Atomic Structure and the Periodic Table

1
Chapter 3

• Atomic Structure and the Periodic Table

2
Sec 3.1 Internal Structure of Atom

• Subatomic particles (smaller than atom)
• Proton(P) Charge of 1 Mass of 1 (amu)
• Neutron(N) Charge of 0 Mass of 1
• Electron(e) Charge of -1 Mass of 0.0005

Similar Table on on page 48
3
Sec 3.1 Internal Structure of Atom

• Atomic mass units (amu)
• 1 amu 1.6605X10-25 grams
• Like charges repel, opposites attract
• Overall the charge of an atom is neutral (0)
• Thus Protons must be equal to Electrons

4
Sec 3.1 Internal Structure of Atom

• Nucleus tight cluster in the center of the atom
  containing the P and N
• Electrons move around the nucleus
• 99 of the mass of an atom in the nucleus

5
Sec 3.2 Atomic Number Mass Number

• Atomic number number of protons in an atom
• Mass number the sum of the protons and neutrons
  in an atom
• Mass P N
• Since 99 of the mass of an atom is in the
  nucleus this is appropriate
• Neutrons Mass number Atomic Number

6
Sec 3.2 Atomic Number Mass Number

• Arrangement on periodic table
• Atomic is a whole number generally above the
  symbol
• Mass is a decimal generally below the symbol
• Revised definition of element
• A pure substance in which all atoms present have
  the same atomic number

7
Sec 3.3 Isotopes Atomic Masses

• Isotopes the number of neutrons can change and
  still maintain the identity of the element.
  Examples Carbon-13 or Hydrogen-2 (deuterium)
• Isotopes of an element have a different mass
  number but the same atomic number
• Isotopes still remain neutrally charged

8
Sec 3.3 Isotopes Atomic Masses

• Isotopes are written with two numbers to the left
  of the symbol
• The atomic number is written as a subscript (XC)
• The mass number is written as a superscript (YC)
• Many elements exist in nature as a mixture of
  isotopes
• The atomic weight (atomic mass) for an element is
  a weighted average of the masses of the isotopes

9
Sec 3.3 Isotopes Atomic Masses

• Example Chlorine exists as Cl-35 75.53 and
  Cl-37 24.47
• Cl-35 has an atomic weight of 34.97 amu, Cl-37
  has an atomic weight of 36.97 amu
• On the periodic table Cl is listed as 35.46
• (75.53 34.97) (24.47 36.97) 35.46
• 100 100

10
Sec 3.3 Isotopes Atomic Masses

• Table 3.2 Page 54
• Isotopic data for
• the first 12 elements
• Some elements
• have no isotopes

11
Sec 3.4 The Periodic Table

• Dmitri Mendeleev put forward the concept of
  arranging the elements by atomic weight in the
  1860s
• Periods are the horizontal rows
• Groups or columns are vertical and have similar
  chemical properties
• Example column 1 are all metals (Li, Na, K, Rb
  and all form compounds with the same ratios LiCl,
  NaCl, KCl, RbCl)

12
Sec 3.4 The Periodic Table

• Main group elements numbered 1A to 8A (or 1-2
  and 13-18), the elements we are most concerned
  with
• Transition metals 3B to 8B (3-12) considered as
  one block
• Series fit inside the periodic table in the gaps

13
Sec 3.4 The Periodic Table
14
Sec 3.4 The Periodic Table

• Figure 3.4 Page 56. In this periodic table,
  elements 58 through 71 and 90 through 103 are
  shown in their proper positions.

