CLEFT

1
Cleft Lip Primary and Secondary Deformities

• This presentation will probably involve audience
  discussion, which will create action items. Use
  PowerPoint to keep track of these action items
  during your presentation
• In Slide Show, click on the right mouse button
• Select Meeting Minder
• Select the Action Items tab
• Type in action items as they come up
• Click OK to dismiss this box
• This will automatically create an Action Item
  slide at the end of your presentation with your
  points entered.

• Nadia Afridi MD, BSc (Med)
• Kenneth Wilson MD, FRCSC

2
Historical background

• Cleft lip
• 1st repair
• Unidentified Chinese surgeon
• 390 AD
• 1st description
• ?1300 AD
• Straight line repair
• Malgaigne
• 1843
• Local flap closure
• Mirault
• Lateral flap to fill medial deficit
• Basis of most modern techniques

3
Historical background

• Cleft lip
• Millard
• 1955
• Concept
• Lateral flap advancement into upper lip
• Downward rotation of medial segment
• Preserves Cupids bow and philtral dimple
• Tension of closure at alar base
• Reduces nasal flare
• Improved alveolar molding
• Most popular method for unilateral lip closure

4
Embryology basics

• Primary germ layers
• Ectoderm
• Cutaneous,

5
Embryology basics
6
Embryology basics

• Facial development
• 4th to 10th week gestation
• Fusion of five processes
• Unpaired frontonasal process
• Nose and philtrum
• Paired maxillary swellings
• Cheeks and upper lip
• Paired mandibular swellings
• Lower face
• Lower lip and chin

7
Embryology basics
8
Embryology basics
9
Embryology basics
10
Embryology basics

• Facial development
• 6th week
• Medial nasal processes migrate and fuse

11
Embryology of Clefting
Facial Development
6th week
Medial nasal processes (green) migrate toward
each other and fuse
7th week
Inferior tips of medial nasal processes expand
laterally to form the intermaxillary process
Tips of maxillary swellings (yellow) grow to meet
the intermaxillary process and fuse
Failure of maxillary swellings to fuse with
intermaxillary process cleft lip
Clinical Aspects of Cleft Lip/Palate
Reconstruction
12
Classification

• Standardized methods
• Key anatomic structure
• Incisive foramen
• Primary
• Lip
• Premaxilla
• Alveolus
• Secondary
• Soft palate
• Hard palate

13
Classification

• Cleft of primary palate (cleft lip)
• Unilateral
• Incomplete
• Lip only
• Complete
• Primary palate
• Lip, nasal floor, alveolus

14
Classification

• Cleft of primary palate (cleft lip)
• Bilateral
• Incomplete
• Lip only
• Complete
• Primary palate
• Lip, nasal floor, alveolus

15
Classification

• Standardized methods
• Kernahan
• 1971
• Striped Y
• Incisive foramen as focal point
• Position 7
• Hard palate
• Position 8
• Soft palate
• Position 9
• Submucous cleft

16
Classification

• Standardized methods
• Millard modification

17
Epidemiology

• Cleft lip and palate
• Racial heterogeneity
• Asians
• 2.1 in 1000 live births
• Whites
• 1 in 1000 live births
• African Americans
• 0.41 in 1000
• Isolated cleft palate
• Constant incidence
• 0.5 in 1000 live births

18
Epidemiology

• Relative incidence
• Fraser and Calnan
• 21 cleft lip
• 46 cleft lip and palate
• 33 cleft palate
• Left gt right gt bilateral
• 631

19
Epidemiology

• Associated factors
• Parental age
• Incidence increases with age
• Fathers age more significant
• Risk highest with both parents over 30 years
• Seasonal incidence
• No strong evidence
• Birth order
• No evidence
• Social class
• High incidence in low socio economic status
• Poor nutrition

20
Epidemiology

• Associated factors
• Parental head topography
• Parents
• Underdeveloped maxillae
• Flattened anterior surfaces
• Trapezoidal/rectangular faces
• Thin upper lips
• Increased interorbital and intercoronoid process
  distance
• Wide nasal cavity
• Increased length of anterior cranial base

21
Epidemiology

• Associated defects
• Overall incidence of associated defects 29
• CNS malformations
• Club foot
• Cardiac abnormalities
• Highest with isolated cleft palate

