Chapter 18: Distributed Process Management

1
Chapter 18 Distributed Process Management

• CS 472 Operating Systems
• Indiana University Purdue University Fort Wayne

2
Distributed Process Management

• Note Chapter 18 is an online chapter and does
  not appear in the textbook
• Available under Online Chapters at
• WilliamStallings.com/OS/OSe6.html
• Be aware that the URL is case sensitive
• A .pdf of this chapter should also be available
  on the class web site under Resources

3
Distributed Process Management

• This chapter concerns some issues in developing a
  distributed OS
• Process migration
• Global state of a distributed system
• Distributed mutual exclusion

4
Process migration

• A sufficient amount of the state of a process
  must be transferred from one computer to another
  for the process to execute on the target machine
• Goals
• Load sharing
• Efficient interaction with other processes and
  data
• Access to special resources
• Survival

5
Process migration goals

• Load sharing
• Move processes from heavily loaded to lightly
  load systems
• OS typically initiates the migration for load
  sharing
• Communications performance
• Processes that interact intensively can be moved
  to the same node to reduce communications cost
• May be better to move process to where the data
  reside when the data set is large
• The process itself typically initiates this
  migration

6
Process migration goals

• Utilizing special capabilities
• Process can migrate to take advantage of unique
  hardware or software capabilities
• Availability (survival)
• Long-running process may need to move because the
  machine it is running on will be down

7
To migrate process P from A to B . . .

• Destroy the process on A and create it on B
• Move at least the PCB
• Update any links between P and other processes
  and data . . .
• Including any outstanding messages and signals,
  open files, etc.

8
(No Transcript)
9
Migration of process P from A to B

• Entire address space can be moved or pieces
  transferred on demand
• Transfer strategies (assuming paged virtual
  memory)
• Eager (all)
• Precopy
• Eager(dirty)
• Copy-on-reference
• Flushing

10
Transfer strategies

• Eager (all) Transfer entire address space
• No trace of process is left behind
• If address space is large and if the process does
  not need most of it, then this approach my be
  unnecessarily expensive
• Precopy Process continues to execute on the
  source node while the address space is copied
• Pages modified on the source during precopy
  operation have to be copied a second time
• Reduces the time that a process is frozen and
  cannot execute during migration

11
Transfer strategies

• Eager (dirty) Transfer only modified pages in
  main memory
• Any additional blocks of the virtual address
  space are transferred on demand from disk
• The source machine is involved throughout the
  life of the process
• Copy-on-reference Transfer pages only when
  referenced
• Has lowest initial cost of process migration
• Flushing Pages are cleared from main memory by
  flushing dirty pages to disk
• Relieves the source of holding any pages of the
  migrated process in main memory
• Needed pages are subsequently loaded from disk

12
Initiation of migration can be made by ...

• by a load balancing process
• by the process itself
• for communications performance
• for survival
• to access special resources
• by the foreign system (eviction)

13
Global state of a distributed system

• Difficult concept to understand
• Global state of a distributed system needs to be
  known for mutual exclusion, avoiding deadlock,
  etc.
• Operating system cannot know the current state of
  all process in the distributed system

14
Global state of a distributed system

• A node can only know the current state of all
  local processes and earlier states of remote
  processes
• States of remote processes are known only through
  messages
• Even the exact times of remote states cannot be
  known
• It is impossible to synchronize clocks of nodes
  accurately enough to be of use

15
Example

• A bank is distributed over two branches
• To close a checking account at a bank, the
  account balance (global state of account) needs
  to be known
• Deposits may not have cleared
• Fund transfers may be pending
• Checks may not have been cashed
• Ask all correspondents to state pending activity
• Close the account when all reply
• Situation is analogous to determining the global
  state of a system

16
Example

• At 3 PM the account balance is to be determined
• Messages are exchanged for needed information
• A snapshot is established for each branch as of
  3 PM

17
Example

• Suppose at the time of balance determination, a
  fund transfer message is in progress from branch
  A to branch B
• The result is a false balance determination (0)

18
Example

• To correct the balance, all messages in transit
  at the time of observation must be examined
• Total consists of balance at both branches and
  amount in the messages

19
Example

• Suppose the clocks at the two branches are not
  perfectly synchronized
• Transfer amount at 301 from branch A
• Amount arrives at branch B at 259
• At 300 the amount is counted twice (200)

