Structural Zone Mapping

1
Structural Zone Mapping

• Its Use In All-Risk Incidents and for Evacuation
  Purposes
• Ralph Sheffer
• Fire Operations Specialist
• WI DNR
• 608-635-8101
• ralph.sheffer_at_wisconsin.gov

2
Zone Mapping What is it?

• Takes mapping of structural locations and breaks
  them into manageable units (Zones).

3
GIS mapping created and maintained from County
Land Information database
4

• Kept in 3 Forms
• Book in every emergency vehicle (extras for
  ICP/EOC)
• PDF computer format
• GIS Mapping Layers (ArcView)

5
Book Setup

• Currently there are a wide variety of setups
  across the state.
• DNR is working to establish recommended minimum
  standards.
• Page size 11 x 17

6
Overview map

• Shows entire county with townships delineated
  with page the township is on.

7
Zone page/structural page pairs.

• Structure Location
• Zone boundaries
• County, township, section boundaries
• Roads
• Rivers, streams, lakes
• Water Points
• Railroads, pipelines, power lines
• Map Legend
• Zone legend
• Color coded zone name
• Number of addresses in zone

8
Full county zone index
9
Structure Location

• At minimum, the structure point should be
  geo-coded (address matched) along the buildings
  address road.
• Ideally the structure location should be a point
  at the actual structure with an accompanying line
  from structure along driveway to main road access
  point for driveways over 200.
• On each page, with the legend, a small text note
  should briefly indicate how the structure
  location was determined (i.e. GPS, Geo-coded,
  etc.)

10
Zone Boundaries

• All structures should be within a zone.
• Limit should equal approximately 20 addresses per
  zone.
• Zones should connect so there are no un-zoned
  gaps on a road.
• Zones should follow the shape of the road as much
  as possible, but reach out away from the road far
  enough to included isolated structures.
• If a structure is at an intersection where 2 or
  more zones meet, if possible, it should be put in
  the zone on the road named in its address.

11
Optional

• Miscellaneous maps (county major road map,
  emergency districts, etc.
• Other indices may be included as deemed
  beneficial
• i.e.. County road index including
• Road
• Address range
• Township
• Page number

12
GIS Maps/Databases

• Structural database maintained by County Land
  Information.
• Zone layer maintained by DNR in areas of state
  that fall under DNR protection.
• Can be utilized at an ICP/EOC.
• Can hold more information than what map books can
  hold.

13
Information can be tied to GIS point
Columbia County
14
Adams County
15
Other info can be in database

• Hazardous materials permitted storage areas.
• Digital photo of structure.
• Tax parcel information.
• Anything else you may need/want.

16
Can be used for fire
17
Tornado
Above Stoughton tornado 2005, Dane Co. Right
Easton tornado 2004, Adams Co.
18
Flooding
Above Wyocena dam 2004, Columbia Co. Right
Randolph flooding 2004, Columbia Co.
19
HAZMAT
Left Weyauwega train derailment 1996, Waupaca
Co. Right Watertown tire fire 2005, Dodge Co.
20
Other potential uses

• Large area search and rescue (Wood County 2007).
• WMD/terrorist effected areas.
• Crowd control.
• Planned events (Ironman race, Summerfest, ESPN
  Games, etc).
• ERT/SWAT efforts (Virginia Tech, Beverly Hills
  (?) robbery)
• Anything that effects a few city/village blocks
  up to multiple counties.

21
One of the keys to a successfully run incident is
organization
22
Evacuation

• How do you organize and track evacuation
• in a large urban area?

23
Evacuation

• Or in an area that is 7 miles long and over 1
  mile wide?

24
Zone Mapping

• Zone maps help organize resources by giving them
  a specific area to concentrate on.
• Reduces duplication of efforts.

25
Zone Mapping

• Zone maps provide resources with number and
  location of addresses in their area of
  responsibility.

26
Zone Mapping

• Zone maps can be used to delineate areas of
  evacuation for a Reverse 911 system.

27
Where Do We Have Maps?
28
What does it take?

• Time
• - Potential federal grant funding (Hazard
  mitigation grant) in areas under DNR protection.
• Cooperation between departments
• Emergency Management
• County Sheriffs Dept.
• County Land Information
• County Zoning
• WI DNR
• Support from supervisors.

29
Updating

• County Land Information updates the database
  continually as new houses/businesses are built.
• Recommended to print new map books every 5 years.
• Sooner if major changes are made.

30
Questions?

• Ralph Sheffer
• WI Dept. of Natural Resources
• W7303 CTH CS
• Poynette, WI 53955
• 608-635-8101
• ralph.sheffer_at_wisconsin.gov
