Orientation

1

• Orientation
• Location
• Scale

By Eleanor Joyce City of Salem Schools
2
Objectives

• Prior to this activity, the students have
  demonstrated a knowledge of
• The definition of latitude and longitude
• The concept of hemisphere and how the globe is
  divided into four hemispheres.

• The Student will draw a compass rose and
  determine orientation on a map.
• The student will locate and label latitude and
  longitude coordinates on a map of the world
• The student will state the relative location of
  regions on a map.
• The student will estimate the distance between
  two points on a map by using a scale of miles.
• The student will compare maps to understand how
  the scale ratio determines the amount of detail
  on a map.

3
Orientation

• Location or position relative to the points on
  the compass.

Cardinal Directions North, South, East,
West Intermediate Directions- Northwest,
Northeast, Southeast, Southwest
4
Draw a compass rose and fill in the cardinal and
intermediate directions.
5
Answers
North
Northeast
Northwest
West
East
Southeast
Southwest
South
Never Eat Shredded Wheat
6
Location

• Absolute and Relative

7
Relative Location

• The description of the location of a place in
  relationship to another place.

8
Europe
North America
Asia
Africa
South America
Australia
Antarctica
Europe is located North of Africa North America
is located of South America
Next
North
9
Europe
North America
Asia
Africa
South America
Australia
Antarctica
Asia is located of Europe. Australia
is located of Antarctica.
East
Next
Northeast
10
Absolute Location

• The global address of a point on the globe is
  an absolute location.
• The latitude and longitude coordinates define
  the absolute location of a point on the globe.
• The correct order for global addresses are
• North and South followed by East and West
• 60N, 120W is a correctly written address.

11

• Absolute location is the point were lines of
  latitude and longitude intersect on a grid.
• Longitude lines or Meridians run north to south
  but are read east to west.
• Latitude lines or Parallel lines run east to west
  but are measured north to south.

12
Step 1. Highlight the Equator Step 2. Highlight
the Prime Meridian.
Next
13
NE
NW
SW
SE
Step 3. Draw and X where the two lines
intersect. Step 4. Label the hemispheres
Next
14
20N, 80 W
NE
NW
SW
SE

• Step 5. Locate 20N, 80 W
• Locate the Northwest hemisphere. Why
• Locate 20 N, draw a line along this line to
  the Prime Meridian .
• Locate 80 W, draw a line along this line to
  the Equator
• Where the two lines intersect is 20N, 80 W

Next
15
Use the same skills to identify the absolute
location of the red star. What is the answer?
Next
40N, 140E.
16
Use the same skills to identify the absolute
location of the red star. What is the answer?
Next
60S, 60E.
17
Use the same skills to identify the absolute
location of the red star. What is the answer?
Next
20S, 20W.
18
Use the same skills to identify the absolute
location of the red star. What is the answer?
Next
20N, 0.
19
Use the same skills to identify the absolute
location of the red star. What is the answer?
0N, 100W.
20
Scale

• Ratio between a distance on a map and the
  corresponding distance on the earth

http//geography.uoregon.edu/buckley/teaching/geog
311/lectures/lecture420-20map20scale/sld003.htm
21
Representative Fraction

• a fraction or ratio between units on themap and
  units on the earths surface
• format
• 11,000,000 OR 1/1,000,000

http//geography.uoregon.edu/buckley/teaching/geog
311/lectures/lecture420-20map20scale/sld003.htm
22
Graphic or Bar Scale

• a line subdivided like a ruler to show the
  lengths of earth distance units on the map.

50
100
150
200
250
300
350
0
1 inch 50 miles
http//geography.uoregon.edu/buckley/teaching/geog
311/lectures/lecture420-20map20scale/sld003.htm
23
The distance from Captain Cook to Hilo would be
approximately how many miles?

• 10 miles
• 25 miles
• 50 miles
• 100 miles

24
The distance from Captain Cook to Hilo would be
approximately how many miles?

• 10 miles
• 25 miles
• 50 miles
• 100 miles

25
Map Scale

• The smaller the scale of miles, the more detail
  the map shows.
• The larger the scale of miles, the less detail
  the map shows.

26
Scale of Miles range is 0-5 miles
How much detail can you see on this map?
27
Scale of Miles range is 0-1.2 miles
How much detail can you see on this map?
28
Scale of Miles range is 0-.6 miles
How much detail can you see on this map?
29
Scale of Miles range is 0-.3 miles
How much detail can you see on this map?
30
Scale of Miles range is 0-160 yards
How much detail can you see on this map?
31
Which map shows the most detail?
A
C
D
B
32
Which map shows the most detail?
A
C
D
B
33
Which map has the smallest scale of miles?
A
C
D
B
34
Which map has the smallest scale of miles?
A
C
D
B
35
Review

• Fill in the blanks
• The larger the scale of miles, the _______ detail
  will be shown on the map.
• The smaller the scale of miles, the_______detail
  will be shown on the
• detail.

36
Review

• Fill in the blanks
• The larger the scale of miles, the _______ detail
  will be shown on the map.
• The smaller the scale of miles, the_______detail
  will be shown on the
• detail.

less
more
