Design of a Diversified Router: Lookup Block

1
Design of aDiversified Router Lookup Block
John DeHartjdd_at_arl.wustl.edu http//www.arl.wust
l.edu/arl
2
Overview

• These slides are as much a definition of what is
  NOT in the Lookup Block as they are what is.
• In defining what is not in the Lookup Block I am
  putting some requirements on other blocks.
• These requirements have to do with where fields
  are added to frame headers.
• Not everything can or needs to be kept in the
  TCAM.
• There are also
• Constants
• Fields that have to be calculated for each frame
• Fields that are configurable per Blade or per
  physical interface.
• Etc.
• Also, there is a lot of information about the
  TCAM here.

3
Architecture Review

• First lets review the architecture of the
  Promentum ATCA-7010 card which will be used to
  implement our LC and NP Blades
• Two Intel IXP2850 NPs
• 1.4 GHz Core
• 700 MHz Xscale
• Each NPU has
• 3x256MB RDRAM, 533 MHz
• 4 QDR II SRAM Channels
• Channels 1, 2 and 3 populated with 8MB each
  running at 200 MHz
• 16KB of Scratch Memory
• 16 Microengines
• Instruction Store 8K 40-bit wide instructions
• Local Memory 640 32-bit words
• TCAM Network Search Engine (NSE) on SRAM channel
  0
• Each NPU has a separate LA-1 Interface
• Part Number IDT75K72234
• 18Mb TCAM

4
NP Blades
5
TCAM HW Details

• CAM Size
• Data 256K 72-bit entries
• Organized into Segments.
• Mask 256K 72-bit entries
• Segments
• Each Segment is 8k 72-bit entries
• 32 Segments
• Segments are not shared between Databases.
• Minimum database size is therefore 8K 72-bit
  entries.
• Do databases wider than 72-bits use multiple
  parallel segments or do they use sequential
  entries in a segment to make up the long entries?
• Sequential entries are used to comprise one
  longer entry.
• 36b DB has 16K entries per segment
• 72b DB has 8K entries per segment
• 144b DB has 4K entries per segment
• 288b DB has 2K entries per segment
• 576b DB has 1K entries per segment
• Can a segment be dynamically added to a Database
  as it grows?
• Yes, more on this feature in a future issue of
  the IDT User Manual

6
TCAM HW Details

• Number of Databases available 16
• Database Core Sizes 36b, 72b, 144b, 288b, 576b
• Coresize indicates how many CAM core entries are
  used per DB entry
• Key/Entry size
• Can be different for each Database.
• Key/Entry size lt Database Core Size
• Key/Entry size indicates how many memory access
  cycles it will take to get the Key into the TCAM
  across the 16-bit wide QDR II SRAM interface.

7
TCAM HW Details

• Result Type
• Absolute Index relative to beginning of CAM
• Database Relative Index relative to beginning of
  Database
• Memory Pointer Translation based on database
  configuration registers
• Base address
• Result size
• TCAM Associated Data of width 32, 64 or 128 bits
• Memory Usage
• Results can be stored in TCAM Associated Data
  SRAM or IXP SRAM.
• TCAM Associated Data
• 512K x 36 bit ZBT SRAM (4 bits of parity)
• Supports 256K 64-bit Results
• If used for Ingress and Egress then 128K in each
  direction
• Supports 128K 128-bit Results
• If used for Ingress and Egress then 64K in each
  direction
• Results deposited directly in Results Mailbox
• IXP QDR II SRAM Channel
• 2 x 2Mx18 (effective 4M x 18b)
• 4 times as much as the TCAM ZBT SRAM.

8
TCAM HW Details

• Lookup commands supported
• Direct Command is encoded in 2b Instruction
  field on Address bus
• Indirect Instruction field 11b, Command
  encoded on Data bus.
• Lookup (Direct)
• 1 DB, 1 Result
• Multi-Hit Lookup (Direct)
• 1 DB, lt 8 Results
• Simultaneous Multi-Database Lookup (Direct)
• 2 DB, 1 Result Each
• DBs must be consecutive!
• Multi-Database Lookup (Indirect)
• lt 8 DB, 1 Result Each
• Simultaneous Multi-Database Lookup (Indirect)
• 2 DB, 1 Result Each
• Functionally same as Direct version but key
  presentation and DB selection are different.
• DBs need not be consecutive.
• Re-Issue Multi-Database Lookup (Indirect)
• lt 8 DB, 1 Result Each
• Search Key can be modified for each DB being
  searched.

9
TCAM HW Details

• Mask Registers Notes (mostly for reference)
• When are these used?
• I think we will need one of these for each
  database that is to be used in a Multi Database
  Lookup (MDL), where the database entries do not
  actually use all the bits in the corresponding
  core size.
• For example a 32-bit lookup would have a core
  size of 36 bits and so would need a GMR
  configured as 0xFFFFFFFF00 to mask off the low
  order 4 bits when it is used in a MDL where there
  are larger databases also being searched.
• 64 72-bit Global Mask Registers (GMR)
• Can be combined for different database sizes
• 36-bit databases have access to 31 out of a total
  of 64 GMRs
• A bit in the configuration for a database selects
  which half of the GMRs can be used
• A field in each lookup command selects which
  specific GMR is to be used with the lookup key.
• Value of 0x1F (31) is used in command to indicate
  no GMR is to be used. Hence, 36-bit lookups
  cannot use all 32 GMRs in its half.
• 72-bit databases have access to 31 out of a total
  of 64 GMRs
• A bit in the configuration for a database selects
  which half of the GMRs can be used
• A field in each lookup command selects which
  specific GMR is to be used with the lookup key.
• Value of 0x1F (31) is used in command to indicate
  no GMR is to be used. Hence, 72-bit lookups
  cannot use all 32 GMRs in its half.
• 144-bit lookups have 32 GMRs available to it.
• 288-bit lookups have 16 GMRs available to it.
• 576-bit lookups have 8 GMRs available to it.
• Each lookup command can have one GMR associated
  with it.

