Title: Metro Transit INTELLIGENT TRANSPORTATION SYSTEMS ITS


1
Metro TransitINTELLIGENT TRANSPORTATION
SYSTEMS (ITS)
2
CUSTOMERBENEFITS
3
Automated Trip Planning
  • Customers may get personalized trip itineraries
    on the Internet at
  • www.mymetrobus.com
  • Metro information is available 24/7

4
Automated Trip Plannerhttp//www.mymetrobus.com/
5
(No Transcript)
6
Itinerary Choices
7
Itinerary Results
8
(No Transcript)
9
(No Transcript)
10
Real Time Schedule Information for Passengers
  • Possibly added to Internet Trip Planner
  • Possibility of additional digital information
    signs at major bus stops.
  • Possible access via Cell Phone or PDA
  • Possibility of Automated Telephone Response
    Technology

11
Customer Travels to RecommendedBus Stop Location
12
External Route Announcements
  • Provide passengers with visual impairments
  • the same information other customers have

13
Customer Boards Bus and Pays Fare
  • Fare box equipment accepts
  • Cash fares
  • Transfers magnetically encoded with expiration
    time
  • Passes magnetically encoded with valid dates
  • 10-Ride Cards automatically deducts rides
  • One-Day Pass product may be purchased from
    Operator
  • 2-4-6 Pass product may be purchased from
    Operator on Saturdays, Sundays Holidays
  • Fare box equipment records
  • Fare media by type (i.e., 31-Day, UW Employee,
    etc.)
  • Fare media by expiration date
  • Fare media by time of day and location.

14
Internal Stop Announcements
  • Both audio and visual internal stop
    announcements
  • 1,090 bus stops have been programmed for internal
    announcements, representing approximately 50 of
    all Metro bus stops
  • These announcements keep Metro in compliance with
    ADA and Transit Parking Commission policy
  • Time and Date display added in Fall of 2006

15
Digital Display Signs
16
TRANSIT OPERATOR BENEFITS
17
Transit Operator Benefits
  • Single Point of login to Radio, Fare Box and
    Destination Sign.
  • New Fare Box Equipment helps with fare and
    transfer validation
  • Mobile Data Terminal provides operator schedule
    information as well as voice radio control and
    passenger messaging

18
Mobile Data Terminal (MDT)
19
Mobile Data Terminal (MDT)Fixed-Route
Paratransit
  • Allows driver to send emergency signal to
    Dispatch
  • Enables Driver and Dispatcher to have voice
    contact in emergency situations
  • If warranted, Dispatcher can contact 9-1-1
  • 9-1-1 can then communicate directly with Metro
    Driver

20
Mobile Data Terminal (MDT)Fixed-Route
Paratransit
  • Enables driver to make automated transfer
    requests
  • Allows driver to receive text messages from
    Dispatch and then reply back to Dispatch
  • Plays prerecorded informational messages

21
OPERATIONS SUPERVISOR BENEFITS
22
Mobile Data Terminal (MDT)Road Supervisor
Functions
  • Controls the two-way radio
  • Displays Metro Transit time date
  • Displays driver fixed-route and paratransit
    schedule information
  • Allows Supervisor to send and receive messages
    to/from Drivers Dispatch

23
Mobile Data Terminal (MDT)Road Supervisor
Functions
24
Operations Dispatch Terminal Dispatch Supervisor
Functions
  • Controls the two-way radio
  • Displays Metro Transit time date
  • Displays driver fixed-route and paratransit
    schedule information
  • Allows Dispatcher to send and receive messages
    to/from Drivers Road Supervisors

25
Operations Dispatch Terminals Dispatch Supervisor
Functions
Fixed-Route
Paratransit
26
Automatic Vehicle Location (AVL)
  • 800 MHz Trunked Voice Radio System
  • - Metro purchased new radio tower equipment
    that
  • is being utilized by Metro, MPD, MFD other
    city agencies
  • Vehicle Area Network
  • - Every bus is equipped with a computer, MDT,
    Global Positioning
  • Satellite (GPS) antenna/receiver
    and voice data radio
  • - Metro facility has wireless Local Area Network
    (LAN) to
  • constantly update buses with
    current route announcement data
  • 2,034 Bus Stops Surveyed
  • - Each bus stop had to be located by latitude
    longitude
  • - Precise distance between each bus stop had to
    be recorded

27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
MAINTENANCESUPERVISOR BENEFITS
33
ELECTRONIC TRANSMISSION OFENGINE PROBLEMS
  • Maintenance Supervisors May Monitor
  • Hot engines
  • Low oil
  • Transmission malfunctions

34
AVL Map Application
  • Maintenance Supervisors may
  • use application to
  • locate disabled buses
  • communicate with Transit Operators

35
METROS SERVICE DEVELOPMENT STAFF TEAM BENEFITS
forRoute Schedule Recommendations
36
Automatic Passenger Counters (APCs)
  • Infra-red Beams Provide Accurate
  • Boarding Alighting Passenger Counts
  • Beams are located in stairwell at front rear
    doors
  • 40 fixed-route buses equipped with APCs are
    rotated throughout the route system every four
    days
  • Information may be tracked to the bus stop
    location level for route schedule planning
    purposes
  • Provides federally mandated ridership data

37
AVL Playback Feature
  • Used to evaluate the on-time performance of
    revenue service
  • Provides Transit Scheduler with more accurate
    information to determine travel time between
    scheduled time points
  • Playback Module is Extremely use for Passenger
    Complaint Resolution, especially schedule
    adherence issues.

38
Fare Box Planning Data
  • Used to evaluate passenger boardings
  • by fare media type
  • Provides Service Development Team with
    information to determine passenger boardings by
    route and time of day
  • Provides more accurate means of reporting
    monthly ridership data

39
TRANSIT PARTNER BENEFITS
40
Fare Box Data
  • Used to report unlimited-ride pass customer
    boardings
  • for contracting partners
  • Provides accurate pass usage data for program
    evaluation and billing purposes

41
POLICY MAKER BENEFITS
42
Improved Data forDecision Makers
  • Metro staff is able to provide policy makers with
    more accurate data for purposes
  • of considering
  • Fare changes
  • Route and schedule changes
  • Transit unlimited-ride pass agreements
