Title: PSEG Fossil LLC NOx Reduction Technologies


1
PSEG Fossil LLCNOx Reduction Technologies
  • August 9, 2005

2
Types of Electric-Generating Units
  • Baseload
  • Load-Following
  • Peaking

3
Baseload
  • Units intended to operate continuously at full
    load
  • High annual capacity factors
  • Nuclear units, e.g.
  • Hope Creek Unit No. 1
  • Salem Units No. 1 2
  • None of PSEGs fossil fuel-fired units in New
    Jersey are baseload

4
Load-Following
  • Unit operation and output vary with demand
  • Low to Moderate annual capacity factors (60)
  • Coal/Gas/No. 6 oil-fired steam boilers
  • Hudson Unit No. 1 (water injection)
  • Hudson Unit No. 2 (scheduled for SCR, baghouse in
    2007)
  • Mercer Unit No. 1 (SCR since 2004 lb/MMBtu)
  • Mercer Units No. 2 (SCR since 2004 lb/MMBtu)
  • Sewaren Units No. 1, 2, 3, 4 ( 0.15 lb/MMBtu)
  • Gas/distillate oil-fired combined-cycle gas
    turbines
  • (all
  • Bergen Unit No. 1 (DLNC, water injection)
  • Bergen Unit No. 2 (SCR)
  • Linden Unit No. 1 (SCR)
  • Linden Unit No. 2 (SCR)

5
Peaking
  • Serve a unique purpose
  • Low to extremely low annual capacity factors
  • Satisfy PJM Requirements
  • Energy on high demand days
  • Grid reliability security
  • Congestion management
  • Primary Reserve
  • Energy in
  • Synchronous Condenser (Spinning Reserve)
  • Secondary Reserve
  • Energy in

6
Peaking
  • Gas/distillate oil-fired simple-cycle gas
    turbines
  • General Electric (GE) LM6000
  • aeroderivative (
  • GE Frame 7EA
  • industrial (
  • Pratt Whitney FT4
  • aeroderivative ( 0.15 lb/MMBtu)

7
(No Transcript)
8
Low Load Day
9
High Load Day
10
Congestion Management
  • June 22, 1999 PSEG Generation
  • PJM Contingency lines B on K system split at hr.
    1554
  • - PJM orders Essex 11 12 for contingency (4
    hrs.)

Nuclear
Steam Combined-Cycle
Simple-Cycle
11
PSEG Peaking Turbines

12
Capacity Factors (2001-2004)
13
Unit Retirements Since 1990
14
Unit Retirements Since 1990 (continued)
15
PSEG Fossil Environmental Progress
16
Generation NOx Emission Rates PSEG Combustion
Turbines
MWh (000)
lb/MWh
2,500
2.0
2,000
1.5
1,500
1.0
1,000
0.5
500
2000
2001
2002
2003
2004
Year
17
Potential FT4 NOx Reduction Technologies
  • Selective Catalytic Reduction (SCR)
  • Dry Low NOx Combustors (DLNC)
  • Light Oil Emulsification (LOE)
  • Water Injection
  • Others
  • SCONOx, XONON
  • Repowering/Replacement

18
Selective Catalytic Reduction (SCR)
  • Description
  • Ammonia is injected into exhaust gas, which then
    passes through a catalyst reactor where elemental
    nitrogen and water are the products of the
    NOxammonia reaction
  • NOx Reduction Potential
  • 80 to 95

19
Selective Catalytic Reduction (SCR)
  • Applications
  • Boilers (e.g. Mercer 12)
  • Combined-cycle or cogeneration turbines
  • Bergen 2, Linden 12 (NJ)
  • Bethlehem Energy Center (NY)
  • Lawrenceburg (IN)
  • Simple-cycle turbines
  • Tracy, Hanford, Henrietta (CA)
  • Gas only
  • Different duty cycle (
  • SCR-equipped simple-cycle turbines are newer,
    originally designed with SCR
  • Mixed track record, especially with oil-firing

20
Selective Catalytic Reduction (SCR)
  • Issues/Concerns
  • Exhaust Gas Temperature
  • Optimum range of conventional catalysts (650F to
    850F)
  • FT4 exhaust gas temperatures (1,040F to 1,200F)
  • Attenuation air to cool exhaust gas or
  • High-temperature catalysts (e.g. Zeolites)
  • Thermal Shock
  • Rapid start-ups and shutdowns
  • Oil Operation
  • Sulfur compounds may poison catalyst
  • Ammonia Storage Handling
  • Increased PM2.5, PM10 emissions

