PRACTICAL

1

• PRACTICAL
• OBJECT-ORIENTED
• DESIGN WITH UML
• 2e

Chapter 14 Principles and Patterns
2
Principles and Patterns

• The activity of design can be informed by
• principles general statements of what properties
  a design ought to have
• patterns concrete examples of successful designs
  for particular purposes

3
Valid or Correct Models

• A model is said to be valid (or legal) if it
  conforms to the UML rules. A model is correct if
  it faithfully represents reality. Assuming that
  the UML is correct, we can state that all correct
  models are valid models. However, the converse
  may not true valid models are not necessarily
  correct models. For example, imagine that a
  hospital is being modeled, but the modeler fails
  to include a critical state, such as a WardFull
  state. In this case, the UML class diagram is
  valid (UML does not require a WardFull state ,
  but merely allows it), but is incorrect, since it
  does not represent reality. However, if the UML
  required every model to include the a WardFull
  state, the model would be invalid. We can now
  consider good configurations or designs of valid
  models.

4
System Evolution

• How can we insulate modules from change?
• We would like to be able to change modules
  without affecting their clients
• this will increase the maintainability of the
  system

5
Open and Closed Modules

• A module is said to be closed if it is not
  subject to further change
• clients can then rely on the services the module
  provides
• A module is said to be open if it is still
  available for extension
• this will make it possible to extend and modify
  the system

6
The Open-Closed Principle

• Open and closed modules both have advantages
• The open-closed principle states that developers
  should try to produce modules that are both open
  and closed
• This sounds like a paradox
• to resolve it we need a way of making a module
  extendible without having to change it

7
Interface and Implementation

• The interface of a module is what is visible or
  available to clients
• The implementation is the internal details of the
  module that support the interface
• One approach to open-closed modules is to ensure
  that clients only depend on the interfaces of the
  modules they use
• and make it possible to change the
  implementations freely

8
Data Abstraction

• Data abstraction assigns an access level to each
  feature in a class
• Clients can use only the public interface
• Private features - eg method bodies - can be
  freely changed

9
Limitations

• Even with data abstraction, Java classes are
  technically not closed
• changes to method bodies affect the source code
  and entail recompilation of clients
• The interface actually used by clients is left
  implicit (no actual interface just concrete
  supplier or server)

10
Abstract Interface Classes

• An approach based on generalization (not pure
  interfaces)
• Abstract classes can provide a complete or
  partial implementation of a method(s).

11
How the Interface Works

• Clients access different concrete suppliers
  through the abstract supplier interface
• This is enabled by features of the
  object-oriented programming paradigm
• polymorphism a reference to the interface class
  can actually refer to any implementation class
• dynamic binding messages to the interface are
  passed on the appropriate implementation class

12
Dependencies

• The dependency structure indicates that the
  client is independent of the concrete suppliers

13
Open and Closed

• The abstract supplier class is
• open in the sense that its functionality can be
  extended by adding further subclasses
• closed in that this can be done without affecting
  clients
• However, the client is not protected against
  changes in the interface exported by the abstract
  supplier class

14
No Concrete Superclasses

• It has sometimes been recommended that all
  superclasses in a system should be abstract
• Often subclasses are added to concrete classes as
  a system evolves

15
A Dependency Problem

• The savings account class is now dependent on the
  current account class
• changes to the current account - altering
  functionality or adding and removing operations -
  will affect savings accounts
• This leads to problems
• the changes may not apply to savings accounts
• the code may become cluttered with checks for
  special cases

16
Refactoring the Design

• A better approach is to introduce an abstract
  interface class
• even if it initially seems unnecessary

17
Decoupling Interfaces

• Clients can be protected from interface change by
  defining separate interface and implementation
  hierarchies
• Make the abstract supplier an interface

18
Separate Interface Hierarchy

• Extend the interface to add a new operation
• abstract supplier can be extended without
  affecting existing clients

