Wireless Security Basics

1
Wireless Security Basics

• Thomas Torgerson, CISSP
• October 24th, 2005

2
Topics At A Glance

• Which wireless are we talking about?
• Some interesting statistics
• Some questions to ponder
• Common Wireless 802.11 Terms
• 802.11 standards and risks
• Wireless in the news
• Reasons for wireless attacks and who those
  attackers are

3
Topics At AGlance - Continued

• Proving an attack ever happened
• Issues with small companies deploying wireless
• Home Wireless Security - The Basics
• Home Wireless Security - Facts Advice
• Securing corporate wireless
• Rogue access points and prevention
• Wireless assessments
• Useful links

4
Which Wireless Are We Talking About?

• 802.11x - the one being used by you, your
  neighbor, the local coffee shop, etc.
• It is also being heavily deployed in larger
  cities by large companies such as Google,
  Verizon, etc.
• Not BlueTooth
• Not Cellular
• Not InfraRed

5
Some Interesting Statistics

• One study stated that WIFI client growth
  (laptops, PDAs and phones) is around 65 per
  year
• Gartner predicts that by 2006, frequent users of
  public WIFI spots will exceed 4 Million in North
  America alone
• JiWire reports over 77k WIFI hotspots in 103
  countries
• Increased over 6k since mid September
• Security Related
• Normally less than 30 of APs have WEP enabled
• Approximately 20 use default SSID
• Lack of education is the largest reason for
  insecure wireless deployments!!
• Note These statistics include a large of
  businesses, even IT based companies and
  government agencies.

6
Some Questions To Ponder

• What kind of data do you have crossing that WLAN
  connection?
• Are you at risk for data loss, manipulation,
  destruction or even identity theft?
• Do you know if anyone has sniffed the traffic on
  your WLAN?
• Have you noticed anyone outside or near the WLAN
  that had a pringles can in hand and a laptop in
  the other? - If so, did you give them a strange
  look and wonder why the pringles can?
• Are you scared YET?

7
Common 802.11Wireless Terms

• Access Point - wireless to wired world - bridging
• Station - devices with wireless network
  interfaces
• Wireless Medium - radio frequency physical layers
• Distribution System - underlying infrastructure
• Infrastructure - clients to AP communication
• Independent or ad-hoc - client to client
  communication
• WEP - wireless equivalent privacy - many
  weaknesses
• 802.1X - device based authentication
• TKIP - Temporal Key Integrity Protocol -
  immediate help to address common WEP issues
• WPA - WIFI Protected Access - Interim solution
  from the WIFI Alliance while 802.11i was being
  developed

8
802.11 Standards

• Remember that vendors drive many of these
  standards
• 802.11 began as a IEEE standard way back in 1997
• 802.11a/b/g - established and many extensions
  exist
• 802.11e - QoS extentions for WLANs
• 802.11i - some security enhancements - namely
  support for AES and 802.1X
• 802.11.k - control power output of clients
• Anyone know why this is important?

9
802.11 StandardsIn Use Today

• RF communication has been around for decades
• First standard adopted in 1997 - 2.4GHz band -
  802.11 - up to 2Mbps
• 802.11a - 5GHz band - 1999 but no products till
  late 2000 - up to 54Mbps
• 802.11b - 2.4GHz band - 1999 - most widely
  deployed - up to 11Mbps
• 802.11g - 2.4GHz band - 2003 - backwards
  compatible - up to 54Mbps
• Anyone know what other kind of devices operate in
  the 2.4GHz band?

10
802.11 Risks

• Physical location
• Signal leakage and overlap
• Open authentication - SSID based authentication
• RF Jamming - CSMA\CA Physical layer
• Data flooding
• Hijacking
• Protocol weaknesses

11
Wireless In The News

• In April, a man was arrested in Florida for using
  a wireless connection without permission.
• Still another was arrested and found guilty and
  in this case, fined for use of a wireless network
  without permission.
• In July, a man in the UK was found guilty and
  fined for using a wireless connection without
  permission.
• Find additional information at
• http//www.theregister.co.uk/

12
Reasons For Wireless Attacks

• Fun and Intriguing - for those geeky kinds
• Anonymous access for hacking makes it difficult
  to track
• It is free bandwidth!!!
• Out of band lateral attacks against corporate
  networks

13
Who The Attackers Are

• Curious People Like them and use them, for they
  are our friends. If they had bad intentions,
  they would not inform us of our security issues.
• Bandwidth Snatchers - You can dislike these as
  they are normally those that are too lazy to find
  a public hotspot or even just pesky script
  kiddies doing no one any favors. Either way,
  they are disliked.
• Black Hats - Be worried about these try not to
  let them know that you dislike them as this only
  motivates them more. For those who are in
  security, these are the people that keep us White
  Hats in business.

