INFECTIONS IN SOLID ORGAN TRANSPLANT RECIPIENTS

• DR. ATUL HUMAR
• INFECTIOUS DISEASES / MULTI-ORGAN TRANSPLANTATION

2
OBJECTIVES

• To review the concept of compromised host
• To gain an understanding of the common infections
  after transplant
• To gain further understanding into herpesvirus
  infections after transplant
• CMV
• EBV

3
Definition

• Compromised host
• Patient lacks resistance to infection due to a
  deficiency in defense mechanisms against
  microbial invasion and/or disease
• Inherited or acquired

4
PATHOGENESIS
Microbe
Host
DISEASE DETERMINANTS
Defense Mechanisms
Inoculum or Organisms Virulence Latency
5
HOST DEFENSE MECHANISMS

• Intact skin and mucous membranes
• Disrupted due to trauma, burns, ulceration, IV
  catheters, surgery
• Types of infection
• Wound infections, burn sepsis, diabetic foot
  infection, line sepsis
• Usual organisms
• Bacteria environmental, endogenous
• Fungi environmental, nosocomial

6
(No Transcript)
7
HOST DEFENSE MECHANISMS

• Physical removal / clearance of micro-organisms
• Respiratory muco-ciliary clearance
• Peristalsis and dynamics of hollow viscus (gut,
  bile ducts, ureter, fallopian tube)
• Maybe abnormal due to underlying disease,
  surgery, smoking etc.
• Intact sphincters/valves
• Types of infection
• Pneumonia, urosepsis, biliary sepsis
• Usual organisms
• Bacteria environmental, endogenous

8
(No Transcript)
9
(No Transcript)
10
HOST DEFENSE MECHANISMS

• Endogenous microflora
• Oropharyngeal, gut, skin, vagina
• Important for preventing colonization with
  disease causing organisms (competitive)
• Antibiotics remove natural flora
• E.g. C. difficile colitis
• Chemical antimicrobial agents
• Gastric acidity, cutaneous fatty acids

11
HOST DEFENSE MECHANISMS

• Inflammatory response
• Number (mass) and function of circulating and
  tissue phagocytic cells
• Neutrophils, monocytes, macrophages, spleen
• Humoral Mediators
• Complement, fibronectin

12
HOST DEFENSE MECHANISMS

• Specific Immune response
• T-lymphocytes
• CD4, CD (helper, cytotoxic)
• Number, function
• B-lymphocytes
• Make antibodies
• IgG, IgA

13
Common problems
14
Common problems
15
Common problems
16
INFECTION BASIC PRINCIPLES

• Inflammatory response attenuated by immunosup.
• may abolish typical signs/symptoms
• decreased sensitivity of serological,
  radiological tests
• Efffects of established infection may be
  devastating
• Treatment may have more toxicities
• Rifampin - decrease CsA
• Erythromycin, azoles increase CsA
• Synergistic nephrotoxicity - aminoglycosides,
  AmB, septra, cipro, vancomycin, pentamidine

17
INFECTIONS IN TRANSPLANTATION

• Three main determinants of the risk of infection
• in transplant recipients
• Infections related to technical / surgical
  problems

18
TECHNICAL COMPLICATIONS

• Liver - biliary tree - leaks, strictures
• Lung - bronchial anastomosis necrosis, dehiscence
  mediastinal fluid collection
• Kidney - uroterocystostomy - leak, urinoma
• Pancreas - duodenum-bladder duodenum-bowel
  anastomotic leaks, abscess

19
(No Transcript)
20
INFECTIONS IN TRANSPLANTATION

• Major determinants of the risk of infection

The net state of Immunosuppression
Epidemiological exposures
21
NET STATE OF IMMUNOSUPPRESSION

• Immunosuppressive therapy dose, duration,
  temporal sequence - area under the curve
• Underlying immune deficiency
• Mucocutaneous barrier integrity intubation,
  drains, catheters, central lines
• Devitalized tissue, fluid collection
• Neutropenia, lymphopenia

