San Diego Creek Natural Treatment System

1
San Diego CreekNatural Treatment System
A Regional Approach toWater Quality
2
San Diego Creek WatershedNatural Treatment System

• List of Topics
• IRWD at a Glance
• San Diego Creek Watershed
• San Joaquin Marsh
• Natural Treatment System Overview
• Selenium
• Financial Considerations
• Research Opportunities

3
Irvine Ranch Water DistrictAt A Glance

• California Water District
• 20 of Orange County population 330,000
• Multiple Water Systems
• Potable Water (71 of delivered water)
• Irrigation/Recycled Water (29 of delivered
  water)
• Sewage Collection and Treatment
• Urban Runoff Treatment

4
Why is IRWD Involvedin Urban Runoff?

• Environmental stewardship
• General and specific experience/expertise
• Gap of responsibility
• Total water resource management policy
• Significant portion of urban runoff is from over
  watering
• Boundaries coterminous with watershed
• Avoidance of diversion to sanitary sewer and
  ultimately recycled water

5
San Diego Creek WatershedAt A Glance

• Primary freshwater source for Newport Bay
• 118 square miles
• City of Irvine and portions of
• City of Lake Forest
• City of Newport Beach
• City of Orange
• City of Tustin
• Unincorporated County
• 4 TMDLs
• Nutrients (Nitrogen/Phosphorus)
• Sediment
• Pathogens (Fecal Coliform)
• Toxics (Pesticides, Metals,
• Selenium)

6
Newport Harbor
Pacific Ocean
Upper Newport Bay
UC Irvine
UC Natural Reserve
Natural Treatment SystemPonds
San Diego Creek
CarlsonMarsh
Restored wetlands/uplands
IRWD Plant(MWRP)
San Joaquin Marsh
N
7
San Joaquin Marsh Year 10 NTS Ponds/Marsh Pump
Station -- 2007 (Looking south from pump station)
8
The Success of San Joaquin Marsh

• 320 acres owned and operated by IRWD
• Removes about 65,000 pounds of nitrogen from San
  Diego Creek per year
• Removal of 50,000 tons of sediment and 10,000
  pounds of phosphorus per year from desilting
  basins

N
9
Expanding SJM Success to System Approach --
Objectives of NTS

• Regional solution to urban runoff
• Treat pollutants from existing urban and natural
  sources - and new development
• Dry weather (349 days) and first flush
  treatment
• Strategically located facilities to optimize
  pollutant removal
• Efficient joint use of public facilities(flood
  control channels and basins)
• Incremental habitat and open space benefits for
  Natural Communities Conservation Plan

10
Wetland Pollutant Removal

• Pathogens (UV and Time)
• Nitrogen (NO3 to N2)
• Phosphorus (Sequestered)

11
Types of Wetlands
Type II -- Inline

• Type I -- Offline
• Type II -- Inline
• Type III -- Co-located Within Detention Basins

Type I -- Offline
Type III -- Co-located
12
TYPE I(Offline)
Planning Area 17 West (Quail Springs) (Sand
Canyon Ave. and I-405)
13
Quail Springs Type I (Shady Canyon Drive, south
of I405, near Quail Hill) Visible on Google Earth
14
Type II (In-Line) Woodbridge In-line Basins
(Under Construction)
15
Woodbridge In-Line Basins
16
TYPE II -Woodbridge In-Line Basins
Photo 1 2
- San Diego Creek, looking downstream at grade
control structure between E Yale Loop and Creek
Road.
Photo 3
San Diego Creek, looking upstream from
Photo 4
San Diego Creek looking downstream from
grade control structure toward East Yale Loop
overpass.
grade control structure at energy dissipaters.
17
Type III(Co-located)Trabuco Retarding Basin
(Future)(Trabuco and Jeffrey Rd.)
18
Trabuco Retarding Basin (Future)
19
Type IIITrabuco Retarding Basin (Future)
north at channel and adacent Jeffrey Road (left of
- Trabuco Basin, north corner inlet, looking
channel).
Photo 2
Photo 1
- Trabuco Basin, looking west at outlet to
Central-Irvine channel.
20
Predicted Pollutant RemovalDry Weather Flow
Levels without NTS
126,000 poundsremoved annually
21,000 poundsremoved annually
26 reductionannually
Pounds of Phosphorus (x1,000)
Concentration -- MPN/100 ml
Pounds of Nitrogen (x1,000)
21
Expected Effectiveness of the NTS Plan
Flow regimes for which the pollutants of concern
have been modeled
Dry season
Wet season
Storm
Constituent

low flow

low flow

Events

Sediment



X

Total Nitrogen

X

X


Total Phosphorous

X

Pathogens

X

X

X




X

Metals
X



Selenium
X



Pesticides and Toxics



X TMDL set and modeled

22
Nitrogen Reduction - Model Estimates
TMDL Goals
23
Sediment Reduction - Approach Estimates

• Estimated loads are rainfall dependent
• NTS facilities are estimated to remove on average
  30 of the sediment loads from urban and open
  space sources
• Does not include instream sources of sediments

