Q

1
Quasars Cosmology
Quasars and Cosmology
ASTR-1510-01 ASTR-1510-02
Department of Physics, Applied Physics
Astronomy, RPI
2
Week 12

• The Early Universe II
• t1 second to t3 minutes
• Jones Lambourne
• Sections 6.4-7
• November 16, 2009
• 300 PM
• Darrin 330

Department of Physics, Applied Physics
Astronomy, RPI
3
Outline

• Review The First Second
• Elemental Abundances in the Universe
• Nucleosynthesis in the Early Universe
• Nucleosynthesis in Stars

4
bosons

Image Stanford/SLAC
5
Review The First Second of Time

• 0 sec lt t lt 10-44 sec - Planck Epoch
• Interactions 1 (gravitystrongweakEM)
• Particles Unknown! Superstrings?
• Starts The Big Bang.
• Ends Gravity force decouples.
• 10-44 sec lt t lt 10-36 sec - GUT Epoch
• Interactions 2 (gravity, strongweakEM)
• Particles False vacuum.
• Starts Gravity force decouples.
• Ends Strong force decouples.

6
The First Second (contd)

• 10-36 sec lt t lt 10-34 sec Inflation
• Interactions 3 (gravity, strong, weakEM)
• Particles free quarks, leptons, bosons
  antiparticles.
• Starts Strong force decouples, inflation begins
• Ends Inflation ends.
• Phase transition vacuum jumps to lower energy
  state.
• Energy released fuels exponential expansion.
• Universe grows by factor 1050!
• Vacuum energy released also forms all known
  particles.
• Very slight (10-9) matter/antimatter asymmetry.

7
The First Second (contd)

• 10-34 sec lt t lt 10-12 sec The Particle Desert
• Interactions 3 (gravity, strong, weakEM)
• Particles free quarks, leptons, bosons
  antiparticles.
• Starts Inflation ends.
• Ends Weak force decouples.
• 10-12 sec lt t lt 10-5 sec
• Interactions 4 (gravity, strong, weak, EM)
• Particles free quarks, leptons, bosons
  antiparticles
• Starts Weak force decouples.
• Ends free quarks form hadrons (protons,
  neutrons).

8
The First Second (contd)

• 10-5 sec lt t lt 1 sec Hadron Epoch
• Interactions 4 (gravity, strong, weak, EM)
• Particles protons, neutrons, leptons, photons
• Starts free quarks form hadrons.
• Ends neutrinos decouple.
• Protons (p), neutrons (n) annihilate with
  antiparticles.
• Tiny matter excess yields some n and p
  leftovers!
• Neutrino reactions converted n into p and vice
  versa,
• ne p n e
• but protons were favored, protonsneutrons 51.

9
(No Transcript)
10
The Elements and Their Isotopes
Z no. protons, N no. neutrons
Element nuclei with the same Z (carbon
Z6). Example all carbon nuclei have Z6
protons. Isotopes nuclei with same Z but
different N. Example carbon can have N6, N7,

11
Periodic Table of Chemical Elements
12
Cosmic Abundances of the Elements
Number of protons in nucleus
13
Temperature (T) Particle Energy
At t1 sec, the energies are about right for
nuclear reactions. Were all of the elements made
in this way?
14
Reactions of the Light Elements
5
4
3
Z
2
dashedunstable
1
0
5
6
7
0
1
2
3
4
N
15
Big Bang Nucleosynthesis (BBN)

• Problem 1 free neutrons unstable.
• Problem 2 universe is expanding and cooling!
• MUST WORK FAST (3 MINUTES)
• Problem 3 no stable nuclei of atomic mass 5, 8.
• CANNOT GET PAST LITHIUM.
• Hey, its not all bad
• BBN EXPLAINS WHY UNIVERSE IS
• MOSTLY HYDOGEN, HELIUM!

16
A Simulation of BBN
17
Simulated vs. Actual Abundances
4He
actual

• Simulations depend on Wb baryonic
  density/critical density.
• Actual abundances require Wb between 0.02 and
  0.03.

18
Origin of Elements Heavier than Li

• BBN seeds the Universe with H, He, Li.
• Galaxies and stars form from primordial gas.
• Stars fuse light elements into heavier elements.
• This happens VERY SLOWLY.
• 10 billion yr. for a star like the Sun.
• 10 million yr. for much heavier stars.
• Some dead/dying stars release products back into
  space, enriching the interstellar gas.
• Later generations form from enriched gas.
• And the cycle repeats

19
(No Transcript)
20
Hydrogen Fusion in Stars

• Main sequence stars like the Sun consume H to
  make He by a variety of fusion reactions
  collectively known as hydrogen burning.
• There are 2 H-burning processes
• pp chain (dominant in Sun-like stars)
• CNO cycle (dominant in heavy stars)

21
The Proton-Proton (PP) Chain

• The first reaction is pretty inefficient, but
  once d is formed the reaction proceeds rapidly.
• For second reaction T gt 106 K
• Energy released as KE, photons, neutrinos by
  annihilation of e

22
CNO Cycle

• Net Result 12C 4p 12C 4He

23
Beyond Helium

• Helium Burning
• 4He 4He 4He 12C
• CNO Cycle
• 12C 14N
• Carbon Burning
• 12C , 12C 20Ne, 23Na, 24Mg
• And so on

24
Summary Nucleosynthesis in stars.
25
Summary Origin of the Elements

• Vacuum Phase Transition (10-36 sec)
• energy released forms free quarks, leptons,
  bosons ( every particle)
• matter/antimatter asymmetry
• Quark-Hadron Transition (10-5 sec)
• free quarks combine to (mostly) protons
  neutrons
• Big Bang Nucleosynthesis (t1 sec)
• makes H, He, and Li
• Stellar Nucleosynthesis
• makes all the other natural elements
