Title: Feedback 101


1
Feedback 101
  • Stuart Henderson

August 30, 2004
2
Outline
  • Introduction to Feedback
  • Block diagram
  • Uses of feedback systems (dampers, instabilities,
    longitudinal, transverse
  • System requirements
  • Resources
  • Simplest feedback system scheme
  • Ideal conditions
  • Eigenvalue problem and solution
  • Loop delay, delayed kick
  • Closed-orbit problem
  • Filtering schemes (analog/digital)
  • Two turn filtering scheme
  • Type of digital filters (FIR, IIR)
  • Kickers
  • Concepts
  • Dp and dtheta calculation
  • Figures of merit
  • Plots of freq response, etc.
  • Complete System Response
  • Estimates for damping e-p

3
Resources
  • Several good overviews and papers on feedback
    systems and kickers
  • Pickups and Kickers
  • Goldberg and Lambertson, AIP Conf. Proc. 249,
    (1992) p.537
  • Feedback Systems
  • F. Pedersen, AIP Conf. Proc. 214 (1990) 246, or
    CERN PS/90-49 (AR)
  • D. Boussard, Proc. 5th Adv. Acc. Phys. Course,
    CERN 95-06, vol. 1 (1995) p.391
  • J. Rogers, in Handbook of Accelerator Physics and
    Technology, eds. Chao and Tigner, p. 494.

4
Why Do We Need Feedback Systems?
  • High intensity circular accelerators eventually
    encounter collective beam instabilities that
    limit their performance
  • Once natural damping mechanisms (radiation
    damping for ee- machines, or Landau damping for
    hadron machines) are insufficient to maintain
    beam stability, the beam intensity can no longer
    be increased
  • There are two potential solutions
  • Reduce the offending impedance in the ring
  • Provide active damping with a Feedback System
  • A Feedback System uses a beam position monitor to
    generate an error signal that drives a kicker to
    minimize the error signal
  • If the damping rate provided by the feedback
    system is larger than the growth rate of the
    instability, then the beam is stable.
  • The beam intensity can be increased until the
    growth rate reaches the feedback damping rate

5
Types of Feedback Systems
  • Feedback Systems are used to damp instabilities
  • Typical applications are bunch-by-bunch feedback
    in ee- colliders, hadron colliders to damp
    multi-bunch instabilities
  • Dampers are used to damp injection transients,
    and are functionally identical to feedback
    systems
  • These are common in circular hadron machines
    (Tevatron, Main Injector, RHIC, AGS, )
  • Feedback systems and Dampers are used in all
    three planes
  • Transverse feedback systems use BPMs and
    transverse deflectors
  • Longitudinal feedback systems use summed BPM
    signals to detect beam phase, and correct with RF
    cavities, symmetrically powered striplines,

6
Elements of a Feedback System
  • Basic elements
  • Pickup
  • Signal Processing
  • RF Power Amplifier
  • Kicker
  • Pickup is BPM for transverse, phase detector for
    longitudinal
  • Processing scheme can be analog or digital,
    depending on needs
  • Transverse Kicker
  • Low-frequency ferrite-yoke magnet
  • High-frequency stripline kicker
  • Longitudinal Kicker can be RF cavity or
    symmetrically powered striplines

Signal Processing
RF amp
Kicker
Pickup
Beam
7
Specifying a Feedback System
  • Feedback systems are characterized by
  • Bandwidth (range of relevant mode frequencies)
  • Gain (factor relating a measured error signal to
    output corrective deflection)
  • Damping rate
  • In order to specify a feedback system for damping
    an instability, we must know
  • Which plane is unstable
  • Mode frequencies
  • Growth rates
  • RF power amplifier is chosen based on required
    bandwidth and damping rate. Typical systems use
    amplifiers with 10-100 MHz bandwidth, and
    100-1000W output power.

8
Simple picture of feedback
X?
  • Take simple (but not very realistic) situation
  • ?-functions at pickup and kicker are equal
  • 90? phase advance between kicker pickup
  • Integer tune

Position measurement (coordinates x, x)
X
Kick (coordinates y, y)
  • System produces a kick proportional to the
    measured displacement
  • At the kicker
  • At the BPM after 1 turn

9
Simple picture of feedback, continued
  • So x-amplitude after 1 turn has been reduced by
  • Giving a rate of change in amplitude
  • Giving a damping rate
  • But, we made two gross simplifications
  • We dont really operate with integer tune.
    Averaging over all arrival phases gives a factor
    of two reduction
  • In real life, we may not be able to place the BPM
    and kicker 90 degrees apart in phase, and the
    locations will not have equal beta functions. We
    need a realistic calculation.

10
Realistic damping rate calculation for simple
processing
  • Follow Koscielniak and Tran
  • Coordinates at pickup are (xn,x?n) on turn n
  • Coordinates at kicker are (yn,y?n) on turn n
  • Transport between pickup and kicker has 2x2
    matrix M1 and phase ?1
  • Transport between kicker and pickup has 2x2
    matrix M2 and phase ?2
  • Give a kick on turn n proportional to the
    position measured on the same turn
  • Where G is the feedback gain

M2, ?2
Kicker (y,y?)
Pickup (x,x?)
M1, ?1
11
Simple processing, contd
  • The coordinates one turn later follow from

12
More realistic damping rate calculation, contd
  • After n turns the coordinates are
  • This is an eigenvalue problem with solution
  • The eigenvalues can be obtained from

One-turn matrix
13
General solution for 2x2 real matrix
  • Since we have a 2x2 real matrix, we expect two
    eigenvalues which are complex conjugate pairs.
    Writing
  • Where we can identify ? as the damping rate (per
    turn), and ? as the tune, which in general will
    be modified by the feedback system
  • Solution

