Proportions in Similar Triangles

1
Proportions in Similar Triangles
2

• GSP c8\sss_sas.gsp

3
SSS Theorem

• If corresponding sides of two triangles are
  proportional then the two triangles are similar.

4
SAS Theorem

• If two corresponding sides of two triangles are
  proportional and the included angles are
  congruent then the two triangles are similar.

5
Side Splitter Theorem

• If a line is parallel to one side of a triangle
  and intersects the other two sides, it divides
  those two sides proportionally.

6
Side to Side Problem
Side Side
Side Side
C
gtgt
B
D
gtgt
E
A
gtgt
7

• Theorem If three or more parallel lines are
  intersected by tow transversals, the parallel
  lines divide the transversals proportionally.

8
Side to Base Problem
?CBD?CAE
Side Base
Side Base
Side Base
Side Side
C
Base Base
B
D
gtgt
E
A
gtgt
9
Corollary

• If three or more parallel lines intersect two
  transversals, then they cut off the transversals
  proportionally.
• Hint Many proportions are created in this
  diagram... just a few are provided.  With any
  proportion simply make sure that corresponding
  parts line up.

10
Corollary

• If three or more parallel lines cut off congruent
  segments on one transversal, then they cut off
  congruent segments on every transversal.

11
Side to Side Problem
Side Side Side
Side Side Side
A
E
gtgt
B
F
gtgt
G
C
gtgt
D
H
gtgt
12
Triangle Midpoint Proportionality Theorem

• A segment whose endpoints are the midpoints of
  two sides of a triangle is parallel to the third
  side of the triangle, and its length is one-half
  the length of the third side. Hint CBCA 12,
  CDCE 12 and BDAE 12

13
Converse of the Triangle Proportionality Theorem

• If a line intersects two sides of a triangle and
  separates the sides into corresponding segments
  of proportional lengths, then the line is
  parallel to the third side.
• If a line intersects two sides of a triangle and
  separates the sides into corresponding segments
  of proportional lengths, then the line is
  parallel to the third side.

14
Triangle Proportionality Theorem

• If a line is parallel to one side of a triangle
  and intersects the other two sides in two
  distinct points, then it separates these sides
  into segments of proportional lengths.

15
Angle Bisector Theorem

• If a ray bisects an angle of a triangle, it
  divides the opposite side into segments that are
  proportional to the adjacent sides.

proportional angle segments.gsp
16
Angle Bisector Problem
Side Side
base base
B
//
//
A
D
C
E
17
Angle Bisector

• An angle bisector divides the opposite side into
  segments proportional to the lengths of the
  adjacent sides.

B
\
A
\
C
D
18
Proportional Perimeters Theorem

• If two triangles are similar, then the perimeters
  are proportional to the measures of corresponding
  sides.

19
Proportional Altitudes Theorem

• If two triangles are similar, then the measures
  of the corresponding altitudes are proportional
  to the measures of the corresponding sides.

20
Proportional Angle Bisectors Theorem

• If two triangles are similar, then the measures
  of the corresponding angle bisectors are
  proportional to the measures of the corresponding
  sides.

21
Proportional Medians Theorem

• If two triangles are similar, then the measures
  of the corresponding medians are proportional to
  the measures of the corresponding sides.

22
Practice Problems

• 1.8.6  Find the value of x.
• A. 6.4 B. 10  C. 5.8 D. 7.6

23
B
B
B
D
D
C
A
?ABC? ?ADB ? ?BDC ? ?
D
C
A
D
24
Practice Problems

• 2. 8.6 Find the value of y.
• A. 1.9 B. 2.2  C. 1.8 D. 2

25
Practice Problems

• 3. 8.6  If a median of a triangle is also an
  angle bisector, then the triangle is_______.
• A. isosceles
• B. right
• C. scalene
• D. equilateral

26
Practice Problems

• 4. 8.6 The perimeter of HIJ 22, and the
  perimeter of FGH 38. If BH 6, then AH
  _____.
• 114/11
• B. 66/9
• C.22
• D.10

27
Practice Problems

• 5. 8.6   ?ABC ?XYZ. If BM 5, YZ 4, and XY
  8, then AB ______.
• A.17
• B.10
• C.20
• D.40

28
Example

• 1.8.4  Find the value of x.
• A. 9
• B. 7
• C. 50/7
• D. 8

29
Example

• 2.8.4 In the figure, . If AB 4, DE x 1, BC
  4, and EF 3x - 9, what is the value of x?
• A. 6
• B. 3
• C. 5
• D. 4

30
Example

• 3.8.4  Based on the figure below, which statement
  is false?
• ltLPQ ltLMN
• PQMN
• ?LMN ? LQP
• mltM lt mltN

31
Example

• 4.  If PQBC and PM MQ, which statement is not
  necessarily true?
• ?APQ is isosceles.
• ?ABC is isosceles.
• ?ABC is equilateral.
• D. ?ABC ?APQ

32
Example

• 5.8.4.  If AB 1, WX 2, BD 7, and YZ 3,
  then what is the measure of XY?
• A.14
• B.11
• C.4
• D.10

33
8.4.7
?ABC ?DEF
34
8.4.8
35
8.4.11
36
8.4.17
37
8.4.20
5.5
12
3
?
38
8.5.2
39
8.5.4
40
8.5.6
41
8.5.7
42
8.5.11
43
8.5.20
44
8.5.26
45
8.R.16
46
8.R.29
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
Pretest 25
57
(No Transcript)
