Wireless Communications Engineering
Lecture 11 Spread Spectrum and CDMA Prof.
Mingbo Xiao Dec. 16, 2004
2
Spread Spectrum

• Input is fed into a channel encoder
• Produces analog signal with narrow bandwidth
• Signal is further modulated using sequence of
  digits
• Spreading code or spreading sequence
• Generated by pseudonoise, or pseudo-random number
  generator
• Effect of modulation is to increase bandwidth of
  signal to be transmitted

3
Spread Spectrum

• On receiving end, digital sequence is used to
  demodulate the spread spectrum signal
• Signal is fed into a channel decoder to recover
  data

4
Spread Spectrum System Model
5
Spread Spectrum

• What can be gained from apparent waste of
  spectrum?
• Immunity from various kinds of noise and
  multipath distortion
• Can be used for hiding and encrypting signals
• Several users can independently use the same
  higher bandwidth with very little interference

6
Frequency Hoping Spread Spectrum (FHSS)

• Signal is broadcast over seemingly random series
  of radio frequencies
• A number of channels allocated for the FH signal
• Width of each channel corresponds to bandwidth of
  input signal
• Signal hops from frequency to frequency at fixed
  intervals
• Transmitter operates in one channel at a time
• Bits are transmitted using some encoding scheme
• At each successive interval, a new carrier
  frequency is selected

7
Frequency Hoping Spread Spectrum

• Channel sequence dictated by spreading code
• Receiver, hopping between frequencies in
  synchronization with transmitter, picks up
  message
• Advantages
• Eavesdroppers hear only unintelligible blips
• Attempts to jam signal on one frequency succeed
  only at knocking out a few bits

8
Frequency Hoping Spread Spectrum
9
FHSS Using MFSK

• MFSK signal is translated to a new frequency
  every Tc seconds by modulating the MFSK signal
  with the FHSS carrier signal
• For data rate of R
• duration of a bit T 1/R seconds
• duration of signal element Ts LT seconds
• Tc ? Ts - slow-frequency-hop spread spectrum
• Tc lt Ts - fast-frequency-hop spread spectrum

10
FHSS Performance Considerations

• Large number of frequencies used
• Results in a system that is quite resistant to
  jamming
• Jammer must jam all frequencies
• With fixed power, this reduces the jamming power
  in any one frequency band

11
Direct Sequence Spread Spectrum (DSSS)

• Each bit in original signal is represented by
  multiple bits in the transmitted signal
• Spreading code spreads signal across a wider
  frequency band
• Spread is in direct proportion to number of bits
  used
• One technique combines digital information stream
  with the spreading code bit stream using
  exclusive-OR (Figure 7.6)

12
Direct Sequence Spread Spectrum (DSSS)
13
DSSS Using BPSK

• Multiply BPSK signal,
• sd(t) A d(t) cos(2? fct)
• by c(t) takes values 1, -1 to get
• s(t) A d(t)c(t) cos(2? fct)
• A amplitude of signal
• fc carrier frequency
• d(t) discrete function 1, -1
• At receiver, incoming signal multiplied by c(t)
• Since, c(t) x c(t) 1, incoming signal is
  recovered

14
DSSS Using BPSK
15
Spread spectrum signal
16
PN Sequences

• PN generator produces periodic sequence that
  appears to be random
• PN Sequences
• Generated by an algorithm using initial seed
• Sequence isnt statistically random but will pass
  many test of randomness
• Sequences referred to as pseudorandom numbers or
  pseudonoise sequences
• Unless algorithm and seed are known, the sequence
  is impractical to predict

17
Important PN Properties

• Randomness
• Uniform distribution
• Balance property
• Run property
• Independence
• Correlation property
• Unpredictability

18
Linear Feedback Shift Register Implementation
19
Properties of M-Sequences

• Property 1
• Has 2n-1 ones and 2n-1-1 zeros
• Property 2
• For a window of length n slid along output for N
  (2n-1) shifts, each n-tuple appears once, except
  for the all zeros sequence
• Property 3
• Sequence contains one run of ones, length n
• One run of zeros, length n-1
• One run of ones and one run of zeros, length n-2
• Two runs of ones and two runs of zeros, length
  n-3
• 2n-3 runs of ones and 2n-3 runs of zeros, length 1

