Yaping Zhu

1
UFO A Resilient Layered Routing
Architecture

• Yaping Zhu
• Advisor Prof. Jennifer Rexford
• With Andy Bavier and Nick Feamster (Georgia
  Tech)

2
Scalability High Availability ?
Scalability Scalability of routing control
plane Efficiency of routing data plane
High Availability Quick adaptation and re-route
3
Can We Have the Best of Both Worlds?
Basic Idea 1. Layered routing architecture
(borrowing idea from overlay routing) 2. Underlay
Support for efficient and scalable overlay routing
4
Outline

• Background
• Internet routing architecture
• Overlay routing (Resilient Overlay Networks)
• Basic idea of Layered routing architecture
• Efficient overlay forwarding
• Scalable overlay monitoring
• Enhancing the scalability of UFO
• Implementation and Evaluation
• Conclusion and deployment

5
Internet Routing designed for Scalability
Autonomous System (AS)
Peering
6
Internet Routing without High Availability

• Scalability
• Statistics 25K ASes, 200K prefixes, millions of
  routers
• Hierarchical intra-domain / inter-domain routing
• Prefix aggregation
• Routing protocols oblivious to performance
• Intra-domain static link weights
• Inter-domain routing policies
• Slow outage detection and recovery
• Disruptions during convergence
• Performance suffers from black-holes and loops

7
Scalable Internet Routing without Customization

• IP does destination-based forwarding
• All traffic follows the same paths
• Independent of the application requirements
• Yet, applications have different needs
• Voice and gaming low latency and loss
• File sharing high throughput

High throughput, but high latency
low latency, but low throughput
8
Outline

• Background
• Internet routing architecture
• Overlay routing (Resilient Overlay Networks)
• Basic idea of Layered routing architecture
• Efficient overlay forwarding
• Scalable overlay monitoring
• Enhancing the scalability of UFO
• Implementation and Evaluation
• Conclusion and deployment

9
RON Resilient Overlay Networks (by D. Andersen)
Scalable IP routing substrate
10
RON Resilient Overlay Networks System Components

• Overlay Control Plane
• Probing, overlay path evaluation
• Disseminate routing messages, update routes
• Overlay Data Plane
• Tunnel setup packet encapsulation/decapsulation
• User Opt-in Method
• DNS redirection to overlay server
• Connection to overlay server tunnels (e.g VPN)

11
Overlay Routing

• Pros
• High availability End hosts discover
  network-level path failure and cooperate to
  re-route.
• Customization Forwarding paths tailored to the
  application
• Applications
• Content distribution (e.g. Akamai SureRoute)
• Application layer multicast

12
Overlay Routing Poor Efficiency

• Problem traffic must traverse bottleneck link
  both inbound and outbound
• Additional latency overhead
• Additional traffic consumption

Upstream ISP
13
Overlay Routing Poor Scalability
Lets just keep probing
Scalable IP routing substrate
I dont know when failure happens
Shall I re-route if one packet lost?
14
Overlay Routing Poor Scalability

• Fundamental trade-off between probing freq and
  adaptation
• To get Quick adaptation
• - aggressive probing at short time interval
• - poor scalability
• -RON only supports for a small (i.e.,nodes) set of connected hosts
• Can not differentiate packet lost due to
  different events
• Failure - fast re-route
• Congestions - may slower? - oscillation?

15
Outline

• Background
• Internet routing architecture
• Overlay routing (Resilient Overlay Networks)
• Basic idea of Layered routing architecture
• Efficient overlay forwarding
• Scalable overlay monitoring
• Enhancing the scalability of UFO
• Implementation and Evaluation
• Conclusion and deployment

16
Can We Have the Best of Both Worlds?
17
A Resilient Layered Routing Architecture

• Combination of underlay and overlay routing

18
UFO Underlay Friendly to Overlays

• In-network support for overlays

• Underlay

Friendly to
Overlays
19
A Resilient Layered Routing Architecture

• Questions
• Which functionality belong to which layer?
• What are the interfaces between both layers?
• Cross-layer design
• Efficiency improvement
• Direct control over forwarding table entries
• Scalability improvement
• Explicit notification about changing network
  conditions

20
Outline

• Efficient overlay forwarding
• Overlay forwarding on line cards
• Hosting the overlay control plane
• Scalable overlay monitoring
• Registration of overlay links
• Notification of network events
• Lazy recovery
• Enhancing the scalability of UFO
• Implementation and Evaluation
• Conclusion and deployment