15
Sec 3.4 The Periodic Table

• The periodic table allows us to see patterns in
  properties of the elements
• Columns often have names Column 1A are the
  alkali metals, column 7A are the halogens, column
  8A are the noble gases

16
Sec 3.4 The Periodic Table
17
Sec 3.5 Metals and Nonmetals

• Metals all but 22 elements are metals.
• Metals are solids (except Mercury) and conduct
  electricity, shiny, ductile, malleable, and can
  form alloys
• Nonmetals 18 nonmetal elements
• Do not conduct electricity, include the organic
  elements (C,N,O,H,P,S)
• Metalloids 4-5 elements
• Some properties of both, in-between metals and
  non metals. Semi-conductor

18
Sec 3.5 Metals and Nonmetals
Figure 3.5 Page 56

• Some familiar metals are aluminum, lead, tin, and
  zinc.

(b) Some familiar nonmetals are sulfur,
phosphorus, and bromine.
19
Sec 3.5 The Periodic Table
Metals, nonmetals, and metalloids
20
Sec 3.6 Electron Arrangement

• The energy of electrons in an atom is quantized,
  which means that an electron in an atom can have
  only certain allowed energies
• Ground state the electron configuration of
  lowest energy

21
Sec 3.6 Electron Arrangement

• Electrons arranged into energy levels or shells
• Shells are subdivided into subshells and orbitals
• The names for the subshells come from the words
  sharp, principal, diffuse, and fundamental

22
Sec 3.6 Electron Arrangement

• Each shell is able to hold more electrons
• This number expands up to a maximum of 32
• The formula is 2n2
• For shell 3, 2(3)2 18
• Figure 3.7 Page 59

23
Sec 3.6 Electron Arrangement

• Orbitals have definite shapes and orientations in
  space

24
Sec 3.7 Electron Configuration

• Electron configurations are governed by three
  rules
• Rule 1 orbitals fill in the order of increasing
  energy from lowest to highest

25
Sec 3.7
Figure 3.10 page 61
Figure 3.11 Page 62
26
Sec 3.7 Electron Configuration

• Rule 2 when there is a set of orbitals of equal
  energy, one orbital becomes half filled before
  any of them becomes completely filled
• Applies to p, d, and f orbitals
• P has 3 equal orbitals
• D has 5 equal orbitals
• F has 7 equal orbitals

27
Sec 3.7 Electron Configuration

• Rule 3 each orbital can hold up to two electrons
  with spins paired
• with four electrons, the 1s and 2s orbitals are
  filled and are written 1s2 2s2
• with an additional six electrons, the three 2p
  orbitals are filled and are written either 2px2
  2py2 2pz2, or they may be written 2p6

28
Sec 3.7 Electron Configuration

• Orbital box diagrams
• a box represents an orbital
• an arrow represents an electron
• a pair of arrows with heads in opposite
  directions represents a pair of electrons with
  paired spins
• Example Lithium atomic number 3

29
Sec 3.7 Electron Configuration

• Example carbon (atomic number 6)

30
Sec 3.7 Electron Configuration

• Example phosphorus (atomic number 15)

31
Sec 3.8 Electron Configuration and Periodic Law

• Chemical Properties repeat themselves among the
  elements because electron configurations repeat
  themselves
• We find a strong correlation between electron
  configurations and chemical properties

32
Sec 3.8 Electron Configuration and Periodic Law

• The arrangement of the periodic table is
  consistent with the 4 types of orbitals
• s(2), p(6), d(10), f(14)
• The last filled electron (called the
  distinguishing electron) largely determines the
  placement and hence the properties of the
  elements

33
Sec 3.8
Fig 3.12 Page 67
34
Sec 3.9 Classification of Elements

• Color Schemes allow us to classify the elements
  is different ways
• We have seen metals and nonmetals
• We have seen names for specific groups, and
  blocks of elements

35
Sec 3.9 Classification of Elements
Chemistry at a Glance Summary Page 69
36
Problems

• Assigned problems pages 70-74
• 3.4, 3.5, 3.9, 3.13, 3.14, 3.22, 3.25
• 3.31, 3.33, 3.37, 3.34, 3.53, 3.55, 3.59, 3.61
• 3.69, 3.70, 3.71, 3.72
• Practice Test Page 45-46
