HVAC Energy Efficiency using Mass Flow and Building Pressurization

1
HVAC Energy Efficiency using Mass Flow and
Building Pressurization

• Jay Richardson
• Professional Supply, Inc.

2
Professional Supply, Inc. - PSI

• Professional Supply, Inc. was founded by Tom
  Kiser in 1979 to support Architects and Engineers
  in developing energy efficient HVAC designs
• PSI Technology has provided significant energy
  savings for Ford, Goodyear and Delphi
• Today, PSIs innovative energy solutions extend
  to waste heat recovery, lighting, photovoltaic
  and thermal solar based on precise energy models
• PSI has a strategic alliance with Giffels, Inc.
  to create Sustainable Energy and Building Designs
• PSIs Energy Service Agreement with Ford is a
  business model that delivers technical solutions
  to energy challenges with no capital expenditure
  by our clients based on guaranteed performance

3
Todays Energy Challenge

• HVAC energy consumed for Commercial Buildings is
  4.5 quadrillion BTUs
• 13 for Heating
• 11 for Cooling
• 6 for Ventilation
• 6 Hot Water
• Americas Commercial HVAC creates 34 of CO2
  emissions 90.2 MMTCE
• HVAC Technology dates back 2000 years to the
  Roman Baths
• Incremental technical improvements will not solve
  the Global Climate Change Challenge

4
Laws of Physics

• Cold air is heavier than hot air
• Hot air rises, cold air falls
• Air is subject to the laws of mass flow and fluid
  dynamics
• In Winter, warm air rises as a result of stack
  effect promoting cold air infiltration at base of
  the building
• In Summer, stack effect is less and hot air
  collects at the roof promoting heat retention in
  the building

5
HVAC Engineering Practice

• HVAC Forced Air Handling Systems use a blower to
  push hot air
• HVAC designs require dampers or sized ducts to
  maintain pressure and velocity at the discharge
  vent
• Higher air temperatures are needed for personal
  comfort when air blows directly on people
• Temperature controlled by discharge temperature
  and thermostat
• Blow enough tempered air with volume, pressure
  and velocity to accommodate all possible
  conditions
• Buildings tend to draws air from outside to
  produce sufficient updraft and pressure
  differential for roof exhaust to be effective

6
Traditional Design
50,000 scfm Air Supply
Powered Roof Exhaust
Ducted Supply
Negative Pressure Updraft
Discharge Vent
7
Cool Air Heating

• Cool air is heavier than warm air
• Cool air introduced at the top of the building
  naturally falls to the floor
• This eliminates the need for ductwork
• This allows PSI to recover process and building
  heat gain to reduce energy needs
• Inverse stratification uses mass flow to provide
  energy efficiency while creating a comfortable
  workspace

55F
65F
72F
8
Bigfoot Air Handler

• Capable of delivering 200,000 scfm of air with
  two 100,000 scfm centrifugal blowers
• Variable frequency drives give Big Foot the
  ability to adjust to the building air supply
  requirements, thus minimizing the electric and
  natural gas usages
• Fresh air and return air
  bypass dampers react
  automatically to system
  changes to
  maintain the
  building conditions
• Discharge head louvers
  direct air horizontally
  and vertically

9
PSI Engineering Practice

• Big Foot distributes air at the truss and
  pressurizes the building.
• Pressurization and perimeter relief dampers
  allows PSI to control air distribution Without
  Ductwork
• Big Foot modulates air flow using VFD blowers and
  damper control
• Big Foot System maintains uniform building
  temperature and positive pressure

55F
65F
72F
10
Global Controls

• Global controls continuously monitor and respond
  to interior/exterior temperature, humidity and
  pressure as well as wind speed/direction
• Big Foot modulates VFDs to adjust to building
  pressure
• In Winter, smart discharge heads respond to cold

  spots by directing warm air down to the floor
• In Summer, ventilation is
  increased at night to cool
  the
  building. During the
  day, outside air is

  minimized until the
  interior temperature

  exceeds the exterior,
  then
  ventilation is
  increased

11
PSI Design Cool Air Heating
Bigfoot Air Supply
Global Controls
Diffuser at Truss Level
Exhaust Louvers
Monitors
Positive Pressure
12
Average Ford Assembly PlantPSI Energy Service
Agreement

• Average of 8 Assembly Plants
• Plant 3.1 million sq. ft.
• Converted both Steam or Forced Air Gas Systems
• Abandoned 182 HVAC Air Houses and numerous Unit
  Heaters
• Installed 12 Big Foot Units and/or modified
  existing air handlers and 2 Direct Contact Hot
  Water Heater
• PSI Investment - 11 million
• Ford Guaranteed Energy Savings 2.0 million per
  year at 2000 Energy Prices
• Energy reduction from baseline year
• 54 Gas
• 46 Electricity
• ESA includes daily monitoring, new equipment
  warranty and monthly on site review.

13
Energy Performance

• Building pressurization, global controls and Big
  Foot Air Handlers reduce first cost, operating
  cost and provide a better cleaner work
  environment
• The PSI approach using mass flow and building
  pressurization allows us to heat and cool
  uniformly with less energy
• Adaptive controls respond to internal and
  external temperature, pressure and humidity
• Complete energy model allows the client to
  prioritize their potential solutions
