Title: Immune Recognition : MHC and TCR interactions


1
Immune Recognition MHC and TCR interactions
2
Antigen Recognition
  • B cells can recognise antigens via their surface
    Ig molecules
  • T cells can only recognise antigen in association
    with a Major Histocompatibility Complex (MHC)
    molecule.

3
T cells
  • T cells display TCR as their antigen recognition
    protein
  • When stimulated they become Cytotoxic or Helper T
    cells
  • Secrete cytokines that recruit other cells of the
    IS
  • TCRs only recognise short peptides.

4
MHC T cells
  • T cells have a requirement to recognise both the
    ANTIGEN and the MHC moleculeThis is because the
    molecular structure of the MHC-Antigen complex is
    arranged so that some of the polymorphic amino
    acids of the MHC molecule are in direct contact
    with the TCR
  • Therefore T cell recognition of antigen is said
    to be MHC restricted.

5
(No Transcript)
6
Antigen Processing and Presentation
  • Fragmentation of protein into peptides
  • Association of peptide with an MHC molecule
  • Transport to cell surface for expression
  • Different cellular pathways for association of
    peptide with MHC class I and class II molecules

7
MHC Antigens
  • MHC Class I
  • present endogenously derived peptides.
  • these can be either self or derived from viruses
  • because MHC Class I is present on all cells any
    cell can interact with T cells if infected by a
    virus
  • MHC Class II
  • present exogenous antigen which has been
    phagocytosed and processed.eg. Bacteria
  • This is performed by professional antigen
    presenting cells eg macrophages

8
MHC
  • MHC Class II
  • seen only on the professional antigen processing
    cells e.g macrophage
  • slightly less polymorphic
  • accepts peptides of up to 15 aa acids
  • MHC Class 1
  • detected on all nucleated cells
  • very highly polymorphic
  • Tight fit for peptides of only about 9 aa
  • consists of an a-chain of 3 domains associated
    with b-2 microglobulin

9
MOLECULES OF T LYMPHOCYTE RECOGNITION
  • Major histocompatibility complex (MHC)
    humanHuman Leukocyte Antigen (HLA) mouseH-2
  • Gorer and Snell identified a genetic basis for
    graft rejection and Snell named it
    histocompatibility 2 (H-2). Nobel prize awarded
    to Snell.
  • Highly polymorphic genes organized in a complex
    on chromosome 6 (human) and 17 (mouse).
  • Glycoproteins expressed on the surface of cells.
    MHC class I is composed of one polypeptide,
    non-covalently associated with b2microglobulin.
    MHC class II is composed of two polypeptides,
    referred to as a and b.

10
MHC Class I and Class II Proteins
  • Class I
  • Alpha Chain
  • 3 External domains
  • 1 Transmembrane
  • 1 Cytoplasmic tail
  • Encoded in MHC
  • Beta-2 Microglobulin
  • 1 External domain
  • No transmembrane
  • No Cytoplasmic tail
  • Not encoded in MHC
  • Class II
  • Alpha Chain
  • 2 External domains
  • 1 Transmembrane
  • 1 Cytoplasmic Tail
  • Encoded in MHC
  • Beta Chain
  • 2 External domains
  • 1 Transmembrane
  • 1 Cytoplasmic Tail
  • Encoded in MHC

11
MHC Class I and Class II Proteins
  • Class I
  • Tissue Distribution
  • All nucleated cells
  • RBCs in some species
  • Function
  • Presentation of antigens to CD8 T cells
  • Class II
  • Tissue Distribution
  • Antigen presenting cells
  • Macrophages
  • Dendritic cells
  • B cells
  • Thymic Epithelium
  • Function
  • Presentation of antigens to CD4 T cells

12
MHC Class I and Class II Proteins
13
(No Transcript)
14
STRUCTURE OF MHC MOLECULES AND PEPTIDES BOUND TO
THE GROOVE
  • Crystal structure (solved in late 1980s)
    revealed a binding groove formed by anti-parallel
    b-pleated sheets (bottom of groove) and a-helices
    (sides of groove).
  • a1 and a2 of MHC class I and a1 and b1 of MHC
    class II form mirror images of each other to
    create the peptide binding groove.
  • Amino acids along the edges of the groove
    interact (through hydrogen bonds and ionic
    attractions) with the amino acids of the peptide
    to stabilize peptide binding (Figure).

