Title: OnBody Sensing


1
On-Body Sensing
  • Daniel Ashbrook
  • Tracy Westeyn

2
Introduction
  • Who we are why we are qualified

3
Sensors are great!
  • input from world rather than input from human

Good!
Bad!
(This guy is too busy - leave him alone!)
4
Sensors, sensors, everywhere
  • sensors are ubiquitous

5
Making things easier
  • Not so many circuits to build

aa162171c7202 aa1721f1bf200 aa1821a1c11fd aa1921f1
bd1fc aa1a2191c3201 aa1b21d1bb1fd aa1c2191c0200 aa
1d21b1bb1fb aa1e21b1bd1fd aa1f21d1bb1ff aa202191c5
201 aa2121c1bd200
Before
6
Making things easier
  • Not so many circuits to build

After
7
Making things easier
  • Pre-built sensors
  • sparkfun.com
  • Accelerometers, Camera / Imaging, Capacitive, IMU
    / Gyros, IR / Ultrasonic, Magneto, Temperature

8
Making things easier
  • Pre-built sensors
  • sparkfun.com
  • Accelerometers, Camera / Imaging, Capacitive, IMU
    / Gyros, IR / Ultrasonic, Magneto, Temperature
  • xsens.com
  • 3-DOF inertial sensors

9
Making things easier
  • Pre-built sensors
  • sparkfun.com
  • Accelerometers, Camera / Imaging, Capacitive, IMU
    / Gyros, IR / Ultrasonic, Magneto, Temperature
  • xsens.com
  • 3-DOF inertial sensors
  • qprox.com
  • Capacitive sensor chips evaluation boards

Touch-based slider
Touch buttons
10
Making things easier
  • Pre-built sensors
  • sparkfun.com
  • Accelerometers, Camera / Imaging, Capacitive, IMU
    / Gyros, IR / Ultrasonic, Magneto, Temperature
  • xsens.com
  • 3-DOF inertial sensors
  • qprox.com
  • Capacitive sensor chips evaluation boards
  • xbow.com
  • Wireless sensor networks (Acceleration, Magnetic,
    Light, Temperature, Acoustic)

Mote professional kit
11
Making things easier
  • Pre-built wireless solutions
  • Bluetooth serial modules (btdesigner.com)
  • ZigBee (IEEE 802.15.4) (maxstream.net)
  • Nordic radio (nvlsi.no)

12
Making things easier
  • Mounting

Polar heart rate monitor strap
Bodymedia BodyBugg
13
Making things easier
  • Abstraction

No!
Good!
Yes!
Hard!
14
Why on-body sensing?
  • Often easier to sense personal contextual data
  • e.g., activity, location
  • Unique data available
  • heart rate, GSR
  • Less infrastructure needed
  • pressure-sensitive floor vs. accelerometer for
    activity level
  • Privacy benefits
  • control access to your own data

15
Types of sensors
  • altimeter
  • compass
  • GPS (Global Positioning System)
  • capacitive (touch)
  • pressure
  • temperature
  • accelerometers
  • GSR (Galvanic Skin Reponse)
  • gyroscopes
  • bend flex
  • light
  • cameras
  • sound (mics)

16
Thats a lot of types what next?
  • What the sensor measures
  • What are some of the errors
  • When to use / not use

17
Accelerometers
  • Acceleration dynamic characteristic of object
    requiring application of a force (a F/m)
  • 2nd derivative of position
  • 1st derivative of velocity
  • Taking derivatives in high frequency noisy
    signals result in large errors
  • Sensing method is dependent on application
    frequency

position
velocity
acceleration
1Hz
lt 1kHz
gt1Hz
18
Characteristics of an accelerometer
  • single-degree-of-freedom
  • Vibration periodic oscillatory motion around a
    reference position.
  • seismic mass
  • a spring-like supporting system
  • frame structure w/ damping properties

19
How an accelerometer works
  • measure displacement of an object with respect to
    some reference object
  • displacement transducer generates an electrical
    signal as a function of acceleration.

