C o n t e n t s (Home Page )
Digital Satellite Receivers
User Interface Software
Get your FREE Demo CD Now!

• Universal
• LNBFs

DiSEqC Switch
Satellite Antenna
Contact Us
3
Digital Satellite Receivers
Hard Disk Satellite Receivers
Software Features Comparison Chart
DVR 7000 HDD Viaccess
DVR 5000 HDD Viaccess
Hardware Features Comparison Chart
Analog Digital 2Ci Positioner MP3 Photo
Album
Digital HDD 2Ci Viaccess
Physical Specifications Comparison Chart
Also available without CA DVR-5000 HDD
Motorized Receivers With Integrated High Power
Positioner
D-2400 IP
AD-3600 IP Viaccess
Digital 2Ci Positioner
Analog Digital 2Ci Positioner
Fixed Receivers
DSB-2200 2Ci Viaccess
DSB-808 2Ci Viaccess
DSB-707 FTA
Digital 2Ci Viaccess
Digital 2Ci Viaccess
Digital Free-To-Air
Also available without CA DSB-2200 2Ci
Also available without CA DSB-8082Ci
Also available DSB-707 Viaccess
4
DVR-7000 HDD Viaccess

• H A R D W A R E F E A T U R E S
• 40 Gbyte Low Noise Audio/Video Disk
  Drive
• 2 Common Interface Slots
• Digital / Analog
• Digital Audio Output
• Integrated High Power Positioner
  (36 Volt, 5Amp.)
• Embedded Viaccess (optional)
• Front Panel Display
• Echostar Universal Remote Control
• LNB Control 0/12 Volts

• S O F T W A R E F E A T U R E S
• MP3 Player 500 songs (typ.)/USB Port
• Photo Album 5000 Digital Images
• 6 weeks EPG (Electronic Programming Guide)
• 8 Favorite lists for TV, Radio, DVR, MP3 Photo
  Album
• Powerful Channel Sorting Grouping
• Software update via Internet/Satellite (O.T.A.)
• Multiple Scan Modes (incl. Update scan)
• ECHONAV Multilingual Advanced User Interface
  (14 languages)
• 6000 channels, 100 satellites, 1500 transponder.s
• DiSEqC 1.0
• Smart Cards Type PC 2.4 Support
• Volume Control Offset per Channel
• Satellite Name Based Channel Numbering
• Advance Installation Mode
• Exclusive Echostar Autosat.

5
DVR-5000 HDD Viaccess

• H A R D W A R E F E A T U R E S
• 40 Gbyte Low Noise Audio/Video Disk Drive
• 2 Common Interface Slots
• Digital Audio Output
• Front Panel Display
• Echostar Universal Remote Control

• S O F T W A R E F E A T U R E S
• 6 weeks EPG (Electronic Programming Guide)
• 8 Favorite lists for TV, Radio, DVR
• Powerful Channel Sorting Grouping
• Multiple Scan Modes (incl. Update scan)
• Software update via Internet/Satellite (O.T.A.)
• ECHONAV Multilingual Advanced User Interface (14
  languages)
• 5000 channels, 100 satellites, 1500 transponders
• DiSEqC 1.2
• Smart Cards Type PC 2.4 Support
• Volume Control Offset per Channel
• Advance Installation Mode
• Satellite Name Based Channel Numbering.

6
D-2400 IP

• H A R D W A R E F E A T U R E S
• 2 Common Interface Slots
• Digital Audio Output
• Embedded Viaccess (optional)
• Integrated High Power Positioner (36
  Volt, 5Amp.)
• Front Panel Display
• Echostar Universal Remote Control
• LNB Control 0/12 Volts

• S O F T W A R E F E A T U R E S
• 7 days EPG (Electronic Programming Guide).
• 8 Favorite lists for TV, Radio.
• Powerful Channel Sorting Grouping.
• Multiple Scan Modes (incl. Update scan).
• Software update via Internet/Satellite (O.T.A.).
• DiSEqC 1.0.
• ECHONAV Multilingual Advanced User Interface (14
  languages).
• 5000 channels, 100 satellites, 1500 transponders.
• Smart Cards Type PC 2.4 Support.
• Volume Control Offset per Channel.
• Advance Installation Mode
• Satellite Name Based Channel Numbering.
• Exclusive Echostar Autosat.

7
AD-3600 IP Viaccess

• H A R D W A R E F E A T U R E S
• 2 Common Interface Slots
• Digital / Analog
• Digital Audio Output
• Embedded Viaccess (optional)
• Integrated High Power Positioner (36
  Volt, 5Amp.)
• Front Panel Display
• Echostar Universal Remote Control
• LNB Control 0/12 Volts

• S O F T W A R E F E A T U R E S
• 7 days EPG (Electronic Programming Guide)
• 8 Favorite lists for TV, Radio
• Powerful Channel Sorting Grouping
• Multiple Scan Modes (incl. Update scan)
• Software update via Internet/Satellite (O.T.A.)
• DiSEqC 1.0
• ECHONAV Multilingual Advanced User Interface (14
  languages)
• 5700 channels, 100 satellites, 1500 transponders
• Smart Cards Type PC 2.4 Support
• Volume Control Offset per Channel
• Satellite Name Based Channel Numbering
• Advance Installation Mode
• Exclusive Echostar Autosat.

