The FRB and XML:

1
The FRB and XML

• National data and International standards
• San Cannon
• Federal Reserve Board
• IASSIST 2005

2
Background

• The Fed is a statistical agency as well as a
  central bank and regulatory agency.
• Lots of data and information are available on the
  public website.
• Statistical data is varied Monthly industrial
  production indexes (non-financial), daily
  interest and exchange rates (financial) and
  quarterly financial flows for various sectors of
  the economy, surveys of small businesses and
  consumers, etc.

3
The different roles are often competing
interests...

• Sometimes it seems that the statistical agency
  role is secondary.
• Data are not always easy to find.
• Downloads are not customizable.
• Example Trying to extract one industrial
  production series Requires two text files,
  cutting and pasting, reformatting.
• All or nothing approach.
• Complete yes. User Friendly no.

4
Other agencies making great strides

• Bureau of Economic Analysis has wonderful tabling
  capabilities www.bea.gov
• Bureau of Labor Statistics has query screens,
  series select screens and frequently requested
  statistics www.bls.gov

5
Taking an extra step

• We wanted to build something forward looking XML
  was identified early on.
• Most flexible and seems to be the trend for
  future.
• Financial data already heading that way FinXML,
  FpML (financial product ML), MDDL (Market data
  definition language), XBRL (eXtensible Business
  reporting language)

6
How do we do it?

• Build our own XML definitions
• Pro would fit our data perfectly
• Con wed be the only ones
• Use financial definitions
• Pro lots of others use them
• Con we have nonfinancial data
• Try SDMX (Statistical Data and Metadata
  eXchange)
• Pro designed for time series data
• Con new kid on the block

7
But nothing goes smoothly at first

• SDMX is based on key families and codelists
  where every concept can be represented by a code
  with a corresponding definition in a list

8
We think about data differently

• The Fed uses mnemonic series names where each
  character in our series name has meaning and
  names are hierarchical.

9
Fitting a square peg in a round hole.

• Data represented by a concrete number of concepts
  are much easier to represent with key family
  dimensions and attributes
• Q.SCBA.GB.92 ? Freq.Topic.Country.BIS code
• M.HBBA.US.01 ? Freq.Topic.Country.BIS code
• Hierarchical relationships and varying number of
  concepts makes life more difficult a single key
  family isnt possible
• JQI_I02YMF_N.M ? Topic_Industry_SA.Freq
• RIFSPPNA2P2D30_N.B ? Topic?_SA.Freq

10
SDMX only provides a framework

• We still needed to build the actual schemas to
  describe our data within the SDMX metaschema
  framework.
• Each data release uses its own schema or set of
  schemas. Each schema is based on a key family
  used to describe the data.
• Currently, our schemas are tailored to meet our
  data needs.

11
Storage adds further complications

• We need to store data and metadata in a database
  to be retrieved with queries.
• Native XML databases in their infancy.
• We couldnt find many people storing XML tagged
  data in relational databases

12
So what did we end up with?

• Data model is hybrid tree structure flattened
  to fit codelist setup.
• We store the XML as carefully sliced text in a
  relational database and we can build an index
  structure that allows us to respond to ad-hoc
  queries very efficiently, even for large volumes
  of data.

13
This kind of structure
14
Looks like this in SDMX-ML

• Commercial
  Paper Outstandings
• codelist"CL_TIME"
• concept"FREQ" codelist"CL_FREQ"/
• codelist"CL_CP_SA"/
• codelist"CL_CP_IND_TYPE"/
• codelist"CL_CP_ORIG"/
• codelist"CL_CP_OWN"/
• codelist"CL_CP_NSASC"/
• codelist"CL_UNIT" attachmentLevel"Group"
  assignmentStatus"Mandatory"/
• codelist"CL_UNIT_MULT" attachmentLevel"Group"
  assignmentStatus"Mandatory"/
• codelist"CL_OBS_STATUS" attachmentLevel"Observat
  ion" assignmentStatus"Mandatory"/
• attachmentLevel"Series" assignmentStatus"Mandat
  ory" /
• attachmentLevel"Series" assignmentStatus"Condit
  ional" /

15
Which gets stored like this
16
And the end result?

• The Data Download Project (DDP) is the largest,
  most complex application on the Boards public
  website.
• Its also the first production application to
  deliver customized data extracts in SDMX format.
• And now.
• Version 1.0!

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Next steps

• Performance testing and verify server load
  capabilities.
• Polish interface, do usability testing and verify
  compliance with Section 508 regulations.
• Long run work with other central banks on
  common schema framework.
• Release on the unsuspecting public! Target
  Third quarter 2005

37
The last slide

• Questions? Comments?
• Thank you for your attention!
• San Cannon
• scannon_at_frb.gov
