The Vyatta CLI

1
The Vyatta CLI
2
Module Objectives

• After completing this module, you should be able
  to
• Login into the OFR using either the root or
  vyatta default user
• Access Operational Mode
• Access Configuration Mode
• View command output that longer than 1 page
• Invoke the Vyatta CLI help function
• Describe configuration nodes
• List the three main configuration commands
• Navigate the configuration node hierarchy
• Create Users and passwords
• Recover from lost passwords
• Save the configuration file to a floppy drive or
  a hard drive
• Log out of the router shell

3
Logging In to the CLI

• Login prompt displayed following boot sequence
• vyatta login
• Root User
• Username root Password vyatta
• Provides access to the Linux shell
• Can start router shell (xorpsh) from the Linux
  shell
• Vyatta User
• Username vyatta Password vyatta
• Provides access to the router shell (xorpsh)

4
Operational Mode

• Initial mode when you first log into the router
  shell
• Allows you to perform general node functions such
  as
• Setting node date time
• Deleting system files
• Formatting floppy disks
• Rebooting the node
• Displaying various system information
• Operation Mode prompt is
• show version displays the router software
  version
• quit or exitexits the router shell and puts
  you back into the Linux shell

5
Configuration Mode

• Typing configure in Operational mode invokes
  Configuration mode
• Configuration Mode allows to add, delete, and
  modify system configuration information
• Configuration Mode prompt is
• show displays system configuration information
• quit or exit exits Configuration mode and
  puts you back in Operational mode
• If uncommitted changes have been made to the node
  configuration you must save or discard (exit
  discard) them prior to exiting Configuration
  mode.

6
CLI Help

• ? (help)
• Type a ? at the command prompt to see a list of
  available commands
• Type a ? after the name of a command to see a
  list of the command parameters

7
Command Completion

• Using the TAB key or SPACEBAR when typing a
  command name will complete the command.
• Must type enough characters to uniquely identify
  the command desired

8
Working with Long Command Output

• If command output cannot be displayed on one
  screen the MORE indication will be displayed
  (--MORE--)
• When the MORE indication is displayed, type
• Enter Key - will display the next line of the
  output
• Space Key - will display the next page forward of
  the output
• b will display the previous one page of the
  output
• k allows you to scroll up through the entire
  output
• j allows you to scroll down through the
  entire output
• When the END flag (END) appears next to the MORE
  indication it indicates that the output is
  complete
• q will exit from the MORE display

9
Configuration File

• Configuration file is plain text file
• There are three kinds of statements
• Configuration nodes. These can be either
• Single nodes (just one instance can be created
  for example, the RIP protocol node)
• Multi-nodes (more than one instance can be
  created for example, address nodes)
• Attribute statements. These set the values or
  characteristics for parameters within a node.

10
Default Configuration File

• When the OFR is first booted
• A Default configuration file is created
• All node interfaces are recognized and the
  configuration file is populated with these
  interfaces
• The Default configuration file contains other
  default values such as the default user
  definitions for the root and vyatta users.
• Restoring the OFR to a Default configuration
• Save the config.boot file under another name
• Delete the config.boot file
• Reboot the OFR
• Upon reboot the OFR will rebuild a default
  configuration file

11
Configuration Nodes

• Configuration nodes have braces associated
  with them
• Attribute statements would be enclosed in the
  braces
• Configuration node examplessh port
  165534 protocol-version v1v2all
• Empty configuration braces signify that the
  configuration node has no configurable
  attributeswins-server ipv4

Configuration node
Attribute Statements
Braces
12
Configuration Commands

• Configuration of the system is accomplished
  using
• Set
• Used to create or modify configuration nodes and
  attributes
• Cannot be used to change the identifier of a
  multi node
• Delete
• Used to delete a configuration node
• Deleting a configuration node will also delete
  all sub nodes
• Edit
• Used to navigate to a specific configuration node
  in the tree

13
Navigating the Nodal Hierarchy

• root_at_vyatta configureEntering configuration
  mode.There are no other users in configuration
  mode.root_at_vyatta edit interfaces ethernet
  eth0edit interfaces ethernet eth0root_at_vyatta
  set description my interface 1edit interfaces
  ethernet eth0root_at_R1 upedit interfaces
  ethernetroot_at_R1 exitedit interfacesroot_at_R1
  topeditroot_at_R1quitroot_at_R1

