Software Engineering 2 Spring 2003 Coding conventions and Standards

1
Software Engineering 2Spring 2003 Coding
conventions and Standards

• Eliezer Kaplansky
• and
• Guy Wiener

2
Role  Implementer

• The implementer role is responsible for
  developing and testing components.

• The appropriate skills and knowledge for the
  implementer include
• Knowledge of the system or the application
  domain.
• Familiarity with testing and test automation
  tools.
• Programming skills.

3
Why to invest in standard code?

• Large software projects are generally undertaken
  by correspondingly large teams of developers.
• Readable code is easier to maintain
• Reduce the mental programming efforts required
  from not so experienced developers.
• Enforce a consistent project-wide coding style.
• Enable to apply quality measures to the resultant
  software.
• Support the reuse of project resources
• Allow developers to be moved from one project to
  another without requiring re-learning.

4
Fundamental Principles

• Source code is read much more often than it is
  written or updated.
• Minimal Surprise over the code lifetime.
• Code should read like an English-language
  description of what is being done.
• Programs are written more for people than for
  computers
• A uniform style should not be perceived as some
  kind of punishment or as an obstacle to
  creativity and productivity.
• A design decision should be expressed at only one
  point in the source.
• Write ONCE and ONCE only.

5
Undocumented Code
int a( int i, char c ) if( c m ) if( i1000 ) return 0 else if( i return 500 else return
1200 else return 1300
6
Somewhat Documented Code
int tax( int anEarning, char aStatus ) if(
aStatus m ) if( anEarning return 0 // no tax for married, 1000 else if( anEarning return 500 // married, 1000-10000 else
return 1200 // married, 10000 // If not
married, apply single tax rate of 1300
regardless else return 1300
7
Documented Code
/ This method implements requirement 4.3
State tax effective 9/1/98 -12/31/99
_at_author Eric J. Braude _at_version 2.3.4
(8/6/98) _at_param an_Earning earnings 9/1/98
thru 12/31/99 _at_param a_Status m signifies
married (anything else designates
unmarried) / int tax( int an_Earning, char
a_Status )
8
EKs First rule of coding

• Code should read like an English-language so the
  reader understand of what is being done without
  any comments.
• Code units should be understood by reading the
  comments only without any code.

9
Implement EKs rule of coding

• One implementer write a class or method with
  comments only.
• Another implementer read the comments. Mark
  anything he fail to understand.
• First implementer add the code.
• Run a utility to remove the comments.
• Another implementer read the code only and mark
  anything he fail to understand.

10
EKs coding style

• Liberal use of comments.
• Descriptive variable and function names
• Logical, modular structure.
• Liberal use of white space.
• One statement per line.
• Consistent, and clear indentation size 3.
• Separating blocks of dissimilar code into
  "paragraphs.

11
EKs code fragment

• //ek
• // Notice how the declarations are separated
• // from the computations which are separated
• // from the output producing statement.
• int x_position
• float y_position
• x_position irand( 0 )
• y_ypostion 2.0 sin( stating_point_y/start
  ing_point_x )
• cout

12
EKs code alignment

• Use alignment wherever it enhances readability.
• if      (a low_Value)
  compute_Something()
• else if (a medium_Value) compute_Something_Els
  e()
• else if (a high_Value)
  compute_Something_Else_Yet()
• value (motor_potential        oil_Density)
  / constant1         (the_depth
    water_Density) / constant2
  (z_Coordinate_Value gas_Density)   /
  constant3
• Min_Position     compute_Distance (min,
  x, y, z)
• Average_Position compute_Distance (average, x,
  y, z)
• switch (value)   case PHASE_OIL   strcpy
  (string, "Oil")   break  case PHASE_WATER
  strcpy (string, "Water") break  case
  PHASE_GAS    strcpy (string, "Gas")
  break

13
Code Organization

• Place module specifications and implementations
  in separate files.
• Sys_Network.hpp // The extension ".hh" used to
  designate a "Sys_Network" module header.
• Sys_Network.cpp // The extension ".cc" used to
  designate a "Sys_Network" module implementation.
• Avoid defining more than one class per module
  specification.
• Always use include to gain access to a module's
  specification
• Break large modules into multiple translation
  units

14
Isolate platform dependencies

• Separate out platform-dependent code from
  platform-independent code. This will facilitate
  porting.
• Platform-dependent modules should have file
  names qualified by their platform name to
  highlight the platform dependence.
• Example
• Sys_Low_Level_Stuff.hpp // "Low
  Level Stuff" specification Sys_Low_Level_Stuff.Sun
  OS54.cpp // SunOS 5.4 implementation
  Sys_Low_Level_Stuff.HPUX.cpp // HP-UX
  implementation Sys_Low_Level_Stuff.AIX.cpp
  // AIX implementation
• Never use define or if ( ) or switch for
  platform dependency!