14
Proving An Attack Ever Happened

• This can prove very interesting and challenging
• The attacker can spoof MAC address and then
  change after the attack took place.
• The attacker can remove the tools used during the
  attack - wipe their system clean of any trace.
• If the attacker is physically on public property
  (property not owned by you), you cannot force
  them to hand over their cool equipment they used
  for the attack while law enforcement is called to
  the rescue - they can simply walk away while they
  wipe their cool system clean of any trace. -)

15
Issues With Small Companies Deploying Wireless

• Issues are very obvious but most of the time
  overlooked
• System Admin is overloaded with work and it must
  be done immediately to make someone happy
• Cheap wireless equipment is used - security not
  included - may not support that brand new
  standard that was just approved
• There is no central authentication server
• There is no wireless IDS and no central logging
  server
• There is no wireless security policy - oh yeah,
  not to mention all of the other security policies
  missing
• There is no funding for having an outside party
  audit the deployment

16
Home Wireless Security -The Basics

• MAC address filtering
• Disable DHCP
• Disable SSID broadcast
• Use encryption - WEP, WPA/WPA2, etc.
• Never use default WEP keys
• Use good key management TKIP, manually change
  keys frequently, etc.
• Change default device passwords
• Disable dynamic routing
• Do these controls work?

17
Home WirelessSecurity Facts Advice

• Only high end DSL/Cable modems provide stateful
  firewall functions and in-depth security
  controls. Most provide rudimentary firewall
  functions built around NAT (network address
  translation).
• Never share out resources to the external world
  from your internal network unless you have a
  secondary device that serves as a dedicated
  firewall.
• Always disable your wireless AP and any clients
  when not in use.

18
Home Wireless SecurityFacts Advice Continued

• Use WPA if it is supported if not available,
  use WEP at a minimum even with its known
  weaknesses
• Disable all file sharing and any other default
  services on all systems participating on the
  wireless and wired networks if the services are
  not required.
• Systems participating on the wireless and wired
  networks should have the latest AV signatures,
  latest OS application patches and if possible,
  a personal firewall configured and running. You
  can also pickup free anti-spyware programs such
  as Ad-aware and Spybot Search and Destroy that
  can certainly help with pesky spyware programs.

19
Securing Corporate Wireless

• Site survey is always the very first item
• 802.1X authentication (supplicant, authenticator
  and authentication server)
• Reliable and supported EAP method
• Access Control Lists or Firewall or both
• Why would you do both?
• Layer 3 encryption using IPSec Tunneling - PPTP
  and L2TP are normally insufficient
• Two factor strong authentication
• Always perform frequent assessments

20
Site Survey

• Should be done both prior to deployment and
  intermittently after deployment
• Utilize wireless card and AP along with survey
  software - Cisco Aironet cards come with survey
  software
• Tune AP and wireless card transmit/receive power
  accordingly
• Tune antennas accordingly - both client and AP
  when available
• End result is to limit RF leakage

21
What is 802.1X?

• 802.1X
• IEEE framework ratified in December 2001
• Implemented on network devices and clients at the
  link layer
• Provides port based access control/authentication
• Transports higher level authentication protocols
• MAC based filtering and port state monitoring
• Is used between the supplicant and the
  authenticator
• IEE Terms Common Terms
• Supplicant Client
• Authenticator Network Access Device
• Authentication Server AAA/RADIUS Server

22
802.1X - Requirements

• Reliable Supplicants 3rd party may be best
  since MS is developing their own Network Access
  solution (NAP) platform availability is a big
  item to consider
• Funk Software, MeetingHouse, Cisco, etc.
• Authenticator - 802.1X supported network devices
  - (APs, switches, routers, etc.)
• Authentication server
• Microsoft IAS - free with Windows 2003
• Cisco ACS - not so free, but plenty of options
• Any IETF based RADIUS server
• Identity Store - integration
• NDS, LDAP, ADS, etc.