22
Etiology

• Categorize cleft deformity
• Malformation
• Morphologic defect of organ or body region
• Intrinsic error of morphogenesis
• Disruption
• Morphologic defect
• Extrinsic breakdown of normal developmental
  process
• Ie. infectious
• Deformation
• Abnormal form, shape or position caused by
  mechanical forces

23
Etiology

• Categorize cleft deformity
• Syndromic
• More than one malformation
• More than one developmental field
• Non-syndromic
• One defect
• Multiple anomalies as a result of a single
  initiating event or primary malformation

24
Genetics

• Associated syndromes
• Stickler
• Cleft palate alone
• Autosomal dominant
• Type 2 collagen gene mutation
• Myopia, retinal detachment and glaucoma
• Van der Woudes syndrome
• Autosomal dominant
• Bilateral lower lip pits
• Absence second molars

25
Genetics

• Associated syndromes
• Blepharo-cheilo-dontic syndrome
• Eyelids
• Euryblepharon
• Ectropion
• Lagophthalmia
• Teeth
• Oligodontia
• Conical crown form
• Autosomal dominant

26
Genetics

• Non syndromic presentations
• Cleft lip /- palate
• Different chromosome regions
• 6p23
• 2q13
• 19q13.2
• Cleft palate alone
• Recessive single major gene
• ? 2q13/TGFA

27
Environmental agents

• Chemical agents
• Animal model
• Alcohol
• No increased risk of cleft with low quantities of
  EtOH
• Increased risk of clefting with higher quantities
  of EtOH
• Dilantin
• 10X higher risk of cleft lip
• Smoking
• Dose response relationship
• Increased risk of clefting

28
Environmental agents

• Folic acid
• Beneficial effect
• Reduced incidence of unilateral cleft lip and
  palate with at risk mothers
• Isotretinoin
• Accutane dysmorphic syndrome
• Rudimentary external ears
• Absent/imperforate auditory canals
• Triangular microcephalic skull
• Cleft palate
• Depressed midface
• Brain/jaw/heart anomalies

29
Environmental agents

• Altitude
• Higher relative risk in highlands
• Also microtia
• Preauricular tags
• Branchial arch anomaly complex
• Constriction band
• Anal atresia
• Speculation
• Chronic hypobaric hypoxia during embryologic and
  fetal development

30
Multifactorial model

• Non mendelian inheritance
• Concept of genetic susceptibility
• Threshold determined by genetics and enviroment
• Defect clusters in families
• Risk for first degree relatives ?population
  risk
• Risk for second degree relatives lower than
  first degree
• Greater severity increased recurrence
• Increased number of affected relatives increased
  risk
• Risk of recurrence increased in relatives of less
  affected sex
• Consanguinity increases risk

31
Genetic counseling
32
Prenatal diagnosis

• Ultrasound
• Late 1st trimester/early second trimester
• 3.5 MHz scanner
• Cleft lip/nose at 15 weeks
• 6.5 MHz transvaginal scanner
• 12 weeks
• Controversy
• Termination of pregancy
• Northern Israel
• 23/24 abortions
• 1/24 couple would terminate if faced with
  situation again
• Variation in culture

33
Timing of surgery

• Rule of tens
• 10 weeks of age
• Allow lip tissues to develop
• 10 lbs in weight
• Hgb 10 g/dL (100 in our world!)
• WBC less than 10,000

34
Anatomy

• Millard
• Critical anatomic features of unilateral cleft
  lip
• Cleft side
• Premaxilla outwardly rotated
• Lateral maxillary segment retropositioned
• Inferior edge of septum dislocated out of vomer
  groove
• Nasal spine in floor of nostril
• Shortened columella

35
Anatomy

• Millard
• Critical anatomic features of unilateral cleft
  lip
• Cleft side
• Lower lateral cartilage attenuated
• Medial crus lower in columella
• Dome rests below opposite alar cartilage
• Lateral segment flattened and spread across cleft
  at obtuse angle
• Alar crease continues through rim of ala
• Alar base rotated outwardly in a flare

36
Anatomy

• Millard
• Critical anatomic features of unilateral cleft
  lip
• Cleft side
• Skin curtain droops over alar rim
• Reduces apparent height of columella
• Deficient vestibular lining
• Orbicularis oris ends upward at margin of cleft
  and inserts into alar wing
• Incomplete cases muscle does not cross cleft
• Short philtrum

