Stats 330: Lecture 31

1
Stats 330 Lecture 31
Course Summary
2
The Exam!

• 25 multiple choice questions, similar to term
  test (60)?
• 3 long answer questions, similar to past exams
  You have to do all the multiple choice
  questions, and 2 out of 3 long answer questions
  (3 out of 3 for 762)?
• Held on pm of Monday 16th Nov 2009

3
STATS 330 Course Summary

• The course was about
• Graphics for data analysis
• Regression models for data analysis

4
Graphics

• Important ideas
• Visualizing multivariate data
• Pairs plots
• 3d plots
• Coplots
• Trellis plots
• Same scales
• Plots in rows and columns
• Diagnostic plots for model criticism

5
Regression models

• We studied 3 types of regression
• Ordinary (normal, least squares) regression for
  continuous responses
• Logistic regression for binomial responses
• Poisson regression for count responses
• (log-linear models)?

6
Normal regression

• Response is assumed to be N(?,?2)?
• Mean is a linear function of the covariates
• ?????????????????????????x??????????????kxk
• Covariates can be either continuous or
  categorical
• Observations independent, same variance

7
Logistic regression

• Response ( s successes out of n) is assumed to
  be Binomial Bin(n,?)?
• Logit of Probability log(????????is a linear
  function of the covariates
• ?????log(??????????????????x??????????????kxk
• Covariates can be either continuous or
  categorical
• Observations independent

8
Poisson regression

• Response is assumed to be Poisson(?)?
• Log of mean log(???is a linear function of the
  covariates (log-linear models)?
• ?????log(????????????x??????????????kxk
• (Or, equivalently
• ????????????????????exp????????x??????????????kxk)

• Covariates can be either continuous or
  categorical
• Observations independent

9
Interpretation of ?? -coefficients

• For continuous covariates
• In normal regression, ? is the increase in mean
  response associated with a unit increase in x
• In logistic regression, ? is the increase in log
  odds associated with a unit increase in x
• In Poisson regression, ? is the increase in log
  mean associated with a unit increase in x
• In logistic regression, if x is increased by 1,
  the odds are increased by a factor of exp(??
• In Poisson regression, if x is increased by 1,
  the mean is increased by a factor of exp(??

10
Interpretation of ?? -coefficients

• For categorical covariates
• In normal regression, ? is the increase in mean
  response relative to the baseline
• In logistic regression, ? is the increase in log
  odds relative to the baseline
• In logistic regression, if we change from
  baseline to some level, the odds are increased by
  a factor of exp(parameter for that
  level??relative to the baseline
• In Poisson regression, if we change from baseline
  to some level, the mean is increased by a
  factor of exp(parameter for that level??relative
  to the baseline

11
Measures of Fit

• R2 (for normal regression)?
• Residual Deviance (for Logistic and Poisson
  regression)?
• But not for ungrouped data in logistic

12
Prediction

• For normal regression,
• Predict response at covariates x1, . . . ,xk
• Estimate mean response at covariates x1, . . .
  ,xk
• For logistic regression,
• estimate log-odds at covariates x1, . . . ,xk
• Estimate probability of success at covariates
  x1, . . . ,xk
• For Poisson regression,
• Estimate mean at covariates x1, . . . ,xk

13
Inference

• Summary table
• Estimates of regression coefs
• Standard errors
• Test stats for coef 0
• R2 etc (normal regression)?
• F-test for null model
• Null and residual deviances (logistic/Poisson)?

14
Testing model vs sub-model

• Use and interpretation of both forms of anova
• Comparing model with a sub-model
• Adding successive terms to a model

15
Topics specific to normal regression

• Collinearity
• VIFs
• Correlation
• Added variable plots
• Model selection
• Stepwise procedures FS, BE, stepwise
• All possible regressions approach
• AIC, BIC, CP, adjusted R2, CV

16
Factors (categorical explanatory variables)?

• Factors
• Baselines
• Levels
• Factor level combinations
• Interactions
• Dummy variables
• Know how to express interactions in terms of
  means, means in terms of interactions
• Know how to interpret zero interactions

17
Fitting and Choosing models

• Fit a separate plane (mean if no continuous
  covariates) to each combination of factor levels
• Search for a simpler submodel (with some
  interactions zero) using stepwise and anova

18
Diagnostics

• For non-planar data
• Plot res/fitted, res/xs, partial residual plots,
  gam plots, box-cox plot
• Transform either xs or response, fit polynomial
  terms
• For unequal variance
• Plot res/ fitted, look for funnel effect
• Weighted least squares
• Transform response

19
Diagnostics (2)?

• For outliers and high-leverage points
• Hat matrix diagonals
• Standardised residuals,
• Leave-one-out diagnostics
• Independent observations
• Acf plots
• Residual/previous residual
• Time series plot of residuals
• Durbin-Watson test

20
Diagnostics (3)?

• Normality
• Normal plot
• Weisberg-Bingham test
• Box Cox (select power)?

21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Topics specific to Poisson regression

• Offsets
• Interpretation of regression coefficients
• (same as for odds in logistic regression)?
• Correspondence between Poisson regression
  (Log-linear models) and the multinomial model
  for contingency tables
• The Poisson trick

26
(No Transcript)
27
Contingency tables (2)?

• A model for the table is anything that
  specifies the form of the probabilities,
  possibly up to k unknown parameters
• Test if the model is OK by
• Calculate Deviance 2(log LMAX - log LMOD)
• log LMAX replace ?s with table frequencies
• log LMOD replace ?s with estimated ?s from the
  model
• Model OK if deviance is small,(p-value gt 0.05)?
• Degrees of freedom m - 1 - k
• k number of parameters in the model

28
Independence models

• Correspond to interactions being zero
• Fit a saturated model using Poisson regression
• Use anova, stepwise to see which interactions are
  zero
• Identify the appropriate model
• Models can be represented by graphs

29
Odds Ratios

• Definition and interpretation
• Connection to independence
• Connection with interactions
• Relationship between conditional ORs and
  interactions
• Homogeneous association model

30
Association graphs

• Each node is a factor
• Factors joined by lines if an interaction
  between them
• Interpretation in terms of conditional
  independence
• Interpretation in terms of collapsibility

31
Contingency tables final topics

• Association reversal
• Simpsons paradox
• When can you collapse
• Product multinomial
• comparing populations
• populations the same if certain interactions are
  zero
• Goodness of fit to a distribution
• Special case of 1-dimensional table
