Automating the Analysis of Simulation Output Data

1
Automating the Analysis of Simulation Output Data

• Katy Hoad (kathryn.hoad_at_wbs.ac.uk),
• Stewart Robinson, Ruth Davies, Mark Elder
• Funded by EPSRC and SIMUL8 Corporation

2
Project Web Site http//www.wbs.ac.uk/go/autosimo
a

• INTRODUCTION

Appropriate use of a simulation model requires
accurate measures of model performance. This in
turn, requires decisions concerning three key
areas warm-up, run-length and number of
replications. These decisions require specific
skills in statistics. Most Simulation
software provides little or no guidance to users
on making these important decisions. The
AutoSimOA Project is investigating the
development of a methodology for automatically
advising a simulation user on these three key
decisions

3

• How long a warm-up is required?
• How long a run length is required?
• How many replications should be run?

• PROJECT OBJECTIVES
• To determine the most appropriate methods for
  automating simulation output analysis
• To determine the effectiveness of the analysis
  methods
• To revise the methods where necessary in order to
  improve their effectiveness and capacity for
  automation
• To propose a procedure for automated output
  analysis of warm-up, replications and run-length
• (Only looking at analysis of a single scenario)

4
Obtain more output data
Analyser
Replications analysis
Recommendation possible?
Use replications or long-run?
Recommendation
Warm-up analysis
Simulation model
Output data
Run-length analysis
5

• Task 1
• MODEL CLASSIFICATION
• Creating A Standard Set of Model Outputs

At the beginning of this project it was decided
that a standard set of model outputs was required
for testing the output analysis methods. As this
was not readily available in the literature it
was proposed to create a representative and
sufficient set of models / data output that could
be used in discrete event simulation research by
this project and other researchers. A set of
artificial data sets were developed and a range
of real simulation models gathered together.
6
LITERATURE REVIEW Artificial Models

• 22 artificial models located in literature
  All steady state outputs with or without a
  warm-up period.

• Cash et al 1992 AR(1) M/M/1 Markov Chain.
• Robinson 2007 AR(1) M/M/1.
• Goldsman et al. 1994 AR(1) M/M/1.
• White, Cobb Spratt 2000 AR(2).
• Ockerman Goldsman 1997 Random Walk AR(1)
  MA(1).
• Kelton Law 1983 M/M/1 (FIFO) M/M/1
  (LIFO) M/M/1(SIRO) M/M/1 (initialized
  with 10 customers) E4/M/1 M/H2/1 M/M/2
  M/M/4 M/M/1/M/1/M/1.
• Hsieh et al 2004 M/M/1/199 M/G/1/199
  M/M/1/19 Number-in-stock process single
  item inventory management system.

7

• There are three main methods for creating
  artificial models/output data sets
• Create simple simulation models where theoretical
  value of some output / response is known.
• E.g. Model M/M/1. Output mean waiting time.
• Create simple simulation models where the value
  of some output / response is estimated but model
  characteristics can be controlled.
• E.g. Model Single item inventory management
  system. Output Number-in-stock.
• Create data sets from known equations, which
  closely resemble real model output, with known
  value for some specific output / response.
• E.g. AR(1) with Normal(0,1) errors

8
Real models are defined as discrete event
simulation models of real existing systems
For example

• Our aim was to collect a wide range of real
  models and artificial models/output such that the
  collection would cover each general type of model
  and output encountered in real life modeling.

9

• METHODOLOGY
• It was determined that model output fell into two
  main categories or groups
• Transient (including out-of-control trend)
• Steady-state (including steady-state cycle)

9 other characteristics of models and output data
sets were chosen to be used to categorize the
models/output within these two main groups
10
(No Transcript)
11

• After collection or creation of model / output
  the data output sets were identified as one of 5
  types
• Steady state Steady state cycle Transient
  Out-of-Control
• Each type was statistically analysed as follows
• Steady State Subtract mean from output data.

• Test residuals for Auto-correlation and
  Normality.
• 2. Steady State Cycle Run model for many
  cycles.
• Take mean of each cycle to create a new time
  series.
• Subtract mean from this new output data.
• Test residuals for Auto-correlation and
  Normality.
• 3. Transient Test for Auto-correlation on
  output data.
• Run many replications (1000)
• Take mean of each replication to create new
  (non auto-correlated) data series.
• Test for what type of statistical
  distribution best fits this new data series.

12

• RESULTS
• The following distributions were found to be a
  good fit to the various transient data output.

Normal, Beta, Pearson5, LogNormal, Weibull,
Gamma, Pearson6, Erlang, Chi squared No fits
could be found for two of the transient data sets.

• Classification tables were drawn up

13

• DISCUSSION
• YOUR COMMENTS APPRECIATED
• Using our chosen classification criteria, we
  have classified a complete set of possible
  models / output
• But are these criteria sufficient?
• Main model/output types missing from our
  collection
• Transient with warm-up.
• Deterministic transient.
• Cycle with warm-up
• Are these missing model criteria feasible?

?
14

• Justification of selection of model results /
  output e.g. through-put etc
• Picked most likely output result for each model,
  using already programmed results collection when
  feasible.
• Future intentions
• To create artificial data sets for each category
  that is missing a real model example.
• To test chosen (automatic) simulation output
  analysis methods on each category of model /
  output.

?
15
Task 2NUMBER OF REPLICATIONS
16
REPLICATION DEFINITIONS

• Precision, d, ½ width of Confidence Limit
  expressed as of the mean
• Inner Precision Limits (IPL)
• Where is described as a
  of

17
REPLICATIONS ALGORITHM

• While Criteria not met
• Run n replications of model.
• Calculate cumulative mean
• If required precision d is reached
• Let Nsol be the number of replications required
  to reach required d.
• Check kLimit replications ahead that Criteria is
  met
• d stays below required limit
• is stable i.e. stays within Inner
  Precision Limits.

• Let n n1
• Loop

Recommend Nsol replications.
18
For Example
19
FUTURE WORK

• To determine the most appropriate methods for
  automating warm-up and run-length analysis
• To determine the effectiveness of the analysis
  methods
• To revise the methods where necessary in order to
  improve their effectiveness and capacity for
  automation
• To propose a procedure for automated output
  analysis of warm-up and run-length