20
Accelerometers everywhere!
any displacement transducer capable of measuring
microscopic movements under strong vibrations or
linear acceleration
21
Accelerometers anyone?Things to consider
  • Anticipated magnitude of acceleration
  • How fast the ambient temperature changes
  • Anticipated frequency range
  • Accuracy range required
  • Maximum tolerable size vs power
  • Amount of moisture present
  • Anticipated over-shock
  • Surrounding acoustic, electromagnetic, and
    electrostatic interference

22
GSR sensor
  • Galvanic skin response change in skins
    conductivity resulting from change in arousal
    levels
  • Fluctuates quickly during mental, physical and
    emotional arousal
  • Eccrine glands produce ionic sweat lowering
    resistance and increasing conductivity

23
Characteristics of a GSR sensor
  • Two electrodes in close proximity
  • Typically attached to areas of high eccrine gland
    concentration
  • palms of hands
  • soles of feet
  • arm pit
  • simple DC amplifier

24
How the simple GSR works
  • Measures changes in electrical resistance across
    two regions of the skin
  • Low voltage applied to one electrode
  • Current flows to second electrode
  • transistor amplifies signal
  • potentiometer can be used to adjust for
    individual conductivity differences

25
When can I use GSR sensors
26
GSR anyone?Things to consider
  • Placement of electrodes
  • Relative position of electrodes
  • Pressure applied to electrodes
  • Sensitivity of reading
  • Duration of data collection (hours vs days)
  • Activity level during data collection

27
Gyroscopes (Gyros)
  • Orientation sensors
  • 1 or 2 degrees-of-freedom possible
  • Traditional gyros
  • massive disk
  • framework rotates about 1 or 2 axes

28
How the Traditional Gyro Works
  • Based on principle of Conservation of Angular
    Momentum
  • Spin axis will remain fixed with respect to
    space (assuming no external forces act on it)
  • Delivers a torque proportional to the angular
    velocity about an axis perpendicular to the spin
    axis

29
MEMS Gyros
  • rotation is replaced by vibration
  • suspended mass moves linearly in simple harmonic
    motion.

30
Gyros anyone?Things to consider
  • Size and cost
  • Durability of device

31
Applied Force Sensors (strain gauges)
  • Measuring the strain produced in a elastic member
    by an external force
  • piezoresistive effect
  • Long longitudinal and short transverse segments
    provide good sensitivity

32
Characteristics of Strain Gagues
  • Resistor bonded with an elastic carrier
  • Elastic carrier (backing), is applied to object
  • Must be reliably coupled to the gauge wire
  • Wire electrically isolated from the object
  • Coefficient of thermal expansion of the backing
    should be matched to that of the wire

33
Strain Gauges Anyone?Things to consider
  • semiconductive strain gauges are quite sensitive
    to temperature variations
  • Sensor should be well bonded to device
  • withstand force strain (dont snap in half)

34
Light Sensors
  • Detect electromagnetic radiation in spectral
    range (ultraviolet to far infrared)
  • Absorption of photons (2 response types)
  • quantum detectors (ultravi to mid-infrared)
  • thermal detectors (mid and far-infrared)

35
How Light Sensors Work
  • photoelectric effect
  • photon transfers energy to surface electron
  • high energy, the electron may become mobile
  • results in an electric current

36
Light Sensors Anyone?Things to Consider
  • Temperature of operations (thermal gtefficiency
    quantum at room temp)
  • amount of light vs intrinsic noise level of
    detector
  • surface area of detector lens
  • sensitivity / response range of detector

37
Cameras
  • lens focuses light behind rear element
  • film
  • silicon chip
  • CCD charged coupled device
  • CMOS complimentary medal oxide sensor

38
How Camera CCDs work
  • grid of photosites
  • typically monochrome
  • color filters laid over photosites
  • RGB
  • CMYK

39
Cameras Anyone?Things to Consider
  • ambient light conditions
  • camera settings
  • type of light to sense
  • resolution

40
Microphones
  • detects audible range acoustics
  • pressure transducer
  • adapted for the transduction of sound waves over
    a broad spectral range
  • generally excludes very low frequencies (below a
    few hertz)
  • cannot measure constant or very slow-changing
    pressures

41
How Microphones Work
  • moving diaphragm
  • displacement transducer converts diaphragms
    deflections into electrical signal

42
Microphones Anyone?Things to Consider
  • sensitivity
  • directional characteristics
  • frequency bandwidth (acoustic sensors)
  • dynamic range
  • size of device
  • sound transmitting media (liquid, gas, or
    solids)

