Introduction to Radial Basis Function Networks

1
Introduction to Radial Basis Function Networks

• ??? ???

2
Content

• Overview
• The Models of Function Approximator
• The Radial Basis Function Networks
• RBFNs for Function Approximation
• The Projection Matrix
• Learning the Kernels
• Bias-Variance Dilemma
• The Effective Number of Parameters
• Model Selection
• Incremental Operations

3
Introduction to Radial Basis Function Networks

• Overview

4
Typical Applications of NN

• Pattern Classification
• Function Approximation
• Time-Series Forecasting

5
Function Approximation
Unknown
Approximator
6
Supervised Learning
Unknown Function
Neural Network
7
Neural Networks as Universal Approximators

• Feedforward neural networks with a single hidden
  layer of sigmoidal units are capable of
  approximating uniformly any continuous
  multivariate function, to any desired degree of
  accuracy.
• Hornik, K., Stinchcombe, M., and White, H.
  (1989). "Multilayer Feedforward Networks are
  Universal Approximators," Neural Networks, 2(5),
  359-366.
• Like feedforward neural networks with a single
  hidden layer of sigmoidal units, it can be shown
  that RBF networks are universal approximators.
• Park, J. and Sandberg, I. W. (1991). "Universal
  Approximation Using Radial-Basis-Function
  Networks," Neural Computation, 3(2), 246-257.
• Park, J. and Sandberg, I. W. (1993).
  "Approximation and Radial-Basis-Function
  Networks," Neural Computation, 5(2), 305-316.

8
Statistics vs. Neural Networks
9
Introduction to Radial Basis Function Networks

• The Model of
• Function Approximator

10
Linear Models
Weights
Fixed Basis Functions
11
Linear Models
Linearly weighted output
Output Units

• Decomposition
• Feature Extraction
• Transformation

Hidden Units
Inputs
Feature Vectors
12
Linear Models
Can you say some bases?
y
Linearly weighted output
Output Units
w2
w1
wm

• Decomposition
• Feature Extraction
• Transformation

Hidden Units
?1
?2
?m
Inputs
Feature Vectors
x1
x2
xn
x
13
Example Linear Models
Are they orthogonal bases?

• Polynomial
• Fourier Series

14
Single-Layer Perceptrons as Universal
Aproximators
With sufficient number of sigmoidal units, it can
be a universal approximator.
Hidden Units
15
Radial Basis Function Networks as Universal
Aproximators
With sufficient number of radial-basis-function
units, it can also be a universal approximator.
Hidden Units
16
Non-Linear Models
Weights
Adjusted by the Learning process
17
Introduction to Radial Basis Function Networks

• The Radial Basis Function Networks

18
Radial Basis Functions
Three parameters for a radial function
?i(x)? (x ? xi)
xi

• Center
• Distance Measure
• Shape

r x ? xi
?
19
Typical Radial Functions

• Gaussian
• Hardy Multiquadratic
• Inverse Multiquadratic

20
Gaussian Basis Function (?0.5,1.0,1.5)
21
Inverse Multiquadratic
c5
c4
c3
c2
c1
22
Most General RBF
Basis ?i i 1,2, is near orthogonal.
23
Properties of RBFs

• On-Center, Off Surround
• Analogies with localized receptive fields found
  in several biological structures, e.g.,
• visual cortex
• ganglion cells

24
The Topology of RBF
As a function approximator
Output Units
Interpolation
Hidden Units
Projection
Feature Vectors
Inputs
25
The Topology of RBF
As a pattern classifier.
Output Units
Classes
Hidden Units
Subclasses
Feature Vectors
Inputs
26
Introduction to Radial Basis Function Networks

• RBFNs for
• Function Approximation

27
The idea
y
x
28
The idea
y
x
29
The idea
y
x
30
The idea
y
x
31
The idea
y
x
32
Radial Basis Function Networks as Universal
Aproximators
Training set
Goal
for all k
33
Learn the Optimal Weight Vector
Training set
Goal
for all k
34
Regularization
Training set
If regularization is unneeded, set
Goal
for all k
35
Learn the Optimal Weight Vector
Minimize
36
Learn the Optimal Weight Vector
Define
37
Learn the Optimal Weight Vector
Define
38
Learn the Optimal Weight Vector
39
Learn the Optimal Weight Vector
Design Matrix
Variance Matrix
40
Summary
Training set
41
Introduction to Radial Basis Function Networks

• The Projection Matrix

42
The Empirical-Error Vector
43
The Empirical-Error Vector
Error Vector
44
Sum-Squared-Error
If ?0, the RBFNs learning algorithm is to
minimize SSE (MSE).
Error Vector
45
The Projection Matrix
Error Vector
46
Introduction to Radial Basis Function Networks

• Learning the Kernels

47
RBFNs as Universal Approximators
Training set
Kernels
48
What to Learn?

• Weights wijs
• Centers ?js of ?js
• Widths ?js of ?js
• Number of ?js ? Model Selection

49
One-Stage Learning
50
One-Stage Learning
The simultaneous updates of all three sets of
parameters may be suitable for non-stationary
environments or on-line setting.
51
Two-Stage Training
Step 2
Determines wijs.
E.g., using batch-learning.
Step 1

• Determines
• Centers ?js of ?js.
• Widths ?js of ?js.
• Number of ?js.

