Title: Digital Transmission


1
Digital Transmission
  • Chapter 4

2
Digital To Digital Conversion
  • Data element vs signal element, r.
  • a digital data element is a bit.
  • a signal element carries the data element from
    the source to the destination.
  • If people are data elements, cars and busses are
    the signal elements.

3
Data rate vs signal rate
  • Data rate is measured in bps.
  • Signal rate is the number of signals sent in one
    second. (a signal may contain more than one bit).
    Signal rate is the baud rate, aka
  • Modulation rate
  • Pulse rate

4
Data rate vs Signal rate
  • S c (N/r)
  • S baud rate
  • c case factor 0 lt c lt 1
  • The average is c .5
  • N data rate in bps
  • r ratio of data elements to signal elements.

5
Figure 4.2 Signal element versus data element
6
Baud Rate
  • Buad rate determines the bandwidth based on the
    ratio of data elements to signal elements.
  • Traffic congestion is not determined by the
    number of people on the road, but the number of
    vehicles.
  • Using busses to reduce cars on the road reduces
    overall congestion.

7
  • Let N max bit rate
  • B bandwidth
  • r data elements / signal element
  • N ½ B r

8
Example
  • Let r 1 (one data element / one signal element)
  • Let c the average is ½
  • B 100kbps
  • Find the baud rate S
  • S ½ 100kbps 1 50kbaud

9
Digital Signal Problems
  • DC Components ( baseline wandering )
  • Synchronization

10
DC Components
  • A constant output generates a DC signal.
  • Some systems cannot pass low frequencies easily.
  • Example A telephone line cannot pass frequencies
    below 200Hz.

11
Synchronization
  • The intervals between bits must match between
    sender and receiver. If the intervals are
    different, then the data will not be translated
    correctly.
  • Example sender requires 3 time units per bit,
    the receiver uses 2 time units between bits. If
    two 1s are sent, the receiver will translate them
    as 3 bits.

12
Figure 4.3 Effect of lack of synchronization
13
Example 4.3
In a digital transmission, the receiver clock is
0.1 percent faster than the sender clock. How
many extra bits per second does the receiver
receive if the data rate is 1 kbps? How many if
the data rate is 1 Mbps?
Solution At 1 kbps, the receiver receives 1001
bps instead of 1000 bps.
At 1 Mbps, the receiver receives 1,001,000 bps
instead of 1,000,000 bps.
14
Line Coding
  • Unipolar
  • Polar
  • Bipolar
  • Multilevel
  • Multitransitional

15
Figure 4.5 Unipolar NRZ scheme
16
NRZ
  • Non-return-to zero (NRZ) implies that the signal
    does not return to zero during the transmission
    of the bit.

17
Figure 4.6 Polar NRZ-L and NRZ-I schemes
18
Polar Line Coding
  • NRZ-Level the voltage level determines the bit
    value.
  • NRZ-Invert the change in voltage level at the
    bit boundary determines the bit value.
  • No change relative to the last bit is a zero
  • change relative to the last bit is a one.

19
Polar RZ
  • 3 values positive, zero, and negative
  • Signal changes (returns to zero, RZ) during the
    bit transmission.
  • Positive implies a one
  • Negative implies a zero
  • Return to zero during the bit transmission to
    synchronize the sender and receiver.

20
Figure 4.7 Polar RZ scheme
21
Polar RZ
  • Requires twice the bandwidth compared to NRZ
    methods because of the change during the bit
    transmission.

22
Figure 4.8 Polar biphase Manchester and
differential Manchester schemes
23
Manchester Line Coding (polar)
  • No synchronization problems due to the transition
    of each bit.
  • Requires twice the bandwidth of NRZ.
  • Not suited for long distances (LANs only)
  • Differential Manchester is used by Ethernet.

24
Bipolar Line Coding
  • Voltage levels are positive, zero, or negative.
  • One alternates between positive and negative
    voltage.
  • Zero is no voltage.

25
Bipolar DC
  • Zero voltage has zero amplitude. Therefore there
    is no DC component.
  • Commonly used for long distance communication.
  • Bipolar line coding is subject to synchronization
    problems.

26
AMI Pseudoternary
  • AMI Alternate mark inversion
  • Pseudoternary

27
Figure 4.9 Bipolar schemes AMI and pseudoternary
28
Multilevel Line Coding mBnL
  • m data elements
  • n signal elements
  • B is binary, 2m
  • L different levels T three, Q 4.
  • Note 2m lt Ln, otherwise there are not enough
    signal elements to represent each data element.