19
Liskov Substitution Principle

• States the conditions under which references to
  superclasses can safely be converted to
  references to subclasses
• it must be possible to substitute an instance of
  a subclass for an instance of a superclass
  without affecting client classes or modules
• this defines what generalization means in UML

20
Design Based on Structure

• It is sometimes tempting to base a design on the
  physical structure of the artefact being modelled
• for example, a mobile phone

21
Realizing Make a Call

• This interaction looks plausible
• But the associations based on the phone structure
  do not support these messages

22
Design Based on Interactions

• A better model of the phone is derived from the
  interactions in the realization

23
Design Patterns

• Solutions to common design problems
• Catalogued and published to aid reuse
• A pattern consists of
• a name, for easy reference
• a description of the problem being solved
• a description of the solution proposed
• a discussion of the consequences of adopting the
  pattern

24
Recursive Structures

• Many data structures are recursive, eg

25
The Composite Pattern

• Composite defines the essential properties of
  this sort of situation

26
Discussion of Composite

• The problem is how to implement tree-like
  structures
• The diagram shows only the solution
• Leaf and Composite classes share a common
  interface, defined in Component
• Composite implements this by iterating through
  all its components

27
Patterns in UML

• UML documents patterns as parameterized
  collaborations

28
Documenting Pattern Application

• When applying a pattern you must show what the
  its classes correspond to

29
The State Pattern

• Problem how to allow an object to alter its
  behaviour when its internal state changes
• applicable if a class is described by a
  statechart
• Solution represent each state by a separate
  class
• each state class will implement the behaviour
  appropriate for each operation in that state only

30
The State Solution

• A consequence of this pattern is that the state
  classes need access to the internal details of
  the context class

31
The Strategy Pattern

• Problem how to allow different instances of a
  class to support different implementations of an
  operation
• Solution separate out the implementation of the
  operation into a new class hierarchy
• link each instance to a particular implementation
  object

32
The Strategy Solution

• The structure is very similar to that of State
• treated as a different pattern because the
  problem being solved is different

33
Models, Views and Controllers

• MVC a design proposal put forward for the
  Smalltalk language
• to design programs with graphical interfaces
• separates manipulation and presentation of data
• Now widely used in a variety of contexts
• the model stores and maintains data
• views display data in specific ways
• controllers detect and forward user input

34
Models, Views and Controllers
35
Interactions in MVC

• User input detected by a controller
• The model is notified
• The views are updated

36
Document/View Architecture

• Widely used by Microsoft
• A simplification of MVC
• Views combine the functions of MVC views and
  controllers

37
Document/View Structure
38
Document/View Interactions

• Compare this with the MVC interaction

39
The Observer Pattern

• Problem to define a dependency between objects
  so that when one object changes state all its
  dependants are notified
• Solution like MVC, separate subject (ie model)
  from observer (ie view)

40
Observer Structure
41
Observer Interactions

• This interaction is simpler because the initial
  message is sent straight to the model class

42
Parts Explosion

• New requirement for the stock control program
• print a listing of all the parts and
  subassemblies in an assembly
• Simple approach
• add an explode operation to each class
• call it recursively, like the existing cost
  operation

43
Problems

• There are a number of problems with this
• this approach involves changes to every class in
  the hierarchy
• the code that controls the recursion is repeated
  in both cost and explode
• model classes like Part should not produce
  output
• Is there a pattern that can help?

44
The Visitor pattern

• Problem Visitor lets you define a new operation
  without changing the classes of the elements on
  which it operates
• Solution define a visitor class and an
  operation in each class to be visited to accept
  a visitor
• Consequence the design becomes more complex, but
  more extendible

45
Finding Costs with Visitor

• This illustrates Visitor with a single operation

46
The CostVisitor Class

• CostVisitor gets called for each component
  and keeps track of the total cost of parts
• public class CostVisitor
• private int total
• public void visit(Part p)
• total p.cost()
• public void visit(Assembly a)

47
Finding the Cost

• We no longer call a cost function belonging to an
  assembly
• Instead, we pass a cost visitor to it
• Assembly a
• CostVisitor visitor new CostVisitor()
• a.accept(visitor)
• int cost visitor.getTotal()

48
Visitor Interactions
49
Adding Part Explosions

• Extend the design by defining a visitor hierarchy

50
Mediator Pattern

• The intent is to define an object that
  encapsulates how a set of objects interact.
  Mediator promotes loose coupling by keeping
  objects from referring to each other explicitly,
  and it lets you vary their interaction
  independently. The purpose of a Mediator is to
  manage the relationships between numerous objects
  so that they can each focus on their own
  behaviour independently of the others.