10
TCAM Usage Notes

• Database Types are defined and managed by the IMS
  Software.
• The Type of the Database is defined in the
  software only.
• It tells the software how to define and use masks
  and priorities (weights).
• Allows the software to provide to the user a more
  flexible way to specify entries.
• Types of Databases
• Longest Prefix Match (LPM)
• Mask matches length of prefix
• Exact Match (EM)
• Mask matches full Entry size
• Best/Range Match What we typically call General
  Match.
• Mask is completely general.
• Priority
• Priority within a database is done by order of
  the entries.
• Exact Match should not need priority within the
  database since only one Entry should match a
  supplied Key.
• LPM and Best/Range Match do use priority within
  the databases.
• So, the order in which the entries are stored in
  these databases is important.
• For LPM DBs we would want to group prefixes by
  length in the TCAM.
• And this is almost certainly what the IMS
  software does.
• Changing priorities on existing entries may cause
  us some problems.

11
TCAM Performance

• Three Factors that affect performance
• Lookup Size (Key)
• Associated Data Width (Result)
• CAM Core Lookup Rate
• IXP/TCAM LA-1 Interface
• 16 bits wide
• 200 MHz QDR II SRAM Interface
• Effectively 32bits per clock tick
• So getting Key in is 32bits/tick
• Example 128b Key would take 4 ticks to get
  clocked into TCAM.
• Max of 50 M Lookups/sec
• Table on next slide shows some of the performance
  numbers for some Sizes that are of interest to
  us.
• What well see a little later is that in the
  worst case, we need a TOTAL Lookup rate of 12.5
  M/sec (6.25 M/sec on each LA-1 interface)

12
TCAM Performance (Rates in M/sec)
13
TCAM Software

• Several software components exist, enough to be
  really confusing.
• IDT Libraries
• MicroEngine Libraries
• NSE-QDR Data Plane Macro (DPM) API
• Iipc.uc and Iipc.h
• IIPC Integrated IP Co-processor
• Microengine Lookup Library (MLL)
• IipcMll.uc
• XScale
• Lookup Management Library (LML)
• Control Plane
• Initialization Management and Search (IMS)
  Library
• Simulation
• NSE with Dual QDR Interfaces IDT75K234SLAM
• Intel Libraries
• TCAM Classifier Library
• Microengine and XScale support for using TCAM.
• Requires installation of MLL and LML.
• Is geared toward a very specific application of
  NSE to IPv4 Forwarding App.

14
Lookup Block

• Three Lookup Blocks Needed
• All the Lookup Blocks will use the TCAM
• LC-Ingress
• All Databases for Ingress will be Exact Match
• LC-Egress
• All Databases for Egress will be Exact Match
• MR
• There will probably be multiple versions of this
• Shared
• Dedicated
• IPv4
• MPLS
• But lets think of it as one for now and focus on
  IPv4.
• Discussion later on what combination of the three
  types of DB we might use.
• Base functionality should be the same for all
  three
• A lot of code should be common
• LC-Ingress and LC-Egress will share a TCAM
• There will be two MR Lookup engines sharing a
  TCAM
• ARP on the LC might need/want to use the TCAM.

15
MR Lookup Block
Control
TCAM
XScale
XScale
DeMux
Rx
Parse
DeMux
Rx
Parse
Lookup
Lookup
Tx
HeaderFormat
Tx
HeaderFormat
MR (NPUA)
MR (NPUB)
16
LC Lookup Block
Ingress (NPUB)
S W I T C H
R T M
Lookup
Switch Tx
QM/Schd
Hdr Format
Phy Int Rx
Key Extract
XScale
LC
TCAM
ARP
XScale
Lookup
Phy Int Tx
QM/Schd
Hdr Format
Key Extract
Switch Rx
Rate Monitor
Egress (NPUA)
17
Lookup Block Requirements

• General
• Number of Packets per second required to handle?
• Line Rate 10Gb/s
• Assume an average IP Packet Size of 200 Bytes
  (1600 bits)
• (10Gb/s)/(1600 bits/pkt) 6.25 Mpkt/s
• Ethernet Header of 14 Bytes
• Average Frame Size of 214 Bytes (1712 bits)
• (10Gb/s)/(1712 bits/pkt) 5.841 Mpkt/s
• Ethernet Inter-Frame Spacing 96 bits
• Average Frame Size with Inter-Frame Spacing 1808
  bits
• (10Gb/s)/(1808 bits/pkt) 5.53 Mpkt/s
• LC Number of Lookups per second required
• 1 Ingress and 1 Egress lookup required per packet
• If we assume 6.25 MPkts/sec then we need 12.5 M
  Lookups/sec.
• MR/NPU Number of Lookups per second required
• 5 Gb/s per MR/NPU 3.125 M Lookups/sec
• Total of 6.25 M Lookups/sec
• Total Number of Lookup Entries to be supported?
• Dependent on Size of Entries

