Provably hard problems below the satisfiability threshold

1
Provably hard problems below the satisfiability
threshold
A sharp threshold in proof complexity yields
lower bounds for satisfiability search
Paul Beame Univ. of Washington
Dimitris Achlioptas Microsoft Research
Michael Molloy Univ. of Toronto
2
CNF Satisfiability

• (x1 ? x2 ? x4) ? (x1 ? x3) ? (x3 ? x2) ? (x4 ?
  x3)
• NP-complete but many heuristics because of its
  practical importance
• presumably exponential in the worst case
• If you know formula is satisfiable
• How hard is it to find assignment?
• No lower bounds known for interesting heuristics.

3
Satisfiability Algorithms

• Local search (incomplete)
• GSAT Selman,Levesque,Mitchell 92
• Walksat Kautz,Selman 96
• Backtracking search (complete)
• DPLL Davis,Putnam 60
  Davis,Logeman,Loveland 62
• DPLL clause learning

4
Backtracking search/DPLL

• Select a literal l (some x or ?x)
• Remove all clauses containing l
• Shrink all clauses containing l
• While there are 1-clauses
• Pick some (arbitrary) 1-clause, satisfy it and
  simplify
• If there is a 0-clause (contradiction)
• Backtrack to last free step

Free step
Yields residual formula
many options for select
5
Resolution

• Start with clauses of CNF formula F
• Resolution rule
• Given (A ? x), (B ? ?x) can derive
  (A ? B)
• F is unsatisfiable ? 0-clause derivable
• Proof size of clauses

Running DPLL (with any select) on an
unsatisfable formula F results in a
tree-resolution proof of ? F
6
Random CNF formulas

• Random 2-CNF formula with sn clauses
• is satisfiable w.h.p. for s ? 1
• and simple DPLL will find a satisfying assignment
  in linear time w.h.p.
• is unsatisfiable w.h.p. for s ? 1
• and simple DPLL will finish and yield a
  resolution proof of unsatisfiability in linear
  time w.h.p.

7
DPLL on random 3-CNF
Can prove 2W(n/D1e ) time is required for
unsatisfiable formulas above the threshold
What about satisfiable formulas below threshold?
D ratio of clauses to variables
n 50 variables
8
Phase transitions and algorithmic complexity

• Easy connection
• Hardest random problems will always be at a
  monotone sharp threshold bn if it exists
• Can randomly reduce satisfiable problems of lower
  density to those at the threshold
• Given a formula with Dn clauses D? b can always
  add (b-D-e) n random clauses to make it a random
  problem nearly at the threshold and use that soln
• Can reduce unsatisfiable problems of larger
  density to those at the threshold
• Given a formula with Dn clauses D? b ignore all
  but the first (be) n of them

9
Hard satisfiable formulas?
With non-deterministic select we could simply
guess n correct value assignments. .... How can a
satisfiable formula possibly be hard?
Any implementation of select must run in
polynomial time. . Very simple heuristics used
in practice
10
Some standard select rules for DPLL algorithms

• UC
• Pick variables in a fixed order
• Always set True first
• UCwm
• Pick variables in a fixed order
• Apply a majority vote among 3-clauses for
  assigning each value
• GUC
• Pick a variable v in a shortest clause C
• Set v to satisfy C

11
Contributions

• These natural DPLL algorithms take exponential
  time on satisfiable formulas
• ? family of unsatisfiable random formulas
  parametrized by s s.t. w.h.p.
• s ? 1 ? linear size resolution proofs
• s ? 1 ? only exponential size
  resolution proofs possible

12
Key property of each of the select rules weve
seen

• On random 3-CNF, before the first backtrack
  occurs, the residual formula is a uniformly
  random mix of 2-clauses and 3-clauses
• If it has m2 2-clauses and m3 3-clauses then it
  is equally likely to be any formula with these
  properties
• key property ? proofs of algorithms success
  without backtracking

13
What do long runs look like?
Residual formula at each node is a mix of 2-
and 3-clauses
Residual formula at is unsatisfiable
2rn
Algorithms proof of unsatisfiability is
exponentially long
Every resolution
14
Proof Complexity
Theorem. A random CNF formula with Dn 3-clauses
and sn 2-clauses where s ? 1
has no resolution refutation of size 2rn w.h.p.
Chvátal-Szemerédi 88
Achlioptas,B.,Molloy 2001
Formula is unsatisfiable w.h.p. for D ? 4.57
s ? 1-e and D ? ????
15
Non-rigorous results
Kirkpatrick, Monasson, Selman, Zecchina 97
2-clause ratio
s
We can add 2/3 n 3-clauses but not ?n 2-clauses
1
UNSAT
SAT
4.26
2/3
3-clause ratio D
16
Rigorous results Achlioptas, Kirousis,
Kranakis, Krizanc 97
2-clause ratio
We can add 2/3 n 3-clauses but not ?n 2-clauses
1
?
UNSAT
s
?
SAT
4.57
8/3
2/3
2.28
D
3-clause ratio
17
Proof Complexity
Theorem. A random CNF formula with Dn 3-clauses
and sn 2-clauses where s ? 1
has no resolution refutation of size 2rn w.h.p.
Achlioptas,B.,Molloy 2001
Formula is unsatisfiable w.h.p. for D ? 4.57
D ? 2.281 and s ? 1-e for e ? .0001
Sharp threshold since resolution is linear for s
? 1e
18
These DPLL algorithms follow trajectories
2-clause ratio
1
Chao,Franco 88
Frieze,Suen 95
s
Achlioptas 00
Achlioptas,Sorkin 00
UC
GUC
2/3
3.26
3-clause ratio
8/3
D
19
DPLL crossing into the bad zone
2-clause ratio
Algorithm Trajectory
1
Provably UNSAT Hard
s
Provably SAT Easy
4.57
3.26
4.26
3-clause ratio
D
20
Exponential lower bounds far below the threshold.
Theorem. Let A? UC, UCwm, GUC. Let
DUC 3.81 DUCwm 3.83 DGUC
4.01
W.h.p. algorithm A takes more than 2rn steps on
a random 3-CNF with DAn clauses
Lower bound also applies to any resolution-based
algorithm that extends the first branch of the
execution of A
21
Related Work

