PCE Communication Protocol PCEP draftietfpcepcep02'txt

1
PCE Communication Protocol
(PCEP)
draft-ietf-pce-pcep-02.txt



J.P. Vasseur (Cisco System Inc.)
J.L. Le Roux (France
Telecom) A. Ayyangar
(Juniper Networks) E.
Oki (NTT) A. Atlas
(Google) A. Dolganow
(Alcatel) Y. Ikejiri
(NTT Communications Corporation)
K. Kumaki (KDDI Corporation)

• IETF 66, PCE WG, Montreal 07/13/2006

2
Changes since last version

• One new bit defined in the RP object, the F bit,
  to indicate a request for a backup path
  computation after Failure
• The requests includes the current path (carried
  in an RRO), and the failed element (carried in an
  XRO)
• Allows avoiding the failed elements and avoiding
  double bandwidth booking
• Added a Finite State Machine
• Added a section that discusses compliance to
  generic requirements

3
PCEP Finite State Machine (1)

• Simple State Machine common to PCC and PCE
• Five states
• PCE-PCE communication with a single TCP session
• If two PCEP peers try simultaneously to setup a
  TCP connection (collision) the connection with
  the lower source IP _at_ is killed
• Distinct parameters (keepalive timer, deadtimer)
  to be negotiated in each direction
• Independent parameters negotiation
• OpenWait state used to negotiate remote
  parameters
• KeepWait state used to negotiate local parameters
• The session is up once local and remote
  parameters are agreed

4
PCEP Finite State Machine (2)
5
Compliance to the requirements

• Evaluation of the PCEP spec against requirements
  listed in the PCECP generic requirement ID
• All MUST requirements are covered, except three
  points
• Indication whether load balancing is allowed, and
  associated parameters (minimum bandwidth per
  path, max path)
• Inclusion of the desired objective function in
  the request
• Resynchronization of information requests
  between sender receiver after a communication
  failure

6
Next steps

• Need to address not yet covered generic
  requirements
• Load balancing will be covered in the next
  revision
• Objectives functions will be covered in a
  separate ID
• More discussion required on protocol recovery
• Need to add elements for PCE identification (for
  multiple PCE computation)
• PCE list enforcement in the PCReq message
• PCE list recording in the PCRep message
• PCE identification in the PCErr message
• Start working on extensions to cover Inter-Area,
  Inter-AS and inter-layer specific requirements
• Will be done in separate IDs
• Continue discussion on the list

7
ThanksQuestions?