20
Properties of M-Sequences

• Property 4
• The periodic autocorrelation of a 1
  m-sequence is

21
Definitions

• Correlation
• The concept of determining how much similarity
  one set of data has with another
• Range between 1 and 1
• 1 The second sequence matches the first sequence
• 0 There is no relation at all between the two
  sequences
• -1 The two sequences are mirror images
• Cross correlation
• The comparison between two sequences from
  different sources rather than a shifted copy of a
  sequence with itself

22
Advantages of Cross Correlation

• The cross correlation between an m-sequence and
  noise is low
• This property is useful to the receiver in
  filtering out noise
• The cross correlation between two different
  m-sequences is low
• This property is useful for CDMA applications
• Enables a receiver to discriminate among spread
  spectrum signals generated by different
  m-sequences

23
Gold Sequences

• Gold sequences constructed by the XOR of two
  m-sequences with the same clocking
• Codes have well-defined cross correlation
  properties
• Only simple circuitry needed to generate large
  number of unique codes
• In following example (Figure 7.16a) two shift
  registers generate the two m-sequences and these
  are then bitwise XORed

24
Gold Sequences
25
Orthogonal Codes

• Orthogonal codes
• All pairwise cross correlations are zero
• Fixed- and variable-length codes used in CDMA
  systems
• For CDMA application, each mobile user uses one
  sequence in the set as a spreading code
• Provides zero cross correlation among all users
• Types
• Welsh codes
• Variable-Length Orthogonal codes

26
Walsh Codes

• Set of Walsh codes of length n consists of the n
  rows of an n n Walsh matrix
• W1 (0)
• n dimension of the matrix
• Every row is orthogonal to every other row and to
  the logical not of every other row
• Requires tight synchronization
• Cross correlation between different shifts of
  Walsh sequences is not zero

27
Introduction to CDMA system

• CDMA is both an access method and air-interface
• CDMA systems have a similar network architecture
  to GSM network, consisting of MS, BTS, BSC, MSC,
  OMC, relevant database (EIR, AUC, HLR, VLR)
• The major differences between GSM and CDMA system
  are BTS, MS, air interface between BTS and MS
• Power control and handoffs are different
  Frequency reuse factor is 1

28
(No Transcript)
29
(No Transcript)
30
CDMA Network Reference Model
IWF Internetworking Function SME Short Message
Entity MC Message Center AC Authentication
Center A, C, , Um Interfaces
31
Multiple Access Techniques
32
CDMA for Direct Sequence Spread Spectrum
33
CDMA in DSSS
34
Advantages of CDMA Cellular

• Higher capacity
• Improves voice quality (new coder)
• Soft-handoffs decrease the call dropping
  probability
• Less power consumption (6-7 mW)
• Choice for 3G systems

35
Advantages (Contd)

• Frequency diversity frequency-dependent
  transmission impairments have less effect on
  signal
• Multipath resistance chipping codes used for
  CDMA exhibit low cross correlation and low
  autocorrelation
• Privacy privacy is inherent since spread
  spectrum is obtained by use of noise-like signals

• Graceful degradation system only gradually
  degrades as more users access the system

36
Drawbacks of CDMA Cellular

• Self-jamming arriving transmissions from
  multiple users not aligned on chip boundaries
  unless users are perfectly synchronized
• Near-far problem signals closer to the receiver
  are received with less attenuation than signals
  farther away
• Soft handoff requires that the mobile acquires
  the new cell before it relinquishes the old this
  is more complex than hard handoff used in FDMA
  and TDMA schemes

37
Drawbacks (Contd)

• Air-interface is the most complex
• Not symmetrical (unlike TDMA)
• Forward and reverse channels are different
• Forward channel (1 to Many) synchronized
• Forward channel uses orthogonal spreading codes
• Reverse channel transmissions are not
  synchronized
• Orthogonal codes are used for orthogonal waveform
  coding

38
IS-95 Air interface parameters
39
IS-95 CDMA Forward Channel

• The forward link uses the same frequency spectrum
  as AMPS (824-849 Mhz)
• Each carrier 1.25MHz
• 4 types of logical channel A pilot, a
  synchronization, 7 paging, and 55 traffic
  channels
• Channels are separated using different spreading
  codes
• QPSK is the modulation scheme
• Orthogonal Walsh codes are used (64 total)
• After orthogonal codes, they are further spread
  by short PN spreading codes
• Short PN spreading codes are M sequences
  generated by LFSRs of length 15 with a period of
  32768 chips.