18
Keys and Results for Ingress LC and Egress LC

• Keys
• Ingress (Link ? Router)
• What fields in the External Frame Formats
  uniquely identify the MetaLink?
• First we have to identify the Substrate Link Type
• Then we can Identify the Substrate Link and
  MetaLink
• Egress (Router ? Link)
• What fields in the Internal Frame Format uniquely
  identify the MetaLink?
• Results
• We need to identify what fields are needed to
  build the appropriate frame headers.
• The fields needed may consist of several parts
• Constant fields constants in the LC Rx/Tx Code
• Calculated fields
• Things like TTL and Checksums
• Statically configured Fields that can be stored
  in Local Memory
• Things like per physical interface or Blade
  Ethernet Src Addresses
• ARP results for Ethernet DAddr on a Multi-Access
  link
• Lookup Result from TCAM
• Everything else
• Ingress (Link ? Router) Details later

19
Field Sizes in Keys and Results

• Field and Identifier sizes
• MR id 16 bits (64K Meta Routers per Substrate
  Router)
• MR ID VLAN (Defined locally on a Substrate
  Router)
• Note We can probably shorten this to 12 bits
  since our switch only supports 4K VLANs which is
  12 bits.
• MI id 16 bits (64K Meta Interfaces per Meta
  Router)
• This seems like a lot. What level of flexibility
  do we need to support?
• MLI 16 bits (64K Meta Links per Substrate
  Link)
• This seems safe and should not changed.
• Port 4 bits (16 Physical Interfaces per Line
  Card)
• Note I originally had this defined as 8 bits but
  since the RTM only supports 10 physical
  interfaces, 4 bits is enough. There were some
  places where the extra 4 bits pushed us to a
  larger size.
• QID 20 bits (QM_IDQueue_ID)
• Queue_ID 17 bits (128K Queues per Queue
  Manager)
• QM_ID 3 bits (8 Queue Managers per LC
  or PE.)
• We probably can only support 4 QMs, which could
  be encoded in 2 bits.
• (64 Q-Array Entries) / (16 CAM entries) ? 4 QMs
  per SRAM Controller.

20
LC Internal Frame Formats
Internal Frame Leaving Ingress LC
Internal Frame Arriving at Egress LC
Packet arriving On Port N
Packet leaving On Port M
LC
MR
Switch
Switch

IXP PE
21
LC External Frame Formats
P2P-DC (Configured)
Multi-Access
Legacy
22
LC TCAM Lookup Keys
Internal Frame Leaving Ingress LC
Internal Frame Arriving at Egress LC
Ingress LC
Egress LC

• Blue Shading Determine SL Type
• Black Outline Key Fields from pkt

P2P-DC (Configured)
P2P-VLAN0
P2P-Tunnel
Legacy
Multi-Access
23
LC TCAM Lookup Keys on Ingress
P2P-DC
24 bits
IPv4 Tunnel
72 bits
Legacy
24 bits
P2P-VLAN0
24 bits
MA
72 bits
DstAddr (6B)

• Blue Shading Determine SL Type
• Black Outline Key Fields from pkt

SrcAddr (6B)
Type802.1Q (2B)
TCI ? VLAN0 (2B)
TypeIP (2B)
Ver/HLen/Tos/Len (4B)
ID/Flags/FragOff (4B)
TTL (1B)
ProtocolSubstrate (1B)
Hdr Cksum (2B)
Src Addr (4B)
Dst Addr (4B)
MLI (2B)
LEN (2B)
Meta Frame
PAD (nB)
CRC (4B)
P2P-DC (Configured)
P2P-Tunnel
24
LC TCAM Lookup Results on Ingress

• We need the Ethernet Header fields to get the
  frame to the blade that is to process it next.
• We also need a QID and RxMI
• Ethernet header fields that are constants can be
  configured and do not need to be in the TCAM
  Lookup Result.
• Ethernet Header fields
• DAddr Depends on MetaLink
• SAddr Can be constant and configured per LC
• EtherType1 Can be a constant 802.1Q
• VLAN(TCI) Different for each MR
• EtherType2 Can be a constant Substrate
• TCAM Lookup Result (60b)
• VLAN (16b)
• RxMI (16b)
• DAddr (8b)
• We can control the MAC Addresses of the Blades,
  so lets say that 40 of the 48 bits of DAddr are
  constant across all blades and 8 bits are
  assigned and stored in the Lookup Result.
• Will 8 bits be enough to support multiple
  chasses?
• We could go up to 12 bits and still use 64bit
  Associated Data
• QID (20b)
• What about Ingress ? Egress Pass Thru MetaLinks?
• We will define a special Substrate VLAN for this
  use

25
Pass Thru MetaLinks and Multi-Access SLs

• When going MR ? LC-Egress the MR may provide a
  Next Hop MN Address for the LC to use to map to a
  MAC address.
• This is particularly used when the destination
  Substrate Link is Multi-Access and there may be
  multiple MAC addresses used on the same
  Multi-Access MetaLink.
• When going LC-Ingress ? LC-Egress for a pass
  through MetaLink, do we need to do something
  similar?
• This could arise when a MetaNet has hosts on a
  multi-access network but the first Substrate
  Router that these hosts have access to does not
  have a MR for that MN.
• However, I contend that if there is no MR on that
  access SR, then there is nothing there to
  discriminate between the multiple MN addresses on
  the single MA MetaLink and hence it cannot be
  supported.

26
Pass Thru MetaLinks and Multi-Access SLs
Host1
No way to communicate Next Hop addresses from MR
to distant LC
Host2
Host3
Host4
LC
LC
LC
ARP
ML
MR
MA Network
Host5
P2P SL
MA SL
Host6
Substrate Router1
Substrate Router2
Host7
Host8

HostN

• Implications
• We will not extend MA links across Substrate
  Routers and other Substrate Links.
• MetaNets must place a MR in the substrate router
  that terminates a MA Substrate Link on which they
  want to support hosts.