52
Train the Kernels
53
Unsupervised Training
54
Methods

• Subset Selection
• Random Subset Selection
• Forward Selection
• Backward Elimination
• Clustering Algorithms
• KMEANS
• LVQ
• Mixture Models
• GMM

55
Subset Selection
56
Random Subset Selection

• Randomly choosing a subset of points from
  training set
• Sensitive to the initially chosen points.
• Using some adaptive techniques to tune
• Centers
• Widths
• points

57
Clustering Algorithms
Partition the data points into K clusters.
58
Clustering Algorithms
Is such a partition satisfactory?
59
Clustering Algorithms
How about this?
60
Clustering Algorithms
?1


?2

?4

?3
61
Introduction to Radial Basis Function Networks

• Bias-Variance Dilemma

62
Goal Revisit

• Ultimate Goal ? Generalization

Minimize Prediction Error

• Goal of Our Learning Procedure

Minimize Empirical Error
63
Badness of Fit

• Underfitting
• A model (e.g., network) that is not sufficiently
  complex can fail to detect fully the signal in a
  complicated data set, leading to underfitting.
• Produces excessive bias in the outputs.
• Overfitting
• A model (e.g., network) that is too complex may
  fit the noise, not just the signal, leading to
  overfitting.
• Produces excessive variance in the outputs.

64
Underfitting/Overfitting Avoidance

• Model selection
• Jittering
• Early stopping
• Weight decay
• Regularization
• Ridge Regression
• Bayesian learning
• Combining networks

65
Best Way to Avoid Overfitting

• Use lots of training data, e.g.,
• 30 times as many training cases as there are
  weights in the network.
• for noise-free data, 5 times as many training
  cases as weights may be sufficient.
• Dont arbitrarily reduce the number of weights
  for fear of underfitting.

66
Badness of Fit
Underfit
Overfit
67
Badness of Fit
Underfit
Overfit
68
Bias-Variance Dilemma
However, it's not really a dilemma.
Underfit
Overfit
Large bias
Small bias
Small variance
Large variance
69
Bias-Variance Dilemma

• More on overfitting
• Easily lead to predictions that are far beyond
  the range of the training data.
• Produce wild predictions in multilayer
  perceptrons even with noise-free data.

70
Bias-Variance Dilemma
It's not really a dilemma.
71
Bias-Variance Dilemma
The mean of the bias?
The variance of the bias?
The true model
bias
bias
bias
E.g., depend on hidden nodes used.
72
Bias-Variance Dilemma
The mean of the bias?
The variance of the bias?
Variance
The true model
E.g., depend on hidden nodes used.
73
Model Selection
Reduce the effective number of parameters.
Reduce the number of hidden nodes.
Variance
The true model
E.g., depend on hidden nodes used.
74
Bias-Variance Dilemma
Goal
The true model
E.g., depend on hidden nodes used.
75
Bias-Variance Dilemma
Goal
Goal
0
constant
76
Bias-Variance Dilemma
0
77
Bias-Variance Dilemma
Goal
bias2
variance
Minimize both bias2 and variance
noise
Cannot be minimized
78
Model Complexity vs. Bias-Variance
Goal
bias2
variance
noise
Model Complexity (Capacity)
79
Bias-Variance Dilemma
Goal
bias2
variance
noise
80
Example (Polynomial Fits)
81
Example (Polynomial Fits)
82
Example (Polynomial Fits)
Degree 1
Degree 5
Degree 10
Degree 15
83
Introduction to Radial Basis Function Networks

• The Effective Number of Parameters

84
Variance Estimation
Mean
Variance
85
Variance Estimation
Mean
Variance
Loss 1 degree of freedom
86
Simple Linear Regression
87
Simple Linear Regression
Minimize
88
Mean Squared Error (MSE)
Minimize
Loss 2 degrees of freedom
89
Variance Estimation
Loss m degrees of freedom
m parameters of the model
90
The Number of Parameters
m
degrees of freedom
91
The Effective Number of Parameters (?)
The projection Matrix
92
The Effective Number of Parameters (?)
Facts
Pf)
The projection Matrix
93
Regularization
The effective number of parameters
Penalize models with large weights
SSE
94
Regularization
The effective number of parameters
Without penalty (?i0), there are m degrees of
freedom to minimize SSE (Cost). The effective
number of parameters ? m.
Penalize models with large weights
SSE
95
Regularization
The effective number of parameters
With penalty (?igt0), the liberty to minimize SSE
will be reduced. The effective number of
parameters ? ltm.
Penalize models with large weights
SSE
96
Variance Estimation
The effective number of parameters
Loss ? degrees of freedom
97
Variance Estimation
The effective number of parameters
98
Introduction to Radial Basis Function Networks

