Audiobased Music Similarity Analysis

1
Audio-based Music Similarity Analysis

• MUMT 611
• Beinan Li
• Music Tech _at_ McGill
• 2005-3-17

2
Content

• Overview (based on Foote and Logans work)
• Application background
• Summary on common approach
• Foote 1997 Content-based Retrieval of Music and
  Audio
• Foote 2002 Audio Retrieval by Rhythmic
  Similarity
• Logan 2001 A Music Similarity Function Based on
  Signal Analysis

3
Overview

• Application background
• Query by similarity
• Automatic play-list generation
• Automatic D.J.
• Automatic summarizing and categorization

4
Overview

• Common approach of audio similarity analysis
• Find a hidden metaphor to relate acoustic
  similarity with statistical audio features, based
  on defined application domains.
• Distance between features from different audio
  samples is taken as the measure of similarity.
• Supervised vs. Unsupervised approach.

5
Overview

• Common steps
• Audio Parameterization
• Windowing time-domain signal and extract
  low-level features, usually frequency-domain or
  cepstral features.
• Quantization (lower the dimensionality)
• Transform low-level features into some
  higher-level statistical features according to
  the metaphor.
• Supervised discriminative quantization, training
  involved.
• Unsupervised statistical clustering
• Distance calculation
• Calculate distance between high-level features
  from different audio samples, based on certain
  type of measures.

6
Foote Content-based Retrieval of Music and Audio

• Application domain
• Audio search engine for audio documents by
  acoustic similarity
• Metaphor
• Sample-specific template Histogram of feature
  groups
• Maximized Mutual Information (informatics)
• Supervised approach
• Multiple distance measures are tested.

7
Foote Content-based Retrieval of Music and Audio

• Picture taken from Foote 1997

8
Foote Content-based Retrieval of Music and Audio

• Audio parameterization
• Hamming window, overlapping steps.
• 13-D feature
• 12 MFCC coefficients and an energy term
• Emphasizes on mid-frequency bands.

9
Foote Content-based Retrieval of Music and Audio

• Quantization
• Tree-based vector quantization.
• Leaves - Histogram bins (features fall in)
• Off-line training of binary-tree construction
• Supervised training data labeled by known
  classes
• Binary branching threshold
• determined via MMI between features and
  class-labels
• 1-D feature space partition (find the dimension
  by MMI)
• Stopping rule thresholds for probability-weighted
  MMI
• Practical tree construction
• Sample-specific template signature (Logan 2001)

10
Foote Content-based Retrieval of Music and Audio

• Distance calculation
• Euclidean distance
• Straightforward
• Sensitive to magnitude
• Successful in Speaker ID domain.
• Cosine distance
• Derived from scalar product
• Insensitive to magnitude
• No evidence on the relation of measures to
  perception.

11
Foote Content-based Retrieval of Music and Audio

• Experiments
• Performance measurement
• No subjective test
• File-naming hints (oboe) - TREC-like Average
  Precision.
• Percentage of top-ranked items that are actually
  relevant
• On simple sounds (laughter, musical notes,
  animal, etc.)
• On music clips

12
Foote Content-based Retrieval of Music and Audio

• Experiments on simple sounds (no predominance)
• Q-tree vs. Muscle Fish (unsupervised)
• Pitch vs. timbre similarity - subjective
  importance?

(Diagram from Foote 1997)
13
Foote Content-based Retrieval of Music and Audio

• Experiments on music clips
• Each artist as a class
• Cosine distance performs best

(Diagram from Foote 1997)
14
Foote Content-based Retrieval of Music and Audio

• Conclusion and future
• Histogram bins can be further weighted to
  maximize the entropy.
• May be used to measure subjective perceptual
  qualities.
• Audio content change (via templates within a
  stream)
• Tree can show importance of feature dimensions
  (1-D)
• Compressed audio may help skip the step of
  parameterization.
• Demo link http//www.fxpal.com/people/foote/music
  r/doc0.html

15
Foote Audio Retrieval by Rhythmic Similarity

• Previous tempo/rhythm tracking approach
• Restricted to narrow application domains
• Dannenberg 1987 MIDI
• Schierer 1998 strong percussive elements
• Goto 1994 4/4, bass drum on downbeat
• Muscle Fish drum-only tracks
• Cliff 2000 dance music
• Not robust.