22
NET STATE OF IMMUNOSUPPRESSION

• Metabolic conditions
• Uremia
• Malnutrition
• Diabetes
• Viral infection Immune modulation
• Cytomegalovirus
• Epstein-Barr virus
• Hepatitis B, C, HIV

23
EPIDEMIOLOGICAL EXPOSURES

• Community
• Community acquired pneumonia pathogens
• Environmental fungi
• Enteric bacterial pathogens (salmonella)
• TB, zoonosis, HIV, hepatitis viruses
• Nosocomial
• MRSA,VRE
• Pseudomonas, MDR gram negatives
• Aspergillus

24
CASE PRESENTATION

• 61 y.o. male heart transplant 1991
• Stable immunosuppression x years
• cylosporin, prednisone
• 3 week history of progressive leg cellulitis,
  fever unresponsive to antibiotics
• Intermittent confusion

25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
TIMETABLE 0-1 MONTH

• Infections usual to post-op patients
• nosocomial pneumonia, wound, line sepsis, UTI
• Key factors nature of the operation, technical
  skill
• Lung, heart, liver at highest risk
• longer intubation, ICU stay, lines, catheters
• Most OIs (eg. PCP) absent in the first month
• Exceptions HSV, HHV6, Candida, Aspergillus

29
TIMETABLE 0-1 MONTH

• Also may see
• Infection transmitted with the allograft eg.
  lung transplant with pneumonia or a donor
  bacteremia which seeds the vascular anastamosis
• Pre-existing infection within the recipient made
  worse by the transplant

30
TIMETABLE OF INFECTION

• One to 6 months post-Tx
• Maximal period of immunosuppression
• Effect of sustained immunosuppression or area
  under the curve
• Opportunistic infections in the absence of
  excessive epidemiological hazard

31
TIMETABLE - 1 TO 6 MONTHS

• VIRAL
• CMV, EBV, VZV, HHV-6, Adenovirus, Influenza, RSV
• BACTERIAL
• Nocardia, Legionella, Listeria, TB
• FUNGAL
• PCP, Aspergillus, Cryptococcus, endemic mycosis
• PARASITIC
• Toxoplasma, Strongyloides

32
TIMETABLE - gt 6 MONTHS

• GROUP 1 Good graft function, minimal
  immunosuppression
• Community acquired pneumonia, UTI, OI based on
  intense exposure
• GROUP 2 Recurrent or chronic rejection, high
  level immunosuppression, chronic viral
  replication
• Continued risk of opportunistic infections

33
CASE PRESENTATION

• 55 year old female OLTx for PSC
• Acute rejection Steroid resistant requiring OKT3
  for 10 days (pre-emptive ganciclovir)
• Neoral, prednisone, MMF
• 2 months later presents with fever, malaise,
  elevated transaminases

34
CMV HEPATITIS
35
CMV VIRAL LOAD
6
CMV hepatitis
5
4
3
Log viral load
2
1
0
0
25
50
75
100
125
Days Post-transplant
36
CYTOMEGALOVIRUS

• Betaherpesvirus
• DS DNA
• Icoshedral capsid
• Lipid envelope
• Establishes latency
• Once infected always infected

37
CLINCAL MANIFESTATIONS

• DIRECT EFFECTS
• Asymptomatic viral shedding
• Acute viral syndrome
• Pneumonitis BMT, Lung Transplant
• Infection of allograft hepatitis, pneumonitis,
  nephritis, myocarditis, pancreatitis
• Infection of native tissue GI, CNS, retina

38
INDIRECT EFFECTS
CMV INFECTION/DISEASE
39
(No Transcript)
40
CMV THE ROLE OF CYTOKINES

• TNF-a has been shown to stimulate the CMV-IE gene
  enhancer/promotor region in a dose-dependent
  manner leading to CMV reactivation
• CMV has direct effects on cytokines CMV-IE gene
  products shown to increase IL-6 and IL-8 gene
  expression
• This has been shown to enhance neutrophil
  trans-endothelial migration
• Cytokine mediated PMN recruitment may enhance CMV
  dissemination

