Title: ICCAP Project


1
ICCAP Project
  • Wk 11

2
ICCAP
  • ICCAP Integrated Circuit Characterization Program
    by Agilent Technologies
  • Used in Junior Lab along with A5631 DC Source
    Monitor to DC characterize BJT,s and FETs.
  • Can also be used with microwave network analyzer
    to extract device capacitance model.

3
2 port circuit models
  • Two port circuit model relate voltages and
    currents of two pairs of terminals in a 2x2
    matrix form. Current into the ports is considered
    positive. Usually one of the two terminals at
    each port is considered grounded.
  • Various forms are possible depending on how the
    voltages and currents are arranged. The include
    Z, Y, H, G, T, and S parameter form.

4
Two port impedance Z parameters
  • The two port Z parameter equations are
  • Z11 and Z22 can be obtained by applying a source
    to a port with the opposite port open circuit
    making that that port current zero.
  • Z12 and Z21 can be obtained by applying a forced
    current to a terminal pair and measuring the
    opposite terminal open circuit voltage.

5
Two port admittance Y parameters
  • The two port admittance equations are
  • Y11 and Y22 can be obtained by applying a source
    to a port with the opposite port short circuited
    making that port voltage zero.
  • Y12 and Y21 can be obtained by applying a forced
    voltage to a terminal pair and measuring the
    opposite terminal short circuit current. (Note I
    positive into terminal).

6
FET two port admittance Y parameters
  • FET Y parameters have a PI shaped capacitor
    arrangement Cgs, Cgd, Cds with a transconductance
    voltage dependant current source in parallel with
    Cds.
  • The Y parameter matrix is then
  • Measured AC data can be used to find Cgd from
    Y12. Then Cgs can be found from Cgd and Y11. Cds
    can be found from Y22 abd Cgd. Lastly gm can be
    found from the real part of Y21.

7
H and ABCD parameters
  • Less common are the H parameters used for BJTs
    where H21 (also called hfe) is beta
  • The ABCD parameters solve port to port connection
    by taking the matrix product in ABCD form.

8
Parallel and Series Two Port
  • Parallel two port connection connects the same
    port pins of two circuits together. Parallel
    connected two port admittance matrices add.
  • Series two port connection connects the upper
    port 1 of one circuit to the lower port 1 pin of
    the second circuit and the upper port 2 of the
    first circuit to the lower port two of the second
    circuit. Series connected two port impedance
    matrices add.

9
S parameters
  • Microwave network analyzers measure the
    transmitted and reflected power waves of a
    circuit referred to as the S parameters.
  • The S parameters are complex numbers with
    magnitude and phase.
  • The reflection and transmission depend on the
    impedance of the transmission lines (cables)
    involved usually 50 ohms.
  • The S parameters can be converted to Y or Z
    parameters if the transmission line impedance is
    known.

10
S to Y parameter conversion
  • The Y admittance matrix in terms of S parameters
    is given as
  • ICCAP directly controls the network analyzer to
    get the s parameters and has built in software
    for s to Y or Z conversion and Y to Z or Z to Y
    conversion.

11
Deembedding
  • Network analyzer measurement relies on
    calibration to know standards that fix the
    reference locations pr planes.
  • Additional transmission line, parasitic
    inductance, capacitance, and resistance occur
    between the reference plane and the device.
  • A circuit with a transmission line between the
    reference planes, another circuit without a
    device, and another with a shorted replacing the
    device can be used to measure the parasitic
    elements.
  • Once the transmission line and parasitic element
    values are known they can be removed by
    deembedding.
  • The transmission line is removed by
    multiplication in the s parameter domain.

12
Deembedding 2
  • S parameters are converted to Z parameters.
  • Known parasitic series inductance and resistance
    are removed in the Z domain by subtraction.
  • The remaining Z parameters are converted to Y
    parameters.
  • Known parasitic capacitors in parallel connection
    are removed by subtracting Y matrices.
  • The remaining intrinsic device Y parameters are
    then used to extract the device parameters Cgs,
    Cgd, Cds, gm, etc. depending on the device model.
