 NO
• 6 no yes no yes some ok yes yes
  Ital 0-10 YES
• 7 no yes no no none cheap yes no US
  0-10 NO
• 8 no no no yes some ok yes yes
  Chin 0-10 YES
• 9 no yes yes no all cheap yes no US
  gt60 NO
• 10 yes yes yes yes all exp no yes
  Ital 10-30 NO
• 11 no no no no none cheap no no
  Chin 0-10 NO
• 12 yes yes yes yes all cheap no no US
  30-60 YES

18
Learning decision trees

• Can a program learn a decision tree by looking at
  these 12 examples?
• It could build a decision tree which covered only
  the 12 cases - i.e. had a path to a decision for
  those 12 only.
• That is not very useful - there are over 9000
  possible situations using the attributes I have
  given, but the tree is designed to deal with the
  12.
• The assumption is that there is a simpler
  solution.
• What we would like the system to do is to come up
  with a decision tree that general enough to
  predict the outcome in all possible cases
  (including the 12).
• We would also like the smallest tree which
  satisfies this.
• Learning is non-incremental.

.
19
Which attribute? Take them in order ..
20
Discriminating Attributes
We will determine which attribute provides the
most information at each stage, and use that as
the root of a sub-tree.
yes 1,3,4,6,8,12 no 2,5,7,9,10,11
How many tables are occupied?
all
none
some
yes4, 12 no2, 5, 9, 10
yes no 7, 11
yes1, 3, 6, 8 no
What type of restaurant?
French
Italian
US
Chinese
yes1 no 5
yes4, 8 no2, 11
yes3, 12 no7, 9
yes6 no10
21
Splitting heuristic

• What do we mean by providing the most
  information
• Based on information theoretic measure (Shannon)
• Aims to minimise the number of tests needed to
  provide a classification
• "ID3, An algorithm for learning decision trees"
  J. R. Quinlan, 1979.

22
Information

• Want a numerical measure for each attribute
• Maximum when attribute is perfect (provides
  perfect separation)
• Minimum when attribute is useless (no separation)
• Suppose attribute has n possible values the ith
  value has prior probability Pi
• Information content of the attribute is
• I(P1, P2, Pn ) ?-Pilog2Pi
• Chose attribute with highest information content.
• Bit more complex see RN

23
Measure of Impurity GINI

• Gini Index for a given node t
• (NOTE p( j t) is the relative frequency of
  class j at node t).
• Maximum (1 - 1/nc) when records are equally
  distributed among all classes, implying least
  interesting information
• Minimum (0.0) when all records belong to one
  class, implying most interesting information

24
Examples for computing GINI
P(C1) 0/6 0 P(C2) 6/6 1 Gini 1
P(C1)2 P(C2)2 1 0 1 0
P(C1) 1/6 P(C2) 5/6 Gini 1
(1/6)2 (5/6)2 0.278
P(C1) 2/6 P(C2) 4/6 Gini 1
(2/6)2 (4/6)2 0.444
25
Splitting Based on GINI

• Used in CART, SLIQ, SPRINT.
• When a node p is split into k partitions
  (children), the quality of split is computed as,
• where, ni number of records at child i,
• n number of records at node p.

26
Binary Attributes Computing GINI Index

• Splits into two partitions
• Effect of Weighing partitions
• Larger and Purer Partitions are sought for.

B?
Yes
No
Node N1
Node N2
Gini(N1) 1 (5/7)2 (2/7)2 0.408
Gini(N2) 1 (1/5)2 (4/5)2 0.320
Gini(Children) 7/12 0.408 5/12
0.320 0.371
27
Categorical Attributes Computing Gini Index

• For each distinct value, gather counts for each
  class in the dataset
• Use the count matrix to make decisions

Multi-way split
28
Decision Tree Induction

• Induce(Examples, Attributes, Default) Decision
  tree
• if (a) Examples return the leaf node leaf
  node is labelled with the Default
• else if (b) all elements of Examples have same
  decision D, return the leaf node
• leaf node is labelled with D
• else if (c) Attributes return the leaf
  node leaf node is labelled with the Default
• else (d) delete A, the element of Attributes
  which provides most information.
• create a node A
• for each possible value V of A
• let E be the subset of Examples where the value
  of attribute A is V
• let D be the majority decision in Examples
• let N Induce(E, Attributes,D)
• add a directed arc from A, labelled V, ending
  at N
• return A (together with the tree rooted on it)

29
Learned Decision Tree
30
Learned Decision Tree
31
Learned Decision Tree
32
Learned Decision Tree
33
Agreed Decision Tree
34
Problems (1)

• Problems with examples
• Missing the value of an attribute for an example
• Incorrect example (errors in data collection)
• Both can affect performance element and learning
• What do we do with continuous (or very many)
  valued attributes? (e.g. price)
• discretise the attribute (e.g. cheap / OK /
  expensive)
• normally done by hand, but would be better if it
  could be done automatically.

