Bud Basu, VP Product Management

1
Demystifying the Complexities in IP Convergence

• Bud Basu, VP Product Management
• February 7, 2006

2
What Does Convergence Mean?
Integrate and transport voice, fax, video and
data traffic on single, IP-based network
One structure, one architecture to support all
forms of information media on all forms of
network technology
Convergence is the term for combining personal
computers, telecommunications, and television
into a single user device
An integrated communications and IT
infrastructure, based on Internet Protocol (IP)
networking with guaranteed quality of service
(QoS)
Business combined with entertainment traffic
IP convergence refers to the integration and
transfer of voice, fax, video and data traffic on
a single, IP-based network.
Wired combined with wireless transmission
Convergence is all about merging voice and data
onto a single IP-based network
All information media on one network
Now, Ive got it. That was simple.
The coming together of two or more disparate
disciplines or technologies.
Convergence refers to the trend for some set of
technologies initially having distinct
functionalities to evolve to having those that
overlap.
Congratulations Pittsburgh Steelers!  Superbowl
XL Champions!
3
Agenda

• What Our Customers Are Telling Us
• Challenges To Consider
• The Big Picture Global Crossings Perspective
• Simplifying Your Migration to a Converged Service
  Environment

Global Crossing Company Proprietary
4
We Listen Carefully To Customers Needs

• Customers want to
• Mitigate risk and minimize capital expenditures.
• Converged IP is driving the demand for managed
  services.
• Customers realize advantages of lease versus
  purchase with no upfront capital expenditure
  router payments can be made over the longer term.
• Simplify the complexities inherent in
  convergence.
• Maintaining application performance across the
  LAN/WAN.
• Ensuring security and maintaining control.
• Migration interoperability from legacy to IP,
  including a full set of features regardless of
  where you are in the migration.
• Mixed environment support.
• Migrate to IP at their own their pace.
• VoIP and conferencing are driving convergence.
• Adapting the pace of migration to the needs of
  the business.

Global Crossing Company Proprietary
5
We Listen Carefully To Customers Needs

• Do more with less.
• Compression technologies
• Online QoS
• Bandwidth link efficiencies
• Realize more than cost savings from VoIP.
• Expand eBusiness capabilities click to talk
• Global seamless services
• Improved productivity for a more mobile workforce
  follow me features
• Get more than a pipe.
• Networking has become more strategic
• IP applications are mission critical
• Help with the engineering and design of solutions

Global Crossing Company Proprietary
6
Why are Companies Converging Networks?
The Benefits of IP Convergence Driven by Business
Needs
Global Crossing Company Proprietary
7
The Premise Being
A convergence strategy that is integrated with
corporate business objectives becomes the means
by which an enterprise can truly gain the full
benefits of convergence
Global Crossing Company Proprietary
8
IP Convergence Defined

• An end-to-end service environment where all
  networking applications voice, video, data and
  rich-media are managed and delivered on a
  single secure IP based network
• Holistic view of convergence
• WAN
• LAN
• Network Applications
• Operations

One Connection, Any Service
Global Crossing Company Proprietary
9
However
before you can get there.
Global Crossing Company Proprietary
10
Complexities For Enterprises To Consider
Customer Challenge
Business Driver
Considerations

• Size, Reach
• End user profile
• Existing/new equipment
• Contractual commitments
• Impact on systems and processes
• Financial
• Organizational
• Skill set of existing resources
• Insource vs Outsource

• Network planning and design
• Implementation approach
• Complexity of managing new technology

• Cost Savings

Increased Productivity
Global Crossing Company Proprietary
11
Complexities For Enterprises To Consider
Customer Challenge
Business Driver
Considerations

• of teleworkers and benefits of remote desktop
  functions
• Multimedia collaboration services
• Carrier hosted VoIP solutions
• Managed solutions
• Self service portal for network management
• Skill set of existing resources
• Individual applications still need to be managed
• Benefits of managed solutions

• Which applications will really drive increased
  end user productivity?
• Which capabilities will truly streamline internal
  IT/telecom workflow?
• Is one multi-application network really easier to
  manage than multiple one application networks?