37
Anatomy

• Millard
• Critical anatomic features of unilateral cleft
  lip
• Non cleft side
• Shortened philtral height
• Shortened columella
• Two thirds of Cupids bow, one philtral column
  and a dimple hollow preserved
• Hypoplastic muscle between philtral midline and
  cleft

38
Anatomy

• Muscular deformity
• Muscular bulge
• Haphazard arrangement of muscle fibers
• Transverse/oblique/anteroposterior
• Orbicularis oris
• Two well defined components
• Deep orbicularis

39
Unilateral cleft lip

• Evaluation and classification
• Three categories of unilateral cleft lip
• Microform cleft lip
• Incomplete cleft lip
• Complete cleft lip
• Associated nasal deformity
• Mild
• Moderate
• Severe

40
Unilateral cleft lip

• Microform cleft lip (forme fruste)
• Presentation
• Furrow or scar
• Transgresses vertical length of lip
• Vermilion notch
• White roll imperfections
• Vertical lip shortness
• Three characteristic elements
• Vermilion notch
• Band of fibrous tissue from edge of red lip to
  nostril floor
• Deformity of ala on notch side

41
Unilateral cleft lip

• Microform cleft lip (forme fruste)
• Three characteristic elements
• Vermilion notch
• Band of fibrous tissue from edge of red lip to
  nostril floor
• Deformity of ala on notch side

42
Unilateral cleft lip

• Microform cleft lip
• Surgical management
• Usually indicated
• Vertical height equal on affected side and normal
  side
• Straight line repair
• Elliptical excision
• 2 layer closure
• Vertical difference greater than 1-2mm
• Rotation advancement repair

43
Unilateral cleft lip

• Unilateral incomplete cleft lip
• Varying degree of vertical separation of the lip
• Intact nasal sill
• Simonarts band
• Corrected with rotation advancement repairs
• Nasal repair carried out with primary repair

44
Unilateral cleft lip

• Unilateral complete cleft lip
• Presentation
• Separation of lip, nostril sill and alveolus
• Derivative of primary palate
• Secondary palate often is involved
• Position of alveolar segments critical

45
Unilateral cleft lip

• Unilateral complete cleft lip
• Alveolar (maxillary) segment
• Four positions
• Narrow with no collapse
• Narrow with collapse
• Wide with no collapse
• Wide with collapse
• Wide
• Alveolus position lateral to desired alar base
  position
• Collapse
• Lingual position of lateral maxillary segment

46
Unilateral cleft lip
47
Unilateral cleft lip

• Unilateral complete cleft lip
• Narrow with no collapse
• Rotation advancement lip and nasal repair
• Static molding useful for maintaining ideal arch

48
Unilateral cleft lip

• Unilateral complete cleft lip
• Narrow with collapse
• Ideal with presurgical palatal orthopedic
  expansion
• Start at 2 weeks
• Continue until surgical intervention

49
Unilateral cleft lip

• Unilateral complete cleft lip
• Wide without collapse
• Molding appliance
• Maintain width
• Guide alveolar segments together
• Lip adhesion

50
Unilateral cleft lip

• Unilateral complete cleft lip
• Wide with collapse
• Presurgical appliance
• Expands collapse
• Molds to reduce width of interalveolar space

51
Unilateral cleft lip

• Unilateral complete cleft lip
• Lip adhesion
• Highly selected unilateral and bilateral wide
  clefts
• Temporarily brings lip margins together

52
Unilateral cleft lip

• Evolution of cleft lip repair
• 1st principle
• Lengthen vertical height of cleft side to match
  normal side
• Rose Thompson
• Straight line repair curvilinear cleft side
• Ideal for microform clefts

53
Unilateral cleft lip

• Evolution of cleft lip repair
• 2nd principle
• Using lateral lip tissue in deficient medial
  segment
• 3rd principle
• Retaining normal anatomic Cupids bow
• Hagerdon, LeMesurier
• Quadrangular flap
• Tennison Randall
• Triangular flap

