Biometeorology of Humans in Desert Environments

1
Biometeorology of Humans in Desert Environments

• Chapter 19

2
The Heat Balance of the Human Body - Components

• Longwave radiation gain or loss
• Conductive and convective exchange with the
  atmosphere gain or loss
• Metabolic source - gain
• Direct, diffuse, and reflected solar radiation -
  gain
• Evaporation loss
• Conduction with the ground gain or loss

3
The Energy Conservation Equation
QM QLR QSR QH QE QG ?QS
?QS is the net rate of heat gain or loss as a
result of an imbalance in the terms. ?QS not
equal to zero means that the body temperature
will increase or decrease. ?QS must remain small,
or be large for only a short time, in humans
because of the small range in tolerable body
temperatures.
4
Long-wave (Infrared) Radiation

• Emitted by the skin surface
• - IR (lost) intensity sTskin4, with Tskin
• 92 F, 33.3 C
• - clothing absorbs some of the emitted IR and
  re- emits it back to the skin and to the
  environment.
• Absorbed by the skin surface
• - IR (gained) intensity sTenviron4, where
  Tenviron applies to the atmosphere, the ground,
  etc.
• - clothing absorbs some of the IR from the
  environment, and emits it to the skin and back
  to the environment
• Whether there is a net gain or loss by the skin
  depends on Tskin versus the average Tenviron

5
Metabolic Source of Heat

• Body at rest generates about 80 Cal of heat per
  hour enough to heat 1 liter of ice water to
  boiling point.
• The greater the level of exercise, the more heat
  generated normal to fast walk generates 280
  Cal per hour.
• Over a typical work day, the metabolic energy
  generated in a day would be about 3 times that of
  a person at rest.

6
The greater the activity level, and the greater
the body weight, the greater the perspiration
rate required to maintain a heat balance.
Surrogate for rate of heat gain
7
Conductive and Convective Exchange of Heat
Between the Skin and the Atmosphere

• In a very shallow layer above the skin surface,
  conduction is responsible for the heat exchange
  the direction of heat transfer is from hot to
  cold.
• Outside this layer, convection transfers the
  heat.
• This is analogous to how heat is transferred
  between the ground surface and the atmosphere

8

• Thus, heat is gained by the body if the air
  temperature is greater than the skin surface
  temperature.
• A shallow boundary layer forms over the skin
  surface, with this thin boundary-layer air having
  a temperature near the skin temperature reduces
  heat transfer.
• Wind strips the boundary layer away from the
  skin, increases the temperature contrast, and
  increases the heat transfer.
• Thus, heat is gained most rapidly on windy days
  with air T over 92 F, when no clothes protect
  the boundary layer from the wind.
• Note parallel with the concept of wind-chill
  factor.

9
Rate of Heat Gain
10
How might perspiration rate be estimated?
11
Evaporation

• Takes place in the respiratory system and from
  the skin.
• Respiratory evaporative cooling is responsible
  for loss of only 25 of metabolic heat generated
  in resting person. In a cool environment, the
  rest of the heat is lost through conduction and
  radiation.
• In the hot desert where conduction/convection, IR
  radiation, and solar radiation all represent heat
  gains, or when metabolic heat generation is high,
  perspiration from the skin is the main/only way
  that the body loses heat.

12
Rate of Evaporation From the Skin Depends On

• Humidity
• Wind speed
• Temperature

In the desert, these conditions are favorable
enough for evaporation that we often dont see
any moisture on the skin.
13
(No Transcript)
14
Fluid balance
15
Example of the Efficiency of Evaporation For Heat
Regulation - Sauna

• Dry air that is heated to 110 C (230 F)
• Pan of water taken into this environment will
  boil, and a steak will cook in the amount of time
  that a person is in the sauna.
• Why doesnt the body overheat? rapid
  evaporation into the hot, dry environment.
• Evidence of evaporative loss of heat?
• Blow on the skin to remove the boundary layer
  blister forms immediately
• Nostrils become raw
• Water thrown on hot rocks in sauna makes it feel
  hotter because it reduces evaporation rate.

16
Solar Radiation Direct, Diffuse, Reflected

• Amount absorbed by the body depends
• Sun angle
• Cloud cover
• Dust content of atmosphere
• Albedo of surface, and slope
• Position of the body
• Clothing

17
(No Transcript)
18
Maintaining the Heat Balance
QM QLR QSR QH QE QG ?QS
19
What the Body Does To Maintain The Heat Balance
in Hot Environments

• Increase perspiration
• Dilation of arteries to increase capillary blood
  flow at the skin surface (if air T is less than
  blood T)
• But, even with unlimited water consumption,
  strenuous physical activity in the desert can
  cause dangerously high body temperatures
• heat is not transported fast enough from the
  interior of the body to the surface where the
  heat is lost
• not enough perspiration is generated to
  produce the required cooling

20
(No Transcript)
21
High work rate
Low work rate
22
Deaths per summer day in Shanghai
Threshold
23
Acclimatization to Desert Heat- Worked 100 min
at 120 F -
24
Physical Effects of Heat Stress and Dehydration
25
Survival daily water requirement, July,
acclimatized person at rest
26
Number of Days Without Water For Which It is
Possible to Walk At Night