21
Selective Catalytic Reduction (SCR)
  • Issues/Concerns
  • Lost power output from back-pressure
  • Space considerations
  • New stacks
  • Jeopardizes FT4 spinning reserve capability
  • system reliability issues (PJM)
  • 30 million/yr lost revenue
  • Cost-prohibitive
  • Several times more expensive than water injection
  • Not a viable technology for FT4s

22
Dry Low-NOx Combustors (DLNC)
  • Description
  • Combustor can design premixes air and fuel,
    creating a fuel lean combustion environment that
    reduces peak flame temperatures controls
    thermal NOx
  • NOx Reduction Potential on FT4s
  • 60 to 70

23
Dry Low-NOx Combustors (DLNC)
  • PSEG Experience
  • In mid-1990s, DLNC pilot-tested on Edison FT4s
  • Unreliable performance
  • Combustor cans readily developed thermal stress
    cracks
  • Dropped in favor of water injection
  • Not a viable technology for FT4s

24
Light Oil Emulsification (LOE)
  • Description
  • Water emulsified fuel lowers peak flame
    temperatures to reduce thermal NOx
  • NOx Reduction Potential on FT4s
  • 40
  • PSEG Experience
  • In early-1990s, LOE pilot-tested on Edison FT4s
  • Oil firing only
  • CO emission concerns
  • Dropped in favor of water injection
  • Not a viable technology for FT4s

25
SCONOx
  • Description
  • A single catalyst oxidizes nitric oxide (NO) to
    nitrogen dioxide (NO2), then absorbs NO2 onto
    its surface, which is coated with potassium
    carbonate (K2CO3)
  • NOx Reduction Potential
  • 90 to 95

26
SCONOx
  • Issues/Concerns
  • To date, used only on combined-cycle or
    cogeneration turbines
  • Not commercially available on simple-cycle
    turbines
  • Optimum temperature range 300F to 700F
  • 2 to 3 times more expensive than SCR
  • Not a viable technology for FT4s

27
XONON
  • Description
  • A catalyst integrated into turbine combustors
    limits combustion temperatures thermal NOx
    formation
  • Combustors are customized to the particular
    turbine by the original equipment manufacturer
    (OEM)
  • Currently only commercially available from
    Kawasaki Gas Turbines-Americas on a small
  • (1.4 MW) turbine
  • Not a viable technology for FT4s

28
Water Injection
  • Description
  • Demineralized (DM) water is injected into turbine
    combustion zone to reduce peak flame temperatures
    control thermal NOx formation
  • System Components
  • Water injection skids
  • Metering pumps (1 per engine)
  • DM trailer processing pad
  • DM water storage tank
  • Instrumentation Controls
  • NOx Reduction Potential on FT4s
  • 40

29
Water Injection
  • PSEG Experience
  • Retrofitted on Edison Units No. 1, 2, 3 (24
    FT4s)
  • Successfully operated since 1999
  • Edison represents 35 to 45 of total FT4
    operations
  • Estimated Cost 500k to 1 million per FT4
  • Most FT4s dont run enough to justify the cost
  • Unmanned locations (Bayonne, National Park)
    present additional difficulties

30
Repowering/Replacement
  • PSEG has been systematically repowering or
    replacing its electric-generating units since
    1990
  • Cost-prohibitive
  • Installed cost of new simple-cycle peaking
    turbines
  • 500 kW (0.5 million/MW)
  • Replace 200 MW 100 million
  • Replace entire FT4 fleet 1 billion
  • System reliability issues (PJM)

31
Summary
  • PSEG has already dramatically reduced its
    stationary source NOx emissions
  • Water injection most viable technology for FT4
    peaking turbines
  • Further unit-specific evaluation necessary

32
Other Areas for Investigation
  • Compensation with NOx allowances
  • Restrict oil usage during ozone events
  • Increase operating flexibility of clean units
  • No stack testing when units not ordinarily
    running
  • Airport NOx emissions (e.g. Newark)
  • Electrification of truck stops
  • Port Elizabeth, Port Newark
  • Ferries

33
Surrounding States
  • PA
  • Ozone season surrender NOx allowances for
    peaking turbines
  • actuals greater than allowables
  • CT
  • same as PA
  • NY
  • Addressed in NOx RACT averaging plan
  • DE
  • Addressed in NOx RACT averaging plan