20
Terminology

• Channel
• Exists between two processes if they exchange
  messages
• State
• Sequence of messages that have been sent and
  received along channels incident with the process
• Snapshot of a process
• Current local state of the process . . .
• together with the state as defined above
• Global state
• The combined snapshots of all processes

21
Problem

• Process P gathers snapshots from the other
  processes and determines a global state
• Process Q does the same
• The two global states as determined by P and Q
  may be different
• Solution Settle for consistent global states
• Global states are consistent if . . .
• for each message received, the snapshot of the
  sender indicates that the message was sent

22
Inconsistent global state
23
Consistent global state
24
Distributed snapshot algorithm

• Assumes that all messages are delivered in the
  order sent and no messages are lost (e.g. TCP)
• Special control message called a marker is used
• Any process may initiate the algorithm by
• recording its state
• sending out the marker on all outgoing channels
  before any other messages are sent

25
(No Transcript)
26
Distributed snapshot algorithm

• Let P be any participating process
• Upon first receipt of the marker (say from
  process Q) process P does the following
• P records its local state SP
• P records the state of the incoming channel from
  Q to P as empty
• P propagates the marker to all its neighbors
  along all outgoing channels
• These three steps must be performed atomically
  without any other messages sent or received

27
Distributed snapshot algorithm

• Later, when P receives a marker from another
  incoming channel (say, from process R) . . .
• P records the state of the channel from R to P as
  the sequence of messages P has received from R
  from the time P recorded its local state SP to
  the time it received the marker from R
• The algorithm terminates at process P once the
  marker has been received along every incoming
  channel

28
Distributed snapshot algorithm

• Once the algorithm has terminated at all
  processes, the consistent global state can be
  assembled at any node
• Any node wanting a consistent global state asks
  every other node to send it the state data
  recorded at that node

29
Distributed snapshot algorithm

• The algorithm succeeds even if several nodes
  independently decide to initiate the algorithm
• The algorithm is not affected by any other
  distributed algorithm the processes are
  executing
• Algorithm terminates in a finite amount of time
• Algorithm can be used to adapt any centralized
  algorithm to a distributed environment

30
Distributed mutual exclusion

• Recall that shared memory and semaphores cannot
  be used to enforce mutual exclusion
• Instead, any mechanism must depend on the
  exchange of messages
• Algorithms for mutual exclusion may be
• Centralized
• Distributed

31
Centralized mutual exclusion algorithm

• Algorithm is straightforward
• One node is designated as the control node
• This node controls access to all shared objects
• Only the control node makes resource-allocation
  decisions
• Uses Request, Permission, and Release messages
• The control node may be a bottleneck
• Failure of the control node causes a breakdown of
  mutual exclusion

32
Distributed mutual exclusion algorithm

• Each node has only a partial picture of the total
  system and must make decisions based on this
  information
• All nodes bear equal responsibility for the final
  decision
• Failure of a node, in general, does not result in
  a total system collapse
• There is no common clock and no way to adequately
  synchronize clocks

33
Distributed mutual exclusion

• Distributed algorithm does require a time
  ordering of events
• For this, an event is the sending of a message
• Did event E1 on node S1 occur before event E2 on
  node S2 ?
• Communication delays must be overcome
• The answer need not be correct, but all nodes
  must reach the conclusion

34
Lamports timestamping algorithm

• Gives a consistent time-ordering of events in a
  distributed system
• Each node I has a local counter CI
• When node I sends a message, it first increments
  CI by 1
• Messages from node I all have form ( m, TI, I),
  where
• m is the actual message (like Request or Release)
• I is the node number
• TI is a copy of CI (the nodes timestamp) at
  the time the message was created

35
Lamports timestamping algorithm

• When node J receives a message from node I, it
  updates its local CJ to 1 max CJ , Ti
• ( m, TI, I ) precedes ( m, TJ, J ) . . .
• if TI lt TJ
• if TI TJ and I lt J
• For this to work, each message must be sent to
  all other nodes

36
Example

• (a,1,1) lt (x,3,2) lt (b,5,1) lt (j,5,3)

37
Example

• (a,1,1) lt (q,1,4)

