Topographic Map, Colorado

1
(No Transcript)
2
General summary

• The Fort Collins flood was the biggest natural
  disaster to ever affect the city (in nearly 130
  years of record).
• It was the largest 24-hour rainfall ever to fall
  on a Colorado urban drainage.
• There were a total of 5 deaths, more than 62
  injuries requiring hospitalization, 120 mobile
  homes and 22 houses destroyed, 2000 homes
  damaged, and 250m in total damage.

3
Topographic Map of Colorado
4
Some aspects of the flood were entirely expected

• The event occurred during a period in which
  severe weather is expected somewhere in the near
  vicinity (Weaver Doesken, Weather, 1990)
• It took place in an environment considered
  synoptically favorable for severe weather on the
  high Plains. (Doswell, Bull. Amer. Meteor. Soc.,
  1980)

5
Monsoonal Flow began several days before the event
6
500 mb Heights and Vertical Velocity
7
1200 UTC 28July97 Surface
8
1800 UTC 28July97 Surface
9
Pre-flood setup

• Heavy rain fell to the northwest of Fort Collins
  the day before the flood
• Up to 9 of rain fell just north of Laporte,
  Colorado between 430 p.m. on 27 July 97 through
  noon on the 28th.
• West Fort Collins received up to 4 during this
  same period.

10
Fort Collins arterials and collector streets
shown in red
11
Some were not . . .

• The morning sounding found a tropical-oceanic
  airmass throughout the depth of the troposphere
• There were no severe storm indications on
  satellite
• Radar-estimated rainfall was as much as 50
  understated
• Sheeting runoff played as great a role in the
  event as did stream overflow

12
(No Transcript)
13
Satellite Imagery

• Satellite imagery over Colorado showed a line of
  storms (probably along the returning cold
  front) moving eastward during the afternoon.
• Vis loops showed that upslope was accelerating
• Infrared loops showed that storm activity on the
  Plains was transitional in nature, while the Fort
  Collins activity was recurrent

14
(No Transcript)
15
(No Transcript)
16
Multiple storm cells early on

• During the first half of the evening, a series of
  storms formed southwest of the city and traveled
  north-northeastward at about 8 ms-1 across
  western Fort Collins.
• 3 - 4 of rainfall in west Fort Collins between
  600 and 830 p.m. MDT.
• E-911 calls begin to increase dramatically after
  815 p.m.

17
Overall nature of the rainfall

• Rainfall totals were extremely large in southwest
  Fort Collins the night of the 28th
• The rainfall was concentrated primarily within
  two large drainage basins
• The heaviest rains came near the end of the event
  which is unusual (according to NWS Office of
  Hydrology)

18
(No Transcript)
19
(No Transcript)
20
Radar-estimated rainfall was 40-50 too low

• The underestimate by radar was due to the lack of
  frozen precipitation (i.e., the storm did not
  fit the normal upon which Z-R is based).
• Also, there were no reports from spotters,
  because a) the storms just looked like heavy
  rain, to them, or b) they were having problems
  of their own with flooding

21
15-min lightning strikes ending 930 p.m.
(Relatively little lightning in the FCL
activity)
22
Large, slow-moving storms late

• Storm motion changed abruptly at around 830 p.m.
• The storms after 830 moved toward the
  east-northeast at about 3 ms-1.
• The reason for the slowing and turning was
  outflow from a storm near Greeley, CO.

23
(No Transcript)
24
A Developing surge of water

• Between 830 and 900 p.m. a surge of water
  developed.
• This was different from the deepening creeks and
  irrigation ditches -- it was a sudden deepening
  of runoff water on collector streets.

25
(No Transcript)
26
Detection was a major problem

• A 50-acre detention area, designed to handle a
  500-year flood, filled to capacity by 1045 p.m.
  The areal extent is about 40 football fields, and
  the contained area 19-foot deep on its east side.
• There were no rain gauges in the region, and
  there was no human habitation nearby
• A 19-foot railroad bed over-topped, and a 12x14
  culvert failed

27
Horizontally-striped region is the 50-acre
detention pond
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
Summary

• Radar-estimated rainfall was 40-50 low,
• There were major problems with recognition
  detection - - weather spotters did not even
  report,
• Lightning activity was minimal due to a lack of
  ice processes in the storm,
• No large storms were observed on satellite in the
  vicinity of Fort Collins throughout the night,
• Sheeting urban runoff played the major role in
  the evolution of the event.

33
Timing of Critical Events

• Flash Flood Watch at 500 p.m.
• Urban Small Stream Flood Advisory 736p.m.
• Spring Creek flooding problems begin at 830
  p.m.
• Drainage basin runoff problems begin at 900
  p.m.
• Urban Small Stream Advisory extended at 902
  p.m.
• Flash Flood Warning 940 p.m.
• Colorado State University problems begin 1000
  p.m.
• Converging of drainages 1030 p.m.
• Culvert breach at 1046 p.m.
• Deaths occur 1055 through 1105 p.m.

34
Future Plans

• Fort Collins is installing an Emergency Managers
  Weather Information Network (EMWIN) ground
  station.
• The citys EM will be paged-out only when local
  events, exceeding a pre-determined, critical
  threshold are anticipated.
• Alerts to local officials and city/county
  departments can be carried out in a multi-tiered,
  preset order.

35
Future Plans

• The city is also installing a Local Data
  Acquisition and Display (LDAD) system.
• Critical stream and precipitation gage
  information will reach the NWS in a timely
  fashion.
• Better local guidance for the citys EM will
  thereby be available from the NWS.

36
Future Plans

• The city of Fort Collins has begun a project to
  develop a real-time flood inundation mapping
  capability. The project is funded primarily by
  FEMA.
• The first step will take place in late February
  or early March. At that time a one-foot
  resolution topographic data base will be
  developed for the FCL metro area.

37
Future Plans

• The city of Fort Collins is
• a) purchasing a reverse 911 telephone dialing
  system, EDD cards for dispatch
• b) installing a low-power am radio station for
  re-broadcasting NOAA weather radio information
  during critical events.
• c) designing a two-level training program for
  natural disasters -- one for the general public,
  and one for emergency responders

38
Future Plans

• The general public training will be based on
  so-called action videos which illustrate people
  making critical mistakes (fun to watch),
• The emergency responder program will include
  weather/spotter training, exercises and learning
  to look at false alarms as useful events.
  Weather spotters will be treated as part of the
  total emergency response force.

39
Flood Photo Site http//www.verinet.com/rwf/floo
d/pfa3.htm Fort Collins OEM Site http//www.ci
.fort-collins.co.us/C_SAFETY/oem/index.htm
40
Forecaster Tip

• If you are working in an environment that is
  characterized by a tropical, or near-tropical
  airmass, and are looking at either radar or
  satellite output, be especially alert for small,
  shallow storms which have little or no
  electrical activity. Chances are that WSR-88D
  radar-estimated rain rates are significantly
  understated . . .