Tons of Sediment (TN) per Year
Average Annual Load to Newport Bay from Urban and
Open Space Sources
24
Fecal Coliform - 30-day Geometric Mean
Concentration in dry season low flows
25
Selenium Sources - Swamp of the Frogs
(Cienega de las Ranas)

• Swamp formed by prehistoric braiding of Santa Ana
  River and deposition of fine sediments
• Natural Se Sources
• Seepage from shallow groundwater/dewatering
• Continued flow from foothills
• Prehistoric Natural Se Treatment
• Reduced by soil bacteria
• Sequestered
• in sediment

26
Site 67 - Cienega Site (Selenium treatment)
27
SubterraneanBiofilter

• Cross flow 0.75 inch granite rock filter
• Treatment mimics historic natural processes
  anoxic sorption to inorganic substrate
• Bench Scale and Mesocosm studies done

Turfgrass
Coarse
Bed media 50X200X10 composed of 0.75 granite
rock
Water depth
Slotted pipe
gravel
28
Mesocosm Testing
29
Selenium Removal Mesocosm Results
30
Other Issues

• Treatment in waters of the US
• Bioaccumulation of pollutants
• What is really natural in an urban setting?
• Maintaining flood control capacity while
  increasing vegetation
• Monitor, monitor, monitor

31
Laguna Canyon Road Wetland Type I (Old Laguna
Canyon Road, north of I405, near Quail
Hill) Visible on Google Earth
32
Quail Hill Central Wetland Type I (Shady Canyon
Drive, north of I405, near Quail Hill, behind
Albertsons) Visible on Google Earth
33
PA 27 NATURAL TREATMENT FACILITY
Turtle Ridge Wetland Type I (Shady Canyon
Drive, east of Culver Drive) Visible on Google
Earth
34
Cost Recovery Model (2005)

• Construction Costs (41 Million)
• Developer-donated facilities 19.7
  million (48)
• State/federal grants 15.2 million (37)
• (State 4.9 m, Fed 10.3 m)
• IRWD bond financing 6.1 million (15)
• Operation and Maintenance Costs
• IRWD water bills 2.5 million/year (100)

35
Federal Funding Summary

• Public Law 108-233 Irvine Basin Ground and
  Surface Water Improvement Act
• US Bureau of Reclamation Title XVI
• Authorizes Federal Government participation of
  25 - up to 10.3 million for NTS
• Approved May 2004

36
Potential Research Opportunities for Urban
Wetlands

• Aerial Deposition of Metals e.g. Copper, Zinc,
  Mercury
• Urban Runoff Nutrient Removal
• Urban Runoff Bacteria/Pathogen Removal
• Pesticide/Herbicide Sequesteration/Destruction
• Heavy Metal Sequesteration Pathways
• Urban Runoff Flow Rate Evaluation
• Determination of Optimum First Flush Treatment
  Capacity
• Seasonal Removal Efficiencies Determination
• Identification of Self-Sustaining Habitats
• Identification of Low Maintenance Habitats
• Vector Identification and Control Measures
• Management of Flotsam and Jetsam in Wetlands

37
Grant Funding Sources

• US Environmental Protection Agency
• www.epa.gov/owow/funding
• Water Environment Research Foundation
• www.werf.org
• American Water Works Association Research
  Foundation
• www.awwarf.org

38
More Information
www.naturaltreatmentsystem.org
39
Irvine Ranch Water District San Diego Creek
Natural Treatment System
40
Irvine Ranch Water DistrictLong Term 2 Enhanced
Surface Water Treatment Rule

• Activities Completed
• Applied to EPA for certification for E. Coli and
  Cryptosporidium Analysis
• Submitted source water monitoring plan to EPA
  for approval
• Completed On-site EPA Audit for Cryptosporidium,
  not required for E. coli

41
IRWD LT2SWTR

• Activities Underway
• Maintaining EPA certification by analysis of
  Performance Testing Samples
• Waiting for rain seasonal plant operation will
  require amending approved monitoring plan

42
IRWD LT2SWTR

• Future Activities
• Submit bin classification
• Comply with additional treatment technique
  requirements
• Second round of source water monitoring six years
  after bin classification