• Experiments suggested DPLL algorithms may not be
  polynomial all the way to the threshold
• Cocco, Monasson 01 applied non-rigorous methods
  to suggest exponential GUC behavior below the
  threshold
• Assumed every branch of GUC tree operates like an
  independent version of the first branch
• Independent of our work

22
Implications for phase transitions and
algorithmic complexity

• Difference between polynomial and exponential
  hardness is not necessarily a function of the
  phase transition
• Applies in both phases, not just the
  over-constrained phase
• Algorithmically dependent
• A good algorithm will have a transition in a
  different place from a bad algorithm
• Cant study the hardness transition in the
  absence of the study of algorithms

23
Proof Ideas

• Connection between pure literals and resolution
  proof size Chvátal,Szemerédi 88

  Ben-Sasson,Wigderson 99
• pure literals are those that occur only
  positively or only negatively in a formula
• Digraph structure of random 2-CNF subformula
• New graph-theoretic notion clan
• generalization of connected component
• Sharp concentration properties for clan size
• moment generating function argument
• Amortization of pure literals across clans

24
Resolution proof size and pure literals
Ben-Sasson,Wigderson 99

• If formula has an a s.t.
• Every subformula with ? a n clauses has at least
  one pure literal
• Every subformula with between a n and a n
  clauses has a linear of pure literals
• Then
• all resolution proofs of the formula
  require size 2rn

25
Basic idea of argument

• By sparsity of the 2-clause part of the formula,
  any subset of the 2-clauses will have lots of
  pure literals
• Clan size analysis amortization
• In a subformula involving both 2-clauses and
  3-clauses, either there are
• so many 3-clauses that they create lots of new
  pure literals on their own , or
• so few 3-clauses that they cant cover all the
  pure literals in the 2-clauses - analysis of clans

easy case
26
2-CNF Digraph on literals
x
x
c
c
y
y
w
w
z
z
d
d
(?d ? y) (?y ? x) (?z ? y) (?c ? w) (?x ?
w) (?w ? z)
27
Hyper/Digraph on literals
x
c
y
w
f
g
z
d
(a ? b ? z) (f ? g ? ?w)
28
Pure literals
x
x
c
c
y
y
w
w
f
g
z
z
d
d
a
b
29
Pure cycle
x
x
c
c
y
y
w
w
f
g
z
z
d
d
a
b
30
Pure Items Clans of G

• Clans
• small subgraphs of G
• one clan per vertex they cover G
• analog of connected components in sparse random
  graphs
• pure items typically two per clan ? leaves in
  acyclic connected components in an ordinary graph
• mostly constant size
• never more than log3n vertices
• if x? clan(y) then y? clan(x)

31
What are clans?
Simpler notion first in(y) for vertex y in an
ordinary digraph
32
in(y) in ordinary digraph
x
v
y
t
w
z
Subgraph of vertices that can reach y
Ancestors of y
u
33
clan(y) in ordinary digraph
x
v
y
t
w
z
Descendants of ancestors of y
u
34
clan(y) in 2-CNF digraph
35
A complication - bad events
x
x
c
c
w
w
z
z
y
d
(?d ? y) (?z ? y) (?c ? w) (?x ? w) (?w ? z)
(w ? d)
36
in(y) in a bad case
37
clan(y) in a bad case
This can cascade and get even worse!
38
Analysis

• If we ignore bad edges in(y) is dominated by a
  component process in a sub-critical random
  undirected graph
• like trimmed out-trees Bollobás,Borgs,Chayes,Kim,
  Wilson
• Ignoring bad edges clan(y) is dominated by a
  2-level process
• run a component process to get in(y)
• take the union of in(y) independent component
  processes added to in(y)

39
Analysis

• w.h.p. no more than one bad event happens per
  clan
• in(y) is always dominated by the 2-level
  component process
• w.h.p. no more than Clog n bad events occur in
  the whole digraph
• fewer than polylog n literals interact with bad
  clans
• rest of clans dominated by 2-level process

40
Analysis

• Ordinary sub-critical component process on 2n
  vertices w.h.p.
• of vertices with component size ? i is at most
  2n (1-s)i for some fixed s ?0
• We show sub-critical 2-level component process on
  2n vertices w.h.p.
• for i ? i0, of vertices with 2-level size ? i
  is at most 2n (1-t)i for some fixed t ?0

This is false for a 3-level component process!
41
Open problem
Conjecture. For every D 2/3 there exists an s
? 1 such that a random (2,3)-CNF with Dn
3-clauses and sn 2-clauses is w.h.p. unsatisfiable
1
UNSAT
SAT
4.57
3.26
2/3
42
Open problem
Conjecture. For every D 2/3 there exists an s
? 1 such that a random (2,3)-CNF with Dn
3-clauses and sn 2-clauses is w.h.p. unsatisfiable
Implies. For every card-game algorithm A there
exists a critical density DA such that for random
3-CNF formulas with Dn clauses
For D ? DA w.h.p. A takes linear time For D ? DA
w.h.p. A takes exponential time