29
2B1Q
  • Q is for quaternary (4), note that 22 41
  • Uses a translation table for each possible bit
    pattern
  • Used for DSL

30
Figure 4.10 Multilevel 2B1Q scheme
31
2B1Q
  • In North America, 2B1Q operates at 40kHz
  • What is the bit rate N for 2B1Q?
  • N 2flog2(L)
  • What is L for 2B1Q?

32
2B1Q
  • Answer N 160kbps

33
Figure 4.11 Multilevel 8B6T scheme
34
8B6T
  • 8 binary, 6 ternary
  • 3 levels (ternary)
  • 256 28 lt 36 729
  • Each 8 bit data pattern is converted into a 6 bit
    pattern using one of 3 voltage levels (-,0,).
  • Used by 100Mbps Ethernet (Fast Ethernet)

35
4D-PAM5
  • 4 dimensional, 5-level pulse amplitude
    modulation.
  • 4 wires carrying simultaneous signals.
  • Five voltage levels -2, -1, 0, 1, 2.
  • Used by gigabit ethernet

36
Figure 4.12 Multilevel 4D-PAM5 scheme
37
Table 4.1 Summary of line coding schemes
38
Block coding is normally referred to as mB/nB
coding it replaces each m-bit group with an
n-bit group.
39
Block Coding 4B/5B
  • Replace each 4 bit group (a nibble) with a 5 bit
    group.
  • Division divide the data into 4 bit nibbles.
  • Substitution substitute the 4 bit nibble with a
    5 bit code so there is no more than one leading 0
    on the left of the 5 bit word.
  • (8B/10B is also available)

40
Figure 4.16 Substitution in 4B/5B block coding
41
Table 4.2 4B/5B mapping codes
42
  • What impact does 4B/5B block coding have on
    bandwidth?

43
Scrambling B8ZS HDB3
  • B8ZS 8 consecutive zero bits are substituted
    with 000VB0VB
  • V and B designate a pattern of polarized ones.
    This will reduce the DC problem for long strings
    of 0.

44
Figure 4.19 Two cases of B8ZS scrambling
technique
45
PCM Pulse Code Modulation
  • PCM converts analog to digital
  • Sample the analog signal
  • Quantize the sample
  • Encode

46
PCM sampling
  • Sampled at a regular interval, T, where f 1/T.
  • The highest frequency signal is determined by the
    Nyquist theoem. The sample rate is twice the
    maximum frequency.

47
Figure 4.24 Recovery of a sampled sine wave for
different sampling rates
48
Figure 4.22 Three different sampling methods for
PCM
49
PCM Quantization
  • Signal has a maximum and minimum amplitude.
  • Divide the range of amplitudes into L zones
    each of equal height.
  • Delta is (Vmax-Vmin)/L
  • Assign a value to each midpoint of each zone
  • See figure 4.26 page 125 in text.

50
Figure 4.26 Quantization and encoding of a
sampled signal
51
Encoding
  • Normalized PAM is the signal value/delta
  • The quantization code is then converted to its
    binary equivalent.

52
PCM SNR(db)
  • SNR(db) 6.02 n 1.76
  • Where n bit depth
  • If 40db is required for phone audio, what is the
    bit depth required (the next power of two).
    Answer n 6.4 -gt n 8.

53
PCM Sample Rate
  • What bit rate is required for voice and what is
    the bit rate if the bandwidth is 0-4000Hz?
  • Sample rate 2fmax (due to Nyquist)
  • Bit rate Sample rate bit depth

54
Delta Modulation
  • Measures the change from the previous sample.
  • DM requires oversampling beyond the Nyquist rate
    to achieve the same SN compared to PCM.

55
Transmission Modes
  • Parallel Transmission
  • Serial Transmission
  • Asynchronous
  • Synchronous
  • Isosynchronous

56
Figure 4.31 Data transmission and modes
57
Parallel
  • Use n-wires to transmit n bits simultaneously.
  • Usually limited to short distances due to the
    cost of multiple strands of wire bundled together.

58
Figure 4.32 Parallel transmission
59
Figure 4.33 Serial transmission
60
Serial Asynch (byte level)
  • Each byte is sent with a start bit (0) and one
    stop bit (1) at the end of each byte.
  • The start bit alerts the receiver that data will
    arrive.
  • The stop bit can be used as an error check.
  • Idle time is allowed between the transmission of
    bytes. This idle time allows for synchronization.
  • The sender and receiver are synchronized during
    the duration of the byte transfer (10 bits in
    all).

61
Serial Synch (more than 1 byte)
  • A continuous stream of bits are sent from source
    to receiver. The two must be synchronized during
    the entire data frame transfer. Gaps are allowed
    between frames.
  • This requires synchronization but also results in
    the fastest data transfer (no start or stop bits,
    no gaps within a frame).

62
Serial isosynchronous
  • Frames arrive at regular intervals audio and
    video transmission are examples.