15
Protect against repeated file inclusions

• Repeated file inclusion and compilation should be
  prevented by using the following construct in
  each header file
• Example
• if !defined(module_name) // Use
  preprocessor symbols to
• define module_name // protect
  against repeated
•
  // inclusions...
•
  // Declarations go here
• include "module_name_in_lines.cpp" // Optional
  inline
•
  // inclusion goes here.
•
  // No more declarations after
  inclusion
•
  // of module's inline functions.
• endif // End of module_name.hpp

16
Code Style

• Use a maximum line length that would fit on the
  standard screen as now max 80 characters.
• Indent function parameters from the function name
  or scope name
• Example
• void foofunction_name(some_type
  first_parameter,
• / / some_other_type
  second_parameter,
•
  status_type and_subsequent)
• Function name is more less visible.

17
Code Comments

• Comments should not duplicate the language
  syntax.
• They should help the reader to grasp the
  background concepts, the dependencies, and
  especially complex data encoding or algorithms.
• They should highlight deviations from coding or
  design standards, the use of restricted features,
  and special "tricks."
• Use C style (// ) comments rather than C-style
  comments (/ ../).
• Comments should be placed above the
  statements-serving as an introduction to the
  statements.

18
Code Comments

• Comments should not duplicate the language
  syntax.
• Add comment at each unit header.
• Add end of line comments.
• Use an empty comment line to separate comment
  paragraphs
• Avoid redundancy
• Write self-documenting code and comments

19
Header Comments

• The purpose of each class
• The purpose of each function even if its purpose
  is obvious from its name
• The meaning of any return values e.g., the
  meaning of a Boolean return does a true value
  mean the function was successful
• Conditions under which exceptions are raised
• Preconditions and post conditions on parameters,
  if any
• Additional data accessed, especially if it is
  modified especially important for functions with
  side-effects
• Any limitations or additional information needed
  to properly use the class or function
• Any special or close invariants if exists.

20
Importance of Naming policy

• Coming up with good names for program entities
  (classes, functions, types, objects, literals,
  exceptions, namespaces) is very important and no
  easy matter.
• For medium-to-large applications, the problem is
  made even more challenging here name conflicts,
  and lack of synonyms to designate distinct but
  similar concepts add to the degree of difficulty.
• Using a naming convention can lessen the mental
  effort.

21
Naming policy

• Choose clear, legible, meaningful names.
• Use correct spelling in names.
• Use positive predicate clauses for Booleans.
• Choose a naming convention and apply it
  consistently.
• Never declare names beginning with one or more
  underscores ('_')
• Avoid using type names that differ only by letter
  case
• Avoid the use of abbreviations.
• Use of suffixes to denote language constructs
  when needed.

22
Naming policy

• Variables with a large scope should have long
  names, variables with a small scope can have
  short names.
• The prefix nun_ should be used for variables
  representing a number of objects.
• Use the suffix _id for unique object identity
  number.
• Use the words Get, Set, Find, Compute, Init,
  Show, display, ect as part of methods and
  functions.
• Iterator variables should not be called i, j, k
  etc. Use any_line, any_record etc.
• The prefix is should be used for boolean
  variables and methods.

23
Style of Naming policy

• Use namespaces to partition potential global
  names by subsystems or by libraries.
• Use capital letters at the beginning of each
  name.
• Use nouns or noun phrases for class names
• class bank_account ...
• class savings_account public bank_account
  ...
• class checking_account public bank_account
  ...
• Use verbs for procedure-type function names
• void find_first_client(name the_client_name,
  bool is_client_found)
• Augment names with grammatical elements to
  emphasize meaning
• To indicate uniqueness, or to show that this
  entity is the main focus of the action, prefix
  the object or parameter name with "the" or
  "this". To indicate a secondary, temporary,
  auxiliary object, prefix it with "a" or
  "current.

