Data and Data Applications

1
Data and Data Applications

• Helen Cheung
• Motorola

2
Agenda

• Market requirements
• Why a dedicated TETRA Network?
• How is TETRA addressing current market
  requirements?
• Evolution and future vision
• Data on TETRA case story

3
Agenda

• Market requirements
• Why a dedicated TETRA Network?
• How is TETRA addressing current market
  requirements?
• Evolution and future vision
• Data on TETRA - case story

4
What are customers requirements?

• Improve operating efficiency, productivity
• Flexible coordination
• Constant communication
• Improve employee safety
• Improve operations security
• Enhance ease of public access to services
• Facilitate data sharing
• Integrate new applications with existing systems
• Enable secure access to information from anywhere
• Simple, cost effective system expansion and
  enhancements

5
What are the data requirements?

• Centralised resource management operations
  safety
• Automatic Vehicle Location
• Automatic Person Location
• Improved Productivity
• Report Writing
• Email
• Improved Communications
• Texting
• Paging
• File/image transfer

• Information Exchange
• Image (point to point)
• Finger Print System (AFIS)
• Video
• Biometrics
• Database Enquiries
• Directory services (internal)
• Vehicle plate register
• Voter register
• Quick address service (external)
• Criminal intelligence system
• Operational information systems
• Property (lost found)
• Building layouts
• Medical records

6
Improve Operational Efficiency

• Improve response times
• Ability to make right and fast decision based on
  facts
• Improve effectiveness
• Ability to prioritise decisions task
• Improve resource management
• Ability to track and protect staff
• Ability to control fleet for better results
• Improve productivity
• Automated work flow
• Improve cost effectiveness

Moving information to the point of decision
Sir Edmund Burton, Head of PITO
7
Data Applications
Back Office
Information sources

• Accounts Receivable
• Personnel/Administration
• Payroll
• Parking Tickets
• Fingerprinting
• Passenger Information
• Video surveillance

• National/Regional Criminal Database
• Prison Database
• Justice/Courts Database
• Local Crimes Database
• Telemetry
• Medical journals

TETRA Network
Control room
Vehicle/Person

• AVL/Mapping Server
• Database Inquiries
• Records Management
• Console Dispatch/Switch
• Message Switch
• GPS tracking
• Fleet management

• Incident Dispatch
• Database Enquiry
• Mobile Messaging
• Field Report Writing
• Radio Control
• Mug shots

8
Agenda

• Market requirements
• Why a dedicated TETRA Network?
• How is TETRA addressing current market
  requirements?
• Evolution and future vision
• Data on TETRA - case story

9
Operational challenges between Commercial
Dedicated networks

• Commercial networks by definition cater for the
  mass market consumers business users often
  many millions of users
• Mission critical organisations operating on a
  commercial network would compete with ordinary
  users for capacity
• A dedicated network allow organisations to
  control manage the network and resource
  allocation
• Secure communications are increasingly needed for
  mission critical operations

End-User Empowerment
10
User-Driven Standard for Integrated Mission
Critical Communications
SECURE

• Developed by ETSI
• EU Emergency Services involved
• Specific Choice vs. GSM orproprietary solutions
• Open digital standard
• Multiple Vendor Sourcing
• High Pace of Innovation
• Protection of Purchase Decision
• Intersystem roaming (ISI)
• TETRA feature set
• Wide Area Coverage
• Dispatch Operation
• Fast Call Set-Up
• Encryption Services
• Mobile Data
• Spectrum efficiency

Mobile Telephony (Full Duplex Voice)
Fast, Efficient Data Delivery
Cellular Telephony
PacketData
Workgroup Management
(Group, Individual, Priority Emergency, DMO)
TETRA Memorandum of Understanding (MoU),
represents 100 organizations from 30
countries Additionally, 200 companies are
involved in the development of applications
11
Agenda

• Market requirements
• Why a dedicated TETRA Network?
• How is TETRA addressing current market
  requirements?
• Evolution and future vision
• Data on TETRA - case story

