Practical PC, 4e

1
Chapter 1 Getting Started
2
Getting Started

• In this Chapter, you will learn
• How to power up the computer
• How to start the computer
• What to do if prompted for a password
• How to use the mouse and keyboard
• How to turn the computer off
• About different types of hardware

3
Wheres the power switch?

• Your PC (Personal Computer) is a system unit
  consisting of
• Physical Hardware
• A brain or microprocessor to carry out commands
• RAM (Random Access Memory) for temporary storage
• Storage media (hard disk, floppy disk, CD, etc.)

4
Wheres the power switch?
5
Wheres the power switch?

• Your PC is a system unit consisting of (cont)
• Software programs to perform tasks
• An operating system (I.e. Microsoft Windows)
• Application software (such as Word or Excel)
• A computer is turned on by a power switch on the
  system unit

6
Starting the PC

• Booting up your PC
• Make sure the floppy drive is empty and turn the
  PC on to allow the PC to boot up.
• The operating system is stored on the hard drive
  and normally boots from there.
• The PC boot process will also check that the
  systems components are functioning correctly.

7
Starting the PC

• Booting up your PC (cont)
• If you leave a disk in the floppy drive by
  mistake, the system will stop the boot process
  with a non-system disk message.
• If you have problems with the operating system
  stored on the hard drive, you can boot the PC
  from the floppy drive using a system disk to
  correct the problem.

8
Starting the PC
The Windows Desktop after a successful boot of
the PC
9
Using a User Id and Password

• Booting up your PC (cont)
• Your PC may be an individual (stand alone) PC or
  it may be connected to others on a network.
• If your PC is on a network, you may be asked to
  identify yourself with a user ID and password.
• A user ID identifies you individually
• A password provides security and ensures that
  only authorized people access the network.

10
The Mouse and the Keyboard

• You will use both a mouse and a keyboard to input
  information to the PC.
• Normally the keyboard is used to enter text, but
  can also be used to select tasks.
• The mouse allows you to point at and select
  objects.

11
The Mouse and the Keyboard
A Two-button Mouse
12
The Mouse and the Keyboard
A Standard Keyboard
13
Turning off the PC

• Shutting Down the PC
• Your PC may go into sleep mode if unused for a
  while, but it is still on.
• To properly turn off the computer, use the Shut
  Down Windows command.
• Turning off the power abruptly doesnt allow
  Windows to save settings and close down properly.

14
Turning off the PC

• Shutting Down the PC (cont)
• Shutting down properly saves your work and cleans
  out temporary scratchpad areas.
• If the computer freezes, pressing the Ctrl, Alt
  and Del keys at the same time, may release it and
  allow for proper shutdown.

15
Turning off the PC
The Turn off computer command dialog box
16
Hardware Types

• There are several configurations you can select
  for your PC The basic types to consider are
• A Desktop Computer which can be bought in either
  traditional desktop or in a tower style
• Less expensive, but not easy to move
• Most computing power per dollar
• Available for about 1000

17
Hardware Types
A traditional desktop configuration
18
Hardware Types

• There are several PC configurations (cont)
• A Notebook (laptop) Computer
• More expensive, but portable
• Uses an LCD (liquid crystal display) screen
  instead of a monitor
• Limited number of internal devices
• Can use PC cards to connect to phone lines or a
  network
• Typically costs between 1000 and 4000 with
  about the same power as the desktop model

19
Hardware Types
A Notebook computer illustrating its major
components
20
Hardware Types

• There are several PC configurations (cont)
• A PDA (personal digital assistant)
• Basic level computer, but hand held
• No hard drive, software hard-wired
• Links to a PC for data exchange
• Uses simplified operating system (Palm OS or
  Windows CE)
• Costs about 300
• Documents stored in flash memory (no constant
  power source)

21
Hardware Types
A PDA
22
Unpacking Setting up your PC

• When you buy a new PC, you need to be able to
• Identify each of the hardware components
• Connect each of the components to the correct
  port
• Connect the components to power using a surge
  strip

23
Unpacking Setting up your PC
The back of your PC and the different types of
ports
24
What do you think?
Computer haves and have-nots

• Do you own a computer?
• Do you believe that not having a computer at home
  is likely to limit a persons chances to improve
  his or her economic status?
• Do you favor spending tax dollars to make
  computers available in public libraries?
• Would you favor allowing college students to
  spend their financial aid money on computers?

25
Chapter Summary

• You should now be able to
• Unpack and set up your PC
• Find the various hardware components
• Boot up your PC system
• Identify the different types of systems
• Use a user ID and password
• Know when to use a mouse and a keyboard
• Shut down your PC
