Dyn Seg for Pavement Management

1
Dyn Seg for Pavement Management

• MTC GIS Users Group Meeting
• February 27, 2003

2
MTCs Pavement Management System (PMS)

• Storage, analysis and reporting software
• Collection of stored pavement data
• Maintenance and treatment costs
• Data and formulas on pavement deterioration
• Calculates future needs budget scenarios
• Software produces text reports
• Pavement Management Technical Assistance Program
  (P-TAP) helps fund the linkage of PMS GIS

3
Linking GIS and Pavement Management Segments
In an ideal world, there would be a one-to-one
relationship between GIS base-map segments and
pavement segments
2
1
B
A
C
PMS From To 1 A St B St 2 B St C St
GIS From To 1 A St B St 2 B St C St
4
Linking GIS and Pavement Management Segments
In reality, pavement segments frequently dont
match GIS base-map segments
2
1
B
A
C
PMS From To 1 A St 500ft 2 500
ft B St 3 B St C St
GIS From To 1 A St B St 2 B St C St
5
Linking GIS and Pavement Management Segments
LRS and dyn seg allow you to model one-to-many
relationships between GIS base-map segments and
pavement segments, without splitting the GIS
base-map
1
2
3
B
A
C
GIS From To 1 A St 500ft 2 500
ft B St 3 B St C St
PMS From To 1 A St 500ft 2 500
ft B St 3 B St C St
6
Linking GIS and Pavement Management Segments
LRS dyn seg also allow you to model many-to-one
relationships between GIS base-map segments and
pavement segments
2
1
B
A
C
GIS From To 1 A St B St 2 B St C St
PMS From To 1 A St C St
7
Linking GIS and Pavement Management Segments
Roads Layer
Multiple data sets can be modeled using LRS dyn
seg without splitting the underlying GIS base-map
8
Linking GIS and Pavement Management Segments
Arc Segments
A Unique Route
9
Linking GIS and Pavement Management Segments
0.0
0.0
Good
0.0
4.7
Fair
Poor
9.3
Asphalt
15.0
7.2
15.0
15.0
Concrete
15.0
Resurface
9.3
10
GeoPave software for GIS mapping/analysis of PMS
data. Provided by GeoData Analytics, LLC
11
GeoPave software for GIS mapping/analysis of PMS
data. Provided by GeoData Analytics, LLC
12
For More Information

• Contact
• Mike Skowronek
• GIS Coordinator
• Metropolitan Transportation Commission
• 101 Eighth St.
• Oakland, CA 94607
• 510-464-7808
• mskowronek_at_mtc.ca.gov
• http//www.mtc.ca.gov/GIS
