Supporting Topk join Queries in Relational Databases

1
Supporting Top-k join Queries in Relational
Databases

• Ihab F. Ilyas, Walid G. Aref, Ahmed K. Elmagarmid

Presented by Z. Joseph, CSE-UT Arlington
2
Introduction

• Often searches are done on multiple features
• Each feature produces a different ranking for the
  query
• Must thus join and aggregate rankings on
  different features

3
Example

• Find location for a house such that the
  combination of the cost of the house and 5 years
  tuition at a nearby school is minimal.
• Exact location is not predefined in query, per
  location the house and school features would have
  to be analyzed.

4
Motivation

• Current techniques decouple join and sorting
  (ranking) of results.
• Sorting is expensive and is a blocking operation.
• More apparent if ranking and the joining features
  are different.

5
Rank-Join Algorithm

• Generate new valid join combinations
• Compute score for each combination
• For each incoming input, calculate the total
  score of
• The last seen feature value and the top ranked
  feature value for all other features in the
  query.
• Store the maximum of these as T (threshold)
• Store top k in priority queue.
• Halt when lowest value of queue T

6
Optimality

• Is Instance Optimal over all correct top-K join
  algorithms.
• Guarantees that cost of Rank-Join is O (cost of
  any other algorithm).
• Mathematically
• Cost(Rank-Join) cCost(Any Other Algorithm)
  c
• c is the optimality ratio
• c, c gt 0

7
Rank-Join Continued

• Join strategy crucial
• Recommended Ripple Join
• Alternates between tuples
• Flexible in the way it sweeps out (rectangular,
  etc)
• Retains ordering in considering samples
• Variant of Rank-Join
• Hash Rank Join (HRJN)
• Block Ripple Join

8
Hash Rank Join (HRJN) Operator

• Built on idea of hash ripple join
• Inputs are as two hash tables
• Maintains highest (first) and lowest (last
  selected) objects from each relation.
• Results are added to a priority queue
• Advantages
• Smaller space requirement
• Can be pipelined

9
Hash Rank Join (HRJN) Operator Problems

• Local Ranking Problem
• Results from three or more input streams
• Larger queue sizes
• More database accesses
• Buffer Problem
• Cannot predict how many partial joins will result

10
HRJN Solutions?

• Block Ripple Joins
• Do comparisons as blocks
• Score-Guided Strategy
• If thresholds are very different, then this may
  be because of the way one of the rankings is
  larger and descends at a slower rate
• Can then take more inputs from the slower growing
  ranking so that the threshold goes closer to the
  other thresholds

11
Optimal Join-Order

• Try to have the least number of input records in
  order to get a correct ranking
• No clear way of estimating the order of joins
• Have a heuristic Footrule Distance
• Simple measure of similarity among two rankings.
• First join the most similar rankings
• This would quickly yield a join by accessing
  fewer records

12
Rank-Join Algorithm Benefits

• What can it do?
• Integrates well with query plans
• Produces results as fast as possible
• Provides performance guarantees
• Minimizes space requirements
• Offers a mechanism to determine the best order of
  joining to execute query optimally.
• Can be improved further if random access is
  available
• Can eliminate on-the-fly duplicate elimination

13
References

• Supporting top-k join queries in relational
  databases - Ihab Ilyas, Walid Aref, Ahmed
  Elmagarmid (2004)
• Jing Chen DBIR Spring 2005, CSE-UT Arlington
  http//ranger.uta.edu/gdas/Courses/
  Spring2005/DBIR/slides/top-k_join.ppt