• Model Selection

99
Model Selection

• Goal
• Choose the fittest model
• Criteria
• Least prediction error
• Main Tools (Estimate Model Fitness)
• Cross validation
• Projection matrix
• Methods
• Weight decay (Ridge regression)
• Pruning and Growing RBFNs

100
Empirical Error vs. Model Fitness

• Ultimate Goal ? Generalization

Minimize Prediction Error

• Goal of Our Learning Procedure

Minimize Empirical Error
(MSE)
Minimize Prediction Error
101
Estimating Prediction Error

• When you have plenty of data use independent test
  sets
• E.g., use the same training set to train
  different models, and choose the best model by
  comparing on the test set.
• When data is scarce, use
• Cross-Validation
• Bootstrap

102
Cross Validation

• Simplest and most widely used method for
  estimating prediction error.
• Partition the original set into several different
  ways and to compute an average score over the
  different partitions, e.g.,
• K-fold Cross-Validation
• Leave-One-Out Cross-Validation
• Generalize Cross-Validation

103
K-Fold CV

• Split the set, say, D of available input-output
  patterns into k mutually exclusive subsets, say
  D1, D2, , Dk.
• Train and test the learning algorithm k times,
  each time it is trained on D\Di and tested on Di.

104
K-Fold CV
Available Data
105
K-Fold CV
Test Set
Training Set
Available Data
D1
D2
D3
. . .
Dk
Estimate ?2
106
Leave-One-Out CV
A special case of k-fold CV.

• Split the p available input-output patterns into
  a training set of size p?1 and a test set of size
  1.
• Average the squared error on the left-out pattern
  over the p possible ways of partition.

107
Error Variance Predicted by LOO
A special case of k-fold CV.
The estimate for the variance of prediction error
using LOO
Error-square for the left-out element.
108
Error Variance Predicted by LOO
A special case of k-fold CV.
Given a model, the function with least empirical
error for Di.
As an index of models fitness. We want to find a
model also minimize this.
The estimate for the variance of prediction error
using LOO
Error-square for the left-out element.
109
Error Variance Predicted by LOO
A special case of k-fold CV.
Are there any efficient ways?
How to estimate?
The estimate for the variance of prediction error
using LOO
Error-square for the left-out element.
110
Error Variance Predicted by LOO
Error-square for the left-out element.
111
Generalized Cross-Validation
112
More Criteria Based on CV
GCV (Generalized CV)
Akaikes Information Criterion
UEV (Unbiased estimate of variance)
FPE (Final Prediction Error)
BIC (Bayesian Information Criterio)
113
More Criteria Based on CV
114
More Criteria Based on CV
115
Regularization
Standard Ridge Regression,
Penalize models with large weights
SSE
116
Regularization
Standard Ridge Regression,
Penalize models with large weights
SSE
117
Solution Review
Used to compute model selection criteria
118
Example
Width of RBF r 0.5
119
Example
Width of RBF r 0.5
120
Example
Width of RBF r 0.5
How the determine the optimal regularization
parameter effectively?
121
Optimizing the Regularization Parameter
Re-Estimation Formula
122
Local Ridge Regression
Re-Estimation Formula
123
Example
Width of RBF
124
Example
Width of RBF
125
Example
Width of RBF
There are two local-minima.
Using the about re-estimation formula, it will be
stuck at the nearest local minimum.
That is, the solution depends on the initial
setting.
126
Example
Width of RBF
There are two local-minima.
127
Example
Width of RBF
There are two local-minima.
128
Example
Width of RBF
RMSE Root Mean Squared Error In real case, it is
not available.
129
Example
Width of RBF
RMSE Root Mean Squared Error In real case, it is
not available.
130
Local Ridge Regression
Standard Ridge Regression
Local Ridge Regression
131
Local Ridge Regression
Standard Ridge Regression
?j ?? implies that ?j(?) can be removed.
Local Ridge Regression
132
The Solutions
Used to compute model selection criteria
133
Optimizing the Regularization Parameters
Incremental Operation
P The current projection Matrix.
Pj The projection Matrix obtained by removing
?j(?).
134
Optimizing the Regularization Parameters
Solve
Subject to
135
Optimizing the Regularization Parameters
Solve
Subject to
136
Optimizing the Regularization Parameters
Remove ?j(?)
Solve
Subject to
137
The Algorithm

• Initialize ?is.
• e.g., performing standard ridge regression.
• Repeat the following until GCV converges
• Randomly select j and compute
• Perform local ridge regression
• If GCV reduce remove ?j(?)

138
References
Mark J. L. Orr (April 1996), Introduction to
Radial Basis Function Networks,
http//www.anc.ed.ac.uk/mjo/intro/intro.html.
Kohavi, R. (1995), "A study of cross-validation
and bootstrap for accuracy estimation and model
selection," International Joint Conference on
Artificial Intelligence (IJCAI).
139
Introduction to Radial Basis Function Networks

• Incremental Operations