27
LC TCAM Lookups on Egress

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• The Lookup Result for Egress will consist of
  several parts
• Lookup Result
• Constant fields
• Calculated fields
• Fields that can be stored in Local Memory
• Some of these are common across all SL Types
• Other fields are specific to each SL Type
• Common across all SL Types (92b)
• From Result (44b)
• SL Type(4b)
• Port(4b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port

DstAddr (6B)
SrcAddr (6B)
Type802.1Q (2B)
VLAN (2B)
TypeSubstrate (2B)
TxMI (2B)
MnFlags (1B)
NhAddr (nB)
LEN (2B)
Meta Frame
PAD (nB)
CRC (4B)
28
LC TCAM Lookups on Egress

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (92b)
• From Result (44b)
• SL Type(4b)
• Port(4b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• P2P-DC Hdr (64b)
• Constant (16b)
• EtherType (16b) Substrate
• Calculated (0b)
• From Result (48b)
• Eth DA (48b)

29
LC TCAM Lookups on Egress

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (92b)
• From Result (48b)
• SL Type(4b)
• Port(4b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• MA Hdr (64b)
• Constant (16b)
• EtherType (16b) Substrate
• Calculated (0b)
• ARP Lookup on NhAddr (Is ARP cache another
  database in TCAM?) (48b)
• Eth DA (48b)

30
LC TCAM Lookups on Egress

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (92b)
• From Result (44b)
• SL Type(4b)
• Port(4b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• MA with VLAN Hdr (96b)
• Constant (32b)
• EtherType1 (16b) 802.1Q
• EtherType2 (16b) Substrate
• Calculated (0b)
• ARP Lookup on NhAddr (Is ARP cache another
  database in TCAM?) (48b)

31
LC TCAM Lookups on Egress

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (92b)
• From Result (44b)
• SL Type(4b)
• Port(4b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• P2P-VLAN0 Hdr (80b)
• Constant (16b)
• EtherType1 (16b) 802.1Q
• EtherType2 (16b) Substrate
• Calculated (0b)
• From Result (64b)

32
LC TCAM Lookups on Egress

• Result (continued)
• Common across all SL Types (92b)
• From Result (44b)
• SL Type(4b)
• Port(4b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• P2P-Tunnel Hdr for IPv4 Tunnel without VLANs
  (224b)
• Constant (64b)
• Eth Hdr EtherType (16b) 0x0800
• IPHdr Version(4b)/HLen(4b)/Tos(8b) (16b) All can
  be constant?
• IP Hdr TTL (8b) Initialized to a contant when
  sending.
• IP Hdr Proto (8b) Substrate
• Calculated (48b)
• IP Pkt Len(16b) Calculated for each packet.
• IP Hdr ID(16b) should be unique for each packet
  sent, so shouldnt be in Result.

33
LC TCAM Lookups on Egress

• Result (continued)
• Common across all SL Types (92b)
• From Result (44b)
• SL Type(4b)
• Port(4b)
• MLI(16b)
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• P2P-Tunnel Hdr for IPv4 Tunnel with VLANs (240b)
• Constant (64b)
• First Eth Hdr EtherType (16b) 802.1QS
• Second Eth Hdr EtherType (16b) 0x0800
• IPHdr Version(4b)/HLen(4b)/Tos(8b) (16b) All can
  be constant?
• IP Hdr TTL (8b) Initialized to a contant when
  sending.
• IP Hdr Proto (8b) Substrate
• Calculated (48b)
• IP Pkt Len(16b) Calculated for each packet.

34
LC TCAM Lookups on Egress

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (92b)
• From Result (44b)
• SL Type(4b)
• Port(4b)
• MLI(16b)
• Ignored for Legacy Traffic
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• Legacy (IPv4) with VLAN Hdr (96b)
• IP Header provided by MR!
• Constant (16b)
• EtherType1 (16b) 802.1Q
• Calculated (0b)

35
LC TCAM Lookups on Egress

• Key
• VLAN(16b)
• TxMI(16b)
• Result
• Common across all SL Types (92b)
• From Result (44b)
• SL Type(4b)
• Port(4b)
• MLI(16b)
• Ignored for Legacy Traffic
• QID (20b)
• Local Memory (48b)
• Eth Hdr SA (48b) tied to Port
• SL Type Specific Headers
• Legacy (IPv4) without VLAN Hdr (64b)
• IP Header provided by MR!
• Constant (0b)
• Calculated (0b)
• ARP Lookup on NhAddr (Is ARP cache another
  database in TCAM?) (48b)

36
LC Lookup Block Parameters

• All lookups will be Exact Match.
• Ingress
• Databases 1
• 4 bits in Key identify the SL Type
• 0000 DC
• 0001 IPv4 Tunnel
• 0010 Legacy (non-substrate) with or without VLAN
• 0011 VLAN0
• 0100 MA (with or without VLAN)
• Core Size 72b
• Key Size 24b - 72b
• AD Result Size 64b of which well use 60 bits
• Egress
• Databases 1
• Core Size 36b
• Key Size 32b
• AD Result Size 128b of which well use different
  amounts per SL Type
• With one problem to still work out.

37
SUMMARY LC TCAM Lookups

• Ingress Key Size 24 bits or 72 bits
• Ingress Result Size 60 bits
• Egress Key Size 32 bits
• Egress Result Size 128 bits
• The IP Tunnel with VLANs Substrate Link option is
  a problem.
• Discussion of ways to handle them are on next
  slide
• We also need to watch out for the Egress Result
  for Tunnels w/o VLANs. If we introduce anything
  else we want in there then we go beyond the 128
  bits supportable through the TCAMs Associated
  memory.

