Aspect Oriented Software Development

1
Aspect Oriented Software Development

• By Mostafa El Barbary

2
On July 20th 2008, our name has changed from
to
3
Objectives

• To explain the principle of separation of
  concerns in software development
• To introduce the fundamental ideas underlying
  aspect-oriented development
• To show how an aspect-oriented approach can be
  used at all stages of development

4
Agenda

• Introduction
• Problem Statement
• Aspect Solution
• Aspect Anatomy
• Aspect Terminology
• Aspect Weaving
• Evolution of Systems Development Methods
• Aspect Oriented Software Development

5
Introduction

• A concern is an area of interest or focus in a
  system. Concerns are the primary criteria for
  decomposing software into smaller, more
  manageable and comprehensible parts that have
  meaning to a software engineer.
• Object-oriented programming, describing concerns
  as objects
• Procedural programming, describing concerns as
  procedures

6
Introduction

• Separation of concerns (SOC) The principle of
  separation of concerns states that software
  should be organized so that each program element
  does one thing and one thing only.
• Each program element should therefore be
  understandable without reference to other
  elements.
• Object-oriented programming languages such as
  Java can separate concerns into objects.
• Service-oriented architecture can separate
  concerns into services.
• Procedural programming languages such as C and
  Pascal can separate concerns into procedures.

7
Agenda

• Introduction
• Problem Statement
• Aspect Solution
• Aspect Anatomy
• Aspect Terminology
• Aspect Weaving
• Evolution of Systems Development Methods
• Aspect Oriented Software Development

8
Problem Statement
void transfer(Account fromAccount, Account
toAccount, int amount) if
(fromAccount.getBalance() lt amount)
throw new InsufficientFundsException()
fromAccount.withdraw(amount)
toAccount.deposit(amount)
9
Problem Statement
void transfer(Account fromAccount, Account
toAccount, int amount) throws Exception
if (!getCurrentUser().canPerform(OP_TRANSFER))
throw new SecurityException()
Transaction tx database.newTransaction()
try if (fromAccount.getBalance() lt
amount) throw new InsufficientFundsExc
eption() fromAccount.withdraw(amoun
t) toAccount.deposit(amount)
tx.commit() systemLog.logOperation(
OP_TRANSFER, fromAccount, toAccount, amount)
catch(Exception e)
tx.rollback() throw e
Authentication Concern
Transaction Concern
Transaction Concern
Logging Concern
Transaction Concern
10
Problem Statement
Transfer Concern
Authentication Concern
Logging Concern
Transaction Concern
11
Problem Statement
Banking System
Transfer Concern
Cash Deposit Concern
Authentication Concern
Authentication Concern
Logging Concern
Logging Concern
Transaction Concern
Transaction Concern
Cash Withdrawal Concern
Authentication Concern
Logging Concern
Transaction Concern
12
Problem Statement

• Code is scattered when one concern (like logging)
  is spread over a number of modules (e.g.,
  Transfer method).
• Modules end up tangled with multiple concerns
  (e.g., Transfer, logging, and Authentication).

13
Agenda

• Introduction
• Problem Statement
• Aspect Solution
• Aspect Anatomy
• Aspect Terminology
• Aspect Weaving
• Evolution of Systems Development Methods
• Aspect Oriented Software Development

14
Aspect Solution

• AOSD attempts to solve this problem by allowing
  the programmer to express cross-cutting concerns
  (e.g., Transaction, logging, and Authentication)
  in stand-alone modules called aspects.
• Used in conjunction with other approaches -
  normally object-oriented software engineering.
• Aspects encapsulate functionality that cross-cuts
  and co-exists with other functionality.
• Aspects include a definition of where they should
  be included in a program as well as code
  implementing the cross-cutting concern.

15
Agenda

• Introduction
• Problem Statement
• Aspect Solution
• Aspect Anatomy
• Aspect Terminology
• Aspect Weaving
• Evolution of Systems Development Methods
• Aspect Oriented Software Development

16
Aspect Anatomy
aspect authentication //this is the
aspect before call (public void Transfer
(..)) // this is a pointcut // this is
the advice int tries 0 string
userPassword Password.Get ( tries ) while
(tries lt 3 userPassword ! thisUser.password (
) ) // allow 3 tries to get the password
right tries tries 1 userPassword
Password.Get ( tries ) if (userPassword
! thisUser.password ( )) then //if password
wrong, assume user has forgotten to
logout System.Logout (thisUser.uid) //
authentication
17
Agenda

• Introduction
• Problem Statement
• Aspect Solution
• Aspect Anatomy
• Aspect Terminology
• Aspect Weaving
• Evolution of Systems Development Methods
• Aspect Oriented Software Development

18
Aspect Terminology
19
Agenda

• Introduction
• Problem Statement
• Aspect Solution
• Aspect Anatomy
• Aspect Terminology
• Aspect Weaving
• Evolution of Systems Development Methods
• Aspect Oriented Software Development

20
Aspect Weaving

• Aspect weavers process source code and weave the
  aspects into the program at the specified
  pointcuts.

21
Aspect Weaving
22
Agenda

• Introduction
• Problem Statement
• Aspect Solution
• Aspect Anatomy
• Aspect Terminology
• Aspect Weaving
• Evolution of Systems Development Methods
• Aspect Oriented Software Development

23
Evolution of Systems Development Methods
24
Agenda

• Introduction
• Problem Statement
• Aspect Solution
• Aspect Anatomy
• Aspect Terminology
• Aspect Weaving
• Evolution of Systems Development Methods
• Aspect Oriented Software Development

25
Aspect Oriented Software Development

• A holistic approach to developing software
  systems with aspects.
• Better modularity for functional requirements,
  nonfunctional requirements, platform specifics,
  and so on and keeping them separate from each
  other.
• AOSD is not just AOP. It encompasses a whole
  range of techniques to help you achieve better
  modularity.
• object orientation
• component-based development
• design patterns
• object-oriented frameworks such as J2EE and .NET,
  and more

26
Aspect Oriented Software Development
... Requirements Engineering
... Architecture
... Design
Aspect-oriented...
... Programming
... Verification techniques
27