43
Altimeter
  • indirectly measures altitude
  • barometer (measuring atmospheric pressure)
  • uses changes in atmospheric pressure to determine
    altitude
  • inverse relation (high altitude, low pressure)
  • airplanes use laser range finders

44
How an Altimeter Works
  • changes its resistance in proportion with the
    height of mercury in each column

45
Altimeters Anyone?Things to Consider
  • calibration for altitude of use
  • weather conditions
  • air pressure changes by 1 mbar during day
  • skew readings by 26 feet (8 meters)
  • bad weather low pressure

46
GPS
  • Geo Positioning System measures position
  • Receives radio signals from multiple satellites
  • Computes time delay between signals received from
    one satellite to the others
  • When position of a vehicle is determined with a
    periodic rate, computation of velocity is no
    problem.
  • For smaller objects and shorter distances, GPS is
    not a velocity solution.

47
GPS Anyone?Things to Consider
  • capture time (signal delay)
  • signal indoors is typically poor
  • city canyon effect
  • precision (2 meter accuracy)

48
Tactile Sensors
  • special force or pressure transducers
  • two basic types
  • two leaves of foil and a spacer
  • thin layer material responsive to strain

49
How Tactile Sensors Work
  • Active
  • active ultrasonic coupling touch sensor
  • piezoelectric films (polyvinylidene fluoride
    --PVDF)
  • Passive
  • signal generated by piezoelectric film without
    excitation signal
  • response proportional to the rate of stress

50
Tactile Sensors Anyone?Things to Consider
  • Type of senor (switch, capacitive)
  • Contaminates present
  • moisture
  • dust
  • Sensitivity

51
Pressure Sensors
  • measures force applied to a surface
  • detector responding to applied force
  • 3 types
  • absolute (barometer)
  • differential (flow meters)
  • gauge (blood pressure)

52
How Piezoresistive Pressure Sensors Work
  • thin silicon diaphragm (elastic material)
  • piezoresistive gauge resistors as diffusive
    impurities into the diaphragm

53
Pressure Sensors Anyone?Things to Consider
  • Type of sensor
  • Range of operation temperatures

54
Temperature sensors
  • thermal expansion (liquid in glass)
  • electrical transduction
  • resistive
  • optical
  • acoustic
  • piezoelectric
  • thermoelectric
  • semiconductive

55
How Temperature Sensors Work
  • heat conduction occurs at interface between the
    object and the probe
  • sensor converts thermal energy into an
    electrical signal

56
Characteristics of a Temperature Sensor
  • equilibrium
  • no significant thermal gradient exists between
    measured surface and the sensing element (thermal
    equilibrium)
  • predictive
  • equilibrium point determined by rate of the
    sensors temperature change

57
On-body challenges
  • Hardware
  • cables
  • batteries
  • wireless
  • power
  • placement orientation
  • recordkeeping
  • Software
  • data collection
  • synchronization
  • feedback (heartbeat)
  • moving data around
  • processing data

58
Hardware
59
Hardware
60
Sensor placement
  • What kind of data is needed?
  • Sensor limitations
  • Later processing
  • Mounting

61
Sensor placement
  • What kind of data is needed?
  • Or, whats the application?
  • Examples with accelerometer
  • To get steps/minute, place on foot
  • To track activity, place on hip

62
Sensor placement
  • Sensor limitations
  • Accelerometer 2G, 5G, 10G?
  • Proximity sensor ambient light influence?
  • Capacitive touch user wearing gloves?
  • Dynamic range mic recording right frequencies?

63
Sensor placement
  • Later processing
  • Cheat with good placement orientation

64
Sensor placement
  • Mounting
  • At desired measuring points
  • Slack for bending limbs
  • Comfortable(-ish) mounting
  • Anti-slip
  • Sensors all oriented same way

65
Hardware
66
Recordkeeping
  • Write down sensor position orientation!
  • Which sensors where?
  • Take pictures!
  • Label your sensors!
  • Do it the same way every time!

67
Hardware
Wireless
68
Cables vs Wireless
  • Cables
  • No batteries
  • Reliable connection
  • Secure
  • Hard to mount
  • Cable tangles catching
  • Cable breaking
  • Wireless
  • Power
  • Packet loss
  • Insecure
  • Easy to mount
  • Freedom of movement

69
Hardware
70
Cable Management
  • Connection to sensor
  • Flexible cable stiff board breaking
  • Movement of cables along body
  • Allow full range of body movement
  • Consider special clothing
  • Keeping cables from catching
  • Danger doorknobs!