38
Handling IP Tunnel SL with VLANs

• Result Fields (144 bits)
• SL Type(4b)
• Port(4b)
• MLI(16b)
• QID (20b)
• Eth Hdr DA (48b)
• IP Hdr Dst Addr (32b)
• VLAN (16b)
• 128 bits is maximum size of a Result stored in
  TCAM Associated Data SRAM
• Options for handling this Result
• Not allow this type of SL
• Might be ok for short term but almost certainly
  not ok for long term.
• Find 16 bits we dont really need in Result
• Do a second lookup when we find a SL like this.
• Do a Multi-Hit lookup and put two entries in for
  these SLs and only one entry for all others.
• Then concatenate the two results when we get
  them.
• Only allow a small fixed number of this type of
  SL
• Store an index in the 4 bits we have left
• store the extra bits we need in a table in Local
  memory.

39
MR Lookup Block
Control
TCAM
XScale
XScale
DeMux
Rx
Parse
DeMux
Rx
Parse
Lookup
Lookup
Tx
HeaderFormat
Tx
HeaderFormat
MR (NPUA)
MR (NPUB)
40
Common Router Framework (CRF) Functional Blocks
Parse
HeaderFormat
Lookup
Tx
DeMux
Rx
MR-1
. . .
MR-n

• Lookup
• Function
• Perform lookup in TCAM based on MR Id and lookup
  key
• Result
• Output MI
• QID
• Stats index
• MR-specific Lookup Result (flags, etc. ?)
• How wide can/should this be?

41
MR Lookup Block Requirements

• Shared NP Lookup Engine specific
• Number of Lookups per second required
• 1 lookup required per packet
• 5Gb/s per NP on a blade
• If we assume 6.25 MPkts/sec for 10Gb/s then for
  5Gb/s would be 3.125 MPkt/s
• We would want 3.125 M Lookups/sec per LA-1
  Interface, total of 6.25 M Lookups/sec for the
  TCAM Core.
• Number of MRs to be supported?
• Will each get its own database? No. This would
  limit it to 16 which is not enough.
• How many keys will each MR be limited to?
• How much of Result can be MR-specific?
• How much of Key can be MR-specific?
• How are masks to be supported?
• Mask core is same size as Data core. One mask per
  Entry
• Global Mask Registers also available for masking
  key to match size of Entry during Multi Database
  Lookups where the multiple databases have
  different sizes.
• How will multiple hits across databases be
  supported?
• How will priorities be supported?
• Priorities within a database are purely by the
  order of the keys.
• For example, in a GM filter table if Keys 4 and 7
  both match, Key 4 is selected.
• Priorities across databases will have to be
  included in the Entries

42
IPv4 MR Lookup Entry Examples

• Route Lookup Longest Prefix Match
• Entry (64b)
• MR ID (16b)
• MI (16b)
• DAddr (32b)
• Mask (32 Prefix length) high order bits set to
  1
• GM Match Lookup
• Entry (148b)
• MR ID (16b)
• MI (16b)
• If we could shorten the MR/MI fields by a total
  of 4 bits this would fit in a 144 bit core size.
• SAddr (32b)
• DAddr (32b)
• Protocol (8b)
• Sport(16b)
• Dport(16b)
• TCP_Flags (12b)
• Mask Completely general, user defined.
• EM Match Lookup

43
IPv4 MR Lookup Databases

• How many databases to use?
• Three Options
• 3 a separate DB for each
• 2 one DB for GM and one for RL and EM
• 1 RL, GM and EM all in one DB
• 3 Databases
• Means we would use Multi Database Lookup (MDL)
  command
• More efficient use of CAM core entries as each DB
  could be sized closer to its Entry size
• Guaranteed at least one Result from each Database
  if an existing match existed in each database.
• 2 Databases
• We could use MDL command
• Guaranteed one Result from GM and one from either
  EM or RL but not both!
• Order is important
• EM filters would all go first in EM/RL DB, with
  full masks.
• At most one entry would match
• EM filters would always be higher priority than
  Routes.
• This seems ok. That is what is typically implied
  by an Exact match filter.
• If no EM filter match, we would get the best RL
  match.
• RL entries would be sorted by prefix length so
  first match was the longest.

44
IPv4 MR Lookup Key Examples

• Order matters
• Same Key will be applied to all Databases(MDL)
• Multi-Database Lookup (MDL)
• Each Database will use the number of bits it was
  configured for, starting at the MSB.
• DAddr field needs to be first
• TCP_Flags field needs to be last
• Route Lookup Longest Prefix Match
• Key (64b)
• MR ID (16b)
• MI (16b)
• DAddr (32b)
• GM Match Lookup Best/Range Match
• Key (148b)
• MR ID (16b)
• MI (16b)
• DAddr (32b)
• SAddr (32b)
• Protocol (8b)
• Sport(16b)

45
IPv4 MR Lookup Key Examples
Lookup Key 148 bits out of 5 32-bit words
transmitted with Lookup command.
DAddr(32b)
SAddr(32b)
TCP_Flags (12b)
Proto (8b)
DPort(16b)
SPort(16b)
Pad (12b)
MR ID (16b)
MI (16b)
W1
W2
W3
W4
W5
MDL
GMR
GMR
GMR
Core Entries for GM DB 148 bits Core Size 288
bits GMR0xFFFFFFFFF 0xFFFFFFFFF
0xFFFFFFFFF 0xFFFFFFFFF
0xF00000000 0x000000000
0x000000000 0x000000000
46
IPv4 MR Lookup Result Examples

• Result
• QID(20b)
• Output MI (16b)
• Priority(8b) range 0-255
• Drop(1b)
• Stats Index (16b) 65535 indices for stats
• If we need to put anything else in Result, bits
  should be taken from here.
• Total of 45 bits
• Each Database will have 64 bits of associated
  data, of which we will use the low order 61 bits.
• And for MDL lookups only 61 of 64 bits of
  Associated Data is returned.
• RTN1b
• ADSP1b
• AD WIDTH01b
• Results Mailbox
• D Done (1b) set to 1 when ALL searches are
  completed.
• H Hit (1b) set to 1 if the search was
  successful and result is valid, 0 otherwise
• MH MHit (1b) set to 1 if search was successful
  and there were additional hits in database.
• R Reserved bits.
• AD (Associated Data) 61 of the 64 bits of
  Associated Data from the Associated Data ZBT SRAM
  attached to TCAM.