24
Functions policy

• Always declare an explicit function return type.
• Always provide formal parameter names in function
  declarations.
• Use the same names in both function declarations
  and definitions and if possible for invocation.
• Strive for functions with a single point of
  return
• Avoid creating function with global side-effects.
• Declare function parameters in order of
  decreasing importance.
• Avoid declaring functions with a variable number
  of parameters.
• Maximize the use of const in function
  declarations
• Avoid passing objects by value.

25
Functions policy 2

• Never return a reference to a local object.
• Use inline functions in preference to define for
  macro expansion.
• Use default parameters rather than function
  overloading.
• Use function overloading for common semantics.
• Have operator return a reference to this
• String x, y, z
• x y z "A string"
• Do not write overly long functions, not over 60
  lines of code.
• Minimize the distance in lines between the
  declaration of a local object and the first
  instance of its use.
• Functions (methods returning something) should be
  named after what they return and procedures (void
  methods) after what they do.

26
Types

• Define project-wide global system types.
• Avoid the use of fundamental types.
• Use default parameters rather than function
  overloading.
• Use typedef to create synonyms to strengthen
  local meaning
• Use typedef to create synonyms for existing
  names, to give more meaningful local names and
  improve legibility (there is no runtime penalty
  for doing so).

27
Constants and Objects

• Avoid using the preprocessor define directive
  for defining constants.
• Declare objects close to their point of first
  use.
• Always initialize const objects at declaration.
• Try to initialize objects at definition

28
Expressions

• Use redundant parentheses to make compound
  expressions clearer.
• Avoid nesting expressions too deeply.
• Do not assume any particular expression
  evaluation order.
• Use the new bool type for Boolean expressions.
• Do not compare directly against the Boolean value
  true.
• Always assign a null pointer value to a deleted
  object pointer.

29
Statements

• Use an if-statement when branching on Boolean
  expressions.
• Use a switch-statement when branching on
  discrete values.
• Always provide a default branch for
  switch-statements for catching errors.
• Use a for-statement in preference to a while
  statement when iteration and loop termination is
  based upon the loop counter.
• Use a do-while-statement when a post-iteration
  test is required in a loop
• use the goto-statement wisely.

30
Statements 2

• Floating point constants should always be written
  with a digit before the decimal point.
• double total 0.5   // NOT double total .5
• 0" should be used instead of "NULL".
• NULL is part of the standard C library, but is
  made obsolete in C.
• Single statement if-else, for or while statements
  should be written with brackets.
• if (condition)   statement
• EK use
• define then
• define end_if
• if (condition) then
•   statement
• end_if

31
White Space

• Makes the individual components of the statements
  stand out. Enhances readability with white
  spaces.
• use
• a (b c) d           // NOT
  a(bc)dwhile (true)                //
  NOT   while(true) ...for (i 0 i   // NOT   for (i0i
• if (num_of_line max_num_of_line) then
• // NOT if (NumOfLine
  maxnumofline)
• Do_Something (a, b, c, d)
• // NOT
  do_Something (a,b,c,d)

32
White Space in declaration

• Variables in declarations should be left aligned
• Example
• Ascii_File  Readable_Data_fileint
  nun_of_Pointsfloat      x_coor,
  y_coor

33
Loops

• Only loop control statements must be included in
  the for() construction.
• Num_of_lines 0
• for (Any_line 0 Any_line Any_line)           Num_of_lines
  Array_of_linesAny_line
• NOT
• for (Any_line 0, sum 0 Any_line Any_line)           sum
  Array_of_linesAny_line
• Loop variables should be initialized immediately
  before the loop.
• Is_Done false       // NOT
  bool is_Done falsewhile (! is_Done)
  //
    //        while
  (!is_Done)
  //



34
Loops

• Always check while loop with external dependency
  end condition for infinite loop with a counter.
• Example
• Num_of_record 0
• while ( ! At_end_of_file)
• input_file.read_next_record()
• if (Num_of_record 1000000)
• report_error(.)
• break
• process_next_record()

35
Conditionals

• Complex conditional expressions must be avoided.
  Introduce temporary Boolean variables instead.
• Example
• // Bad!
• if ((num_elements
  max_Elements)    num_elements last_Element)

