Securing Information Systems

1
6
Chapter
Securing Information Systems
66 percent of all Webroot-scanned personal
computers are infected with at least 25 spyware
programs. Webroot (2005)
2
Learning Objectives
3
Information Systems Security

• All systems connected to a network are at risk
• Internal threats
• External threats
• Information systems security
• Precautions to keep IS safe from unauthorized
  access and use
• Increased need for good computer security with
  increased use of the Internet

4
Primary Threats to Information Systems Security

• Accidents and natural disasters
• Power outages, cats walking across keyboards
• Employees and consultants
• Links to outside business contacts
• Travel between business affiliates
• Outsiders
• Viruses

5
Unauthorized Access

• Unauthorized people
• Look through electronic data
• Peek at monitors
• Intercept electronic communication
• Theft of computers or storage media
• Determined hackers gain administrator status

6
Gaining Access to a Password

• Brute force
• Try combinations until a match is found
• Protection
• Wait time requirements after unsuccessful login
  attempt
• CAPTCHA

7
Information Modification

• User accesses electronic information
• User changes information
• Employee gives himself a raise

8
Denial of Service Attack

• Attackers prevent legitimate users from accessing
  services
• Zombie computers
• Created by viruses or worms
• Attack Web sites

9
Computer Viruses

• Corrupt and destroy data
• Destructive code can
• Erase a hard drive
• Seize control of a computer
• Worms
• Variation of a virus
• Replicate endlessly across the Internet
• Servers crash
• MyDoom attack on Microsofts Web site

10
Spyware

• Within freeware or shareware
• Within a Web site
• Gathers information about a user
• Credit card information
• Behavior tracking for marketing purposes
• Eats up computers memory and network bandwidth
• Adware special kind of spyware
• Collects information for banner ad customization

11
Spam

• Electronic junk mail
• Advertisements of products and services
• Eats up storage space
• Compromises network bandwidth
• Spim
• Spam over IM

12
Protection Against Spam

• Barracuda Spam Firewall 600
• Filters spam and other email threats
• Decreases amount of spam processed by the central
  e-mail server
• Handles 3,000 10,000 active email users
• Spam messages blocked or quarantines

13
Phishing

• Attempts to trick users into giving away credit
  card numbers
• Phony messages
• Duplicates of legitimate Web sites
• E.g., eBay, PayPal have been used

14
Cookies

• Messages passed to a Web browser from a Web
  server
• Used for Web site customization
• Cookies may contain sensitive information
• Cookie management and cookie killer software
• Internet Explorer Web browser settings

15
Other Threats to IS Security

• Employees writing passwords on paper
• No installation of antivirus software
• Use of default network passwords
• Letting outsiders view monitors

Information Systems Today Managing in the
Digital World
6-15
16
Other Threats to IS Security (II)

• Organizations fail to limit access to some files
• Organizations fail to install firewalls
• Not doing proper background checks
• Lack of employee monitoring
• Fired employees who are resentful

17
Learning Objectives
18
Safeguarding Information Systems Resources

• Information systems audits
• Risk analysis
• Process of assessing the value of protected
  assets
• Cost of loss vs. cost of protection
• Risk reduction
• Measures taken to protect the system
• Risk acceptance
• Measures taken to absorb the damages
• Risk transfer
• Transferring the absorption of risk to a third
  party

19
Technological Safeguards

• Physical access restrictions
• Authentication
• Use of passwords
• Photo ID cards, smart cards
• Keys to unlock a computer
• Combination

• Authentication limited to
• Something you have
• Something you know
• Something you are

20
Biometrics

• Form of authentication
• Fingerprints
• Retinal patterns
• Body weight
• Etc.
• Fast authentication
• High security

21
Access-Control Software

• Access only to files required for work
• Read-only access
• Certain time periods for allowed access
• Business systems applications
• Built-in access control capabilities

22
Wireless LAN Control

• Wireless LAN cheap and easy to install
• Use on the rise
• Signal transmitted through the air
• Susceptible to being intercepted
• Drive-by hacking

23
Virtual Private Networks

• Connection constructed dynamically within an
  existing network
• Secure tunnel
• Encrypted information

24
Firewalls

• System designed to detect intrusion and prevent
  unauthorized access
• Implementation
• Hardware, software, mixed
• Approaches
• Packet filter each packet examined
• Application-level control security measures
  only for certain applications
• Circuit-level control based on certain type of
  connection
• Proxy server firewall acts as the server and
  intercepts all messages Network Address
  Translation

25
Firewall Architecture

• Basic software firewall for a home network
• Firewall router
• Home office
• Small office

26
Firewall Architecture Larger Organization
27
Encryption

• Message encoded before sending
• Message decoded when received
• Encryption allows for
• Authentication proving ones identity
• Privacy/confidentiality only intended recipient
  can read a message
• Integrity assurance of unaltered message
• Nonrepudiation use of digital signature

28
The Encryption Process

• Key code that scrambles the message
• Symmetric secret key system
• Sender and recipient use the same key
• Cons Management problems
• Public key technology
• Asymmetric key system
• Each individual has a pair of keys
• Public key freely distributed
• Private key kept secret

29
How Encryption Works (Asymmetric)
30
Encryption for Websites

• Certificate Authority
• Third party trusted middleman
• Verifies trustworthiness of a Web site
• Checks for identity of a computer
• Provides public keys
• Secure Sockets Layer (SSL)
• Developed by Netscape
• Popular public-key encryption method

31
Other Encryption Approaches

• 1976 Public/private key
• 1977 RSA
• Technology licensed to Lotus and Microsoft
• Federal law prohibited exporting encryption
  technology
• Limited use by organizations
• 1991 Pretty good privacy
• Versatile encryption program
• Global favorite
• 1993 Clipper chip
• Chip generating uncrackable codes
• Scrapped before it became reality