54
(No Transcript)
55
Unilateral cleft lip

• Evolution of cleft lip repair
• 4th principle
• Rotation advancement concept
• Millard
• Incision line follows natural anatomic position
  of philtral ridge
• Avoid placement of scars across lower philtrum
  (different from quadrangular and triangular
  repairs)

56
Unilateral cleft lip

• Evolution of cleft lip repair
• 5th principle
• Muscle reconstruction and preservation of lip
  function
• Extensive dissections
• Nicolau and delineation of layers of muscle
• Deep and superficial orbicularis oris
• Intertwined with paraoral/paranasal muscles

57
Unilateral cleft lip

• Evolution of cleft lip repair
• 6th principle
• Restoration of the bony platform
• Presurgical orthopedics
• Passive
• Active
• Latham appliance
• Bone grafting
• Gingivoperiosteoplasty
• controversial

58
Unilateral cleft lip

• Evolution of cleft lip repair
• 7th principle
• Restoration of normal nasal anatomy
• Complex
• Topic unto itself (stay tuned for next week!)

59
Unilateral cleft lip

• Millard repair

60
Unilateral cleft lip
61
Unilateral cleft lip
62
Unilateral cleft lip
63
Unilateral cleft lip
64
Unilateral cleft lip
65
Bilateral cleft lip

• Complex surgical dilemna
• Multiple techniques described and utilized
• No one technique clearly superior
• Compared to unilateral clefts
• Twice as difficult with result ½ as good

66
Bilateral cleft lip

• Deformity
• Protruding premaxilla
• Lack of connection of premaxilla with lateral
  palatal shelves during development
• Absent nasal spine
• Retruded area under base of septal cartilage
• Recession of medial crura footplates
• Lower lateral cartilage footplates drawn by
  lateral palatal shelves
• Broad flat nasal tip

67
Bilateral cleft lip

• Deformity
• Short columella
• Skin over columella is short
• absent columella
• Prolabium
• Anterior inferior extent of frontonasal process
  normally contributes skin between philtral
  columns
• Wide and short
• Hangs directly from nasal tip skin

68
Bilateral cleft lip

• Incomplete bilateral cleft lip
• Near normal nose
• Normal premaxilla
• Simonarts bands across nasal floor
• Surgical management
• Rotation advancement
• Triangular flap
• Similar to unilateral
• Single or double stages
• Can also use bilateral straight line technique

69
Bilateral cleft lip

• Protruding premaxilla
• Main obstacle in bilateral clefts
• Multiple approaches described
• Lip repair/adhesion
• Stages attempt at retracting premaxilla
• Unpredictable
• Closed under tension
• Wide scars with repair
• Lip adhesion
• Inflammation

70
Bilateral cleft lip

• Protruding premaxilla
• Alternate techniques
• Elastic bonnet
• Poor control of premaxilla position relative to
  lateral segments
• Premaxilla excision/setback at 1st operation
• NOT a present day option
• Discards permanent incisors
• Severe midface retrusion
• Pin retained premaxillary retraction devices
• Allows for gingivoperiosteoplasty
• Bone grows across small cleft
• Nasoalveolar molding

71
Bilateral cleft lip

• Construction of central lip vermilion
• Two general methods
• Buccal mucosa
• Inferior aspect of prolabial skin
• Forms central vermilion
• Bulk
• Strips of muscle across
• Deepithelialized buccal mucosa from lateral lip
• Most often inadequate bulk in central section
• Whistle deformity
• Dry versus wet lip problem

72
Bilateral cleft lip

• Construction of central lip vermilion
• Two general methods
• Lateral vermilion tissue
• Muscle rotates with lateral lip elements
• Single scar at depth of Cupids bow
• Scar mimics white roll
• Good bulk

73
Bilateral cleft lip

• Skin paradigm
• How to best use prolabial skin and to attempt to
  lengthen columella?
• Split prolabium
• Form philtrum and neocolumella
• Millard fork flap technique

74
Bilateral cleft lip
75
Bilateral cleft lip
76
Bilateral cleft lip
77
Bilateral cleft lip
78
Secondary deformities

• Introduction
• Factors in decreased need for revisionary
  surgery
• Improved primary techniques
• Specialized centers of excellence
• Sophisticated presurgical orthodontics
• Nasal correction simultaneously
• Gingivoplasty
• Nasal molding