Giving,
14
Damping rate and tune shift for simple processing
  • We have
  • With ?p, ?p the twiss parameters at the pickup,
    ?k, ?k at the kicker, ? the tune, ?1 the phase
    advance between pickup and kicker, ?2 the phase
    advance from kicker around the ring to pickup
  • Finally,

15
Damping rate and tuneshift for small damping
  • For weak damping,
  • And
  • Optimal damping rate, and no tuneshift results
    for ?190 degrees

turns-1
sec-1
radians
16
Damping vs. Gain for ?190 degrees
17
Tuneshift vs. Gain for ?1125 degrees
18
Finite Loop Delay
  • Up to this point we have ignored the fact that it
    takes time to decide on the kick strength in
    the processing electronics
  • It is not necessary to kick on the same turn
  • We can kick m turns later
  • In this way we can wait around for the optimum
    turn to provide the optimum phase

19
Closed-Orbit Problem the 2-turn filter
  • Our simplification ignores another problem
  • A closed orbit error in the BPM will cause the
    feedback system to try to correct this closed
    orbit error, using up the dynamic range of the
    system
  • Solution
  • Analog a self-balanced front-end
  • Digital Filter out the closed-orbit by using an
    error signal that is the difference between
    successive turns
  • 2-turn filter constructs an error signal

20
2-turn filter, contd
  • With
  • The transfer function of the filter is
  • This gives a notch filter at all the rotation
    harmonics, which are the harmonics that result
    from a closed orbit error

21
2-turn Filter Frequency Response
22
2-turn Filter Phase
23
Kickers for Transverse Feedback Systems
  • For low frequencies (lt 10 MHz), it is possible to
    use ferrite-yoke magnets, but the inductance
    limits their bandwidth
  • Broadband transverse kickers usually employ
    stripline electrodes
  • Stripline electrode and chamber wall form
    transmission line with characteristic impedance ZL

24
Stripline Kicker Layout
VL
ZL
ZL
Beam
d
l
ZL
ZL
-VL
25
Stripline Kicker Schematic Model
Zc
VK
Beam Out
Beam In
p?
p? ?p?
26
Stripline Kicker Analysis
  • Deflection from infinite parallel plates over
    length l, separated by distance d, at opposite DC
    voltages, /- V is
  • We need to account for the finite size of the
    plates (width w, separation d). A geometry
    factor g ? 1 is introduced
  • Because we want to damp instabilities that have a
    range of frequencies, we will apply a
    time-varying potential to the plates V(?).
  • We need to calculate the deflection as a function
    of frequency and beam velocity.

V
-V
27
Stripline g?
28
Deflection by Stripline Kicker
  • Stripline kicker terminated in a matched load
    produces plane wave propagating in z direction
    between the plates.
  • For beam traveling in z direction
  • For beam traveling in z direction
  • For relativistic beams, we need the beam
    traveling opposite the wave propagation!

29
Deflection by Stripline Kicker
  • Where
  • This can be written in phase/amplitude form as

30
Powering the Stripline Kicker
  • For transverse deflection, one could
  • Independently power each stripline with its own
    source
  • Power the pair of striplines from a single RF
    power source by splitting (e.g. with a 180 degree
    hybrid to drive electrodes differentially)
  • Using a matched splitting arrangement, the
    delivered power is
  • Which equals the power dissipated on the two
    stripline terminations
  • So that the input voltage is

31
Figures of Merit for Stripline Kickers
  • One common figure of merit seen in the literature
    is the Kicker Sensitivity.
  • From which we get
  • Which can be written in the form
  • Important points
  • Deflection has a phase shift relative to the
    voltage pulse
  • sin?/? shows the typical transit-time factor
    response

32
Transverse Shunt Impedance
  • In analogy with RF cavities, one can define an
    effective shunt impedance that relates the
    transverse voltage to the kicker power
  • The frequency response has notches at
  • For low frequencies, (? ?? c/l)

33
  • So after all this, whats the kick?
  • In the low frequency limit,

34
Transverse Shunt Impedance (wd, ?0.85, 50?,
d15cm)
35
Transverse Shunt Impedance (wd, ?0.85, 50?,
d15cm)
36
Multiple Kickers
  • For N kickers, each driven with power P,
  • Where PTNP is the total installed power
  • To achieve the same deflection (damping rate)
    with N kickers requires only
  • Example One kicker with P11000W gives same kick
    as two kickers each driven at 250 W

37
Putting it all together
  • The RF power amplifier puts out full strength for
    a certain maximum error signal
  • The system produces the maximum deflection ??max
    for a maximum amplitude xmax
  • For optimal BPM/Kicker phase, the optimal damping
    rate is
  • For a Damper systems, xmax is large enough to
    accommodate the injection transient
  • For a Feedback system, xmax is many times the
    noise floor

38
Parameters for an e-p feedback system
  • Bandwidth
  • Treat longitudinal slices of the beam as
    independent bunches
  • Ensure sufficient bandwidth to cover coherent
    spectrum
  • Choose 200 MHz
  • Damping time
  • To completely damp instability, we need 200
    turns
  • To influence instability, and realize some
    increase in threshold, perhaps 400 turns is
    sufficient
  • Input parameters
  • ?y 7 meters
  • Xmax 1mm
  • Stripline length 0.5 m, separation d 0.10,
    w/d 1.0
  • 800 MeV

39
Damping Time vs. Power at 150 MHz
40
Damping Time vs. Frequency at Fixed Power
Write a Comment
User Comments (0)
About PowerShow.com