35
Continuous Attributes Computing Gini Index

• Use Binary Decisions based on one value
• Several Choices for the splitting value
• Number of possible splitting values Number of
  distinct values
• Each splitting value has a count matrix
  associated with it
• Class counts in each of the partitions, A lt v and
  A ? v
• Simple method to choose best v
• For each v, scan the database to gather count
  matrix and compute its Gini index
• Computationally Inefficient! Repetition of work.

36
Continuous Attributes Computing Gini Index...

• For efficient computation for each attribute,
• Sort the attribute on values
• Linearly scan these values, each time updating
  the count matrix and computing gini index
• Choose the split position that has the least gini
  index

37
Problems (2)

• Not enough examples
• branch for value which has no examples (use
  default)
• Not enough attributes
• leaf nodes with positive and negative
  classifications
• Over-fitting
• too many degrees of freedom (questions)
• use pruning to eliminate questions with
  negligible information gain

38
Overfitting
y
y a1x a0 4 data points 2 degrees of freedom
y a5x5 a4x4 a3x3 a2x2 a1 x
a0 4 data points 6 degrees of freedom
x
39
How do we assess performance?

• Put the system into production and see how well
  it performs?
• not safe in any domain where the results are
  important
• Save some of our examples, and use them to test
  results.
• 1. Get a set of examples
• 2. Split into two subsets training and test
• 3. Learn using the training set
• 4. Evaluate using the test set
• Only put into production when we are happy
• It is very important that the test set and
  training set have no examples in common

40
Application GASOIL

• GASOIL is an expert system for designing gas/oil
  separation systems stationed off-shore.
• The design depends on
• proportions of gas, oil and water, flow rate,
  pressure, density, viscosity, temperature, and
  others.
• To build by hand would take 100 person-months
• Built by decision-tree induction 3
  person-months
• At the time (early '80s), GASOIL was the biggest
  Expert System in the world, containing 2500
  rules, and saved BP millions.

41
Application Learning to fly

• Learning to fly a Cessna on a flight simulator.
• Three skilled pilots performed an assigned flight
  plan 30 times each.
• Each control action (e.g. on throttle, flaps)
  created an example.
• 90,000 examples, each described by 20 state
  variables and each categorised by the action
  taken
• Decision tree created.
• Converted into C and put into the simulator
  control loop.
• Program flies better than teachers!
• probably because generalisation cleans up
  occasional mistakes

42
Incremental inductive learning
43
Arch
3
1
2
44
Not an arch
3
1
2
45
Not an arch
3
1
2
46
Arch
3
1
2
47
Arch
3
1
2
48
Not an arch
3
2
1
49
Incremental learning

• Restrict ourselves to binary (yes/no) solutions
• Each hypothesis (performance element) predicts
  that a certain set of positive examples will
  satisfy the goal predicate, and that all other
  examples will not satisfy it.
• The problem is then to find a hypothesis that is
  consistent with the existing set of examples, and
  that can be made be consistent with new examples.
• Aim to improve our hypothesis for every new
  example we get and hope that we eventually get
  stability.

50
True/False Positive/Negative

• positive
  negative
• true hypothesis yes hypothesis no
• correct yes correct no
• false hypothesis yes hypothesis no
• correct no correct yes

NB True/false applies to the prediction of the
hypothesis.
51
Incremental learning

• Some new examples will be consistent with our
  current hypothesis (i.e. true positives and true
  negatives), and so provide no more information.
• Some new examples will be false positive if the
  hypothesis predicts yes but the correct answer is
  no.
• Some new examples will be false negative, if the
  hypothesis predicts no but the correct answer is
  yes.
• Inductive learning is then the process of
  refining a hypothesis by narrowing it to
  eliminate false positives, and extending it to
  include false negatives.

52
Generalisation and specialisation
-
-
-
-
-
-
Discover false negative
-

-



hypothesis says yes
-
-



-
-
-
-
-
-
-

-


Generalise

-
-
correct value means yes - means no




-
-
-
-
-
-
Discover false positive
-

-



-
-
-




-
-
-
-
-
-
-

-


-

Specialise
-

-


-

53
Current Best Hypothesis

• Let S the set of examples
• Let O , the set of old examples
• Select E, a positive example, from S
• Move E to O
• Construct H, a hypothesis consistent with E
• While S ? , select another example E
• move E to O
• if E is a false negative with respect to
  (w.r.t.) H then
• generalise H so that H is consistent with all
  members of O
• else if E is a false positive w.r.t. H then
• specialise H so that H is consistent with all
  members of O
• return H

54
Learning the definition of an "arch"
Suppose we are allowed to build arrangements of
any three objects from a set.
How can we get a computer system to learn, from
examples like these, the definition of an arch?
55
Representation

• We need a language for describing objects and
  concepts
• attribute descriptions describe a single object
  in terms of its features.
• relational descriptions describe a composite
  object in terms of its components and the
  relationships between them.