• Should be replaced by
• // Better!
• Is_Finished   (num_elements (num_elements max_Elements)
• is_Repeated_Entry num_elements last_Element
• if (is_Finished is_Repeated_Entry)

36
Conditionals

• Executable statements in conditionals must be
  avoided.
• Example
• // Bad!if (! (file_Handle open (file_Name,
  "w")))
• Should be replaced by
• // Better!File_Handle open (file_Name,
  "w")if (!file_Handle)

37
Memory Management

• Avoid mixing C and C memory operations. The C
  library malloc, calloc and realloc functions
  should not be used for allocating object space
  Use the C operator new.
• Always use delete when deleting array objects
  created by new Using delete on array objects
  without the empty brackets ("") notation will
  result in only the first array element being
  deleted, and thus memory leakage.

38
Memory Management

• Avoid mixing C and C memory operations. The C
  library malloc, calloc and realloc functions
  should not be used for allocating object space
  Use the C operator new.
• Always use delete when deleting array objects
  created by new Using delete on array objects
  without the empty brackets ("") notation will
  result in only the first array element being
  deleted, and thus memory leakage.

39
Error Handling and Exceptions

• Use assertions liberally during development to
  detect errors.
• Use exceptions only for truly exceptional
  conditions Exceptions should also not be used to
  implement control structures this would be
  another form of "goto" statement.
• Anticipated events should be handled in the
  normal flow of control of the code use a
  function return value or "out" parameter status
  code as required.

40
Logic and Runtime Error Handling

• Logic errors (domain error, invalid argument
  error, length error and out-of-range error)
  should be used to indicate application domain
  errors, invalid arguments passed to function
  calls, construction of objects beyond their
  permitted sizes, and argument values not within
  permitted ranges.
• Runtime errors (range error and overflow error)
  should be used to indicate arithmetic and
  configuration errors, corrupted data, or resource
  exhaustion errors only detectable at runtime.
• Minimize the number of exceptions used by a given
  abstraction. In large systems, having to handle a
  large number of exceptions at each level makes
  the code difficult to read and to maintain.
  Exception processing may dwarf the normal
  processing.
• Declare all exceptions thrown in the function
  header.

41
Development time Error Handling

• Declare all exceptions thrown.
• During development, report all exceptions by the
  appropriate logging mechanism as early as
  possible, including at the "throw-point".
• Create a external switch that toggle on the
  logging mechanism.
• Create an automatic bug report that include the
  logging file.
• Define exception handlers in most-derived, to
  most-base class order.
• Avoid catch-all exception handlers
• Make sure function status codes have an
  appropriate value Start as failure by default.

42
Development time Error Handling

• Declare all exceptions thrown.
• During development, report all exceptions by the
  appropriate logging mechanism as early as
  possible, including at the "throw-point".
• Create a external switch that toggle on the
  logging mechanism.
• Create an automatic bug report that include the
  logging file.
• Define exception handlers in most-derived, to
  most-base class order.
• Avoid catch-all exception handlers
• Make sure function status codes have an
  appropriate value Start as failure by default.

43
IO run time Error Handling

• Check all inputs for proper range.
• Report the exact value and record with the error.
• Specify in the error log file the exact error
  text from the operating system.
• Assign each error a unique error number.
• Always try continue the work with default values
  or ask the user to re enter new inputs.
• Create automatic backup procedures.
• Save open files automatically every few minutes
  and after number of operations.

44
Portability

• Never use hard coded file pathnames.
• Do not assume the representation of a type.
• Do not assume the alignment of a type.
• Do not depend on a particular underflow or
  overflow behavior.
• Do not convert from a "shorter" type to a
  "longer" type.

45
Reuse

• Use standard library components whenever
  possible.
• Use templates to reuse data independent behavior.
• Break any common functionality into small library
  functions.
• Write classes and methods as general as possible.
• Break your libraries to small packages.
• Invest in external documentation and effective
  search engine to your libraries.
• Invest more in the documentation and search
  engine .

46
Compilation Issues

• Do not use any non standard language features!
• Minimize compilation dependencies
• Do not include in a module specification other
  header files that are required. That means
  avoiding use of include files that include other
  include files.
• Use a low level method as possible.
• Avoid using if define in your code. Use
  functions that calls low level OS functions.

47
The First and Last Guideline

• Use common sense

Tricky code should not be commented but
rewritten!