Results Mailbox
AD6032 (1st Search)
D
MH
H
AD31 0 (1st Search)
AD6032 (2nd Search)
H
MH
R
AD31 0 (2nd Search)
AD6032 (3rd Search)
H
MH
R
AD31 0 3rd Search)
Not Used
Not Used
47
IPv4 MR Database Core Sizes

• Route Database
• Core Size 72b
• Entries per Segment 8K
• Number of Entries needed per route 1
• Number of Routes per Segment 8K
• GM Database
• Core Size 288b
• Entries per Segment 2K
• Number of Entries needed per filter dependent on
  filter
• Number of Filters per Segment lt 2K
• EM Database
• Core Size 144b
• Entries per Segment 4K
• Number of Entries needed per filter 1
• Number of Filters per Segment 4K
• Configuration used in our FPX-based Router
• 32 GM filters
• 10K Ingress EM Filters
• 10K Egress EM Filters

48
IPv4 MR Database AD Usage

• Each Segment can be configured with a Base
  Address and a result size for calculating an
  address into the Associated Data.
• The Associated Data is stored in a 512K x 36 bit
  ZBT SRAM
• Using 64bit Results will give us 256K slots in
  the AD SRAM.
• 48K Route DB Entries
• lt 2K GM DB Entries
• 20K EM DB Entries
• Max Total of 70K Results needed.
• Plenty of room in the AD for the IPv4 MR Results

49
MPLS Lookup

• MPLS uses a 20 bit Label
• Key (52 bits)
• MR ID (16b)
• MI (16b)
• MPLS_Label (20b)
• Use an Exact Match Database
• MPLS Label Database
• Core Size 72b
• Entries per Segment 8K
• Number of Entries needed per label 1
• Number of Labels per Segment 8K
• Drop Bit
• Does MPLS need a Drop Bit?
• Perhaps it would use a Miss as the same thing as
  Drop. That is, the fact that a label is not
  entered in the Database is an indication that
  frames using that label should be dropped.
• But, if we explicitly have a drop bit than Hits
  on those Entries could be counted separately from
  Misses.
• What will MPLS Label Lookup Result look like?
• New Label (20 bits)
• QID(20b)
• Output MI (16b)

50
MPLS Lookup Result Examples

• Result
• Reserved (3b) Dont uses these, they will not
  show up in Results Mailbox.
• New Label (20b)
• QID(20b)
• Output MI (16b)
• Stats Index(16b)
• Drop bit (1b)
• Total of 73 bits (76 counting reserved bits)
• DB will use 128 bits of associated data and will
  return the Associated Data followed by the
  Absolute Index.
• We dont need the Absolute Index and we dont
  need the top 3 bits of the AD. With this ordering
  we just have to read the first 4 words on the
  results Mailbox instead of 5.
• RTN1b
• ADSP1b
• AD WIDTH10b
• Results Mailbox
• D Done (1b) set to 1 when search is completed.
• H Hit (1b) set to 1 if the search was
  successful and result is valid, 0 otherwise
• MH MHit (1b) set to 1 if search was successful
  and there were additional hits in database.
• Absolute Index Index offset from beginning of
  TCAM array.
• Associated Data 128 bits of Associated Data from
  the Associated Data ZBT SRAM attached to TCAM.

Associated Data 12496
D
MH
H
Associated Data 9564
Associated Data 6332
Associated Data 310
Results Mailbox
Absolute Index210
Reserved3122
Not Used
Not Used
Not Used
51
Lookup Block
CTX-0
NSE
QDR SRAM NSE Interface
TCAM
SRAM Controller
CTX-1
In NN Ring
Out NN Ring
. . .
. . .
CTX-2
KEY
KEY
KEY
KEY
Result
Result
Result
Result
. . .
CTX-7
52
Lookup Block

• In NN !Empty
• Input NN Ring is not empty, something for us to
  read.
• Out NN !Full
• Output NN Ring is not full, space for us to write
  to it.
• NSE Result Read Done
• Our Read of Results Mailbox has completed.
• Next_Ctx Start
• Our turn to read from the In NN Ring.
• Next_Ctx Done
• Our turn to write to the Out NN Ring.