8
DSB-2200 2Ci Viaccess

• H A R D W A R E F E A T U R E S
• 2 Common Interface Slots
• Digital Audio Output
• Embedded Viaccess (optional)
• Front Panel Display

• S O F T W A R E F E A T U R E S.
• 7 days EPG (Electronic Programming Guide).
• 8 Favorite lists for TV, Radio.
• Powerful Channel Sorting Grouping.
• Multiple Scan Modes (incl. Update scan).
• Software update via Internet/Satellite (O.T.A.).
• DiSEqC 1.2.
• ECHONAV Multilingual Advanced User Interface
  (14 languages).
• 4000 channels, 100 satellites, 1500 transponders.
• Smart Cards Type PC 2.4 Support.
• Volume Control Offset per Channel.
• Advance Installation Mode.
• Satellite Name Based Channel Numbering.

9
DSB-808 2Ci Viaccess

• H A R D W A R E F E A T U R E S
• 2 Common Interface Slots
• Digital Audio Output
• Embedded Viaccess (optional)

• S O F T W A R E F E A T U R E S.
• 7 days EPG (Electronic Programming Guide).
• 8 Favorite lists for TV Radio.
• Powerful Channel Sorting Grouping.
• Multiple Scan Modes (incl. Update scan).
• Software update via Internet/Satellite (O.T.A.).
• DiSEqC 1.2.
• ECHONAV Multilingual Advanced User Interface
  (14 languages).
• 4000 channels, 100 satellites, 1500 transponders.
• Smart Cards Type PC 2.4 Support.
• Volume Control Offset per Channel.
• Advance Installation Mode.
• Satellite Name Based Channel Numbering

10
DSB-707 FTA

• H A R D W A R E F E A T U R E S
• Free To - Air
• Digital Audio Output
• Embedded Viaccess (optional)

• S O F T W A R E F E A T U R E S.
• 7 days EPG (Electronic Programming Guide).
• 8 Favorite lists for TV Radio.
• Powerful Channel Sorting Grouping.
• Multiple Scan Modes (incl. Update scan).
• Software update via Internet/Satellite (O.T.A.).
• DiSEqC 1.2.
• ECHONAV Multilingual Advanced User Interface
  (14 languages).
• 4000 channels, 100 satellites, 1500 transponders.
• Smart Cards Type PC 2.4 Support.
• Volume Control Offset per Channel.
• Advance Installation Mode.
• Satellite Name Based Channel Numbering.

11
Software Feature Comparison Chart
DVR-7000 DVR-5000
AD-3600 D-2400 DSB-2200 DSB-808 DSB-707
Software Features
Digital Channels Satellites Transponders Echona
v 2.1.1 14 languages Favorite Channel
Lists Powerful Channel Sorting
Grouping Multiple Scan Modes DiSEqC Multilingua
l Language Support-EPG Software updates via
Internet/ SatelliteO.T.A. Service on ASTRA1 19.2
East/hotbird 13E Smart Cards Type PC 2.4
Support Advance Installation Mode Satellite
Name Based Channel Numbering Volume Control with
Offset per Channel Exclusive Echostar
Autosat Digital Audio/Video recording with Slow
Motion, Pause, FF, Rew Pause Live Video MP3
Player 500 songs Photo Album 5000 digital
images?
6000 100 1300 8 for TV, Radio DVR, MP3
Photo Album 1.0 6 weeks

5000 100 1300 8 for TV, Radio DVR
1.2 6 weeks

5700 100 1300 8 for TV
Radio 1.0 7 days

5000 100 1300 8 for TV
Radio 1.0 7 days

4000 100 1300 8 for TV
Radio 1.2 7 days

4000 100 1300 8 for TV
Radio 1.2 7 days

4000 100 1300 8 for TV
Radio 1.2 7 days

12
Hardware Feature Comparison Chart
DVR-7000 DVR-5000
AD-3600 D-2400 DSB-2200 DSB-808 DSB-707
Hardware Features
Analog (A) / Digital (D) Embedded Viaccess
(optional) 2 Common Interface Slots Digital
Audio Output Integrated High Power
Positioner Front Panel Display 40 Gbyte Low
Noise/Video HDD Echostar Universal Remote IF
Connector F-Type input, 1 output (loopthrough) D
emodulator QPSK, C/KU band compatible Video
System- PAL, UHF modulator - CH21-69, PAL B/G, 1,
D/K Connectors SCART, RCA, S/PDIF LNB Control
0/12 Volts USB
A / D (36V, 5A)

