PowerBuilder 9'0 New Features

1
(No Transcript)
2
PowerBuilder 9.0 New Features

• RAD Java Server PagesTM (JSPTM) Authoring
• PowerBuilder Native Interface (PBNI)
• EJB Client Support

3
RAD JSP

• Creating JSP Web Applications with PowerBuilder

4
Introduction to JSP Technology

• JSP is
• A technology for delivering dynamic content
• Based upon Java Servlet technology
• JavaServer Pages
• Contain standard HTML
• Can contain Custom tags
• Can contain JSP elements
• JSP Actions
• JSP Directives
• Scripting Elements
• At run time, are compiled into Servlets

5
JSP Authoring in PowerBuilder

• New PowerBuilder Target Type (JSP Target)
• Builds upon the existing Web Targets User
  Interface
• New Wizard - JSP Target
• Extensions to the Page Editor
• System Tree Additions
• Deployment Changes
• EAServers JSP Container
• Apache Tomcat
• Command Line Deployment

6
JSP Authoring in PowerBuilder 9.0

• PowerBuilder 9 provides a powerful object model
  for
• Data transfer between the web client and the
  application server
• HTML generation
• JavaScript generation for server scripts

7
JSP Authoring in PowerBuilder 9.0

• Wizard for
• Creating JSPs that call Web Services
• WYSIWYG editing of JSP pages
• Full access to the page source through the editor

8
PBNI

• Using the PowerBuilder Native Interface to Extend
  Your Applications

9
Definition

• PBNI, the PowerBuilder Native Interface, is a
  standard interface for writing PB extensions,
  including PB non-visual extension, PB visual
  extensions, and PB marshaler extensions, and for
  embedding the PBVM into external C applications.

10
Extending PowerScript

• PowerBuilder can call external C functions from
  PowerScript
• But there are some limitations with external
  functions
• It is not possible to declare an external
  function that requires a callback function. E.g.
  BOOL EnumWindows(WNDENUMPROC lpEnumFunc, LPARAM
  lParam)
• Some C data types cannot be mapped to PB data
  types, such as double.
• An external function cannot callback into the
  PBVM.
• Using external functions is not object-oriented.

11
PBNI is a better solution

• To solve these limitations, PBNI has been
  implemented in PB90
• Using PBNI, you get the following benefits
• The data passed between PowerScript and PB
  extensions are in PBs native data types
• PB extensions can callback into the PBVM to
  perform various jobs, such as creating an object,
  invoking a PowerScript function, triggering an
  event, accessing a variable, accessing an array
  item, and so on
• Once the PBD file representing a PB extension is
  included in a PB target, the classes implemented
  by the PB extension can be used just like normal
  NVOs or custom user objects

12
What can be done with PBNI?

• With PBNI, you can
• Write PB non-visual extensions and use them in PB
  just as normal NVOs
• Write PB visual extensions and use them just as
  custom user objects
• Write PB marshaler extensions to call external
  components and use them in PB just like what you
  do with Jaguar components
• Embed the PBVM in external C applications to
  call PowerScript functions

13
Using a PB extension

• Add the PBD file in the library list of the PB
  target
• Put the DLL file in the directory that is in the
  PATH
• Using the native class as a normal NVO or custom
  user object
• PBNI works on both Windows and Unix platforms

14
PBNI Visual Extension
15
EJB Clients

• Accessing Enterprise Java Beans from a
  PowerBuilder Client

16
J2EE Example
J2EE Server
EJB Container
Home Interface
Home Object
Enterprise Information System
Client
bean
Remote Interface
Services Provided by Server to bean
Naming Transactions Security .
17
Take advantage of EJB Client Support

• EJB Client support makes PowerBuilder glue with
  any application server - J2EE compliant
• Development cycle with EJB client is much shorter
  than using Java(short time-to-market)
• Reuse the source code written in PowerBuilder

18
Overview of EJB Client Implementation

• EJB Client PowerBuilder Native Interface(PBNI)
  implementation
• PowerBuilder Java VM Service
• Creates and manages a Java Virtual Machine(VM)
  within its own process space and communicate with
  Java objects
• PowerBuilder proxy Objects

19
EJB Client PBNI implementation

• EJB Client provides a bridge from PowerBuilder
  into EJB

EJB Client PBEJBCLIENT90.DLL PBEJBCLIENT90.PBD PB
EJBCLIENT90.JAR
Java VM
PowerBuilder VM
JNI
PBNI
EJB
NVO
Java Object
NVO
JNI (Java native interface) http//java.sun.com/j
2se/1.4/docs/guide/jni/
20
EJB Client PBNI Objects

• JavaVM
• load or attach to a Java VM
• work with Java interface and class hierarchies
• EJBConnection
• connect to the J2EE server
• locate EJB via JNDI
• instantiate other Java classes
• EJBTransaction
• Manage the transaction

21
JVM Service in PB IDE

• Sun JDK 1.4 is installed within
  shared/PowerBuilder directory by PowerBuilder as
  default
• Modify this default setting using JDK Location
  dialog
• It is accessible from the Java tab of the Systems
  Options Dialog access from PowerBuilders Tools
  Menu, click the Set JDK Location button

22
EJB Proxy Object

• EJB proxy object is a way to delegate requests to
  and from the underlying Java classes
• Each EJB proxy is inherited from nonvisualobject
  or exception class like other PowerBuilder
  proxies
• Proxy includes all of the public methods defined
  on its associated Java class

23
Generates EJB proxies

• PowerBuilder provides two methods to generate
  proxy object
• Within the development environment
• A standalone command-line application
• Relies on the Javap utility provided with the
  JDK.
• Fully qualified name of an EJBs remote interface
  is required as parameter
• Assumes that the home interface has the same name
  followed by Home
• An additional PB structure is generated as well,
  that records the correspondence of the original
  Java class to the resulting proxy object name

24