32
The Evolution of Encryption

• Future encryption programs will provide
• Strong security
• High speed
• Usability on any platform
• Encryption for cellular phones
• Encryption for PDAs

33
Recommended Virus Precautions

• Purchase and install antivirus software
• Update frequently
• Do not download data from unknown sources
• Flash drives, disks, Web sites
• Delete (without opening) e-mail from unknown
  source
• Warn people if you get a virus
• Your department
• People on e-mail list

34
Audit Control Software

• Keeps track of computer activity
• Spots suspicious action
• Audit trail
• Record of users
• Record of activities
• IT department needs to monitor this activity

35
Other Technological Safeguards

• Backups
• Secondary storage devices
• Regular intervals
• Closed-circuit television (CCTV)
• Monitoring for physical intruders
• Video cameras display and record all activity
• Digital video recording
• Uninterruptible power supply (UPS)
• Protection against power surges

36
Human Safeguards

• Use of federal and state laws as well as ethics

37
Learning Objectives
38
Managing Information Systems Security

• Non-technical safeguards
• Management of peoples use of IS
• Acceptable use policies
• Trustworthy employees
• Well-treated employees

39
Developing an Information Systems Security Plan

• Ongoing five-step process
• Risk analysis
• Determine value of electronic information
• Assess threats to confidentiality, integrity and
  availability of information
• Identify most vulnerable computer operations
• Assess current security policies
• Recommend changes to existing practices to
  improve computer security

40
Security Plan Step 2

• Policies and procedures actions to be taken if
  security is breached
• Information policy handling of sensitive
  information
• Security policy technical controls on
  organizational computers
• Use policy appropriate use of in-house IS
• Backup policy
• Account management policy procedures for adding
  new users
• Incident handling procedures handling security
  breach
• Disaster recovery plan restoration of computer
  operations

41
Security Plan Remaining Steps

• Implementation
• Implementation of network security hardware and
  software
• IDs and smart cards dissemination
• Responsibilities of the IS department
• Training organizations personnel
• Auditing
• Assessment of policy adherence
• Penetration tests

42
Responding to a Security Breach

• 1988 Computer Emergency Response Team (CERT)
• Started after Morris worm disabled 10 of all
  computers connected to the Internet
• Computer Security Division (CSD)
• Raising of awareness of IT risks
• Research and advising about IT vulnerabilities
• Development of standards
• Development of guidelines to increase secure IT
  planning, implementation, management and operation

43
The State of Systems Security Management

• Financial losses of cybercrime are decreasing
• Computer virus attacks result in the greatest
  financial losses
• Only about 25 of organizations utilize
  cyberinsurance
• Only about 20 of organizations report intrusions
  to the law enforcement
• Fear of falling stock prices
• Most organizations do not outsource security
  activities
• 90 of organizations conduct routine security
  audits
• Most organizations agree security training is
  important
• Majority said they do not do enough of training

44
Use of Security Technologies

• CSI/FBI computer crime and security survey
  respondents (2006)

45
End of Chapter Content
46
Opening Case Managing in the Digital World
Drive-by-Hacking

• 60 - 80 of corporate wireless networks do not
  use security
• War driving a new hacker tactic
• Driving around densely populated areas
• War spamming
• Attackers link to an e-mail server and send out
  millions of spam messages
• Companies pay millions in bandwidth fees
• Businesses fight back using bogus access points
• FakeAP
• Network scanners distinguish between real and
  fake APs
• Netstumbler
• Fast Packet Keying to fix shortcomings of WEP

47
Spyware Lurks on Most PCs

• Webroot
• Producer of software to scan and eliminate
  spyware
• Webroot company data
• 66 of scanned PCs infected with at least 25
  spyware programs
• Incidents of spyware slightly decreasing

48
To Cookie or Not to Cookie

• Cookies collected by companies to get data about
  customers
• Footprints that marketers can trace
• Sometimes sold to other companies
• Web browsers can protect against accepting
  cookies
• Constant pop-ups
• Some sites will not work properly
• Customized information will not be available
• National Security Agency (NSA)

49
Anne Mulcahy, CEO and Chairman, Xerox Corporation

• 1974 B.A. in English and journalism
• 1976 joined Xerox
• 2002 promoted to CEO
• Xerox in 2002
• 17 billion debt
• Xerox under Mulcahy
• First time profitable in years
• Cut expenses by 1.7 billion
• Sold non-core assets for 2.3 billion

50
Voiceprint

• 1976 case State of Maine v. Thomas Williams
• Bomb threat
• Voiceprint used for conviction of terrorism
• Each individual has unique voice characteristics
• 1967-2006 more than 5,000 law enforcement voice
  identification cases
• Spectrogram visual inspection of waves
• Voiceprints used for access authorization

51
Is Big Brother Watching You

• Employers can use equipment to
• Read your email
• Monitor Web-surfing behavior
• Collect keystrokes
• Follow the movement of employees
• RFID and GPS
• Companies have rights to collect almost any
  information about employees while on the job

52
Backhoe Cyber Threat

• Telecommunications infrastructure is vulnerable
• Damage to telephone lines, fiber-optic cables,
  water lines, gas pipelines
• 675,000 incidents in 1 year
• Infrastructure information publicly available
• Most of Internet communication goes through
  cables buried along major highways and railroads
• Only two major routes across US for Internet
  traffic

53
Banking Industry

• In the past highly regulated industry
• Banks limited to certain locations and services
• Efforts to make banks safer
• Regulations prevented banks from competition
• 1970 to present many regulations eliminated
• Acquisitions, consolidations and integration
  across state lines
• Better customer service at lower prices
• Benefits to overall economy
• Internet era
• Customers assess banks based on online banking
  services
