Update for Hamamatsu MPPC

1
Update for Hamamatsu MPPC SensL SiPM

• Carl Zorn
• JLAB Radiation Detector
• Medical Imaging Group

Thursday, April 16, 2009
2
470 nm
Remeasure PDE for chosen scintillator
520 nm
SCSF-78
Slide 2
3
JLAB PDE Setup
470 10 nm
Blue LED
Blue LED
T211C
Slide 3
4
SensL PDE curves
470 nm
520 nm
Slide 4
5
Hamamatsu PDE curves
470 nm
520 nm
(100 µm)
(50 µm)
(25 µm)
Slide 5
6
Latest PDE data (470 nm)
Slide 6
7
Effect of Increased Bias on Hamamatsu MPPC
50 µm (1 mm2) _at_ Vop
50 µm _at_ Vop 0.5 v
50 µm _at_ Vop 1.0 v
Slide 7
8
Effect of Bias on Detected Noise (SensL)
A35H (1 mm2) _at_ V Vbr 2 v
A35H (1 mm2) _at_ V Vbr 4 v
Slide 8
9
Current Array Packages
Slide 9
10
Compare packages
18 mm
16 mm
13 mm
Array Size 13 x 13 mm2 Active area 2.85 x 2.85
x 16 mm2 (77) Pixel Count 8640 x 16 (20
µm) 3640 x 16 (35 µm)
Array Size 16 x 18 mm2 Active Area 3x3x16 mm2
(50) Pixel Count 14,400 x 16 (25 µm) 3600 x 16
(50 µm)
Slide 10
11
New SensL Package
Slide 11
12
Hamamatsu MPPC (summed) pulses
200 ns
50 µm
25µm
Blue LED
Slide 12
13
SensL SiPM Array Pulses
Single channel pulse from SPMA-1 16-channel array
Summed pulse from SiPMPlus array
200 ns
Slide 13
14
Relative Response of Full Arrays
Slide 14
