Dozer Operations

1
Dozer Operations
2
Dozer

• Pushes waste
• Spreads Cover Soil
• Low ground pressure
• Good Traction
• Good for pushing...not for Compacting.

3
Vehicle Placement

• At the landfill, vehicles are directed to the
  appropriate tipping area.
• Proper vehicle placement is very important.

4
Vehicle Placement-Other Considerations

• Vehicle placement may also be based on the time
  it takes to unload.
• Its usually more efficient and safer to keep
  commercial vehicles separated from self-haul
  vehicles.

5
When and How to Push to the Face

• Pushing should generally be done with the dozer.
• Pushing
• move dozer to pile
• keep blade about 4 inches from ground
• push straight ahead
• keep grade

6
Keeping Deck Clean
7
Smooth and Well Graded
8
Pushing to the Face

• Waste is pushed from the tipping area to the
  cell. Typically, a dozer performs this task.

9
Pushing to the Face

• Transfer Truck Loads
• Requires large tractors
• Downhill is preferred
• Packer Truck Loads
• density, cohesiveness, type of garbage, unloading
  time
• Small (self-haul) Loads
• hard to handle waste, slow un-loaders

10
Pushing Transfer Truck Loads

• Transfer truck loads are big and heavy
• Often 20 tons.
• These loads should be pushed intact.
• They should be pushed downhill.

11
Pushing Packer Truck Loads

• Dont break apart
• Push along long axis

12
Pushing Packer Truck Loads

• Push straight ahead as much as possible
• May need to break apart to push uphill
• May need to break apart to spread

13
Packer Truck LoadsSticking Together

• With practice, packer truck loads can easily be
  pushed to the face intact
• This saves time, fuel and money

14
Double Semi-U Dozer Blade

• This blade helps to break apart those packer
  truck loads
• It also directs trash to the tracks/wheels for
  optimum compaction

15
Pushing Small (self-haul) Loads

• Self-haul loads are most efficiently pushed
  across the tipping area (as shown)this requires
  caution and good spotter support.

16
Gathering Self-haul Loads

• When pushing self-haul loads, dont push straight
  into the cell
• Instead, gather a full load then push to the
  face
• Its more productive

17
Pushing Waste - Option 1

• Some operators wait until waste piles up at the
  tipping pad before pushing it to the cell.
• They think that theyre saving money by waiting
  as long as possible before pushing.

18
Pushing Waste - Option 2

• Other operators push as soon as any waste is
  dumped... even very small self-haul loads.

19
Pushing Short or Long?

• All garbage must be pushed
• If it piles up, the average push will be longer

20
Prompt Pushing Saves

• While there may be other factors, in most cases,
  pushing loads as they are dumped makes the most
  sense.

21
Push Downhill When Possible

• Regardless of the cell construction method
  utilized, downhill pushing will typically be the
  most cost-effective
• What are some pros and cons of downhill pushing?

22
Tips for Experienced Operators

• Measuring the dozers productivity
• Heres how to do it
• Optimizing Push Distance
• Look at both costs (tipping pad dozer)
• Its shorter than you think

23
Optimum Push Distance

• Two Considerations
• Pad Costs
• Pushing Costs

24
Push Costs

• Optimum push costs
• Push costs related to push distance

25
Pad Costs

• Optimum pad costs
• Pad costs related to push distance

26
Learn From My Mistake !

• We were proud of our ability to push long
• We thought we were cool
• It wasnt cool to waste 5,000 per day !

27
Pushing Waste - What Should We Look For?
Break down the dozers cost into something you
can feel...
How about cost per push? At a 500 tpd landfill
(mostly route trucks) does a survey (counts
pushes) and finds that the D8 Dozer makes105
pushes each day. It spends 7 hours pushing
(includes gather, push, spread, return). The
rest of the time is spend in travel, service,
etc... The machine costs 125/hour to operate.
How much does each push cost?
28
Calculating the cost per push
7 hours/day x 125/hour /105 pushes 8.33 per
push
29
Working With Cost per Push
The goal is to change your perspective and
re-focus your effort
Can you decrease the cost per push? Or make fewer
pushes per day? How about some ideas?
30
How about cost per foot?
During the survey, you also determined that the
dozers average push distance (tipping pad to
cell) was 110 feet. Calculate the /foot... 7
hours/day x 125/hour / 110 feet 7.95 per foot
(per day).
31
Working With Cost per Foot
Again, the goal is to change your perspective and
re-focus your effort
Can you decrease the cost per foot? Or can you
push shorter? How about some ideas?
32
Take Off Those Rose-Colored Glasses of Tradition
Have another look at your dozer
Chances are, you see the dozer pushing waste many
times each day. After a while you dont even
think about it. A long push is just that A
darn long push. But when you think of it in
terms of it costing you 7.95/foot, it takes on
another meaning. A few extra pushes...no big
deal. Wait a minute! Pushes cost 8.33 each.
With that in mind, its better to let the dozer
sit (idle or turned off) if theres nothing to do.
33
Maximize Your Productivity

• Push straight
• Push downhill
• Slot dozing
• Side by side dozing
• Push full loads
• Dont be a clean freak let it pile up.
