Spinner II Model 600 HD Cone Crusher Application

1
(No Transcript)
2
Spinner II Model 600 HD Cone Crusher Application
3
Debris Removed In 1 Week7.5 Pounds
4
Spinner II Model 200 HD Hauler / Loader
Applications
5
Spinner Model 996 removes 1 pound of debris after
1000 hours on a Caterpillar 3408
6
Spinner II, The Principle
7
Barrier Filtration

• Removes Particles By Size
• Fine Filtration Requires
• Larger or More Filters
• Frequent Changing

8
Centrifugal Cleaning

• Removes Particles By Weight
• Less Than One Micron
• No Bypassing or Channeling

9
Centrifugal Oil Cleaners

• Uses Centrifugal Force to remove Debris from your
  oil stream
• Extends Engine / Component Life
• Extends Lube Oil Life
• Used widely in
• Marine Industry
• Natural Gas Pipeline Compression
• Heavy Duty Fleet
• Public Transit
• Construction Equipment

10
Spinner II Operation

• Bypass Oil Cleaner
• Self Powered Centrifuge
• Generates 2000 Gs
• Sized to turn over the sump capacity 5 to 10
  times/hour

11
Spinner II, The Benefit
12
Spinner II Advantage

• Extended Oil Life

Condemnation Limit

• Extended Engine/Component Life

13
Extended Oil-Life

• Dispersant additives keep the soot in suspension.
• Detergent additives prevent the build-up of
  sludge.
• Anti-wear additives work by providing a
  sacrificial chemical-to-chemical Barrier.
• The amount of soot suspended in the oil plays a
  significant part in influencing the performance
  of these type of additive.

14
Spinner II Extends Oil Life

• Reduced Solid Contaminant Levels
• Extend Lubricant Additive Life
• Reduced Oxidation and Nitration
• Decreased Rates of TBN Depletion

15
Extended Engine Life

• Full-flow element filters guard against larger
  particles that might cause a catastrophic engine
  failure.
• Bypass filters capture the smaller particles that
  are responsible for long-term engine wear.

16
Bypass Comparison
150
50
Reduction in Wear Chart
17
Particle Size Distributioncaptured by the
Spinner II Centrifuge

• Percentage Micron Size
• 10 less than...1.1 microns
• 50 ............1.5 microns
• 75 ............2.1 microns
• 98 ............5.0 microns

18
Solids Collected By The Centrifuge Include three
major diesel engine contaminant types as analyzed
by physical chemistry
19
Increased Equipment Utilization

• Extended Oil Service Life
• Extended Full Flow Filter Life
• Extended Service Intervals
• Extended Component Life
• Extended Mean Time Between Overhaul
• More Haul......Less Overhaul