• Improved Efficiencies

Network Simplification
Global Crossing Company Proprietary
12
CIO Needs

• Technology
• Access to a wide variety of real-time voice, data
  and multimedia IP applications
• Interoperability both at the network (Frame, ATM,
  and IP) and application level
• Globally predictable network and application
  performance
• Globally consistent availability of applications
  on an access agnostic basis
• Security
• Protection of private network and information
  from public network and information
• Legal and regulatory compliance
• Protection on physical layers as well as secure
  and segregate logical layer
• Support
• Customer support that is globally consistent and
  available in-region
• Extended global managed solutions services with
  in-region feet on the street
• Experienced design and planning professionals
• Control
• Network management tolls including sophisticated
  self-service tools
• Simplicity
• On-demand/software driven
• Future proof platform

CIOs Have a LOT on Their Minds!
Global Crossing Company Proprietary
13
Our Approach
We Listened We Defined The Solution
We Built The
Model
Global Crossing Company Proprietary
14
The Big Picture IP Converged Service Model
Global Crossing Company Proprietary
15
Service Convergence
Global Crossing Company Proprietary
16
The Global Crossing Converged IP Network
Architecture One Network, Any Service
iMPLS Option A, B, C
Enterprise
Global MPLS 2547bis Network
IP PBX
PSTN
On-Net Call
IP
VoIP
IP VPN
GSX
Session Border Controller
Off-Net Call
Hybrid TDM / IP Audio Conferencing
IPVPN/ DIA
SIP IP Phones
Video Conferencing
IPSec

• Flexible Pricing
• Billing
• Sham Links
• MLPP

Global Crossing Company Proprietary
17
Our Approach
We Listened We Defined The Solution
We Built The
Model We Simplified
Global Crossing Company Proprietary
18
Sample Enterprise Customer Location
19
Sample Enterprise Network Environment
Migrate to convergence at your own pace.
Global Crossing Company Proprietary
20
Convergence Solution Case Study

• Company Profile ASG is a leading enterprise
  software/professional services provider to global
  5000 companies with more than 45 offices serving
  North America, Europe, Middle East, Africa and
  Asia Pacific. ASG has approximately 900 employees
  and 7,000 customer sites, connected by a Frame
  Relay network.
• Business Challenge ASG needed to maximize
  legacy infrastructure investment, while saving on
  travel and maintaining employees communications
  with customers.
• Solution and Benefits GC offered a IP VPN
  converged services platform providing any-to-any
  connectivity for over 40 locations on four
  continents. Hybrid implementation securely
  transports ASGs voice, data, and
  videoconferencing applications over Global
  Crossing MPLS based IP VPN global network. ASG
  enjoys unique, secure self-service portal with GC
  uCommand. ASG can re-route toll-free global
  support numbers in the event of outage, ensuring
  business continuity.

Global Crossing is a true partner. The account
team thinks about our needs strategically, and is
fully dedicated to supporting our business with
state-of the-art solutions that deliver
measurable returns. This long-term partnership
enables us to leverage the superb performance,
cost efficiencies and simplified network
management of a converged IP environment. Alan
G. Bolt, Sr. Vice President and General Manager
Global Crossing Company Proprietary
21
Tips To Consider

• Customer Environment
• You do not need to know every detail to start
  your migration
• You do need to know where you are, your pain
  points, your vision
• Let each phase of the migration stand on its own
  merit
• Ensure each phase meets your immediate needs for
  cost savings, increased productivity, improved
  efficiencies and network simplification
• Plan for QoS Implementation, Link Optimization,
  WAN Bandwidth and Trending/Change Analysis

• Partner with a Service Provider who
• Helps you build a convergence phased
  implementation approach
• Has a holistic, access agnostic approach to
  Convergence
• Provides the flexibility to support your current
  and future business needs
• Will ensure that your CIO need for technology,
  security, support and control are met within each
  phase of your migration

An IP Convergence Strategy Driven by Your
Business Needs
Global Crossing Company Proprietary
22
A Worldwide IP Network for Todays Global Business
Global Crossings highly secure IP network is
managed and operated end-to-end. It is a network
that will not be replicated in the near future,
if ever.
Global Crossing Company Proprietary
23
Discussion