D

D (36V, 5A)

D

D
D
A / D
(36V, 5A)
13
Physical Specifications Comparison Chart
DVR-7000 DVR-5000
AD-3600 D-2400 DSB-2200 DSB-808 DSB-707
Physical Specifications
Dimensions of receiver (L x D x H, cm) Unit
Weight (CTN.) Units in Carton (CTN.) CTN
Size (Cm) CTN Weight Chargeable Weight per
CTN. (Kg) CTNS in a 20 foot container
37x28x7 6.0 3 47x44x44 18 18 120
32x27x7 4.5 4 47x44x44 18 18 120
32x28x7 4.2 5 53x42x38 21 21 130
32x27x7 4.5 4 47x44x44 18 18 120
32x32x7 3.6 5 53x38x36 18 18 150
26x22x5 2.5 10 60x48x33 25 25 145
26x22x5 2.5 10 60x48x33 25 25 145
14
Multilingual Advanced User Interface
is a family of powerful User Interfaces for the
EchoStar Satellite Receivers.
The family consists of
Fixed, customized for use
with the fixed
DiSEqC 1.2 receivers.
Motorized, customized for receivers with an
integrated high Power
positioner.
HDD for receivers with an internal hard
disk.
15
Universal LNBFs
Single
Quad
Quattro
Twin
16
Universal Single LNBF

• Input frequency range
• Low band 10.70-11.70 Ghz
• High band 11.70-12.75 Ghz
• Output frequency range
• Low band 950 1950 Ghz
• High band 1150 2150 Ghz
• L .O. Frequency
• Low band 9.75 Ghz
• High band 10.60 Ghz
• Noise figure
• Low band 0.6 db (typ.)
• High band 0.6 db (typ.)

• Single output

17
Universal Twin LNBF

• Input frequency range
• Low band 10.70-11.70 Ghz
• High band 11.70-12.75 Ghz
• Output frequency range
• Low band 950 1950 Ghz
• High band 1150 2150 Ghz
• L .O. Frequency
• Low band 9.75 Ghz
• High band 10.60 Ghz
• Noise figure
• Low band 0.6 db (typ.)
• High band 0.6 db (typ.)

• 2 independent
• Universal outputs

18
Universal Quad LNBF

• Input frequency range
• Low band 10.70-11.70 Ghz
• High band 11.70-12.75 Ghz
• Output frequency range
• Low band 950 1950 Ghz
• High band 1150 2150 Ghz
• L .O. Frequency
• Low band 9.75 Ghz
• High band 10.60 Ghz
• Noise figure
• Low band 0.6 db (typ.)
• High band 0.6 db (typ.)

• 4 independent
• Universal outputs

19
Universal Quattro LNBF

• Input frequency range
• Low band 10.70-11.70 Ghz
• High band 11.70-12.75 Ghz
• Output frequency range
• Low band 950 1950 Ghz
• High band 1150 2150 Ghz
• L .O. Frequency
• Low band 9.75 Ghz
• High band 10.60 Ghz
• Noise figure
• Low band 0.6 db (typ.)
• High band 0.6 db (typ.)

• 4 IF outputs, specific
• High/Low band
• vertical/horizontal Polarity

20
4 x 1 DiSEqC 2.0 Switch

• SPECIFICATIONS
• Frequency Range 900-2200 Mhz
• Current Loss 25mA max
• Insertion Loss Typ 1.5dB, max 3.0dB
• Isolation More than 25dB
• Def. Mode Output 1
• Amplitude 0.6Vpp 0.2dB
• Switch Control DiSEqC Command
• (position/option)
• Also available 2 x 1 DiSEqC switch.

21
High Performance Satellite Antennas
Technology Exclusive methods of hydraulic
impression are used to produce a technically
flawless finish.
Signal Yield Its unique parabolic design
provides Echostar with an extra 20 signal
yield compared to previous generations
of parabolic antennas.
Adaptability A wide range of attachments makes
Echostar a genuine multi-satellite receiver
unit.
Strength With its twin support bracket and top
quality materials, Echostar is the
worlds strongest antenna!!

• Sizes Available 50cm 60cm 67cm 80cm 85cm
  100cm 110cm 120cm 135cm

22
C o n t a c t U s !
United Arab Emirates Star Vision L.L.C PO Box
20205 Dubai, UAE Tel [phone]
Fax [phone]
Lebanon Star Vision Limited (Offshore) S.A.L PO
Box11-3309 Beirut Free Zone, No. 2108 Tel
9611 567450 Fax [phone]
Kingdom of Saudi Arabia Star Vision L.L.C PO Box
136173, Jeddah 21313 Tel [phone] Fax
966 2 6040933
PO Box 250725, Riyadh 11391 Tel 966 1
4632575 Fax [phone]
E-mail sales_at_starvision.com
Website www.starvision.com