51
Mediator Pattern
52
Mediator Pattern with Java
53
Mediator Pattern in Java

• An Example From Software Design Using Java 2 By
  Lano, Fiadeiro Andrade.
• The mediator pattern centralises dependencies
  between objects. Instead of code being written in
  one (dependent) object to update the state of
  that object when another object that it depends
  on changes state, there is a separate mediator
  object which links them and performs the
  necessary logic to compute the change needed by
  the dependent object.

54
Mediator Pattern in Java

• An Example From Software Design Using Java 2 By
  Lano, Fiadeiro Andrade.
• This reduces the complexity of the objects and
  increases flexibility. For example, if rules
  connecting that objects need to change without
  the objects themselves changing.

55
Mediator Pattern in Java

• An Example From Software Design Using Java 2 By
  Lano, Fiadeiro Andrade.
• Aim to simplify complex connections and
  dependencies between a set of objects by defining
  Mediator objects which centralize information
  about these dependencies.
• Implementation based on the idea of event
  sources and event targets.

56
Mediator Pattern in Java

• An Example From Software Design Using Java 2 By
  Lano, Fiadeiro Andrade.
• The Mediator is more general than the Observer in
  that objects may be both event sources and event
  targets. Also the code for updating event targets
  on notification of an event is separated out from
  these targets.
• The Mediator enhances maintainability and
  flexibility because it removes knowledge of
  dependencies and the detail of the dependency
  management code from collaborating objects and
  puts it in the mediator object instead. When the
  rules of dependency change, only the mediator
  object needs rewriting

57
Mediator Pattern in Java

• An Example From Software Design Using Java 2 By
  Lano, Fiadeiro Andrade.
• In the following program the first action
  ca.credit(600), causes credit of 600 to be added
  to the current account, resulting in cas credit
  listener being activated, and this then trims as
  100 from the current account balance and adds
  this to the deposit account. In the second
  action, cust.withdraw(550), the withdraw listener
  of the customer is activated and removes 500
  units from the current account and 50 from the
  deposit.

58
Mediator Pattern in Java

• An Example From Software Design Using Java 2 By
  Lano, Fiadeiro Andrade.
• In the following program the first action
  ca.credit(600), causes credit of 600 to be added
  to the current account, resulting in cas credit
  listener being activated, and this then trims as
  100 from the current account balance and adds
  this to the deposit account. In the second
  action, cust.withdraw(550), the withdraw listener
  of the customer is activated and removes 500
  units from the current account and 50 from the
  deposit.

59
Mediator Example From Software Design Using Java
2 By Lano, Fiadeiro Andrade.

• interface WithdrawListener
• void withdraw(int ammount)
• interface CreditListener
• void credit(int ammount)

60
Mediator Example From Software Design Using Java
2 By Lano, Fiadeiro Andrade.

• class Customer
• private String name
• private Vector withdrawListeners new Vector()
• public Customer(String nme)
• name nme
• public void addWithdrawListener(WithdrawListener
  w)
• withdrawListeners.add(w)
• public void withdraw(int amount)
• for (int i 0 i i)
• WithdrawListener wl (WithdrawListener)
  withdrawListeners.get(i)
• wl.withdraw(amount)

61
Mediator Example From Software Design Using Java
2 By Lano, Fiadeiro Andrade.

• class Customer
• private String name
• private Vector withdrawListeners new Vector()
• public Customer(String nme)
• name nme
• public void addWithdrawListener(WithdrawListener
  w)
• withdrawListeners.add(w)
• public void withdraw(int amount)
• for (int i 0 i i)
• WithdrawListener wl (WithdrawListener)
  withdrawListeners.get(i)
• wl.withdraw(amount)