15
Peptides bind to MHC Class II molecules in a
common polyproline II conformation
Jardetzky et al., PNAS 93 734-738 (1996)
16
MHC-I Structure
17
Class IPeptide Binding
18
Class IPeptide Binding
19
MHC-II Structure
20
Peptide Binding by Major Histocompatibility
Complex (MHC) Antigen-presenting Proteins
MHC I
MHC II
  • Peptides of intracellular origin
  • Peptides 9-10 residues long
  • Deep pockets bind peptide sidechains
  • Deep pockets bind peptide N- and C-termini
  • Peptides of extracellular origin
  • Peptides 15 residues or longer
  • Shallow pockets bind peptide sidechains
  • Peptide termini free
  • H-bonds to peptide backbone

21
(No Transcript)
22
MHC Polymorphism
  • Both Class I and Class II genes are highly
    polymorphic
  • Most polymorphic residues of Class I are in the
    alpha 1 and alpha 2 domains
  • Most polymorphic residues of Class II are in the
    alpha 1 and beta 1 domains

23
Location of Polymorphic Residues
24
Location of Polymorphic Residues
25
Allelic variation in MHC occurs at the peptide
binding site and on the top/sides of the binding
cleft
26
What Does the aß T Cell Receptor (TCR) Recognize?
  • Only fragments of proteins (peptides) associated
    with MHC molecules on surface of cells
  • Helper T cells (Th) recognize peptide associated
    with MHC class II molecules
  • Cytotoxic T cells (Tc) recognize peptide
    associated with MHC class I molecules

27
Similar to BCR, the TCR alone cannot signal the T
cell that it has bound antigen The TCR is always
associated with CD3 (g,d,e) and z (zeta) chain.
These molecules are involved in signaling the T
cell when it engages antigen
The TCR plus CD3 is referred to as the TCR complex
28
The TCR Complex
  • TCR is expressed on the surface of T cells in
    noncovalent association with a complex of
    transmembrane polypeptides
  • CD3 3 distinct polypeptide chains, g, d and e
  • Members of the Ig superfamily
  • The e chain associates with both g and d
  • chaperone role in transporting newly
    synthesized TCR molecules to the cell surface
  • Expressed exclusively on T cells
  • Two identical z (zeta) chains
  • 16 kDa
  • Found on T cells, macrophages and NK cells
  • Mice also can have a h (eta) form

29
(No Transcript)
30
CD4 and CD8 Molecules
  • Transmebrane molecules
  • Referred to as co-receptor or accessory molecules
  • Member of the Ig superfamily
  • T cells are either
  • CD4 ? CD4()CD8(-)
  • CD8 ? CD4(-)CD8()

31
CD4 and CD8 Functions
  • Extracellular portion bind to the invariant
    portion of the MHC on the APC ? adhesion molecule
  • MHC restriction
  • CD4 ? binds Class II MHC
  • CD8 ? binds Class I MHC
  • Act as signal transducers
  • Linked to specific kinases which are activated
    after binding of MHC peptide
  • CD4 molecule binds HIV ? allowing for virus entry

32
(No Transcript)
33
TCR-peptide-MHC complex
Peptide MHC binding is just like the binding of
drugs to other receptors.
Garcia, K.C. et al., (1998). Science 279,
1166-1172.
34
TRI-MOLECULAR COMPLEXTCR-MHC-PEPTIDE
Hennecke and Wiley. 2001. Cell 1041-4
35
van der Merwe and Davis. 2003. Annu Rev Immunol
21, 659-684
TCR binding to peptide-MHC
36
peptide binding interface 21-34 proportion of
TCR contacts with the peptide26-47 contact are
different between TCR-MHC complex -the
contribution to the binding energy is still
uncleared!
Bandovich and Garcia. 2003. Immunity 18,7-11
37
TRI-MOLECULAR COMPLEX CHARACTERISTICS
-CDR1 and CDR2 interact with MHC molecules (a
helices)
-CDR3 interacts with the peptide
-interaction always in the same orientation -45
to 70 degrees angle related to peptide -Va see
N-ter of the peptide -Vb see C-ter of the peptide
38
TRI-MOLECULAR COMPLEX CHARACTERISTICS
- most of the binding interface is between the
TCR and MHC helices - conformational change
in the TCR CDR loops enhances TCR
crossreactivity - no conformational change in
the TCR constant region (except in one complex
out of ten)
39
Binding properties of TCR-MHC-peptide interaction
van der Merwe and Davis. 2003. Annu Rev Immunol
21, 659-684
40
PARADOX
-TCR-MHC interaction has a weak
affinity -affinity 10 mM -half-life 10s
-restricted numbers of ligands (100) are
displayed at the surface of antigen presenting
cells
-T cell activation requires a long interaction
with antigen presenting cells (2h)
41
key-lock model
-binding via CDR1 and CDR2 -induces fitting of
the CDR3 loops on the peptide -stabilize
interaction
allows scanning of the antigen presenting cell
surface for efficient detection of foreign
peptides (rare and very similar to self-peptides)
42
Antigen Recognition by Antibodies (Ab) and T-cell
Receptors (TCR)
Ab - Ag
TCR MHC/peptide
  • Surface area 2x750 Ã…2
  • Epitope discontinuous in antigen (Ag) sequence
  • Surface area 2x1000 Ã…2
  • Ag peptide contributes only 40 of surface area
  • Epitope continuous in Ag sequence
  • Otherwise similar to Ab - Ag recognition