Next_Ctx Start
Next_Ctx Done
NSE Result Read Done
CTX-x
In NN !Empty
Out NN !Full
Next_Ctx Start
Next_Ctx Done
53
Ingress LC Lookup Block Pseudocode

• Initialization Phase
• Start
• Wait on ((Next_Ctx Start signal) and (In NN Ring
  !Empty signal))
• Phase 1
• Assert Next_Ctx Start signal
• Read In NN Ring(buf_handle, Key, SL_Type)
• Extract Key of correct size based on SL_Type
• Build Lookup command (IDT Macro)
• Send Lookup command to NSE (sram write
  instruction)
• Calculate Delay Time and Wait (IDT Macro)
• Phase 2
• Issue Command to Read Result from Results Mailbox
  (IDT Macro)
• Macro does Wait for Result and checks Done bit
  and continues to read until Done bit is set.
• Wait for ((Next_Ctx Done signal) and (Out NN Ring
  !Full signal))
• Phase 3
• Assert Next_Ctx Done signal
• Send (buf_handle, Result) to Out NN Ring
• Wait on ((Next_Ctx Start signal) and (In NN Ring
  !Empty signal))

54
Egress LC Lookup Block Pseudocode

• Initialization Phase
• Start
• Wait on ((Next_Ctx Start signal) and (In NN Ring
  !Empty signal))
• Phase 1
• Assert Next_Ctx Start signal
• Read In NN Ring(buf_handle, Offset, Key)
• Extract Key of VLAN and TxMI
• Build Lookup command (IDT Macro)
• Send Lookup command to NSE (sram write
  instruction)
• Calculate Delay Time and Wait (IDT Macro)
• Phase 2
• Issue command to Read Result from Results Mailbox
  (IDT Macro)
• Macro does Wait for Result and checks Done bit
  and continues to read until Done bit is set.
• Wait for ((Next_Ctx Done signal) and (Out NN Ring
  !Full signal))
• Phase 3
• Assert Next_Ctx Done signal
• Send (buf_handle, Offset, Result) to Out NN Ring

55
IPv4 MR Lookup Block Pseudocode

• Initialization Phase
• Initialize GMR_GM, GMR_EM, GMR_RL for each
  type/size of lookup database/key
• Start
• Wait on ((Next_Ctx Start signal) and (In NN Ring
  !Empty signal))
• Phase 1
• Assert Next_Ctx Start signal
• Read In NN Ring(buf_handle, dram_ptr(?), Offset,
  MR_Id, Input_MI, MR_Mem_Ptr, Key)
• Extract Key of 124 bits
• Build Multi Database Lookup (MDL) command using
  Key and GMR_GM, GMR_EM, GMR_RL
• IDT Macro
• Send MDL command to NSE (sram write
  instruction)
• Calculate Delay Time and Wait (IDT Macro)
• Phase 2
• Issue command to Read Result from Results Mailbox
  (IDT Macro)
• Macro does Wait for Result and checks Done bit
  and continues to read until Done bit is set.
• If no hits, zero Out_Result and then set Miss bit
• Else compare priority of hits and select highest
  priority and write into Out_Result
• Wait for ((Next_Ctx Done signal) and (Out NN Ring
  !Full signal))

56
Intel/IDT NSE/TCAM Tools

• Tools
• Libraries
• Macros
• Etc.

57
Extra

• The next set of slides are for templates or extra
  information if needed

58
Text Slide Template
59
Image Slide Template
60
IPv4 MR Lookup Result Examples

• PROBLEM one problem with using the MDL is that
  we do not get an index back with our results.
• Hence we will not be able to easily increment a
  counter based on the lookup result.
• Multi Database Lookup (MDL) cmd returns one and
  only one of the following per database searched
• Absolute Index
• Translated Index
• Associated Data
• Lookup cmd returns
• Absolute Index followed by Associated Data
• Associated Data followed by Absolute Index
• Translated Index
• Options 1
• three back-to-back Lookup cmds, one for each
  database.
• Each result would provide us with the
• result data
• Index
• This requires 3 times the number of lookups in
  the TCAM.
• Option 2
• Use MDL but have result include the index and not
  the data.
• We would then have to have the result data in a
  separate memory that we would then read.

61
MPLS Lookup Result Examples

• Note No Stats Index included in Results
• Option 1
• Use the Absolute Index returned with the
  Associated Data, to locate a counter to increment
• Option 2
• Increase the result size to 128 bits.
• This would also allow us to put the Drop bit in.
• Result
• New Label (20b)
• QID(20b)
• Output MI (16b)
• Stats Index(16b)
• Drop bit (1b)
• Total of 73 bits
• Lets go with Option 2.

62
TCAM Latency Data

• IDT App Note AN-459 IDT75K72234 Instruction
  Latency
• Provides data and examples for latency
  calculations
• Assumptions
• The NSE has no instructions in the pipeline
• The measured instruction is the only instruction
  issued
• The other NSE interfaces are idle.

63
TCAM Latency Data

• Example from IDT App Note AN-459
• 288-bit Lookup (288/32 9 QDR cycles to transfer
  288 bit key)
• 32-bits of Associated ZBT SRAM data is returned
• QDR clock frequency is 200 MHz
• System clock frequency is 200 MHz

• Execution Latency numbers are from Table 1 of
  AN-459

64
TCAM Latency Data

• Parameters for our LC Ingress Lookup
• 128-bit Lookup (128/32 4 QDR cycles to transfer
  128 bit key)
• 128-bits of Associated ZBT SRAM data is returned
• QDR clock frequency is 200 MHz
• System clock frequency is 200 MHz
• Core Blocking (CB) Delay 8 cycles
• Backend Latency 14 cycles

65
TCAM Latency Data

• Parameters for possible LC Ingress Lookup
• 72-bit Lookup (72/32 3 QDR cycles to transfer
  72 bit key)
• 128-bits of Associated ZBT SRAM data is returned
• QDR clock frequency is 200 MHz
• System clock frequency is 200 MHz
• Core Blocking (CB) Delay 8 cycles
• Backend Latency 14 cycles

66
TCAM Latency Data

• Parameters for possible LC Ingress Lookup
• 72-bit Lookup (72/32 3 QDR cycles to transfer
  72 bit key)
• 64-bits of Associated ZBT SRAM data is returned
• QDR clock frequency is 200 MHz
• System clock frequency is 200 MHz
• Core Blocking (CB) Delay 4 cycles
• Backend Latency 10 cycles