41
CYTOKINE LEVELS AND CMV DISEASE
Humar et al. J Infect Dis 1999 179 484
42
(No Transcript)
43
MULTIVARIATE ANALYSIS OF RISK FACTORS FOR CMV
DISEASE
Humar et al. Transplantation 2000
44
HHV-6 AND TRANSPLANTATION

• Cytopathic lymphotrophic virus roseola infantum
• Seroprevalence almost universal by age 2-3
• Post-transplant implicated as a cause of febrile
  illness, hepatitis, pneumonitis and other
  infections.
• Rates of reactivation estimated from 14 - 82
• Its main effect post-transplant may be
  immunomodulatory including an interaction with
  CMV

45
HHV-6 AND TRANSPLANTATION

• Infection of T-cells results in down-regulation
  of IL-2 mRNA and protein synthesis, and a
  reduction in mitogen-driven proliferative
  responses resulting in a cell mediated immune
  defect
• HHV-6 infection results in cytokine
  dysregulation induction of TNF-? and other
  immunomodulatory cytokines
• Interactions among herpesviruses may be more
  direct, including specific binding via
  glycoproteins resulting in cellular co-infections
  and facilitating viral spread

46
VIRAL CULTURE MEDIA
6
CMV hepatitis
5
4
3
Log viral load
2
1
0
0
25
50
75
100
125
Days Post-transplant
47
HERPESVIRUS INTERACTIONS

• Serial Quantitative HHV-6 in 200 liver transplant
  recipients
• Serial Quantitative CMV PCR
• Direct effects and Indirect effects of viral
  replication on development of graft rejection and
  opportunistic infection were assessed

48
HHV-6 RESULTS

• HHV-6 infection occurred in 28 (56/200) patients
  (defined as VL gt 2 logs)
• peak VL occurred at a median of 35 days (mean
  44.1 days range 8-177)
• Symptomatic disease occurred in only 2/200
  patients (1) and presented as fever and
  pancytopenia

49
HHV-6 AND CMV
50
CMV PREVENTION

• Universal prophylaxis anti-viral therapy to all
  at-risk patients
• Pre-emptive therapy anti-viral therapy to
  subgroups of at-risk patients usually based on
  further diagnostic tests aimed at identifying
  early viral reactivation

51
PRE-EMPTIVE THERAPY
_
_
_
_
_







TEST
0
4
8
12 weeks
52
CMV IN LIVER TRANSPLANT RECIPIENTS

• PRE-TRANSPLANT Donor and recipient CMV serology
• POST-TRANSPLANT
• D/R, D-/R
• Week 2-12 Every clinic visit
• CMV antigenemia
• CMV quantitative PCR
• D/R-
• Ganciclovir prophylaxis 12 weeks
• Bloodwork at week 12, 14, 16, 18.
• CMV antigenemia and quantitative PCR testing

53
STUDY PROTOCOL CMV IN LIVER TRANSPLANT RECIPIENTS

• OUTCOME
• CMV disease defined according to biopsy evidence
  viral syndrome based on specific clinical
  criteria
• ANALYSIS
• Predictive value for antigenemia and PCR
• Positive gt0 cells/slide gt400 copies/ml
• Sensitivity, specificity, PPV and NPV for
  different cut-off points
• Multivariate logistic regression for predictors
  of CMV disease

54
RESULTS

• CMV disease 21/97 ( 21.7) patients mean 60
  days post-transplant
• PCR sensitivity of 100, specificity 47.4, PPV
  34.4 and NPV 100 for prediction of CMV disease

• Antigenemia 95.2, 55.3, 37.0 and 97.7 .
• The optimal cut-off for PCR in the range of
  2000-5000 copies/ml (sensitivity 85.7,
  specificity 86.8, PPV 64.3, NPV 95.7)
• The optimal cut-off for antigenemia was in the
  range of 6 positive cells/slide.