62
Mediator Example From Software Design Using Java
2 By Lano, Fiadeiro Andrade.

• class Account
• private int accountNo // unique account
  identifier
• private int balance0
• private Vector creditListeners new Vector()
• public Account (int ac) accountNo ac
• public void addCreditListener(CreditListener
  cl)
• creditListeners.add(cl)
• public int getBalance()
• return balance
• public void credit(int amount)
• balance amount
• for (int i 0 i i)
• CreditListener cl (CreditListener)
  creditListeners.get(i)
• cl.credit(amount)
• public void debit(int amount)
• balance - amount

63
Mediator Example From Software Design Using Java
2 By Lano, Fiadeiro Andrade.

• class CurrentAccount extends Account
• public CurrentAccount(int ac)
• super(ac)
• class DepositAccount extends Account
• public DepositAccount(int ac)
• super(ac)

64
Mediator Example From Software Design Using Java
2 By Lano, Fiadeiro Andrade.

• class Mediator implements WithdrawListener,
  CreditListener
• private CurrentAccount caccount
• private DepositAccount daccount
• public void registerCurrentAccount(CurrentAccount
  ac)
• caccount ac
• public void registerDepositAccount(DepositAccount
  ad)
• daccount ad

65
Mediator Example From Software Design Using Java
2 By Lano, Fiadeiro Andrade.

• / business rule /
• public void withdraw(int amount)
• int caBal caccount.getBalance()
• int daBal daccount.getBalance()
• if (caBal amount)
• caccount.debit(amount)
• else if (caBal daBal amount)
• caccount.debit(caBal)
• daccount.debit(amount-caBal)

66
Mediator Example From Software Design Using Java
2 By Lano, Fiadeiro Andrade.

• / business rule /
• public void credit(int amount)
• int caBal caccount.getBalance()
• if (caBal 500)
• caccount.debit(caBal - 500)
• daccount.credit(caBal - 500)

67
Mediator Example From Software Design Using Java
2 By Lano, Fiadeiro Andrade.

• public class MediatorTest
• public static void main (String args)
• Mediator med new Mediator()
• CurrentAccount ca new CurrentAccount(1022)

• DepositAccount da new DepositAccount(7565)

• Customer cust new Customer("Felix")
• cust.addWithdrawListener(med)
• ca.addCreditListener(med)
• med.registerCurrentAccount(ca)
• med.registerDepositAccount(da)
• ca.credit(600)
• System.out.println(ca.getBalance())
• System.out.println(da.getBalance())
• cust.withdraw(550)
• System.out.println(ca.getBalance())
• System.out.println(da.getBalance())

68
Patterns

• The use of patterns is essentially the reuse of
  well established good ideas. A pattern is a named
  well understood good solution to a common problem
  in context. Patterns describe how objects
  communicate without becoming entangled in each
  others data models and methods. Keeping this
  separation has always been an objective of good
  OO programming, objects should mind their own
  business, but obviously need the services of
  other objects as well. Definition from Gamma, et
  al., 1993 Patterns identify and specify
  abstractions that are above the level of single
  classes and instances, or of components.
  Patterns can exist at many levels from very low
  level specific solutions to broadly generalized
  system issues. Patterns are often described using
  UML together with a pattern template A template
  describes a pattern. Typical template may
  contain Name, Intent, AKA, Motivation,
  Application, Structure, Participation,
  Collaborations, Consequences, Implementation,
  Sample Code, Known Uses, Related Patterns.
  Template not usually enough ned context and
  understanding (see Priestley).

69
Patterns

• Main advantages capture best practice, reuse,
  fairly standard way of describing patterns.
• Disadvantages advanced topic, learning design
  patterns is a long multiple step process
  Acceptance, Recognition, Internalisation, on the
  other hand they are worth learning. Role of
  experience. More geared to OO than other
  computing paradigms.