67
TCAM Latency Data

• Parameters for possible LC Ingress Multi Hit
  Lookup
• 72-bit Lookup (72/32 3 QDR cycles to transfer
  72 bit key)
• 64-bits of Associated ZBT SRAM data is returned
• QDR clock frequency is 200 MHz
• System clock frequency is 200 MHz
• Core Blocking (CB) Delay 6 cycles
• Backend Latency 10 cycles

68
IDT Data Plane Macro API

• IDT provides a set of macros for creating
  commands to the TCAM
• Here are some that will be particularly useful to
  us
• IipcMakeBase()
• IipcMakeDirectInstruction()
• IipcMakeIndirectInstruction()
• IipcMakeSubInstruction()
• IipcQDRDelay()
• IipcNPUDelay()
• IipcSignalXXXDone()
• IipcSramRead()
• IipcFormContextFromCsrMeCtx()
• IipcMake36BitLookupInstruction()
• IipcSramReadResultStatus()

69
IDT Data Plane Macro API

• IipcSramRead()
• .sig sramread
• .reg t00, t01, t02, t03,
  t04, t05, t06, t07
• .xfer_order_rd t00 t01 t02
  t03 t04 t05 t06 t07
• .set t00, t01, t02, t03,
  t04, t05, t06, t07
• Read the first word, re-try the reading
  until Done bit is set
• SRAMREAD
• sram read, t00, base, 0x0, 1 ,
  ctx_swap sramread
• br_bclr t00, 31, SRAMREAD
• Now, read again to make sure the index
  is set correctly when the Done bit is cleared
• sram read, t00, base, 0x0,
  amount , ctx_swap sramread
• Manually set the Done bit on the
  returned result
• immed_w0 result0, 0x0000
• immed_w1 result0, 0x8000
• alu result0, result0, or,
  t00

70
IDT Data Plane Macro API Example

• Example of a Direct Lookup command
• channel 0
• select 0
• context 4
• IipcMakeBase iipc_base_word, 0x0,
  IIPC_DOUBLE_32MB_SELECT_0, 0x4
• instruction 0 (IIPC_LOOKUP)
• gmask 31 (no GMR)
• database 0 (database 0)
• IipcMakeDirectInstruction iipc_command_word,
  IIPC_LOOKUP, IIPC_NO_GMASK, 0x0
• Create the 72 bit search key to lookup in the
  write transfer registers.
• key 0xBBBBBBBBBBBBBBBBBB
• immed_w0 data, 0xBBBB
• immed_w1 data, 0xBBBB
• alu w00, --, B, data
• immed_w0 data, 0xBBBB
• immed_w1 data, 0xBBBB
• alu w01, --, B, data

71
TCAM Performance

• Three Performance metrics
• Single LA-1 Max Lookup Rate
• CAM Core Max Lookup Rate
• Associated Data Width
• IXP/TCAM LA-1 Interface
• 16 bits wide
• 200 MHz QDR
• Effectively 32bits per clock tick
• So getting Key in and Result out is 32bits/tick
• Example 128b Key would take 4 ticks to get
  clocked into TCAM.
• Max of 50 M Lookups/sec
• Example 128b results from ZBT SRAM via TCAM
  would take 4 ticks to get clocked out of TCAM.
• Max of 50 M Results/sec
• Performance Numbers
• Key Size (200MHz, 16 bit Interface for commands)
• Rates are max PER LA-1 Interface, up to CAM Core
  max rate
• 32b (1W) 50M Lookups/sec (CAM Core
  constraint)
• 36b (2W) 50M Lookups/sec (CAM Core
  constraint)
• 64b (2W)100M Lookups/sec (Interface
  constraint)

72
TCAM Performance

• Performance Numbers (continued)
• Result Type
• Index or Pointer Types
• Key Size Max CAM Core lookup rate
• 36b 50M/sec
• 72b 100M/sec
• 144b 100M/sec
• 288b 50M/sec
• 576b 25M/sec
• Associated Data CAM Core rates
• These rates are Total across both LA-1 Interfaces
• Key Size (32b Result Rate, 64b Result Rate, 128b
  Result Rate)
• 36b 50, 50, 25
• 72b 100, 50, 25
• 144b 100, 50, 25

73
TCAM Performace Tables
74
TCAM Performace Graphs
75
TCAM Performace Graphs
76
OLD

• The rest of these are old slides that should be
  deleted at some point.

77
START LC-Rx With MA SL on a PT ML

• This set of slides is with the assumption that we
  DO need to support a MA SL on one of a Pass
  Through MetaLink

78
SUMMARY LC TCAM Lookups

• Rx Key 72 bits
• Rx Result Size 61 bits
• 61 bits if there is no need for NhAddr
• Multiple results if there is a need for NhAddr,
  see earlier discussion.
• Tx Key Size 32 bits
• Tx Result Size 128 bits
• We need to watch out for the Tx Result for
  Tunnels. If we introduce anything else we want in
  there then we go beyond the 128 bits supportable
  through the TCAMs Associated memory.

79
LC TCAM Lookup Keys on RX
Port(8b)
MLI(16b)
P2P-DC
24 bits
IPv4 Tunnel
72 bits
Port (8b)
MLI (16b)
IP SAddr (32b)
EtherType (16b) 0x0800
MA
Port (8b)
MLI (16b)
Ethernet SAddr (48b)
72 bits
P2P-VLAN0
Port(8b)
MLI(16b)
24 bits
Legacy
24 bi