14
Creating User Accounts/Passwords

• System Login
• User Username of the new login account
• 32 character max, alphanumeric and hyphens
  allowed
• Full Name Complete name of the user
• Alphanumeric, hyphens, and spaces allowed
• Names containing spaces must be enclosed in
  double quotes
• Plaintext Password Login password for the user
• Password is encrypted and stored on router
  internally
• Encrypted using Message Digest 5
• Encrypted password displayed with show command
• Radius Server IP address of remote Radius
  Authentication Server
• Port IP Port of the remote Radius
  Authentication Server
• Secret Password for Radius Authentication
  Server
• Alphanumeric, spaces, and special characters
  allowed
• Passwords containing spaces must be enclosed in
  double quotes

15
Recovering Lost/Forgotten Passwords

• One or more Users have lost/forgotten their
  password
• Any user password, including the root user
  password, can be changed by any user who has
  access to the OFR CLI
• Root user password CAN be changedset system
  login user root authentication plaintext-password
  vyatta
• Commit the change and save the configuration file

16
Recovering form Lost/Forgotten Passwords

• No users are able to login into the OFR
• Reboot the OFR from a LiveCD
• Login as root with the default password of
  vyatta
• Enter the router shell by typing xorpsh
• show system boot-message on main OFR drive
• Exit to Linux Shell and type fdisk /dev/sda
• Find the largest partition
• Create a directory to mount the device mkdir
  /mnt/hd
• Mount the largest partition mount /dev/sda1
  /mnt/hd
• Enter the OFR Router Shell and type load
  /mnt/hd/opt/vyatta/etc/config/config.boot
• Type show to confirm the loading of the
  configuration
• Reset the root user password set system login
  user root authentication plaintext-password
  vyatta
• Commit the changes and save the configuration
  file
• Reboot the OFR

17
2 Stage Configuration Process

• Configuration statements simply change
  configuration values
• Configuration changes do not take effect until
  they are committed
• Use commit to make changes active
• show will display the contents of the
  configuration file
• Items with - in front of them are deletions
  that have not been committed
• Items with in front of them are
  additions/modifications that have not been
  committed
• If you try to exit the configuration with
  uncommitted changes you must
• Use commit to activate the changes in the
  configuration
• Use exit discard to exit the configuration
  without committing the changes

18
Save Configuration Floppy Drive

• If running software from LiveCD, the only way to
  save the configuration file is to a floppy drive
• Initialize floppy disk from router shell
• Floppy drive is /dev/fd0
• Floppy drive is mounted in /mnt/floppy
• init-floppy (Operational mode) initializes
  floppy disk for configuration storage
• Formats the floppy disk, causing all previous
  data on the disk to be lost
• Enters /mnt/floppy/config as the config-directory
  attribute in the rtrmgr configuration node
• Mounts the floppy
• Saves copy of current configuration to
  /mnt/floppy/config/config.boot
• save (Configuration mode) is used to save the
  configuration
• save /mnt/floppy/config/config.boot saves
  configuration on the floppy as a bootable file
• save /mnt/floppy/config/my_config1 saves
  configuration file on the floppy, the file is not
  bootable

19
Save Configuration Hard Drive

• Software must be loaded onto a partition on the
  hard drive in order to save the configuration to
  the hard drive.
• Hard drives can be a flash device, a USB stick,
  or a physical hard disk
• Default directory - /opt/vyatta/etc/config
• save saves the configuration in a bootable form
  as /opt/vyatta/etc/config/config.boot
• save my_config1 saves the configuration in a
  non-bootable file as /opt/vyatta/etc/config/my_c
  onfig1

20
Logging Out of the Router Shell

• Exit or Quit
• Both commands allow you to exit one level of the
  configuration tree and move to the next higher
  level.
• Using either command at the top level of the
  configuration tree will log you out of the
  configuration mode and put you in operational
  mode
• Using either command in operational mode will log
  you out of the router shell and put you in the
  Linux shell

21
Module Summary

• Having completed this module, you should be able
  to
• Login into the OFR using either the root or
  vyatta default user
• Access Operational Mode
• Access Configuration Mode
• View command output that longer than 1 page
• Invoke the Vyatta CLI help function
• Describe configuration nodes
• List the three main configuration commands
• Navigate the configuration node hierarchy
• Create Users and passwords
• Recover from lost passwords
• Save the configuration file to a floppy drive or
  a hard drive
• Log out of the router shell

22