40
Two Spreading Codes

• The orthogonal codes are used to differentiate
  between the transmissions within a cell
• The PN spreading codes are used to isolate
  different cells (BSs) that are using the same
  frequencies.
• The same PN sequence is used in all BSs.
• The offset for each BS is different. Of course,
  this requires synchronization
• Synchronization is achieved by GPS.

41
IS-95 Forward Channel
42
Basic Spreading Procedure
43
The pilot channel

• Provide a reference signal for all MSs that
  provides the phase reference for COHERENT
  demodulation
• 4-6 dB stronger than all other channels
• Used to lock onto other channels
• Obtained using all zero Walsh code i.e.,
  contains no information except the RF carrier
• Spread using the PN spreading code to identify
  the BS. (512 different BS64 offsets)
• No power control in the pilot channel

44
Pilot Channel Processing
45
Sync channel

• Used to acquire initial time synchronization
• Synch message includes system ID (SID), network
  ID (NID), the offset of the PN short code, the
  state of the PN-long code, and the paging channel
  data rate (4.8/9.6 Kbps)
• Uses W32 for spreading
• Operates at 1200 bps

46
Sync Channel Processing
47
Paging channels

• Used to page the MS in case of an incoming call,
  or to carry the control messages for call set up
• Uses W1-W7
• There is no power control
• Additionally scrambled by PN long code, which is
  generated by LFSR of length 42
• The rate 4.8 Kbps or 9.6Kbps

48
Paging Channel Processing
49
The traffic channels

• Carry user information
• Two possible date rates
• RS19.6, 4.8, 2.4, 1.2 Kbps
• RS214.4, 7.2, 3.6, 1.8 Kbps
• RS1 is mandatory for IS-95, but support for RS2
  is optional
• Also carry power control bits for the reverse
  channel

50
Forward Traffic Channel Processing in IS 95
(Rate Set 1)
51
Forward Traffic Channel Processing in IS 95
(Rate Set 2)
52
IS-95 CDMA Reverse Channel

• Fundamentally different from the forward channels

• Uses OQPSK for power efficiency
• QPSK demodulation is easy
• 869-894 MHz range
• No spreading of the data using orthogonal codes
• Same orthogonal codes are used for WAVEFORM
  encoding
• Two types of logical channels The access
  channels and the reverse traffic channels

53
IS-95 Reverse Channel
54
Mapping data bits to Walsh encoded symbols
55
Access Channel Processing
56
Mobile Wireless CDMA DesignConsiderations

• RAKE receiver when multiple versions of a
  signal arrive more than one chip interval apart,
  Rake receiver attempts to recover signals from
  multiple paths and combine them
• Soft Handoff mobile station temporarily
  connected to more than one base station
  simultaneously
• Power Control attempts to achieve a constant
  received mean power for each user (i.e., solves
  the near-far problem) in the uplink.

57
Principle of Rake Receiver
58
Soft Handoff

• - Reduce the interference into other cells
• Improve performance through macro
• diversity
• In the uplink, two or more base stations
• can receive the same signal because of
• the reuse factor of one.
• After demodulation and combining, the
• signal is forwarded to the BSC.

- In the downlink, however, soft handover creates
more interference to the system, since the new
base station now transmits an additional
signal for the mobile station.
59
Power Control

• OPEN LOOP POWER CONTROL adjusts the initial
  access channel transmission power of the mobile
  station and compensates large abrupt variations
  in the pathloss attenuation.
• Closed loop power control-- To account for the
  independence of the Rayleigh fading in the uplink
  and downlink, the base station also controls the
  mobile station transmission power. One-bit 800Hz
  control.
• Downlink Slow Power Control The base station
  controls its transmission power to a given mobile
  station according to the path-loss and
  interference situation.

60
Open loop power control
61
Closed loop power control
62
CDMA System Parameters

• N the number of users
• S the signal power of each user
• R baseband information bit rate
• W total RF bandwidth
• ? background thermal noise in the spread
  bandwidth
• Assume perfect power control

63
Capacity of cellular CDMA
The number of users that can access the system is
thus given as
where W/R is called the processing gain