21
Outline

• Efficient overlay forwarding
• Overlay forwarding on line cards
• Hosting the overlay control plane
• Scalable overlay monitoring
• Registration of overlay links
• Notification of network events
• Lazy recovery
• Enhancing the scalability of UFO
• Implementation and Evaluation
• Conclusion and deployment

22
Efficient Overlay Forwarding

• Problem traffic must traverse bottleneck link
  both inbound and outbound
• Solution reflection points in routers

Upstream ISP
23
Overlay Forwarding on Router Line Cards

• Building block tunnels

24
Where the overlay control plane runs? On Routers

• On Routers by Router virtualization
• Pros fast updates of forwarding tables
• Pros efficient transmission of control messages
• Pros fate-sharing

Processors
Router
Switching Fabric
Line Cards
25
Where the overlay control plane runs? On Servers
26
Where the overlay control plane runs? On Servers

• On separate set of servers
• Update forwarding table on router line cards
• Data packets reflected in-network
• Pros
• Pros cheap compared to router
• Pros compatibility with legacy overlay server
• Cons
• Lack of fate sharing

27
Outline

• Efficient overlay forwarding
• Overlay forwarding on line cards
• Hosting the overlay control plane
• Scalable overlay monitoring
• Registration of overlay links
• Notification of different kinds of network events
• Lazy recovery
• Enhancing the scalability of UFO
• Implementation and Evaluation
• Conclusion and deployment

28
Scalable Overlay Monitoring
Assumption Rich connectivity, multiple
alternative overlay paths Overlays could even
tolerate false positive notification
What to notify? Different applications may want
notification of different events
Notification Benefits Accurate adaptation
(compared with RON) Reduce probing overhead, and
increase scalability
29
Scalable Overlay Monitoring

• Notification preserve overlay link abstractions
• Message format
• (overlay source, overlay destination, event)
• Routers store states by explicit overlay
  registration
• Explicit notification about events which affect
  performance of overlay applications
• Physical failures of routers or links
• Reachability failures route withdraw, routing
  session failure
• Network congestion
• few hello packets lost

30
Registration of Overlay Links

• Overlay Nodes A, B, C
• Routers 1, 2, 3, 4
• Register for uni-directional overlay links A-B
  and A-C

2
3
1
4
31
Periodical Registration of Overlay Links

• ACK for successful registration

(A,B)
(A,B)
(A,B)
(A,B)
2
3
1
4
32
Periodical Registration of Overlay Links
Registration kept as soft state Periodical
re-registration
(A,B) (A,C)
(A,B) (A,C)
(A,B)
(A,B)
2
3
1
(A,C)
(A,C)
4
33
Notification of Network Events
(A,B) (A,C)
(A,B) (A,C)
(A,B)
(A,B)
2
3
1
(A,C)
(A,C)
4
34
Reactive Routing and Lazy Recovery

• Assumption rich connectivity
• Reactive routing after notification
• Re-route via alternative overlay paths
• Disseminate notification message to peers
• Lazy recovery
• Stick to alternative overlay paths (e.g. for
  mins)
• Re-register for failed overlay
• Reason transient period during convergence of
  recovery, causing loops and blackholes

35
Outline

• Efficient overlay forwarding
• Overlay forwarding on line cards
• Hosting the overlay control plane
• Scalable overlay monitoring
• Registration of overlay links
• Notification of network events
• Lazy recovery
• Enhancing the scalability of UFO
• Implementation and Evaluation
• Conclusion and deployment

36
Unicast Registration is Inefficient

• Overlay Nodes A, B, C, D, E and Routers 1, 2,
  3, 4
• Register for overlay links B-A, C-A, D-A, E-A

(B,A)
2
3
1
(B,A) (C,A) (D,A) (E,A)
(B,A) (C,A) (D,A) (E,A)
(B,A) (C,A)
(C,A)
(D,A) (E,A)
(D,A)
4
(E,A)
37
Unicast Notification is inefficient
(B,A)
2
3
1
(B,A) (C,A) (D,A) (E,A)
(B,A) (C,A) (D,A) (E,A)
(B,A) (C,A)
(C,A)
(D,A) (E,A)
(D,A)
4
(E,A)
38
Multicast Registration
GroupA
2
3
1
GroupA
GroupA
GroupA
GroupA
GroupA
4
GroupA
39
Multicast Notification
GroupA
2
3
1
GroupA
GroupA
GroupA
GroupA
GroupA
4
GroupA
40
Benefits of Multicast registration/notification

