From Ink-Jet Technology to Nano Array Writing Technology

1
From Ink-Jet Technology to Nano Array Writing
Technology

• By
• Szu-kang Hsien
• Ayodeji Coker

2
OVERVIEW

• Objective.
• Approach.
• Our Nano Array Writing Device.
• Conclusion.
• Acknowledgements.

3
OBJECTIVE

• The use of nano-technology and microfabrication
  techniques for nano array writing.
• Replacing conventional lithography methods with
  nano array writing capable of producing 30nm line
  widths.
• The independent control of each AFM tip used in
  the nano-array writing technology using
  comb-drive actuators.

4
APPROACH

• Using the concept employed in Dip Pen
  Nanolithography (DPN) for nano array writing.
• Using ink-jet technology as a mode of delivering
  ink to an AFM tip capable of writing line widths
  on the order of nano-meters.
• Motion control in the x-y-z plane is done using
  comb-drive and electrostatic actuators.

5
INK JET TECHNOLOGY

• Drop On Demand (DOD) ink-jet printing is to be
  utilized in our device.
• A high voltage is to be applied to a PZT crystal
  causing it to bend. This effect in turn applies a
  pressure on the ink reservoir.
• As a result of the applied pressure, the
  reservoir jets out ink on demand, in our case to
  coat the AFM tip.

6
Schematic of Ink delivery structure
7
INK JET TECHNOLOGY

• A change in voltage gives rise to a corresponding
  change in force and the resulting dimensional
  change in length.
• ?Vdij?Fjx/(?o?rA)
• ?F will be 0.11 N using PZT film dimension
  100?m100?m, er3000, d11370 pC/N, d31110 pC/N,
  V10V and x 2?m.
• The displacement of the crystal, ?L LV/(td31),
  will be around 0.2?m.
• So we can stack around 5 PZT crystals together in
  order to have 1?m pressing into the ink

8
DIP-PEN NANOLITHOGRAPHY (DPN)

• Old technique of dip pen writing.
• In place of the nib used in the regular dip-pen,
  an AFM tip is employed.
• Using ink-jet technology, ink is transported to
  the AFM tip, which it coats.
• The ink is delivered to the substrate, by
  choosing an ink and substrate that have an
  affinity for one another e.g ODT and Au.

9
ATOMIC FORCE MICROSCOPE (AFM)

• AFM relies on a scanning technique to to produce
  very high resolution 3-D images of sample
  surfaces.
• There are three methods used in AFM applications.
  They are the contact mode, the intermittent
  contact mode and the non contact imaging.
• The method employed NAWT is the intermittent
  contact mode method.

10
Force vs. distance curve showing tip sample
Separation of different AFM operating modes.
11
Schematic of AFM
12
COMB DRIVE AND ELECTROSTATIC ACTUATORS

• A large number of fine interdigiated fingers are
  actuated by applying a voltage between them.
• This will provide the x-y motion for our device.
• The z-motion is achieved by electrostatically
  actuating the cantilever on which the AFM is
  attached.

13
Comb Drive Actuators
14
Our Nano Array Writing Device

• Ink Jet Structure.
• Scream Process for the fabrication of the comb
  drive actuators.
• AFM tip fabrication.
• 3-D image of our nano array writing device.

15
Ink Jet Fabrication
16
Scream Process
17
AFM tip Fabrication
18
3-D Structure Of Our Device
19
Conclusion

• Technology is feasible.
• NAWT is a faster way of doing lithography.
• Comb drive in Collaboration with electrostatic
  cantilever deflection is a good method of control
  in all 3 dimentions.

20
Acknowledgements.

• Prof. Horacio Espinosa for his guidance and
  advice.
• Prof. Chad Mirkin for taking time to provide us
  with all the necessary information on DPN.
• Zhu the TA for all the literature and help he
  gave us.