16
Foote Audio Retrieval by Rhythmic Similarity

• Application domain
• Automatic D.J., play-list via rhythmic similarity
• Metaphor
• Beat Spectrum autocorrelation
• Within a certain time range (lag),
  autocorrelation of spectral-related audio
  features hints rhythm.
• Unsupervised approach
• Multiple distance measures are tested.

17
Foote Audio Retrieval by Rhythmic Similarity

• Audio Parameterization
• Overlapped windowing, FFT
• Logarithmic magnitude response (power spectrum)
• Others (similar sounds - similar parameters)
• Linear prediction
• MFCC
• Psychoacoustic

18
Foote Audio Retrieval by Rhythmic Similarity

• Quantization
• Distance between ST-powers within the stream
• Similarity Matrix (visualization of audio
  structure)
• End-to-end repeated time-line
• Main diagonal (self-correlate)
• Diagonal stripes (D(i,j) S(k, kl))
• Visible periodicity (repeated stripes)

(Picture from Foote 2002)
19
Foote Audio Retrieval by Rhythmic Similarity

• Similarity Matrix
• Brightness - distance
• Beat Spectrum (in a range)
• Autocorrelation
• Peak of BS - repetition

(Picture from Foote 2002)
20
Foote Audio Retrieval by Rhythmic Similarity

• Distance calculation
• Euclidean distance
• Cosine distance
• Fourier Beat Spectral Coefficients
• Further lower the dimensionality

21
Foote Audio Retrieval by Rhythmic Similarity

• Experiments
• Euclidean distance
• Different-tempo versions of identical music
• Find itself

(Diagram from Foote 2002)
22
Foote Audio Retrieval by Rhythmic Similarity

• Experiments
• Three 10-sec sections from each of 4 songs
• Relevant with sections of same song only
• Lag size carefully chosen
• Within a certain time range (lag),
  autocorrelation of spectral-related audio
  features hints rhythm.
• Rule out overly small/large lag candidates
• Cosine and FBSC win with precision of 96.7

23
Foote Audio Retrieval by Rhythmic Similarity

• Conclusion and future
• Beat Spectrum is actually a vector space, so
  common classification / machine learning can be
  used.
• Auto-play-list build Similarity Matrix in terms
  of ending of Candidate Song N and beginning of
  Candidate Song N1.
• Knowledge constraints.

24
Logan A Music Similarity Function Based on
Signal Analysis

• Application domain
• Automatic play-list via similarity
• Metaphor
• Song-signature instrument type,
  singing-presence?
• Spectral features
• Transformation cost between signatures
• Unsupervised approach
• Multiple distance measures are tested.

25
Logan A Music Similarity Function Based on
Signal Analysis

• Audio Parameterization
• Windowing, MFCC
• Many other candidates so long as a distance
  measure can be found.

26
Logan A Music Similarity Function Based on
Signal Analysis

• Quantization
• signature based on Foote 1997 (template)
• Supervision may overly rely on training data and
  thus emphasize on several specific histogram
  bins.
• K-means clustering
• Assume the number of clusters be fixed for a song
• Signature vector of common statistic parameters
• (means, covariance, weight)

27
Logan A Music Similarity Function Based on
Signal Analysis

• Distance measure
• Earth Movers Distance
• Weighted cost of moving probability mass from one
  cluster to another. EMD is the normalized cost.
• Distance is based on Kullback-Leibler distance.

28
Logan A Music Similarity Function Based on
Signal Analysis

• Experiments
• Test over 8,000 style-variant songs in a
  database.
• Multiple number of MFCC coefficients are tested.
• Main metrics
• Average distance between all songs
• Average distance between songs on the same album
• Average distance between in the same genre
• Average distance between by the same artist
• Objective and subjective relevance tested.
• Robustness to corruption tested.
• Remove a section of a song on purpose

29
Logan A Music Similarity Function Based on
Signal Analysis

• Experiments (Objective)

(Diagrams from Logan 2001)
30
Logan A Music Similarity Function Based on
Signal Analysis
(Diagrams from Logan 2001)

• Experiments
• Subjective
• Corruption

31
Other approaches

• Li Guo, 200x Content-Based Audio
  Classification and Retrieval Using SVM Learning

32
Bibliography

• Summary
• HTML Bibliography