12
Evolution Applications over TETRA
today
Not suitable
Suitable
Effective
13
TETRA IP Packet Data

• Partitions to allow multiple organisations to
  share the TETRA network

Hospital Journals
IP over TETRA TETRA over IP
Data
Voice
Fire Voice Communications
14
Multi-slot Packet Data

• TETRA single-slot packet data
• fulfilling much of todays data transmission
  requirements such as sending and receiving files
  and images
• Multi slot packet data (MSPD) up to four times
  faster
• MSPD will enable mission critical services to
  respond quicker and be more efficient
• MSPD is part of the TETRA open standard

15
Service Interaction - Pre-emption

• Multi slot packet data offers the capability of
  pre-emption
• Allocated as dynamic single slot channels
• Multi slot channels can be partially or
  completely resource pre-empted
• The channels are pre-empted expanded on the
  fly
• No service interruption
• Pre-emption of dynamic single slot channel

16
Pre-emption Example
MCCH
V
V
SS
Multi slot
17
Pre-emption Example
Voice channels are full and another radio is
requesting voice communication
MCCH
V
V
SS
Multi slot
V
18
Pre-emption Example
MCCH
V
V
SS
V
V
V
V
19
Agenda

• Market requirements
• Why a dedicated TETRA Network?
• How is TETRA addressing current market
  requirements?
• Evolution and future vision
• Data on TETRA - case story

20
Data evolution history in TETRA
Complexity
TETRA2
MSPD
MSPD With Pre-emption
QoS managed video
PDS
Slow scan video
SDS
File still images
E-mails
Database search
AVL
Telemetry - Messaging
Years/Technology
TETRA 1
MSPD
TETRA 2
Future
21
High Speed Data on TETRA
Although MSPD is a big step forward for
media-rich applications, it is not the end of the
evolution
Several future alternatives TETRA 2, WLAN,
Wideband, more? TETRA 3?
22
The future of communications

• Technology maturation will result in applications
  explosion
• A much more user centric content that is device
  and context sensitive will rule
• Privacy, safety and security for any mission
  critical market will preside

Moving information to the point of decision
Sir Edmund Burton, Head of PITO
23
Agenda

• Market requirements
• Why a dedicated TETRA Network?
• How is TETRA addressing current market
  requirements?
• Evolution and future vision
• Data on TETRA - case story

24
Data on TETRA

• Real
• In use
• Appreciated
• An example from the real life

25
Hereford and Worcester Ambulance

• Part of the AIRWAVE digital radio network
• Xxx vehicles
• Direct communication with 6 hospitals
• Population more than 720.000
• Geographical coverage close to 4 000 square Km

26
TETRA IP data which saves lives

• Automatic vehicle location
• enables control centre to appropriately direct
  and monitor fleet location
• Remote programming of in-vehicle satellite
  navigation systems
• helps crew to identify most efficient route
• In-vehicle data terminals
• alert crews to emergencies
• if the alert is not 'accepted' within 30 seconds
  the system automatically pages the health
  professional

27
TETRA IP data which saves lives

• Status messaging
• ability for crews to send status messages to
  control centre eg. notifying arrival at scene
• IP data solution to transmit live biometrics
  information from patients side to Consultant at
  hospital
• electrocardiogram, blood gas and blood pressure
  data to facilitate remote prescription of
  powerful drugs complete
• system automatically generates patient record
  forms enabling prompt attention when the
  ambulance arrives at hospital
• supports audit trail

28
Hereford and Worcester Ambulance Launch Mobile
Data and Automatic Vehicle Location Press
statement 9 February 2004
Saving lives The Ambulance Services Project
Manager, Dominic Robertson, said This system
will greatly enhance our ability to get to
patients as quickly as possible and, just as
importantly, to ensure that life-saving, clot
busting drugs can be administered to the patient
by the Paramedics as soon as possible.
29
What Users Says about TETRA Data

• Jeff Parris
• Vice President Airwave mmO2

30
Any questions?

• TETRA MOU - http//www.tetramou.com/

TETRA the Mission Critical Communications
Solution Now, Tomorrow and in the Future