71
Cable management
  • Anti-slip
  • Central data collection

72
Cable management
73
Hardware
74
Wireless
  • Options
  • Bluetooth, ZigBee, Nordic, etc...
  • Transmission

75
Hardware
76
Power
  • How to power your sensors?
  • Cables
  • Only 1 battery to charge
  • Cables power distribution
  • Batteries
  • Multiple charging necessary
  • No cables
  • Make batteries replacable!

77
Hardware
78
Data collection hardware
79
Data collection hardware
  • Good mounting important!
  • comfort
  • cables
  • wireless
  • access
  • feedback

80
Software
Synchronization
Data Collection
Feedback
Moving data
Processing
81
Software
Synchronization
Data Collection
Feedback
Moving data
Processing
82
Data collection
  • More automatic better!
  • (Sensors in same place every time)
  • Saving data
  • Human readable is useful
  • Timestamp everything!
  • Packet numbers too, if you can
  • Meaningful names (arm-left.dat rathern than
    sensor5.dat)

83
Data collection
  • Storing your data
  • Think about structure for future use!
  • Put a short note with each data run
  • context/data/2006-10-14_1335/arm_left.txt
  • context/data/2006-10-14_1335/arm_right.txt
  • context/data/2006-10-14_1335/leg_left.txt
  • context/data/2006-10-14_1335/leg_right.txt
  • context/data/2006-10-14_1335/NOTES.txt

84
Software
Synchronization
Data Collection
Feedback
Moving data
Processing
85
Synchronization
  • Why synchronize?
  • Multi-sensor learning
  • Concurrent actions
  • Ground truth

86
Synchronization
  • How?
  • Timestamp each chunk of data
  • 1132085944.59504 54078 475 465 535
  • 1132085944.59565 54079 476 466 534
  • 1132085944.75205 54080 476 470 536
  • 1132085944.75222 54081 476 470 534
  • 1132085944.75231 54082 478 470 533
  • 1132085944.75238 54083 479 469 533

87
Synchronization
  • How?
  • Multi-sensor spike

88
Software
Synchronization
Data Collection
Feedback
Moving data
Processing
89
Feedback
  • Are sensors still working?
  • Visual feedback
  • HMD or external monitor
  • Show waveform or data stream
  • Uniquely ID each sensor
  • Auditory feedback
  • Heart beat beeping
  • Or beep when expected data does not arrive

90
Software
Synchronization
Data Collection
Feedback
Moving data
Processing
91
Moving data around
  • Think about how to get data off
  • Dont bury your USB ports!
  • Keep backups!

92
Software
Synchronization
Data Collection
Feedback
Moving data
Processing
93
gt2k is
  • A user interface toolkit designed to enable the
    development of gesture-based applications.
  • Written in Java for cross-platform use and easy
    integration into graphical user interface
    development tools.

94
When to use gt2k
  • Applications using symbolic/iconic gesture
  • Sign language
  • handwriting
  • Applicable to research in many fields
  • Human-Computer Interaction
  • Assistive Technologies
  • Robotics
  • Brain Research
  • etc.

95
Outline
  • Example applications
  • WritingPad
  • Accelerometer
  • Camera
  • gt2k architecture
  • Overview
  • Sensor
  • Library
  • Machine Learning
  • Recognition Process
  • Data collection
  • Training
  • Recognition
  • In-depth sample example
  • How to make your own application

96
Application WritingPad
  • Sensor mouse sensor
  • Allows a user to draw a gesture with a mouse

97
Application Accelerometer
  • Sensor Accelerometer
  • Collects information about users physical
    movement

98
Application Vision Tracker
  • Sensor Image Sensor
  • Tracks the movement of objects

99
Architecture overview
Application
Machine Learning
Result
Wrapper
Request
CU-HTK
Library
Segment
Data
Library
Utils/Tools
Sensor
Sample
Sample
gt2k api
user/3rd party app.
100
Sensor
  • Interfaces with the hardware and collect data.
  • Provides parsing or post-processing of the data.
  • Designed around an event-based architecture.
  • Allows for both synchronous or asynchronous
    reading of sensors.