55
ROC CURVE FOR CMV QUANTITATIVE PCR
gt0
gt1000
1.00
gt2000
gt5000
0.75
gt7000
Sensitivity
gt12000
0.50
gt15000
gt20000
0.25
0.00
0.00
0.25
0.50
0.75
1.00
1- Specificity
56
PREEMPTIVE THERAPY

• CMV antigenemia or CMV quantitative PCR useful
  for predicting the development of CMV disease
• Either of these tests could be employed in a
  pre-emptive strategy using optimal cut-offs
• The CMV viral load is the most important
  determinant for the development of CMV disease

57
RESPONSE TO THERAPY
8 weeks after treatment relapsed with fever,
Recurrent CMV disease
58
RESPONSE TO THERAPY

• Virologic response to therapy assessed in 52
  patients with CMV disease treated with
  ganciclovir
• Viral loads done at regular intervals after
  starting treatment
• Genotypic resistance testing
• Clinical response to treatment Relapsing
  disease occurred in 24 of patients

Humar et al. JID 2002
59
VIRAL LOAD KINETICS
yy0eax
60
Humar et al. JID 2002
61
(No Transcript)
62
CONCLUSIONS

• Different people have different rates of response
  to antiviral therapy
• Early phase kinetics are predictive of relapsing
  disease.
• Differential response likely combination of
• Host factors - CTL, immunosuppression
• Viral Factors genotype, immune evasion genes

63
EBV AND PTLD

• DEFINITION
• An abnormal proliferation of B-cells driven by
  EBV
• May be polyclonal or monoclonal
• (occasional tumors are T-cell, NK cell)

64
Viral Infection
Tumor
65
EPSTEIN-BARR VIRUS

• Lytic infection
• 100 genes expressed, lysis of B-cell
• Latent infection
• lt 10 genes expressed
• LMP 1,2, EBNA 1,2,3, EBER, BCRF, BHRF, BARF
• Evades host immune response
• Latent gene products drive B-cell proliferation

66
(No Transcript)
67
CASE PRESENTATION

• 34 y.o. male 2 years post-kidney transplant
• On Neoral, Prednisone and Immuran
• Fever, sore throat, and multiple subcutaneous
  nodules

68
INVESTIGATIONS

• EBV Viral load gt 1000 copies / 106 PBL
• Biopsy Aggressive, undifferentiated monoclonal
  PTLD, EBV positive
• Withdrawal of MMF, treatment with IV ganciclovir

69
6
)
5
-o-
Ganciclovir
4
3
Log viral load (
2
1
0
0
1
2
3
4
TIME (months)
70
RISK FACTORS FOR PTLD

• EBV D/R-
• 1-5 incidence in R vs. 20-30 in R-
• Intensity of Immunosuppression
• Type of transplant
• Small bowel gt lung gt heart gt liver, kidney
• Herpesvirus interactions

71
EBV SEMIQUANTATIVE PCR
Timing of Test PTLD No PTLD P-value (log/106)
(log/106) Prior to PTLD 2.9(1.5) 1.4(1.5)
0.005 PTLD Diagnosis 3.1(1.2) 1.4(1.5) lt
0.001 Peak value 3.4(0.5) 1.8(1.5) lt
0.001 (12 months post-transplant)
72
EBV PROPHYLAXIS STUDY

• Multicentre RCT in EBV D/R- transplant
  recipients
• Group 1 Ganciclovir CMVIG
• Group 2 Ganciclovir placebo
• EBV viral loads taken at regular intervals
  post-transplant

73
EBV PROPHYLAXIS STUDY

• Viral load data was analyzed from 28 (20
  pediatric and 8 adult) patients (15 cytogam and
  13 placebo).
• Transplant types were liver (n11), kidney
  (n10), lung (n6), and pancreas (n1).
• During the first 6 months post-transplant,
  detectable viremia occurred in 9/13 (69.2)
  placebo patients and 10/15 (66.7) cytogam
  patients

74
(No Transcript)
75
SUMMARY

• Reactivation of herpesviruses post-transplant are
  due to a complex interaction of multiple factors
• Viral infections likely produce multiple direct
  and indirect effects on the post-transplant
  course of these patients
• Efforts to minimize the impact of these
  infections should lead to improvement in graft
  outcomes