• Reduce registration states stored at routers
• Unicast store state for each (src, dst) pair,
  O(n2)
• Multicast store state each mcast group, O(n)
• Reduce notification message overhead
• Deployment Benefits
• Exploit IP-Multicast (which routers already have)

41
Outline

• Efficient overlay forwarding
• Overlay forwarding on line cards
• Hosting the overlay control plane
• Scalable overlay monitoring
• Registration of overlay links
• Notification of network events
• Lazy recovery
• Enhancing the scalability of UFO
• Implementation and Evaluation
• Conclusion and deployment

42
Prototype Implementation on VINI

• Whats finished?
• RON
• Control plane probing and reactive routing
• Data plane overlay tunnel setup
• User Opt-in user data packets delivered by
  overlays
• UFO Notification of link failure
• What to do next?
• UFO
• Evaluate inter-domain routing convergence
• Notification of link congestion
• Run applications e.g. VoIP

43
Prototype Implementation on VINI

• Overlay RON
• Overlay FIB
• Client opt-in
• Notification by Filter

UML
RON
XORP IP Router
eth1
eth3
eth2
eth0
Control
Data

Packet Forward Engine
UmlSwitch element
Overlay FIB
Tunnel table
Click
Filters
VPN Server
Clients
44
Evaluation Setup

• Topology
• Routers and Overlay nodes

s
d
r
45
Evaluation1 Reactive Routing of RON

• How much time does RON spend to detect outage?
• RON probe interval 12s
• RON probe timeout 3s
• Average detection time
• Probe interval / 2 probe timeout 3
• What to evaluate?
• Fundamental trade-off between probe frequency and
  detection time
• Parameters probe interval

46
Evaluation1 Reactive Routing of RON

• Detection time probe interval / 2 probe
  timeout 3

47
Evaluation2 comparison of Convergence Speed

• Controlled Experiment
• Fail a link by filtering all the packets
• Comparison of Convergence Speed
• IP routing (XORP)
• RON reactive routing
• Reactive routing with UFO notification

48
Evaluation2 comparison of Convergence Speed

• IP Routing (XORP)
• Hello-interval 15s
• Router-dead-interval 45s

49
Evaluation2 comparison of Convergence Speed

• RON
• Probe interval 12s
• Probe timeout 3s
• Re-route immediately after outage detection

50
Evaluation2 comparison of Convergence Speed

• UFO routing with explicit notification
• Re-route immediately after outage notification

51
Outline

• Efficient overlay forwarding
• Overlay forwarding on line cards
• Hosting the overlay control plane
• Scalable overlay monitoring
• Registration of overlay links
• Notification of network events
• Lazy recovery
• Enhancing the scalability of UFO
• Implementation and Evaluation
• Conclusion and deployment

52
Deployability Benefits

• Forwarding Support
• Low barriers to entry
• Routers already have hardware for setting tunnels
• Upgrade small fraction for overlay forwarding
• Notification Support
• Upgrade all routers to support notification
  (could start with one AS)
• Performance benefits and business incentives
• Better real-time applications VoIP

53
Related Work

• Overlay routing
• Detour (Collins98)
• Resilient Overlay Networks (Andersen01)
• Improving forwarding efficiency
• Path reflection and path painting (Jannotti02)
• Reducing probing overhead
• Routing Underlay for Overlays (Nakao03)
• Network virtualization
• VINI, GENI, CABO, VERA

54
Conclusion

• Contributions
• Scalable overlay routing is feasible with
  in-network support
• UFO provides strong reliability and a compelling
  deployment model
• Future Work
• Further performance evaluation
• Applications VoIP
• Application Layer Multicast (with NEC Lab)

55
Acknowledgement

• General Exam Committee
• Prof. Jennifer Rexford (Advisor)
• Prof. Larry Peterson
• Prof. Vivek Pai
• Collaborators
• Andy Bavier and Nick Feamster (Georgia Tech)
• Cabernet Research Group
• VINI Support, Planetlab Operations

56
Questions?
57
FAQ recovery notification ?

• UFO does NOT support notification of recovery,
  because
• Alternative overlay paths available (overlays
  dont care !)
• Hard for routers to determine intra-domain
  convergence synchronization to determine
  data-plane convergence
• Hard for routers to determine inter-domain
  convergence
