PENS PAN EUROPEAN NETWORK SERVICES

1
PENSPAN EUROPEAN NETWORK SERVICES

• An overview

2
Agenda

• Why PENS
• What is PENS
• PENS Technical overview
• PENS Governance Financials
• PENS Management Unit
• Conclusion

3
Why PENS

• Current data communications in the air traffic
  management industry heavily rely on X.25, a
  technology that is about to be phased out (OLDI,
  ASTERIX, AFTN/CIDIN )
• Most inter- ANSP links are bilateral point to
  point circuits, managed on a bilateral basis
• CFMU and EAD have separate networks with
  different providers
• Future air traffic management will require
  tighter collaboration between all stakeholders
• Business case demonstrated that overall costs
  could be reduced by 15.
• The technical enabler for this is a common shared
  network PENS

4
PENS the future of aeronautical communications
5
Agenda

• Why PENS
• What is PENS
• PENS Technical overview
• PENS Governance Financials
• PENS Management Unit
• Conclusion

6
What is PENS

• A joint EUROCONTROL / ANSP led initiative to
• provide a common IP based managed network service
  across the European region
• covering data and voice communications
• and providing efficient support to
• existing services
• and new requirements that are emerging from
  future Air Traffic Management (ATM) concepts
  (incl. SESAR).
• In line with the SES-2 regulation (FMTP
  Implementation Regulation)

7
PENS scope - Applications

• Today
• AMHS (AFTN/CIDIN transition)
• Inter-centre coordination (FMTP)
• CFMU terminals
• EAD
• ETFMS data collection / distribution
• Circuit emulation (voice)
• .

• Tomorrow
• Surveillance information distribution
• Voice over IP (VoIP)
• Become the SWIM backbone within the SESAR
  initiative

8
PENS scope - Users

• Today
• CFMU
• EAD
• ANSP
• SESAR (validation)
• FABs

• Tomorrow
• Airlines
• Airports
• ATM industry

9
Potential PENS Applications
10
Benefits of PENS
11
The PENS users status
SPAIN DENMARK SWEDEN EUROCONTROL
UK IRELAND ITALY PORTUGAL SLOVAKIA
AUSTRIA BULGARIA SWITZERLAND GERMANY FRANCE HUNG
ARY POLAND
Letter of intent signed
Common procurement Agreement signed
Contract signed
on behalf of the RAPNET community
12
PENS users status
13
Agenda

• Why PENS
• What is PENS
• PENS Technical overview
• PENS Governance Financials
• PENS Management Unit
• Conclusion

14
PENS architecture robust and secure
Remote Site
Primary VC

Primary CE1
P Router
PE1
Core Network
Access Connections
VRRP
PE2
Secondary CE2
MTN / AGN Network
Secondary VC
Local Preference Between Primary Secondary
Path
Weight Between Primary Secondary Path
15
A shared infrastructure
EAD Main Site

VRRP If Link Failure
ANSP BB Site

Primary CE
EAD VPN
PE
CFMU Host Site

VRRP
CFMU VPN
Access Connections
VRRP
IPVPN
ANSP VPN
Secondary CE

VRRP
EAD User
CFMU User
ANSP
ANSP BBSite
16
PENS Transition planning

• Project Initiation Plan Accepted
• Cut-off date for newcomers

First ASNP site accepted
Commencement date
3 months
5 months
Overall transition 18 months
December 1st, 2009
17
Agenda

• Why PENS
• What is PENS
• PENS Technical overview
• PENS Governance Financials
• PENS Management Unit
• Conclusion

18
PENS Governance
ANSPs
EAD
CFMU
PEN Services Steering Group PSSG
PENS User Group PUG
PENS Management Unit
Network Service Provider (NSP)
19
Agenda

• Why PENS
• What is PENS
• PENS Technical overview
• PENS Governance Financials
• PENS Management Unit
• Conclusion

20
PMU mission statement

• Under the guidance of PSSG (PEN Services
  Steering Group), the PENS Management Unit shall
  carry out the day to day management of the PENS,
  including planning, monitoring the service and
  liaising with the NSP (SITA) and the PENS users
  (CFMU, EAD, ANSPs )

21
PMU Roles Responsibilities
Pan European Network Services
22
PMU Main interactions
NSP
PMU
USERS
23
Agenda

• Why PENS
• What is PENS
• PENS Technical overview
• PENS Governance Financials
• PENS Management Unit
• Conclusion

24
The joint PENS teamANSPs, SITA EUROCONTROL
Contact us at pens_at_eurocontrol.int