56
The modelling language
(support X Y) X supports Y - X and Y can
take the values 1, 2 or 3 (touches X Y) X
touches Y (and Y touches X)
X and Y can take the values 1, 2 or
3 (shape X S) the shape of X is S X
can take the values 1, 2 or 3
S can be triangle, rectangle, ellipse,
square () allow negated predicates
(shape 1 rectangle) (shape 2 rectangle) (shape 3
rectangle) (support 1 3) (support 2 3)
(shape 1 rectangle) (shape 2 rectangle) (shape 3
ellipse) (support 1 3)
3
3
2
1
2
1
57
The hypothesis (performance element)
The performance element would be a simple
rule for example if (shape 1 rectangle)
(shape 2 rectangle) (shape 3 rectangle)
(support 1 3) (support 2 3) then yes
we have an arch How do we learn it by being
shown successive examples?
58
Searching for Current Best

• To begin, we will take the first positive example
  to be our hypothesis.
• At each stage, we will choose a minimum
  generalisation or minimum specialisation of our
  current hypothesis that is consistent.
• If no such hypothesis is possible, then backtrack
  to the last point where we had a choice, and
  choose the next generalisation or specialisation.
• The problem is now search, but we have to specify
  how to generalise and specialise our definitions.

59
Generalisation

• We can generalise a positive predicate, e.g.
  (shape 1 rectangle) by removing variable
  bindings
• (shape 1 ?) the shape if 1 doesnt matter
• (shape ? rectangle) everything is a
  rectangle
• (shape ? ?) shape is irrelevant
• We can generalise a negated predicate, e.g.
  (touch 1 ?) by adding variable bindings (i.e.
  make the predicate more restrictive)
• (touch 1 2)
• We can generalise a hypothesis by generalising
  one of its predicates, or by removing a
  predicate.
• (shape ? ?) is equivalent to removal

60
Specialisation

• We can specialise a positive predicate, e.g.
  (shape 1 ?) by adding variable bindings
• (shape 1 rectangle)
• We can specialise a negated predicate, e.g.
  (touch 1 2) by removing variable bindings
• (touch 1 ?)
• We can specialise a hypothesis by specialising
  one of its predicates, or by adding a predicate.

61
Learning the concept of an arch
Example 1 true positive - no action (shape 1
rectangle) (shape 2 rectangle) (shape 3
rectangle) (support 1 3) (support 2 3)
Hypothesis 1 (shape 1 rectangle) (shape 2
rectangle) (shape 3 rectangle) (support 1
3) (support 2 3)
Prediction
3
2
1
Example
Example 2 false positive - specialise (shape 1
rectangle) (shape 2 rectangle) (shape 3
rectangle) (support 1 3) (support 2 3) (touch 1 2)
Hypothesis 2 (shape 1 rectangle) (shape 2
rectangle) (shape 3 rectangle) (support 1
3) (support 2 3) (touch 1 2)
Prediction
3
1
2
Example
62
Learning the concept of an arch
Example 3 true negative - no action (shape 1
rectangle) (shape 2 rectangle) (shape 3
ellipse) (support 1 3)
Hypothesis 3 (shape 1 rectangle) (shape 2
rectangle) (shape 3 rectangle) (support 1
3) (support 2 3) (touch 1 2)
Prediction
3
1
2
Example
Example 4 false negative - generalise (shape 1
rectangle) (shape 2 rectangle) (shape 3
triangle) (support 1 3) (support 2 3)
Hypothesis 4 (shape 1 rectangle) (shape 2
rectangle) (shape 3 ?) (support 1 3) (support 2
3) (touch 1 2)
Prediction
3
2
1
Example
63

Learning the concept of an arch
Example 5 true negative - no action (shape 1
rectangle) (shape 2 rectangle) (shape 3
triangle) (support 1 2) (support 2 3)
Hypothesis 5 (shape 1 rectangle) (shape 2
rectangle) (shape 3 ?) (support 1 3) (support 2
3) (touch1 2)
Prediction
3
Example
2
1
64
Concept Hierarchies
a_shape
polygon
ellipse
trapezium
rectangle
triangle
square
isosceles
equilateral
(shape X isosceles) generalises to (shape X
triangle) (shape X triangle) generalises
to (shape X polygon) (shape X rectangle)
generalises to (shape X polygon)
65
Use of concept hierarchy
E.g. Hypothesis 4 would contain (shape 3
polygon) If this were Example 6 false negative
- generalise
3
Example
1
2
then Hypothesis 6 would contain (shape 3
a_shape)