79
Secondary deformities

• Introduction
• Lip repair expectations
• Accurate skin, muscle and mucous membrane union
• Proper rotation of lateral orbicularis into
  horizontal position
• Symmetric nostril floor and tip
• Even vermilion border and cupid bows
• Eversion of central upper lip
• Minimal scar
• Failure of above needs secondary repair

80
Secondary deformities

• Approach
• Assess following variables
• Anatomic elements
• Components to be preserved and altered
• Residual deformities
• Uncorrected
• Recurrences
• Iatrogenic
• Realistic surgical goals
• Choose procedure with most predictable results
  with fewest interventions

81
Secondary deformities

• Timeline
• Complete majority prior to school age
• Facilitate peer interactions
• Final revisions in adolescence

82
Secondary deformities

• Unilateral cleft lip
• Deficient tubercle
• Vermilion deficiency and irregularities
• Short upper lip
• Long upper lip
• Tight upper lip
• Unfavorable scars

83
Secondary deformities

• Unilateral cleft lip
• Deficient tubercle
• V-Y advancement
• Dermal graft
• Create tunnel along horizontal length with
  orbicularis
• Rotate medial edges of vermilion mucosal flaps
  inferiorly
• Temporoparietal fascia flap

84
Secondary deformities

• Unilateral cleft lip
• Vermilion deficiency and irregularities
• Notch whistle deformity
• Inadequate approximation of orbicularis

85
Secondary deformities

• Unilateral cleft lip
• Vermilion deficiency and irregularities
• Mucosal deficiency
• Z plasty
• V-Y advancement

86
Secondary deformities

• Unilateral cleft lip
• Vermilion deficiency and irregularities
• Loss of Cupids bow
• Unilateral Gillies operation
• Triangular skin excision above mucocutaneous line
• Close horizontally
• Modified Abbe flap

87
Secondary deformities

• Unilateral cleft lip
• Vermilion deficiency and irregularities
• Loss of philtral column
• Limited surgical useful techniques
• Subcutaneous rotation flap
• Rollover muscle flap
• Chondrocutaneous composite flap
• Auricular cartilage graft
• Muscle splitting technique
• Vest over pants closure

88
Secondary deformities

• Unilateral cleft lip
• Vermilion deficiency and irregularities
• Lateral vermilion deficiencies
• Lower lip vermilion flap
• Centrally based cross lip flap

89
Secondary deformities

• Unilateral cleft lip
• Short upper lip
• Measure of distance from Cupids bow to columella
• Failure to lengthen lip at primary repair
• Initial shortening
• 1st 2 months
• Maximal at 6-8 weeks
• Softens and relaxes subsequently
• Resumes immediate post op appearance if muscle
  repair adequate

90
Secondary deformities

• Unilateral cleft lip
• Short upper lip
• Lip lengthening techniques
• Rotation advancement flaps
• Z plasties
• V-Y forked flaps
• Muscle advancements
• Abbe flap

91
Secondary deformities

• Unilateral cleft lip
• Short upper lip
• Most common after straight line repair
• Rotation advancement flap useful
• Indications
• Cleft philtral scar short
• Cupids bow pulled up toward nostril
• Wide nostril floor
• Alar displacement laterally and downwards

92
Secondary deformities

• Unilateral cleft lip
• Short upper lip
• Millard repair
• Inadequate rotation
• Inadequate muscle repair
• Consider rerotation and muscle repair
• Triangular repair
• Flattening of Cupids bow
• Shift of vermilion tubercle to cleft side

93
Secondary deformities

• Unilateral cleft lip
• Long upper lip
• More common in triangular and quadrangular
  repairs
• Unusual to have overrotation of rotation
  advancement flap
• Horizontal excision at alar base
• Full thickness

94
Secondary deformities

• Unilateral cleft lip
• Tight upper lip
• Horizontal tightness across upper lip
• Z-plasty
• Restricts anteroposterior facial growth
• Relative pouting lower lip
• Correction with Abbe flap

95
Secondary deformities

• Unilateral cleft lip
• Tight upper lip
• Abbe flap
• Brings lower lip pouting tissue to upper lip
• Most often with bilateral repairs
• Recreates philtrum
• Rotate on intact labial artery and vein
• 1/3 of lower lip can be harvested
• Mental crease should not be violated
• Division of pedicle after 10-14 days