38
Distributed mutual exclusion using a distributed
queue

• The queue is just an array with one entry for
  each node
• Requests for resources are granted FIFO, based on
  timestamped request messages
• All nodes maintain a copy of the queue
• Each node keeps the most recent message from each
  of the other nodes in the queue

39
Distributed mutual exclusion using a distributed
queue

• All nodes agree on a order for the messages
  within the queue if no messages are in transit
• The transit problem is overcome by the
  distributed queue algorithm (First Version)
• Summary on next slide
• 3(N-1) messages are involved per request
• Version Two is more efficient 2(N-1) messages

40
Summary of distributed queue algorithm

• A timestamped resource Request message is sent to
  all other nodes
• A copy of the Request message is also saved in
  the queue of the requesting node
• If it has not itself made a request, each node
  receiving a request sends a Reply message back to
  the sender
• This assures that no earlier Request message is
  in transit when the requester makes its decision
• A process may access the requested resource when
  its request is the earliest message in its queue
• After acting on a resource request, a node sends
  a Release message to all other nodes and puts a
  copy in its own queue

41
2
Suppose node wants to enter a critical
section . . .
1 2 3 4
1 2 3 4
1
Q
P Q P P
P Q
2
P
L
Q
Q
L
P
P
L
1 2 3 4
1 2 3 4
3
4
Q P
Q P
Q reQuest P rePly L reLease
4
What if node made an earlier request (in
transit)?
42
Token-passing algorithm for distributed mutual
exclusion

• Two arrays are used
• Token array
• Passed from node to node
• The kth position contains timestamp of node k the
  last time the token visited that node
• Request array
• Maintained by each node
• The jth position contains the timestamp of the
  last Request message received from node j

43
Token-passing algorithm

• Send request to all other nodes
• Wait for the token
• Release the resource by sending the token to some
  node requesting the resource
• Choose the first requesting node K whose Request
  message has a timestamp gt its timestamp in the
  token
• That is requestK gt tokenK

44
2
Suppose node wants to enter a critical
section and holds the token
3
1 2 3 4
1 2 3 4
1

Q
Q
2
Q
Q
token
1 2 3 4
1 2 3 4
3
4
Q
Q
Q reQuest T Time of last visit
1 2 3 4
T T T T
token
45
Token-passing algorithm

• See full algorithm in Figure 18.11
• N messages are needed per resource request
• Choice of next requesting node is not FIFO
• However, no starvation

46
Distributed deadlock in resource allocation

• Distributed deadlock prevention
• Circular-wait can be denied by defining a linear
  ordering of resource types
• Hold-and-wait condition can be denied by
  requiring that a process request all of its
  required resources at one time
• The process is blocked until all requests can be
  granted simultaneously
• Resource requirements need to be known in advance

47
Distributed deadlock

• Distributed deadlock avoidance is impractical
• Every node must keep track of the global state of
  the system
• The process of checking for a safe global state
  must be done under mutual exclusion
• Otherwise two nodes, each considering a different
  request, could erroneously honor both requests
  when only one is safe
• Checking for safe states involves considerable
  processing overhead for a distributed system with
  a large number of processes and resources

48
Distributed deadlock

• Distributed deadlock detection
• Each site only knows about its own resources
• Deadlock may involve distributed resources
• Three possible techniques
• Centralized control
• Hierarchical control
• Distributed control

49
Distributed deadlock

• Distributed deadlock detection
• Centralized control
• One site is responsible for deadlock detection
• Simple, subject to failure of central node
• Hierarchical control
• Sites organized as a tree
• Each node collects information from children
• Detects deadlocks at common ancestor
• Distributed control
• All processes cooperate in the deadlock detection
  function
• This may have considerable overhead

50
Deadlock in message communication

• Mutual Waiting
• Deadlock can exist due to mutual waiting among a
  group of processes when each process is waiting
  for a message from another process and there are
  no messages in transit

P1 is waiting for a message from either P2 or P5
51
Deadlock in message communication

• Unavailability of Message Buffers
• Well known problem in packet-switching data
  networks
• Store-and-forward deadlock
• Example of direct store-and-forward deadlock
• buffer space for A is filled with packets
  destined for B
• The reverse is true at B.

52
Deadlock in message communication

• Unavailability of Message Buffers
• For each node, the queue to the adjacent node in
  one direction is full with packets destined for
  the next node beyond
• Indirect store-and-forward deadlock
