VECTORS

1
Chapter 3

• VECTORS

2
Vectors and Scalars

• Vector Quantity - requires both size and
  direction
• Scalar Quantity - requires only size

3
Vectors

• Vectors use arrows to indicate their size and
  direction.
• The length of the arrow is in scale to the size
  of the vector.
• The direction of the arrow is the direction of
  the vector.

5 m
20 m
4
Vector Addition

• Airplane flying with the wind

Wind Velocity 20 km/hr
120 km/hr with wind
Plane Velocity 100 km/hr
5
Vector Subtraction

• Airplane flying against the wind

Wind Velocity 20 km/hr
80 km/hr against wind
Plane Velocity 100 km/hr
6
Right Angle Vectors

• Airplane flying at right angle to wind

Plane Velocity 80 km/hr
Resultant Velocity 100 km/hr
Wind Velocity 60 km/hr
7
Vectors at Right Angles

• The resultant vector of two perpendicular vectors
  is the diagonal of the rectangle constructed with
  the two vectors as sides.
• Two operations with vectors
• 1. Finding the resultant
• 2. Resolving vectors

8
Finding the Resultant Vector

• 1. Draw the two vectors with their tails
  touching.
• 2. From the end of each vector, draw a line
  parallel to the other vector forming a rectangle.
• 3. Draw the diagonal starting in the corner
  where the two tails are touching

9
Resolving Vectors

• Replacing a single vector with two vectors at
  right angles to each other.

10
Vector Resolution

• 1. Vertical and horizontal lines are drawn from
  the tail of a vector.
• 2. A rectangle is drawn that encloses the vector
  as it diagonal.
• 3. The sides of the rectangle are the two
  component vectors starting at the tail of the
  first vector.