96
Secondary deformities

• Unilateral cleft lip
• Unfavorable scars
• 1st scar often the best
• Often restraint between 8 to 18 years best
• Hypertrophic or widened scars
• Present one month post op
• Red, raised and firm
• Taping
• Revision
• Pink scar
• Yellow light laser
• Dermabrasion

97
Secondary deformities

• Unilateral cleft lip
• Unfavorable scars
• Revisional techniques
• Excision and closure
• Straight line
• Wave line
• Z plasty
• W plasty
• Stair step technique
• Philtral column
• Epithelium is resected
• Leave dermis for bulk

98
Secondary deformities

• Unilateral cleft lip
• Buccal sulcus abnormalities
• Adhesions/scars
• Z plasty
• Z-Y technique
• Deepening of sulcus
• STSG
• Oral mucosal free grafts
• Local mucosal flaps

99
Secondary deformities

• Unilateral cleft lip
• Orbicularis oris derangement
• Secondary repair of muscle
• Orient fibers transversely across defect
• Muscle layers
• Superficial
• Deep
• Peripheral and marginal slips
• Separate repair of different layers recommended

100
Secondary deformities

• Bilateral cleft lip
• More commonly has secondary deformity
• Issues
• Scars
• Tight lip
• Wide lip
• Short lip
• Missing or misplaced landmarks
• Vermilion deficiencies
• Buccal sulcus abnormalities

101
Secondary deformities

• Bilateral cleft lip
• Scars
• Same approach as unilateral
• Millard
• Revise scars on side at a time
• Avoid excessive tension
• Bank excessive lip scar
• Useful for columellar lengthening

102
Secondary deformities

• Bilateral cleft lip
• Tight lip
• Often associated with severe clefts
• Innate shortage of lip tissue
• Overresection of tissue at primary repair

103
Secondary deformities

• Bilateral cleft lip
• Tight lip
• Lip switch
• Abbe flap
• Midline placement
• Attempt recreation of philtrum
• Dimensions
• 0.8-1.2 cm wide at vermilion border
• 0.6-0.9 cm at base of columella
• 1.7 cm high

104
Secondary deformities

• Bilateral cleft lip
• Wide lip
• Classic
• Failure to reunite orbicularis oris muscle during
  primary surgery
• Gradual widening of philtrum
• Correction
• Muscle realigning techniques
• Removal of excess philtral skin

105
Secondary deformities

• Bilateral cleft lip
• Short lip
• More common in bilateral clefts
• Greater tissue deficiency
• Z plasty
• Lengthens by reducing horizontal dimension
• Can need Abbe flap

106
Secondary deformities

• Bilateral cleft lip
• Missing or misplaced landmarks
• Missing philtral landmarks
• Absent on prolabium of bilateral clefts
• Same as with unilateral secondary deformity repair

107
Secondary deformities

• Bilateral cleft lip
• Vermilion deficiency and irregularities
• Paucity of central lip
• Whistle deformity
• Thin central lip
• Relative
• Excessive vermilion laterally
• Transverse wedge excisions
• Tendency to contract
• Bulky design of flaps necessary

108
Secondary deformities

• Bilateral cleft lip
• Vermilion deficiency and irregularities
• Lateral vermilion flaps
• V-Y advancement

109
Secondary deformities

• Bilateral cleft lip
• Vermilion deficiency and irregularities
• Lateral vermilion flaps
• Double pendulum flaps

110
Secondary deformities

• Bilateral cleft lip
• Buccal sulcus abnormalities
• Local flaps
• Skin grafts
• Needs splinting
• Second choice with children
• V-Y advancement of entire labial sulcus
• Combination
• Z plasty
• VY advancement

111
Secondary deformities

• Bilateral cleft lip
• Orbicularis oris deformities
• Proper muscle reconstruction
• Perioral and perinasal
• Minimizes secondary skeletal deformities

112
Secondary deformities

• Bilateral cleft lip
• Lower lip changes

113
Secondary deformities

• Residual skeletal deformities
• Issues
• Maxillary hypoplasia
• Alveolar bone grafting
• Orthognathic surgery
• Palatal fistulas
• anterior

114
(No Transcript)
115
(No Transcript)
116
(No Transcript)
117
(No Transcript)