101
Library
  • Responsible for storing and organizing data.
  • Composed of a collection of samples.
  • lt?xml version"1.0" encoding"UTF-8"?gt
  • ltlibrary name"WritingPadLib"gt
  • ltsamplesgt
  • ltsample id"1"gt
  • lttag end"144" label"star" start"0"/gt
  • ltfvectorsgt
  • ltvgt0.0 0.0lt/vgt
  • ltvgt-0.32175055 3.1622777lt/vgt
  • ltvgt-1.815775 4.1231055lt/vgt
  • lt/fvectorsgt
  • lt/samplegt
  • lt/samplesgt
  • lt/librarygt

102
Machine Learning
  • Provides the toolkits abstraction for the
    machine learning algorithms.
  • Used for modeling data samples (training) and
    recognizing gesture samples.
  • Utilizes Cambridge Universitys Hidden Markov
    Model Toolkit (CU-HTK).

103
Gesture Recognition Process
  • Data Collection
  • Segmentlabel data
  • Store data as feature vector
  • Training
  • Train model with collected data
  • Recognition
  • Recognize new raw data using trained
    model

104
Data Collection
Application
Machine Learning
Result
Request
?
?
Library
Segment
Data
Library
?
Utils/Tools
Sensor
Sample
Sample
105
Training
?
Application
Machine Learning
Result
?
Request
Library
Segment
Data
?
Library
?
Utils/Tools
Sensor
Sample
Sample
106
Recognition
?
Application
Machine Learning
Result
Request
?
?
Library
Segment
Data
Library
?
Utils/Tools
?
Sensor
Sample
Sample
107
How to make your own application?
  • Considerations
  • What kind of sensor will you use?
  • Is it already in the gt2k package or should I
    build new sensor?
  • How are you going to segment data?
  • Mouse Sensor segments data by clicking (start)
    and releasing (stop) mouse button
  • How big is my feature vector?
  • Vector size of mouse sensor 2 (X and Y)
  • Vector size of accelerometer 3 (X, Y and Z)
  • What if I have two accelerometer sensors?

108
How to make your own application?
  • Create a new set of options
  • GT2kOptions myOpts GT2kOptions()
  • myOpts.setVectorSize(2)
  • Create or load a library object
  • try libraryLibrary.load(MyLibrary.xml")
  • catch (Exception e)
  • librarynew Library(MyLibrary")
  • Initializes the machine learning component
  • HTK htk new HTK(myOpts)
  • Create a new sensor
  • MouseDragVectorSensor mySensor new
    MouseDragVectorSensor()

109
How to make your own application?
  • For data collection
  • Connect the sensor to the library so it can save
    the samples
  • mySensor.addSensorSampleListener(library)
  • For recognition
  • Connect the sensor to the HTK object
  • mySensor.addSensorSampleListener(htk)
  • Connect HTK object to application to get a result
  • htk.addResultListener(myApplication)

110
How to make your own application?
  • WritingPad application structure
  • WritingPadPanel
  • creates all of the components
  • of UI
  • -defines all buttons actions
  • WritingPad
  • Initializes the program
  • -creates the main frame
  • Instantiates the needed gt2k objects
  • (MouseSensor, Library
  • , Options and HTK)
  • -connects a sensor, library, HTK,
  • Result objects
  • CoordinateArea
  • Displays the on-screen grid for user
  • feedback
  • -listens to the MouseSensor and
  • plots points

111
How to make your own sensor?
  • Considerations
  • Make sensor Runnable?
  • Mouse sensor implements mouse listeners
  • Accelerometer sensor implements Runnable
  • Start or stop from application
  • Drivers and Java library for your sensor
  • May not work under Windows but Linux

112
How to make your own sensor?
  • Things to do/write
  • Communication with physical sensor
  • Parses output (float type)
  • Connects to the gt2k sensor infrastructure

113
How to make your own sensor?
  • Structure
  • Sensor
  • Send out data or sample to the listeners
  • add/remove data listener
  • - add/remove sample listener

extends
  • YourSensor
  • - Provide Post-processing (parsing output)
  • Whenever data gets generated,
  • sends data.
  • Whenever one gesture gets created,
  • sends a sample.
  • YourSensorController
  • Drivers or communication tools with
  • your physical sensor

114
The End
  • Thank you!
Write a Comment
User Comments (0)
About PowerShow.com