23
802.1X Visual
24
EAP Basics

• Extensible Authentication Protocol
• EAP became a standard in 1998 and was originally
  a protocol for PPP authentication supporting
  multiple authentication mechanisms
• EAP is used to carry the authentication payloads
  (referred to as EAP methods)
• EAP standard includes only three methods
• EAP-MD5 - MD5 hashed username/password
• EAP-OTP - one-time passwords
• EAP-TLS - strong PKI - mutual authentication
• end to end support for what method is chosen
• clients AAA server must work well together
• Other EAP methods exist also PEAP, EAP-FAST,
  EAP-TTLS, EAP-SIM, any many others

25
More On EAP-FAST

• EAP-FAST Extensible Authentication Protocol
  based Flexible Authentication via Secure
  Tunneling
• Tunnel is established via symmetric cryptography
  using unique client secrets called PACs
  (Protected Access Credentials)
• Each client has an associated PAC and the PAC is
  generated using a master key that periodically
  expires (TTL configurable)
• EAP-FAST is much faster than methods relying on
  PKI due to the shared secret (PAC)

26
More On EAP-FAST Continued

• Server certificate required, but no client
  certificates required
• Not susceptible to dictionary and MitM attacks
• Supports LDAP, MS AD, local authentication and
  ACS local DB
• Also supports MS AD login scripts, MS AD password
  changing, fast wireless secure roaming and WPA
• Three phases to EAP-FAST
• Phase zero - PAC provisioning can either be
  done manually or automatically using DH key
  exchange MSCHAPv2 protocol is used for user
  identification and authentication to provide the
  correctly assigned PAC
• Phase one - Tunnel establishment PAC is used
  as secret key, but still no network level access
  is granted
• Phase two - Tunnel authentication successful
  authentication of the users credentials

27
ACLs Firewalls

• Both controls can be used regardless of 802.1X
  usage at the AP layer
• Firewalls are best, but more costly - state based
• ACLs are easy, but very limited - layer 4 limit
  with no state support - larger ACLs can cause
  utilization
• Use ACLs at a minimum - default deny rule - only
  permit what is required and deny everything else,
  especially IP ranges outside of the segment being
  used by the wireless clients
• Use firewall if budget permits - wireless should
  be treated as an un-trusted segment - ALWAYS!

28
IPSec At A High Level

• Standard ratified in the late 90s
• Most common protocol used in VPN deployments
• Encryption at the IP layer (layer 3)
• Provides
• Authentication - optional
• Data confidentiality through encryption
• Integrity of traffic by detecting modified
  traffic
• Prevention of replay attacks

29
Why IPSec Over Layer 2 Encryption Methods?

• IPSec is supported by most all vendors in the
  market today (Cisco, CheckPoint, WatchGuard,
  Juniper, etc.)
• Currently most layer 2 methods require vendor
  specific implementations using their hardware to
  work as advertised
• Specific firmware versions and drivers are
  required
• Hardware specs change and need upgraded
• IPSec allows for
• Network card independence
• Access point independence

30
Strong Authentication

• What are these factors anyway?
• What you know - userIDs/passwords
• What you have - tokens/smartcards
• What you are - biometrics
• Single factor (userID/password) has been
  insufficient for years
• Two factor is easy to implement using proven
  products - most common is what you know and what
  you have

31
Corporate Wireless Example Diagram
32
Equipment List

• Windows laptop 1
• Cisco Aironet wireless card
• Cisco VPN client
• Windows laptop 2
• Cisco Secure ACS
• Cisco PIX Firewall
• Cisco Aironet 1220 AP
• Two low end switches

33
Rogue Access Points

• Where do they come from?
• Associates set them up
• Hackers use them from the outside
• What are the risks?
• Unknown access to network and resources
• Unknown usage of network
• Unknown access to wireless clients

34
Preventing RogueAccess Points

• Corporate Policy - this is always the first step
• Physical Security - monitor your environment
• Supported WLAN Infrastructure - have one in place
  if required for business purposes rather than
  waiting on users to install one themselves
• 802.1X implemented on edge switches - prevents
  unknown devices from connecting
• Perform frequent wireless assessments with
  wireless client, scanning tool and external
  antenna - more on this on the next slide

35
Wireless Assessments

• What you need
• Linux or Mac laptop is best, but Windows will
  work in most cases
• Wireless card (Aironet, Prism2 or Orinoco are
  supported by most all tools) with external
  antenna connector
• External antenna providing 5Db gain try not to
  go higher as this increases the chances of
  picking up devices much farther away and may not
  be yours to worry about
• Scanning tools
• WellenReiter, NetStumbler, MacStumbler, Kismet,
  KisMAC, etc.
• Sniffing tools
• Ethereal, tcpdump, windump, etc.
• Cracking tools
• Airsnort, WPA Cracker, WEPAttack, WEPCrack,
  LEAPcracker, etc.

36
Useful Links

• http//www.google.com http//www.cisco.com
• http//www.wi-foo.com http//www.eeye.com
• http//www.airscanner.com http//www.netstumbler.
  org
• http//www.handhelds.org http//www.macstumbler.c
  om
• http//www.airmagnet.com http//www.airdefense.ne
  t
• http//www.sourceforge.net http//www.iss.net
• http//www.jiwire.com http//www.insecure.org
• http//www.shmoo.com http//www.wardrive.net

37
Questions?
38
Thank You
